novel pedar-x Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the pedar-x and is the answer not in the manual?

Questions and answers

Summary of Contents for novel pedar-x

  • Page 2 Welcome to system pedar-x This manual provides instructions for the installation and operation of the system. Also included are tips/guidelines for the proper use of the system to obtain the most accurate data results. pedar-x is an in-shoe dynamic pressure distribution measuring system which utilizes capacitive sensors.

  • Page 3: Table Of Contents

          ...................... 8 ALIBRATION AND  ONFIGURATION  ILES     ‐  ........................ 9 ONNECTING THE PEDAR X  S YSTEM     2.4.1 The pedar-x system components  ...................... 9     2.4.2 The pedar-x Box Components and Connections ................ 10     2.4.3 The pedar-x Data Collection Modes .................... 11     2.4.4 Connect the pedar-x system components .................. 12     2.4.5 Fiber optic cable (FOC) Setup ...................... 13...
  • Page 4     THE PEDAR‐X EMEDLINK PROGRAM  ....................  9 9      ...................... 99 IEWING THE DATA FILE IN EMEDLINK       ............................ 102 ENU OPTIONS     PEDAR‐X SYNC BOXES AND SOFTWARE  ..................... 104     ‐X   .................. 104 PEDAR   YNC  OX  OMPONENTS AND  ONNECTIONS     7.1.1 Wired Sync Box Components ...

  • Page 5: Precautions

    1 PRECAUTIONS  The pedar-x system should not be used in extremely high temperatures or high humidity. The recommended operating conditions are 0-40C (32-100F) and 20-80% humidity.  The flexible insole sensors should be handled with care. Pressure ranges outside the designated loading should be avoided as well as use of sharp objects on the sensing device.

  • Page 6: Setup Of The Pedar-X System

    Firebird-1.5.x.exe novel player iv. Avisynth_258.exe (only if with video is being used) The drivers can also be downloaded from the novel web site. Click the light blue cube to reach the Download section i. For the Aladdin Hardlock driver: www.novel.de/DRIVERS/HASPUserSetup.exe ii.

  • Page 7: Loading The Novel Software

    The installation wizard novel will recommend to install the software on the computer’s default system drive (typically “C:”) in the subfolder “\novel\”. It is highly recommended to follow this novel recommendation because it helps the staff to streamline your support. The following sections refer to the C:\novel\ path.

  • Page 8: Calibration And Configuration Files

    It may be necessary to manually move these files to the appropriate directory. 4. Connect the novel pedar hardlock to the PC and test all programs to make sure they open and run and ensure that all previously collected data and configuration/calibration files are accessible.

  • Page 9: Connecting The Pedar-X System

    Connecting the pedar-x system 2.4.1 The pedar-x system components pedar-x system components include:  Insoles (A)  pedar-x battery (G)   pedar-x pedar-x double insole cable (B) battery cable (H)   pedar-x/xf pedar-x box ( C) battery charger (I) ...

  • Page 10: The Pedar-X Box Components And Connections

    During booting the pedar-x system: pedar-x This LED flashes when the box is turned on and when the internal boot process of the pedar-x box is finished If the pedar-x is in the measuring mode: It flashes when a measurement is started.

  • Page 11: The Pedar-X Data Collection Modes

    Within this documentation we will refer to both devices as unless otherwise noted. 2.4.3 The pedar-x Data Collection Modes pedar-x There are three modes of data collection with the system: 1) Online – in this mode data is transmitted real-time and displayed to the computer. The computer controls the data collection of the device.

  • Page 12: Connect The Pedar-X System Components

    SD card. The computer still controls the pedar-x system within this mode. This mode of data collection can be helpful when the subject reaches the limits of the Bluetooth data transmission and some data might be not received from the PC.

  • Page 13: Fiber Optic Cable (Foc) Setup

    2. Connect the double insole (B) cable to the box (C) via the insole connector (i). Ensure that the clips on the cable are fully attached to the box. Make sure to go straight in and straight out with this connection and do not torque the connector when attaching pedar it or removing it from the box.
  • Page 14 2.4.5.2 Making the FOC connections pedar-x 1. Connect the fiber optic cable (D) to the box (C) via connector (f). 2. Connect the other side of the fiber optic cable to the fiber optic/USB adapter (D). 3. Ensure that the dip switches are set appropriately (all three switches are in lower position, see Section 2.4.3 –...

