Summary of Contents for Polaris Timbersled 120 2023

  • Page 1 2023 For Maintenance and Safety OWNER’S MANUAL Timbersled 120 Timbersled RIOT Timbersled ARO...
  • Page 2 For more information go to www.P65Warnings.ca.gov/passenger-vehicle. For videos and more information about a safe riding experience with your Polaris vehicle, scan this QR code® with your smartphone, or visit www.polaris.com/en-us/safety/...
  • Page 3 2023 Owner’s Manual TIMBERSLED 120 SX TIMBERSLED 120 R TIMBERSLED ARO 129 SPORT TIMBERSLED ARO 129 S SPORT TIMBERSLED ARO 137 PREMIUM TIMBERSLED ARO 3 PREMIUM TIMBERSLED ARO 3 S PREMIUM TIMBERSLED ARO 3 PRO TIMBERSLED ARO 3 S PRO TIMBERSLED RIOT 120 SPORT TIMBERSLED RIOT 120 S SPORT TIMBERSLED RIOT 120 PREMIUM...
  • Page 4 Unless noted, trademarks are the property of Polaris Industries Inc. KLIM® is a registered trademark of Teton Outfitters, LLC. Loctite® is a registered trademark of Henkel IP & Holding GmbH LLC. ORTOVOX® is a registered trademark of Ortovox Sportartikel GmbH. Brembo® is a registered trademark of Freni Brembo S.
  • Page 5 Timbersled technician. Your Timbersled dealer knows your vehicle best and is interested in your total satisfaction. Your Timbersled dealership can perform all of your service needs during and after the warranty period. most up-to-date owner’s manual visit https://www. polaris. com/en-us/owners-manuals.
  • Page 6 SAFETY SYMBOLS AND SIGNAL WORDS The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is involved when these words and symbols are used. Become familiar with their meanings before reading the manual. DANGER DANGER indicates a hazardous situation which, if not avoided, WILL result in death or serious injury.
  • Page 7: Table Of Contents

    TABLE OF CONTENTS Introduction ....7 Safety ..... . 11 Features .
  • Page 9: Introduction

    INTRODUCTION INTRODUCTION IMPORTANT NOTES FOR OWNERS AND DRIVERS After reading this manual, store it with the snow bike for convenient reference. It should remain with the vehicle when it is sold. Some of the illustrations and photos used in this manual are general representations.
  • Page 10: Installation

    INTRODUCTION INSTALLATION PRODUCT PROS Have a question about Timbersled? Talk to one of our Timbersled Product Pros. These are the passionate experts who live and breathe Timbersled and the backcountry. Ask them which system is right for you, how to get your dirt bike ready to shred the snow, and more. Our Timbersled Product Pros are here to help.
  • Page 11: Vehicle Identification Numbers

    INTRODUCTION VEHICLE IDENTIFICATION NUMBERS Whenever corresponding about a Timbersled, be sure to refer to the vehicle identification number (VIN) and the serial number. The VIN and serial number decal can be found on the top of the chassis. Record your Timbersled’s serial number in the spaces provided.
  • Page 13: Operator Safety

    SAFETY SAFETY OPERATOR SAFETY Follow the recommended maintenance program on page 59 to ensure that all critical components on the snow bike are thoroughly inspected at specific intervals outlined in the Periodic Maintenance Chart. Your dealer can perform this service. WARNING Driving a snow bike requires your full attention.
  • Page 14: Riding Position

    SAFETY WARNING Serious injuries may result if hands, feet, or clothing become entangled in the track. Be alert when riding, and remain properly seated to stay clear of the track. Never hold the snow bike up or stand behind it while warming up the track.
  • Page 15: Eye Protection

    SAFETY HELMET Wearing a helmet can prevent a severe head injury. Whenever riding a Timbersled vehicle, always wear a helmet that meets or exceeds established safety standards. Clasp the buckle and pull each strap tight to ensure the helmet is properly secured to the head. Approved helmets in the USA and Canada bear a U.S.
  • Page 16: Survival Preparation

