Summary of Contents for Redarc TOW-PRO LINK EBRHX-ADH-RH
- Page 1 INSTALL GUIDE TOW‑PRO LINK ™ Adhesive Mounted USB Remote MODEL: EBRHX-ADH-RH ƒ...
-
Page 2: Table Of Contents
Unit, refer to the supplied Install Guide� For operation instructions, important safety information, specifications and compliance information for the Tow‑Pro Link system, refer to the User Manual� For the latest version of this document and any available translations, visit the REDARC website: www.redarcelectronics.com/downloads... -
Page 3: Warnings & Safety Instructions
The products referenced in this manual must be installed by a suitably qualified person� Disclaimer: REDARC accepts no liability for any injury, loss or property damage which may occur from the improper or unsafe installation or use of its products�... -
Page 4: Overview
OVERVIEW The EBRHX‑ADH‑RH USB Remote wirelessly connects to and controls the Main Unit of the Tow‑Pro Link electric brake controller� It is powered via USB and can be mounted to the dashboard using the supplied non‑permanent, reusable adhesive tape� PARTS 1. USB REMOTE 2�... -
Page 5: Installation - Connecting To Power
INSTALLATION — CONNECTING TO POWER Plug the USB connector into a powered USB‑A socket� USB-A INSTALLATION — MOUNTING WARNING: Do not mount the Remote in a location that may affect the activation of vehicle air‑bags� CAUTION: It is the installers responsibility to ensure that the installation complies with local safety standards for dashboard mounted devices�... -
Page 6: Mounting Steps
MOUNTING STEPS 1. Make sure the mounting surface and the back of the Remote are clean and dry — clean off any grease or dust using the supplied alcohol swab� 2. Carefully position a piece of the supplied Reusable Adhesive Tape in the marked areas on the back of the Remote�... -
Page 7: Pairing To The Main Unit
PAIRING TO THE MAIN UNIT The Tow‑Pro Main Unit and Remote are supplied factory‑ paired when purchased as a complete system, so Manual Pairing is not needed� If the Main Unit or Remote were purchased separately or as a replacement, they must be paired before use� MANUAL PAIRING STEPS Before you begin the pairing process, make sure: ✓... -
Page 8: Operation
OPERATION For operation instructions, refer to the User Manual supplied with the Main Unit� The User Manual can be downloaded at: www.redarcelectronics.com/downloads TROUBLESHOOTING For troubleshooting information, refer to the User Manual� The Remote does not stick to surfaces Wipe the reusable adhesive with a damp cloth to clean off any dust�... -
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS GENERAL SPECIFICATIONS EBRHX‑ADH‑RH USB 5 V ⎓ Nominal voltage range* USB 4�5 to 5�5 V ⎓ Operating voltage range* Operating current 500 mA max� Standby current 5 mA max� –40°C to +60°C Operating temp −40°F to 140°F Weight 52 g (1�8 oz) Main Unit Compatibility EBRHX‑MU, EBRHX‑MU‑NA Braking Levels 0 (off) to 10 (0�5 increments) -
Page 10: Dimensions
DIMENSIONS 9.5 mm 38 mm (0.4") (1.5") Cable Length (approximate) 1.2 m (3.9') -
Page 11: Compliance And Standards
WARNING: Any changes or modifications not expressly approved by the grantee could void the user's authority to operate this equipment� FCC ID: 2BAH6‑EBRHXADHRH Details of the Responsible party: REDARC Corporation, 1701 Northwest Highway, Suite 100 Grapevine TX, 76051, USA Phone: +1 (704) 247 5150... - Page 12 INDUSTRY CANADA (IC) COMPLIANCE NOTICE This equipment complies with the FCC and ISED Canada radiation exposure limits set forth for an uncontrolled environment� This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and all persons during normal operation� ICES Statement —...
-
Page 13: Warranty
WARRANTY For full warranty terms and conditions, visit the Warranty page of the REDARC website at www.redarcelectronics.com/warranty� AUSTRALIA, NEW ZEALAND & EUROPE REDARC Electronics Pty Ltd, 23 Brodie Road (North), Lonsdale SA 5160, Australia Australia �������������������������������������������������������� +61 8 8322 4848 New Zealand���������������������������������������������������... - Page 14 NOTES...
- Page 15 Visit www�redarcelectronics�com/patent� Design, product configuration and technical specifications are subject to change without notice� | Copyright © REDARC Electronics Pty Ltd� All rights reserved� | REDARC®, THE POWER OF REDARC®, Tow‑Pro® and Tow‑Pro Link™ are trademarks of REDARC Electronics Pty Ltd�...
- Page 16 Tech Support 1300 REDARC (1300‑733‑272) Australia +61 8 8322 4848 New Zealand +64 9 222 1024 UK & Europe +44 (0)20 3930 8109 +1 (704) 247‑5150 Canada +1 (604) 260‑5512 Mexico +52 (558) 526‑2898 redarcelectronics.com INST200‑2...