  • Page 15: Bluetooth Setup

    Bluetooth devices. Check if the antenna is screwed to the socket on the top of the pedar-x device. Ensure that the dip switches are set appropriately (second switch in upper position, see Section pedar-x 2.4.3 –...
  • Page 16 3) The Add a Device Wizard will begin. The computer will begin to search for Bluetooth devices. A list of the Bluetooth devices which were found will then display novel pedar-XF by IWZ Choose the device and click Next.
  • Page 17 Enter the phrase pedarX as the passkey. Click Next. 5) The Bluetooth connection will be established and the virtual COM ports will be created. pedar-x Make note of the Outgoing COM port, as this will be needed within the online software.
  • Page 18 8) An options menu will appear. Please uncheck the option Allow Bluetooth devices to connect to the computer and Alert me when a new Bluetooth device wants to connect. 9) If later it becomes necessary to determine which Bluetooth port is the Outgoing port you can...
  • Page 19 Bluetooth of the computer and/or uninstall the additional Bluetooth software which is on the PC. 2) Check if the antenna is screwed to the socket on the top of the pedar-x device. Ensure that the dip switches are set appropriately (second switch in upper position, see pedar-x Section 2.4.3 –...
  • Page 20 4) The Windows 8 PC Settings App will open to the Devices page. The computer will automatically start searching for Bluetooth devices. In the Select a device window it should find the “novel pedar-XF by IWZ” device, followed by the serial number of your device: Click on the device name to make a connection.
  • Page 21 7) To ensure proper data transmission between the and the computer the ability of other Bluetooth devices should be turned off. Choose Bluetooth menu again from the task bar and choose the Open Settings option. 8) An options menu will appear. Please uncheck the option Allow Bluetooth devices to find this computer and Alert me when a new Bluetooth device wants to connect.

  • Page 22: Preparing The Subject

    10) Please refer to Section 8 for additional information on the Bluetooth connection including troubleshooting a connection, manually creating COM ports and what to do if Bluetooth transmission is not reliable. 2.4.6.3 Making the Bluetooth Connection pedar-x...
  • Page 23 Too much tension on the insole lead. b. Attach the calf and thigh straps to keep the insole cable from moving around, or getting caught on objects. c. Attach any extra cable length to the Velcro straps on the belt.

  • Page 24: Battery Care

    Battery care 2.5.1 General info pedar-x The batteries provided with the system are rechargeable NiMH batteries. Usage times: Standard NiMH battery – approximately 4 hours Lightweight NiMH battery – approximately 10 minutes These batteries have effect called “lazy battery effect”. Partial charging and discharging them often will cause the capacity to decrease.
  • Page 25 If this process occurs regularly, novel and it is hard to know the actual status of the battery’s charge. Please contact your representative for further information. As described above, once every three months (or after 50-60 charge cycles) the battery should be completely discharged.

  • Page 26: Data Collection With Novel Database And Pedar

    The software will begin in one of two viewing modes, the simple (left image below) or advanced mode (right Image below). a. To begin entering patient information in the simple mode, simply click on the button.
  • Page 27 2. Go to and choose the appropriate port from the drop down menu and click (NOTE: older version of software - enter the appropriate Bluetooth or Fiber Optic Cable port manually. See Section 2.4.6.2 to locate the Port number).

  • Page 28: Post-Processing The Steps Within The Step Analysis Program

    10. To play back an activity, choose the thumbnail on the right hand side of the screen and click the button. a. To move forward or backward one frame, use the buttons, or move to the first or last frame with the buttons 11.
  • Page 29 3. Click the button to select all the trials to post-process and then click the Run Application button and then the button and then click the button to begin the step analysis program. 4. Review the steps by looking at the timing information, the force and pressure curves, the COP lines, etc, as in the following screen: 5.
  • Page 30 Report novel projects pedar Report To create a either the software must be pedar Basic, Standard, Expert installed. This software is available in level. 1. A report can be created once the .sol or .col file is created.
  • Page 31 Ensure to include the option to use the Mask Editor by selecting the button. (3) If you would like to create a report for these parameters, click the button and select pictures, tables and graphs to place on the novel report.