    SAFETY SURVIVAL PREPARATION For your safety, always ride in a group. Always tell someone where you're going and how long you expect to be gone. If it isn't possible to ride with others, and you must travel into remote areas, always carry survival equipment that's appropriate to the conditions you may encounter.
  • Page 17: Driver Awareness

    SAFETY HIDDEN OBSTRUCTIONS Always be aware of surroundings and terrain when riding your snow bike. Hazardous obstructions may be hidden beneath the snow. Striking a hidden obstacle could cause loss of control of your vehicle and lead to serious injury or death.
  • Page 18 SAFETY WARNING An avalanche can occur at any time, in any conditions and on any slope. The avalanche information provided in this manual should be considered basic information and is not intended to replace your participation in an avalanche safety training course. After reviewing the avalanche information in this manual, be sure to participate in an avalanche safety training course before riding in mountainous terrain.
  • Page 19 SAFETY GET TO KNOW YOUR SAFETY GEAR Following the safety gear and apparel recommendations will increase your chances of survival if you encounter an avalanche or become stranded in the backcountry, but even experienced and properly-equipped snow bikers, hikers and skiers perish in avalanches or succumb to hypothermia. Using a beacon or probe for the first time during an avalanche recovery operation, or not knowing how to deploy your avalanche air bag backpack during a slide, should be considered UNACCEPTABLE to you and all members of your riding group.
  • Page 20: Get The Picture

    SAFETY GET THE PICTURE Slopes steeper than 30º are more prone to avalanches, but any slope should be considered avalanche terrain, even small slopes with trees. Low-angle slopes are also avalanche terrain if they have steeper slopes above them. NOTICE The 30º...
  • Page 21 SAFETY Always practice riding your snow bike in a safe, open, flat area before attempting your first ride in mountainous terrain. This is especially important for low-elevation riders who are not accustomed to riding a snow bike designed for deep snow. Do not ride in mountainous terrain until you are comfortable riding and controlling your snow bike in deep snow.
  • Page 22 SAFETY • Always review the user instructions provided with your safety equipment and follow the recommendations for maintenance, testing and use. Always test your safety equipment to ensure it works properly before riding in mountainous terrain. • Always store your survival gear in your backpack and wear the backpack. Do not store your survival gear on the snow bike.
  • Page 23 SAFETY North American Public Avalanche Danger Scale Avalanche danger is determined by the likelihood, size and distribution of avalanches. DANGER LEVEL TRAVEL ADVICE LIKELIHOOD AVALANCHE SIZE AND AVALANCHES DISTRIBUTION Natural and Large to very Avoid all avalanche human-triggered large avalanches Extreme terrain.
  • Page 24: Ice And Snow Build-Up

    SAFETY ICE AND SNOW BUILD-UP WARNING Ice and snow build-up may interfere with the steering and braking of your snow bike, resulting in serious injury or death. Keep the snow bike free of snow and ice. Before driving, manually turn the ski to the left and right to be sure ice and snow are not interfering with full left and right steering.
  • Page 25: Driving Downhill

    SAFETY DRIVING DOWNHILL When riding downhill, shift your weight to the rear of the snow bike and reduce your speed to a minimum. Apply just enough throttle to keep the engine from stalling, allowing the engine's compression to help slow the snow bike and keep it from rolling freely downhill.
  • Page 26: Driving Responsibly

    SAFETY MANEUVERABILITY While much control and maneuverability is achieved through the steering system and ski, maximum control is achieved by the shifting of your body weight. Maneuverability will change for lighter operators. DRIVING RESPONSIBLY Every snow bike handles differently, and even the most benign conditions may become dangerous if operators drive improperly.
  • Page 27 SAFETY WINDCHILL/TEMPERATURE CHARTS The following information is provided to help you determine when temperatures become dangerous for riding. WINDCHILL CHART (°F) Wind Actual Thermometer Reading (°F) Speed in MPH -10 -15 -20 -25 -30 -35 -40 -45 Equivalent Temperature (°F) Calm -10 -15 -20 -25 -30 -35 -40 -45 -11 -16 -22 -28 -34 -40 -46 -52...
  • Page 28: Safety Labels And Locations