  • Page 32: Exporting Data From The Novel Database Medical

    1. Once data analysis is complete all parameters can be exported from the database to an ASCII format, which can be opened in Microsoft Excel (or the like). a. It is important to view what parameters you would like to export within the novel database medical. Select the parameters of interest within each table (Patients, Visits, pedar Files, etc) by using the button in each table.

  • Page 33: The Pedar-X Online Program

    4 THE PEDAR-X ONLINE PROGRAM pedar online pedar-x program collects and displays the data captured with the measuring insoles. The program also provides the ability to calibrate the insole sensors trublu (purchase of the calibration device is required for this option). Many different collection and display options are available within the program and will be reviewed in the following sections.
  • Page 34 The measurement is therefore saved as soon as the collection is stopped. By default the data is saved to the c:\novel\novfile\data\pedar\ directory. If this option is not selected, click the save icon and follow normal Microsoft Windows saving procedures. Once saved, a MPP picture of the data file will be shown on the right side of the screen as seen in the following picture.

  • Page 35: Viewing Data

    4.1.2 Viewing data pedar –x online 1. Open the program and select the open file icon. A standard Microsoft Windows open file box will appear. Select the file(s) to open and click open. Alternatively novel database pedar-x...
  • Page 36 1. Pressure Picture – displays the pressure distribution for each foot. Located on the left portion of the screen. a. Pressure values/colors for each sensor of the insole are represented here in the 2D mode. b. The left foot is displayed on the left of the screen, the right foot on the right.
  • Page 37 4. Bars tab – displays force, pressure and area values for each frame, left and right foot respectively in a bar graph format. 5. Masks - When a mask is applied the values for each mask are displayed in this window.
  • Page 38 6. Values On – displays information relative to each frame of data. a. Range: Shows the number of data frames which are being viewed in the time process window. b. Current frame: Displays the current frame number and the corresponding time.
  • Page 39 7. Selected Trial Menu a. Close: Select to close the selected trial novel b. Erase from database: Select to exclude the selected trial from the database . This may be necessary if a trial should be repeated and should not be included in analysis later.

  • Page 40: Menu And Toolbar Options

    Menu and Toolbar Options 4.2.1 File Menu Open Use to open data files. This will display a typical Windows novel database open screen. If using the , data files may be pedar online opened directly into the software.
  • Page 41 Open PDA File The pedar-x box can send data directly to a Windows mobile PDA device. For further information on supported devices and novel software for these devices, please contact your representative. This menu item opens data collected by the PDA device. The files collected will have the extension .mst and may be...

  • Page 42: View Menu

    Close Use to close single data file. Close All Use to close all data files. Print Use to print data file in real size. Just the left or right can be selected at the same time and can be printed in black and white or color.

  • Page 43: Data Acquisition Menu

    The firmware must be transmitted from the computer to the device and the with download firmware (only system XF without loaded firmware) menu should be selected. Ask your novel representative if you unsure which firmware version March 2013 version 23...
  • Page 44 “BthModem”. For a FOC Connection, the statement “VCP”. 4. Click “MS_Stack” to see the name of pedar-x devices which are assigned to the COM ports. This helps to select the correct device quickly from the available COM ports.
  • Page 45 This information may be helpful when discussing or troubleshooting with your novel representative. A message such as serial port locked, or box may be in menu mode indicates that the virtual COM port (either BT or FOC) is not set up properly.
  • Page 46 Soft reset This resets the pedar-x device to the configuration stored on the SD card Mode Different modes of operation can be selected depending on the task to be performed. See Section 2.4.3 for details on these data collection...
  • Page 47 Decrease the scanning rate to an acceptable value. The maximum scanning rate for one pair of insoles is about 101 (100) Hz. Please also see point h below. Stop...
  • Page 48  The Open Mask icon opens a previously defined mask/sensor  The Save Mask icon saves a mask/sensor definition  The Free Drawing icon provides the ability to draw a mask in any shape.  The Rectangle icon draws a square box around the insole and selects all sensors within the box.
  • Page 49 This menu initiates the video camera and displays a preview window Preview for the video Configure NOTE: Only available for pedar-x devices with internal flash Flash memory (serial numbers PEX### not for pedar-xf devices with a removable SD card). Load current insole configuration to flash: select this option to download configuration and calibration files to the flash card.
  • Page 50 Erase measurements in flash: select this option to delete all data from the flash card memory. Read Flash NOTE: Only available for pedar-x devices with internal flash memory (serial numbers PEX### not for pedar-xf devices with a removable SD card).
  • Page 51 The Firmware Listing allows you to change the Firmware for your pedar-xf device. Please contact your novel representative if you are not sure about the consequences of selecting a different Firmware. In the table in the lower part of the window you will see the files that are currently on the card, or that will be copied to the SD card during the configuration process.

  • Page 52: Options Menu

    4.2.4 Options Menu Many of options available within the Options Menu may be accessed by clicking the Options button within the main window toolbar. The options will be described as listed within this dialog box. The options may also be accessed directly from the Options | Set Options Menu.
  • Page 53 This screen shows the 2D pressure picture on the left hand side, overlayed with a coordinate system. The time curves on the right screen side show the X and Y coordinate in mm over time, and the...
  • Page 54 2-sigma ellipse which includes 95% of the COP points. Above the diagram, values are displayed including length of COP line, average velocity, mean X and Y coordinates, angle, numerical eccentricity, area of the 2-sigma ellipse, and the X and Y...
  • Page 55  With ASCII, FGT, MVA, EM_ASCII, Export: Select these options to automatically export the trial into the exported file formats. These will be saved to the path defined within the Configuration program – typically C:\novel\novfile\ascii\asciiout \pedar. Please see section 11 for definitions of each file export format.
  • Page 56 Mean pressure in masks over loaded sensors: If masks are applied to a measurement file and the bar diagrams for Mean Pressure are displayed, the values will be calculated only over the loaded sensors, not over all sensors within the mask.
  • Page 57  With BT transfer error correction: For pedar devices with removable SD card (PXF): When using the Online+SD card mode, this option will automatically replace the file with dropped frames with the complete file from SD card when it is read in the pedar program. It works the...
  • Page 58 SD card, the file name is not changed, and the time curves show now a continuous signal: For pedar devices with internal flash memory (PEX): When using the online + flash mode, this option will automatically fill...
  • Page 59 A button indicates that the audio alert is on; where a button indicates that the audio alert is off. Please also see Point r for additional information on the audio alert feature.  Cycle Counter: To count a cyclic loading of the insoles, and to show the current rate (Cycles per minute).
  • Page 60 If the new trial should be saved, use the menu item File | Save As | SOL file (see Section 4.2.1 - f for additional information. Use the reset total period to view the entire data file.
  • Page 61  Converter overload: This error will occur if the system received data which is above the amplification of the sensor. This error commonly occurs if high loads have been placed on the sensor. For additional information please see calibration Section 4.4.2.2.
  • Page 62 This error will occur if there is insufficient time for the computer pedar-x to communicate with the , or if a sensor element has become damaged. Please see section 9 for information on pedar testing the insoles for errors.
  • Page 63  Read masks: Allows the user to apply a mask to the currently selected file.  Read masks for all files of same type: Allows the user to apply a mask to all currently open files with the same insole setup.
  • Page 64 Audio Alert The audio alert function provides the user with the ability to Setup provide audio feedback for data being collected or played back. This option can be useful during biofeedback training sessions. Force, peak pressure, mean pressure and contact area can all be input variables for the determination of the output sound.
  • Page 65 Proportional Sound: The proportional sound series may be sampled by clicking the Play series button.  Once the options have been selected the settings may be saved as a new sound file by clicking the Store changes button. A previously saved audio alert file may be opened by clicking the Sound File...

  • Page 66: Expert Settings

    Define Cycle Defines Counter settings Cycle Counter. See Section 4.2.3 – k. The insoles can be chosen (left right), threshold levels (to count a cycle) force, peak pressure or area can be set, and the target cycle rate can be defined.
  • Page 67 Please configuration see Section 4.3 for a complete description of the configuration file. Edit insole An insole configuration can be selected from a typical Windows configuration Open screen for editing. Please see Section 4.3 for a complete description of the configuration file.