    Safety and warning labels have been placed on the vehicle for the operator's protection. Make sure the operator understands the information on all labels. If any label becomes illegible or comes off, contact your POLARIS dealer for a replacement. Replacement safety labels are provided by POLARIS at no charge.
  • Page 29 SAFETY ACCESSORY WARNING WARNING Suspension travel reduces distance between exhaust and tunnel. ALWAYS position cargo and accessories to avoid contact with engine, exhaust, or moving components. FAILURE TO COMPLY MAY RESULT IN SUSPENSION INTERFERENCE OR FIRE AND BURN HAZARD. QUICK DRIVE BELT ADJUSTMENT NOTICE Belt debris during break in of a new belt is normal, clean with a dry cloth, or soft bristle brush.
  • Page 31: Features

    FEATURES FEATURES COMPONENT LOCATIONS Brake Lever Drive Chain Exhaust Chain Case or QDT Brake System Front Track Shock Tunnel Track Ski Loop Rear Track Shock Spindle Rail Track Tensioning Block Ski Skags...
  • Page 32 FEATURES CHAIN CASE COMPONENTS Jack Shaft Chain Slider/Tensioning Bolt Chain Case Chain Drive Shaft Chain Pin QDT COMPONENTS 22T Sprocket QDT Pulley Assembly QDT Cover Plate QDT Belt 23T Sprocket...
  • Page 33 FEATURES TOOLS Timbersled recommends carrying a few tools to work on the snow bike kit when in the backcountry. These tools will aid in most service and maintenance items on the snow bike kit. • Wrenches: 0.5 in, 8 mm, 9 mm, 10 mm, 13 mm, 14 mm, 15 mm, 16 mm, 17 mm, 19mm, Adjustable Wrench that adjusts up to 1 in.
  • Page 34 FEATURES RAIL ICE SCRATCHERS Timbersled recommends rail ice scratchers to help prevent overheating when riding on ice or hard-packed snow. ACCESSORIES Timbersled offers a wide range of accessories for your snow bike to help make each ride more enjoyable. WARNING Use only Timbersled-approved parts and accessories on your Timbersled snow bike.
  • Page 35: The Perfect Fit

    THE PERFECT FIT THE PERFECT FIT SUSPENSION QUICK SETUP GUIDE OVERVIEW Front Track Shock Spring Preload Adjuster Rear Track Shock Shock Clicker (if equipped) IMPORTANT Prior to adjusting spring preload, always lay the snow bike on it’s side or elevate it off the ground. The shocks must be fully extended for proper preload adjustment.
  • Page 36: Adjusting The Suspension