  • Page 68: Help Menu

    4.2.6 Help menu novel Opens the novel.de website in the user’s default browser. (www.novel.de) About View software version information. The insole configuration file Please note that not all options are available for all versions of software. The Basic and Standard versions of software will not be able to access all of these features.

  • Page 69: Configuration Of Measurement Tab

    4.3.1 Configuration of Measurement Tab  Selected calibration: will display the calibration file which is associated with this configuration.  Master/Slave Frequency (frames/sec): This section defines the measurement rate of the pedar system. The max sampling rate can be selected by clicking the Set frequencies to pedar maximum button.

  • Page 70: Sync Setup

    4.3.2 Sync Setup  This window displays the options for a trigger output and trigger input. These options may be used with either the wired or wireless synchronization device (Please note: only certain novel versions of the wireless sync can use a trigger input – please contact your representative if you are unsure if your sync device supports a trigger input).

  • Page 71: Sensor Type

    4.3.3 Sensor type This window displays the pressure color code and cutoff value and the layout stored in the original and the masked TBL files. The TBL files are created during calibration or masking and are used to determine the maximum sampling rate of the insole pair.

  • Page 72: Settings And Calibration Software And Calibration Hardware

    This window displays the paths for the set of calibration files. These paths can’t be modified and are for reference only. Settings and Calibration Software and Calibration Hardware The calibration file describes the relationship between an applied known pressure and the novel electrical signal from the insoles.
  • Page 73  Place the calibration device on a flat, stable surface and secure to prevent it from slipping off the surface.  Connect the supplied brass air pressure “T” assembly component and the manometer to the top of the calibration device as shown in the picture above. Please note that all connections utilize a quick release connection.

  • Page 74: Settings + Calibration Online

    Regulator adjustment Connection to quick release IMPORTANT It is extremely important to close the inlet valve from the compressor (clockwise) and open the outlet valve (parallel to the outlet pipe) when not using the calibration device. If this is not performed, it is possible that air can leak from the compressor into the calibration device over time and rupture the rubber bladder.
  • Page 75 3. Place the insoles within the calibration device. a. The insoles should be placed within the calibration device as shown in the first picture in Section 4.4.1 above. b. The insole has two sides; one side shows a square pattern of the leads and the other the “s”...
  • Page 76 6. The following screen will appear 7. Verify the system is connected to the specified COM port and click DOWNLOAD. 8. You will then see that the message box connected and the following screen The numbers and colors shown after the Download button is clicked are not important.
  • Page 77 The software will then indicate with a green window what should occur. The first step will be to load the sensors with the maximum load, which is 60 N/cm , or 6 bar. To ensure that amplification of the sensors occur properly at high loads, it is recommended that you load the insoles slightly higher than the amplification number mentioned above, i.e.
  • Page 78 Please refer to the Expert Mode described in Section 4.4.2.2 for further information. 10. Click on the CALIBRATION tab. A window similar to the following will appear: The first level, 2 N/cm2, will be green. Click measure all levels.
  • Page 79  Minimum and maximum levels: this displays the min and max value that occurred at each pressure level. These values may be important if having problems with the calibration. Errors concerning these values will be displayed in the novel messages/errors box.
  • Page 80 13. The insoles will now be tested within the calibration device to ensure that the calibration is accurate. This process is also the process that should occur when testing whether or not the insoles need recalibrated. a. Choose the appropriate insole configuration file from the drop down menu, if not displaying already.
  • Page 81 4.4.2.2 Calibrating insoles (Expert Level) This method of calibration is recommended for Expert users, or for those recommended to do novel so by their representative, and for users who would like to perform the following:  Calibrate one insole at a time ...
  • Page 82 4.4.2.2.1 Calibrating one insole at a time This method of calibration is used when:  Only one insole is required for data collection  Planning to combine insoles of different sizes  Only one insole fits inside of the calibration device.
  • Page 83 8. Complete Steps 9-11 as described in Sections 4.4.2.1 and 4.4.2.2 a. If the user plans to use just one insole for data collection, please complete Steps 12 and 13 as well b.
  • Page 84 4.4.2.2.3 Changing the maximum load of the insoles The default maximum load for the insoles is 600 kPa / 6 bar / 60 N/cm . The insoles have been designed for measurement within the 20 – 600 kPa range. They are most accurate in the mid-range of measurement where most data will occur during regular walking and running.
  • Page 85 Gain: The gain of the system can be changed if amplification can’t be reached with a gain setting of “1” (the default value). This may occur when smaller insoles, such as children’s size insole N-T or even the adult U insole. It may also be needed if the insoles are calibrated to a maximum pressure lower than the standard 600 kPa.
  • Page 86 The sensor may be removed. See Section 4.4.2.2.2 for additional information. iv. AD: This button will switch back the display of the data from 2. Calibration Tab: a. zero: use this setting to repeat a zero. This may be done if the calibration procedure was stopped reset to begin again.
  • Page 87 4.4.2.3 Combine insoles This menu item is used to combine the calibration files from two different individual calibrations. The insoles must have been calibrated previously as individual insoles. Please see Section 4.4.2.2.1 for additional information on calibrating one insole. It is possible to combine the calibration files of two different insole sizes, which may be helpful with subjects possessing two different sized feet.
  • Page 88 4. Click the blue/green arrow located between the sensor windows to display both insoles on the right side. 5. The name of combination field located below the right set of insoles will automatically fill in with a name for the combined sensor file. The name will start with the insole type.
  • Page 89 3. Move the cursor to the end point and click the LEFT mouse button. 4. A print setup screen will appear. Choose options and then print. Exit Select to exit the program 2. Configuration Directories Use this option to set default paths for files...

  • Page 90: The Pedar-X Step Analysis Program

    5 THE pedar-x STEP ANALYSIS PROGRAM pedar-x This program is used to perform a step analysis in which the measurements’ steps can be examined, post-processed and then saved. The pressure pictures for a selected step can be viewed (in 2D or 3D) as well as the maximum pressure picture (MPP) and the mean value picture (MVP) for the entire data sequence.
  • Page 91 4. Select the step analysis option with the left mouse button. 5. A window similar to the following will appear. March 2013 version 23...

  • Page 92: Menu Options

    6. Several different screen configurations are possible – this is just one example. Each Window is described in detail in Section 5.1.2 – 4a. This arrangement shows: a. Insoles: Top left window - shows the Average Maximum Pressure Picture (MPP AVE –...
  • Page 93  1:1 right values + color: prints a 1:1 picture of the right MPP AVE insole with values and color  Graphics window: prints a copy of the graphic windows Exit Exits the program Exit and save...
  • Page 94 Delete all Select to remove all steps in the file, or just from the view steps of the file. This menu option can be helpful when only one step is required. After deleting all steps the Delete Single...
  • Page 95  Velocity: The velocity that the subject traveled can be calculated if a known distance was traveled.  Renew/Reset/Cancel: Click the Renew button to apply the changes, Reset button to reset to the default settings and Cancel button to cancel all changes.
  • Page 96 A pull-down list in the bottom of this window will describe timing information for the selected step. The scroll bar at the bottom can be used to scroll through the steps.
  • Page 97  MVP over all frames: all frames and all zeros are calculation included in the calculation.  MVP only over loaded frames: completely unloaded frames are not included in the calculation.  MVP over loaded sensors: no zeros are included in the...
  • Page 98 6. Help novel Opens the www.novel.de homepage in your default browser About Displays the version number of the software. ##### March 2013 version 23...

  • Page 99: The Pedar-X Emedlink Program

    6 THE pedar-x EMEDLINK PROGRAM pedar step analysis As with the program, this program is used to perform an analysis in which pedar-x measurements’ steps can be examined, post-processed and then saved. The 2D emedlink pressure pictures and the force curves are displayed within the program.
  • Page 100 The following selection list will appear. 4. Select the emedlink option with the left mouse button. 5. A window similar to the following will appear. March 2013 version 23...
  • Page 101 6. The following windows will appear a. Graphics: displays the 2D pressure picture with pressure values and gaitline (if enabled). b. Color Code: displays the color code, pressure value for the colors and cutoff for the pressure picture.