    Heavier riders will typically require more preload than lighter riders. A spanner wrench is needed to adjust the preload on IFP shocks. (Polaris P/N: 2871095-329) • For LESS weight transfer, increase the rear shock spring preload by turning the preload adjuster clockwise.
  • Page 37 THE PERFECT FIT ski-to-ground pressure is too heavy or light, the bike may experience difficulties in steering and stability on certain terrain. • If ski-to-ground pressure is TOO HEAVY, increase the front shock spring preload and decrease the rear shock preload. •...
  • Page 38 THE PERFECT FIT Sport Timbersled ARO snow bikes are equipped with Timbersled IFP shocks that utilize spring load adjusters to customize weight transfer and ski-to-ground pressure. CAUTION DO NOT EXCEED the MIN / MAX preload values (defined by the tables in this section).
  • Page 39 THE PERFECT FIT PREMIUM AND PRO MODELS Timbersled ARO Premium and Pro snow bikes are equipped with FOX® QS3® shocks that utilize spring preload adjusters and shock clickers to customize weight transfer and shock compression. CAUTION DO NOT EXCEED the MIN / MAX preload values (defined by the tables in this section).
  • Page 40 THE PERFECT FIT 1. Ride your snow bike. Test ride your snow bike on preferred terrain to feel out the factory suspension settings prior to making any adjustments. Optimal suspension settings can change depending on terrain and skill level. 2. Tune vehicle balance using rear shock preload adjuster .
  • Page 41 THE PERFECT FIT MODEL REAR SHOCK SPRING FACTORY MINIMUM RATE INSTALLED ALLOWABLE LENGTH LENGTH ARO 3 PRO FOX® QS3® 7.56 in 6.7 in ARO 3 S PRO FOX® QS3® 7.00 in 6.1 in...
  • Page 42 THE PERFECT FIT TIMBERSLED RIOT MODELS SPORT MODELS Sport Timbersled RIOT snow bikes are equipped with Timbersled IFP shocks that utilize spring load adjusters to customize weight transfer and ski-to-ground pressure.
  • Page 43 THE PERFECT FIT CAUTION DO NOT EXCEED the MIN / MAX preload values (defined by the tables in this section). Never adjust spring preload shorter than the minimum allowable length. Adjusting shorter than this length could result in damage to the suspension.
  • Page 44 THE PERFECT FIT PREMIUM AND PRO MODELS Timbersled RIOT Premium and PRO snow bikes are equipped with FOX® QS3® shocks that utilize spring preload adjusters and shock clickers to customize weight transfer and shock compression. CAUTION DO NOT EXCEED the MIN / MAX preload values (defined by the tables in this section).
  • Page 45 THE PERFECT FIT 1. Ride your snow bike. Test ride your snow bike on preferred terrain to feel out the factory suspension settings prior to making any adjustments. Optimal suspension settings can change depending on terrain and skill level. 2. Tune vehicle balance using rear shock preload adjuster .
  • Page 46 THE PERFECT FIT REAR SHOCK SPRING SETTINGS MODEL REAR SHOCK SPRING FACTORY MINIMUM RATE INSTALLED ALLOWABLE LENGTH LENGTH Timbersled FOX® QS3® RIOT 3 7.5 in 7.5 in PREMIUM Timbersled FOX® QS3® 6.75 in 4.9 in RIOT 3 S PREMIUM Timbersled FOX®...
  • Page 47 THE PERFECT FIT Spring Preload Adjuster Compression Damping Clicker Rebound Damping Clicker SPRING PRELOAD ADJUSTER Adjusting the rear track spring preload helps tune vehicle balance between the ski and rear track during rider weight transfer. See page 34 for spring preload adjustment instruction.
  • Page 48 THE PERFECT FIT SHOCK SPRING SETTINGS SHOCK TYPE SPRING RATE FACTORY MINIMUM SHOCK LOCA- INSTALLED ALLOWABLE LENGTH TION LENGTH Front FOX® 1.5 Zero 7 7/8 in 7 25/32 in Track LSC-R Rear FOX® 1.5 Zero 7 7/8 in 7 25/32 in Track LSC-R TIMBERSLED TSS AND TSS QSL (IF EQUIPPED)
  • Page 49: Adjusting Air Pressure

    THE PERFECT FIT MODEL MAXIMUM TRAVEL RECOMMENDED TRAVEL RANGE 1.5 in 1–1.125 in TSS QSL 1 in 0.75–.80 in ADJUSTING AIR PRESSURE NOTICE The TSS Shock is factory preset at 260 psi. Use a FOX® Float air pump to adjust the spring rate and preload of the TSS Shock. CAUTION DO NOT EXCEED the minimum or maximum pressure values specified below.
  • Page 50 THE PERFECT FIT Factory Setting Maximum Setting 1. Turn bike on side or elevate so the weight of the vehicle is removed from the shock. 2. Remove the valve cap 3. Thread the pump onto the valve-stem until the pump pressurizes and supplied pressure is readable on the gauge.
  • Page 51 THE PERFECT FIT To adjust: 1. Shut off bike engine. WARNING The adjustment clicker knob may be close to hot components, never attempt to adjust the TSS QSL setting while the motorcycle is running or still hot from running. 2. Allow the bike engine to cool of before attempting to adjust the clicker knob. 3.
  • Page 53: Pre-Ride Inspection