  • Page 102: Menu Options

    Insole type: Displays the calibration file used to collect the data file. xi. Comments: Displays any comments saved with the trial e. Force curves: displays a force curve for each step. A selected step is indicated in red.
  • Page 103 Save left steps: will save all left steps as individual .stp files o Save right steps: will save all right steps as individual .stp files o Save all steps: will save all steps as individual .stp files.

  • Page 104: Pedar-X Sync Boxes And Software

    7 PEDAR-X SYNC BOXES AND SOFTWARE pedar-X This section describes how to set up the synchronization of the device with other devices such as video, EMG or motion capture systems. Generally there are two methods of synchronization: pedar-X 1) Two (or more) devices run with their own clock.

  • Page 105: Wireless Sync Unit Components

    C) Sync Out Fiber Optic Cable (2 pins) D) Sync In Fiber Optic Cable (1 Pin) 7.1.2 Wireless Sync Unit Components A) Wireless synchronization unit: PC Side B) Wireless synchronization unit: pedar Side C) Electrical Signal Cable...

  • Page 106: Connections Of The Sync Boxes And Pedar Box

    7.1.3 Connections of the Sync Boxes and pedar Box Sync Box Sync out Rundkabel Sync Cable Wiring to create LED von Sync Box Foot Switch Indicator Testschaltung Connections blau (right foot) LEDs AUX out TTL (rechter Fuß)

  • Page 107: Schematic Diagram Of The Electrical Ports Of The Sync Box

    7.1.4 Schematic diagram of the electrical ports of the Sync Box SYNC01: TTL output SYNCI: input SYNC02: Open collector output March 2013 version 23...

  • Page 108: Connecting The Wired Sync Box To The Pedar Device

    7.1.5 Connecting the wired sync box to the pedar device Connections: (1) For a sync out connection: (a) For a sync out TTL signal: connect the 1 pin FOC cable to the sync out port on pedar box and the sync box (b) For a sync out open connector in combination with an AUX connection (i.e.

  • Page 109: Connecting The Wireless Sync Box To The Pedar Device

    7.1.6 Connecting the wireless sync box to the pedar device 7.1.6.1 Electrical signal output/input Connections: (1) For a sync out connection: (a) For a sync out TTL signal: connect the 1 pin FOC cable to the sync out port on...
  • Page 110 7.1.6.2 Remote trigger Connections: (1) Connect the sync unit trigger cable to the pedar side wireless sync box and to the pedar start/stop port on the box. (2) Connect the start/stop cable to the switch port on the PC side wireless sync box.
  • Page 111 (1) Connect the 1 pin FOC cable to the sync out port on the box and to the pedar side wireless sync box. (2) Connect the flash LED to the Flash LED port on the PC side wireless sync box.

  • Page 112: The Sync Setup Tab In The Pedar Online Software

    The Sync Setup Tab in the pedar online Software The settings for the synchronization signal are found within the insole configuration file. The configuration file can be accessed from the Expert Settings | Edit insole configuration or Edit actual configuration menu.

  • Page 113: Setting The Trigger Input

    An example of the signal will display in the blue box at the bottom of the screen: (2) First picture: With this option a trigger output signal is sent with the first frame of data collected by the pedar.
  • Page 114 To use this feature with pedar-x device (without SD card slot), the firmware version 3.25 (or higher) must be loaded. The newer pedar-xf devices (with SD card slot) can use this feature with all available firmware versions.

  • Page 115: Troubleshooting Bluetooth Connection

    8 TROUBLESHOOTING BLUETOOTH CONNECTION General Bluetooth Information pedar-x pedar online system transmits wirelessly to the computer with the software via novel Bluetooth (BT) transmission. A BT dongle is provided to all customers which is rated to transmit for 100 meters. Many laptops also have a BT connection, though this should not be...