    PRE-RIDE INSPECTION PRE-RIDE INSPECTION PRE-RIDE CHECKLIST Inspect all items on the checklist for proper operation or condition before each use of the snow bike. Procedures are outlined in the referenced sections. ITEM SEE SECTION Steering System page 52 Coolant Level See Host Bike’s Owners Manual Injection Oil Level See Host Bike’s Owners Manual...
  • Page 54: Before Starting The Engine

    PRE-RIDE INSPECTION ITEM SEE SECTION Check rail slide condition. page 90 Check track tension. page 84 Check ski runner/skag condition. page 88 Check ski spindle bolts for tightness. Swing Arm Pivot Bolt page 68 Check chains (chain case and engine drive chain) for wear and tension.
  • Page 55: Brake Lever Travel

    PRE-RIDE INSPECTION BRAKES Always check the following items for proper operation before starting the engine. BRAKE LEVER TRAVEL Squeeze the brake lever. It should move no closer to the handgrip than 1/2 inch (1.3 cm). A smaller distance indicates low brake fluid level or air in the hydraulic system.
  • Page 56 PRE-RIDE INSPECTION CAUTION Use of traction products such as studs increases the possibility of track damage and/or failure. Driving at high speeds for extended periods of time in marginal lubrication could severely damage track rods, break track edges, and cause other track damage. Examples of marginal lubrication would include frozen bodies of water without snow cover, icy trails, and no-snow conditions.
  • Page 57: Operation

    OPERATION OPERATION BREAK-IN PERIOD SNOW BIKE SYSTEM BREAK-IN BREAK-IN FUNCTION BREAK IN PERIOD POST (HOURS OF ENGINE BREAK-IN RUN TIME) MAINTENANCE Chain: Drive and Chain Case 3 hours Lubricate Chain Deflection (Drive and 3 hours Chain Case) NOTE: follow chain tensioning Check Tension procedures on page 68 and page 71.
  • Page 58: Slide Rail And Track Cooling

    OPERATION Follow these steps to ensure proper warm-up of the engine, drive train and track. 1. Use an appropriate stand to securely support the rear of the snow bike. The track should be about 4 inches (10 cm) off the ground. 2.
  • Page 59: Fuel Storage

    OPERATION IMPORTANT Timbersled models with 3” lug tracks have a recommended maximum sustained speed limit of 40 MPH. To avoid track/lug damage, never exceed this maximum recommended sustained speed. FUEL STORAGE WARNING Gasoline is highly flammable and explosive under certain conditions. •...
  • Page 61: Maintenance

    MAINTENANCE MAINTENANCE HOST BIKE MAINTENANCE For host bike maintenance procedures and recommendations, refer to your host bike’s owner’s manual. The maintenance information found in the manual only applies to the Timbersled Snow Bike system. TIMBERSLED RECOMMENDED MAINTENANCE PROGRAM Always follow recommended regular maintenance and perform service checks as outlined in this manual.
  • Page 62: Periodic Maintenance Table

    MAINTENANCE PERIODIC MAINTENANCE TABLE The following chart is a guide based on average riding conditions. You may need to increase frequency based on riding conditions. When inspection reveals the need for replacement parts, always use genuine Timbersled parts, available from your Timbersled dealer. I - INSPECT (CLEAN, ADJUST, TIGHTEN, LUBRICATE, REPLACE IF NECESSARY) C - CLEAN, R - REPLACE, L - LUBRICATE FREQUENCY...
  • Page 63 MAINTENANCE I - INSPECT (CLEAN, ADJUST, TIGHTEN, LUBRICATE, REPLACE IF NECESSARY) C - CLEAN, R - REPLACE, L - LUBRICATE FREQUENCY ITEM Rear Wheel Idler Bolt Idler Bolt Jam Nut Track Alignment Track Tension Rail Slide Condition (see page 90 for inspection procedures) Chain Case Chain (see page 71 and page 73 for inspection and tensioning procedures)
  • Page 64: Chain Lubrication

    MAINTENANCE LUBRICATION CHAIN LUBRICATION Lubricate the chains every 8 to 10 hours of operation. We recommend the use of Timbersled chain lube. It is recommended to lift the track off the ground. Start the bike and put it into first gear and let the clutch out allowing the drive system to spin.
  • Page 65: Hydraulic Brake Inspection

    MAINTENANCE 1. Track tension and alignment adjustment may be required if the track starts to skip on the drivers or if the rail slides are wearing too quickly. For more information on track tension and alignment refer to the Track Maintenance section (page 81).
  • Page 66 MAINTENANCE WARNING DO NOT adjust the brake lever closer than 1/2 in from the handlebar. Adjusting the lever closer than 1/2 in could prevent the brakes from functioning properly resulting in severe injury or death. WARNING Do not remove the brake lever boot. 1.
  • Page 67 MAINTENANCE HAND-GUARD Timbersled snow bikes are equipped with a Brembo® Master Cylinder Hand Brake. Only use Timbersled-approved hand guards. WARNING Make sure gauntlets and other hand protection accessories do not come in contact with the brake lever. Any brake lever contact can create pressure in the brake system and cause it to overheat and fail.
  • Page 68: Brake Components

    MAINTENANCE BRAKE COMPONENTS Brake Caliper Brake Pad Material Brake Disc EXCESSIVE LEVER TRAVEL Hydraulic brakes are self-adjusting, but if excessive brake pad clearance develops, bring the snow bike to an authorized Timbersled dealer for inspection and adjustment. The lightweight brake discs have vent holes that may cause a high-pitched sound during operation.
  • Page 69: Bleeding The Hydraulic Brake System

    MAINTENANCE WARNING Keep the master cylinder cover free of dirt and debris. The vent slits allow for diaphragm movement, and if they become plugged, movement of brake fluid below the diaphragm may be restricted, altering brake function. NOTICE Brake fluid will damage labels, paint and some plastics. Always wipe up spills immediately.
  • Page 70: Drive System

    MAINTENANCE 7. After bleeding is complete, refill the reservoir to the proper level. 8. Reinstall the gasket and cover. TORQUE 6–8 in lbs (0.7–0.9 Nm) DRIVE SYSTEM DRIVE CHAIN TENSION For long chain life and reliability, it is extremely important that you keep the drive chain adjusted properly.
  • Page 71 MAINTENANCE 2. Position a ruler behind or in front of the top chord of the drive chain, halfway between the counter shaft sprocket and the jack shaft sprocket (this is where drive chain displacement should be measured) . Steady the ruler so it does not move as chain displacement is measured.
  • Page 72: Adjusting Drive Chain Tension

    MAINTENANCE ADJUSTING DRIVE CHAIN TENSION To adjust drive chain tension, follow the steps below. 1. If the chain requires adjustment, loosen both 15 mm frame rail slide bolts located on the right side of the Timbersled frame. 2. Loosen the 13 mm inner jam nut on the inner frame tension adjuster bolt...
  • Page 73 MAINTENANCE 3. Adjust the tension adjuster bolt in or out to achieve the correct chain tension. NOTICE Turning the tension adjuster bolt counterclockwise tightens the chain tension. Turning the tension adjuster bolt clockwise loosens the chain tension. 4. Re-torque the jam nut to specification.
  • Page 74 MAINTENANCE 1. Remove fasteners from chain case cover. 2. Position a ruler behind or in front of the right chord of the drive chain halfway between the drive shaft sprocket and the jack shaft sprocket (this is where the chain’s displacement should be measured). Position and steady the ruler so it does not move as chain displacement is measured.
  • Page 75: Chain Inspection