  • Page 116: Possible Solutions For Dropped Frames

    Possible Solutions for Dropped Frames If dropped frames are occurring regularly within the BT transmission, you will see the pressure/force/area values drop to “0” when pressure should be displayed, as shown in the following screen capture: To try to resolve this issue consider the following:...
  • Page 117 BT signal for both outdoor and indoor activities in which the space is very open, or has many novel other wireless signals. Please contact your representative for information on obtaining such a device.

  • Page 118: If Bluetooth Com Ports Are Not Created Automatically

    If Bluetooth COM Ports are Not Created Automatically Problem Description: pedar-x One of the following issues may arise when connecting the box to a Windows XP SP 2 or 3 or Windows Vista computer via a Bluetooth Connection: ...
  • Page 119   Temp. Database: TEMPINTEG1704.EDB  Checking database integrity.                       Scanning Status (% complete)              0    10   20   30   40   50   60   70   80   90  100            |‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|‐‐‐‐|            ...........  Integrity check successful.  Operation completed successfully in 1.592 seconds.  If the Windows security database is corrupted, the output will contain the following line: This operation may find that this database is corrupt.    To work around this problem, follow these steps: 1. If both the Edb.log file and the Edb.chk file are in the %windir%\security directory, follow these steps to repair the security database: a.

  • Page 120: Testing Insoles And Cables For Errors

    9 TESTING INSOLES AND CABLES FOR ERRORS pedar online If a frequent timeout error code is being read by the software, it may be useful to check where the error is coming from. This process can be helpful in reporting the information to...

  • Page 121: Testing The Insole For Errors

    Testing the insole for errors pedar 1) Connect the device as described in Section 2.4.4. Connect the insoles in which the errors are occurring. 2) Lay the system flat on a table. pedar online 3) Open the software.
  • Page 122 4) Open the software. In menu Options – Error Codes please uncheck the option With error correction. Choose the insole relevant configuration file, click the Confirm button, and when the message appers “Unload left insole” click Cancel. Begin a recording.

  • Page 123: Definition Of Variables

    10 DEFINITION OF VARIABLES Maximum Pressure Picture (MPP) Displays the highest pressure that was reached for each sensor at any time during the data collection period. This is therefore an artificial picture that provides a summary of the highest pressures that were reached over the entire surface of the insole –...
  • Page 124 The maximum pressure (sometimes referred to as maximum pressure) is the highest pressure experienced by any one sensor in the picture/frame. Mean Pressure (kPa) The average pressure is calculated for each picture/frame by summing the pressures in all sensors and dividing by the number of sensors (99).

  • Page 125: Definition Of File Types

    Data Files 11.1 By default, the data is stored in the folder C:\novel\novfile\data\pedar\. This directory can be changed from the Expert Settings menu of from the Configuration program.  *.sol – pedar data file. This file can be opened in the...

  • Page 126: Pedar Exported Files

    Exported files 11.3 These files can be exported and created from the .sol or .col files. They are tab delimited files which can be open in programs such as Excel, Notepad, etc. These files can be saved manually...
  • Page 127  *.fgt: This exported file contains the force and gaitline (center of pressure) for the left and right insole throughout time. A header is also included. A portion of an example output is shown here: March 2013...
  • Page 128 March 2013 version 23...
  • Page 129  *.mva: This exported file contains data throughout time for the masked parameters. (For more information on creating masks please see Section 4.2.4 – p. The parameters included are force, peak pressure, mean pressure and standard deviation of pressure. A header is also included.
  • Page 130 March 2013 version 23...

  • Page 131: Other Pedar Files

    Other pedar Files 11.4  *.sgm: This file is the sensor geometry file. It is located at C:\novel\novfile\defin\SOLS. This file is used in definition of the insole size and layout.  *.msk: This is the mask file which is created during the Read/Define Masks process or during the Define sensors to be scanned process.

  • Page 132: Insole Sizing Chart And Measurement Conversions

    12 INSOLE SIZING CHART AND MEASUREMENT CONVERSIONS Pressure Measurements 1 N/cm 0.1 Bar 10 kPa 74.006 mmHg 1.4504 Psi Shoe Sizes pedar-x European United States insoles Children Women 22/23 5.5/6.5 24/25 26/27 8.5/10 28/29 10.5/11.5 30/31 12/13 32/33 1/1.5...