    MAINTENANCE 1. Loosen the tension roller bolt 2. Adjust the chain tension as needed by pushing the roller bolt towards the chain to increase tension or away from the chain to lessen tension. 3. Then tighten the tension roller bolt firmly once again.
  • Page 76 MAINTENANCE 2. Mark out the number of links to measure (see the following table to find the number of links to measure for the chain you are inspecting). To mark this number of links, begin by marking the first pin and counting forward the same number of pins (number of pins counted should equal the number of links to measure).
  • Page 77 MAINTENANCE 3. Then measure the counted number of links by measuring from the center of the first pin to the center of the final pin . This measurement should equal a length somewhere within the acceptable length range (as shown in the previous table). 4.
  • Page 78: Belt Adjustment

    MAINTENANCE QUICK DRIVE BELT MAINTENANCE QUICK DRIVE BELT INSPECTION & ADJUSTMENT WARNING • Do not crimp or bend the belt to a diameter less than the upper sprocket. • Do not bend the belt beyond how it would bend over a sprocket or the idler. •...
  • Page 79 MAINTENANCE 1. Remove the Quick Drive cover and cover nuts 2. Loosen idler pulley mount nut...
  • Page 80 MAINTENANCE 3. Install belt adjust tool onto cover mounting stud. 4. Push belt adjustment tool down to set belt tension. NOTICE Make sure belt tool is pushing on idler mount and not the pulley.
  • Page 81 MAINTENANCE 5. To check belt tension, make sure the bike is in neutral and the brake is released. Apply 10 pounds of tension to the belt in the position indicated by the arrow and measure deflection. Adjust as necessary. MEASUREMENT Belt Deflection (Inspection) 0.25–0.5 in (6.35–12.7 mm) New Belt Install Specification...
  • Page 82 MAINTENANCE 6. Torque the idler nut to specification. TORQUE Idler Nut 44 ft-lbs (60 N·m) 7. Install the Quick Drive cover . Install five nuts . Torque to specification. TORQUE Cover Nuts 18.4 ft-lbs (25 N·m)
  • Page 83: Track Maintenance

    MAINTENANCE TRACK MAINTENANCE TRACK INSPECTION 1. Using a hoist, safely lift and support the rear of the snow bike off the ground. 2. Rotate the track by hand to check for damage. 3. Carefully examine the track along the entire length of each rod. Bend the track to check for breakage.
  • Page 84 MAINTENANCE ADJUSTING TRACK ALIGNMENT To adjust track alignment, follow the steps below. 1. Loosen axle bolt 2. Loosen the adjustment bolt jam nuts...
  • Page 85 MAINTENANCE 3. If the track is running too far to the left, turn the right tension adjustment bolt clockwise approximately one-half turn. If the track is running too far to the right, turn the left tension adjustment bolt clockwise approximately one-half turn. NOTICE Tune the adjustment bolt one half-turn at a time.
  • Page 86: Track Tension

    MAINTENANCE TRACK TENSION WARNING Moving parts can cut and crush body parts. When performing the checks and adjustments recommended on the following pages, stay clear of all moving parts. Never perform track measurement or adjustments with the engine running. CAUTION Always ensure proper track tension.
  • Page 87 MAINTENANCE TRACK TENSION DATA PROPER MEASURE- APPLIED SLACK SUSPENSION MENT MEASURE- WEIGHT LOCATION - MENT All Model Types 3/4” to 1” 10 lbs 10” to 15” in front of the rear axle To measure track tension: 1. Using an appropriate hoist or stand, safely lift and support the rear of the snow bike off the ground.
  • Page 88: Adjusting Track Tension

    MAINTENANCE 4. If the track is properly tensioned, the slack measurement should be between 3/4” to 1” (as shown in the table). If the slack measurement is less or greater than the proper slack measurement ( 3/4” to 1”), the track tension should be adjusted (see the following section, Adjusting Track Tension).
  • Page 89 MAINTENANCE 3. Then tighten or loosen the tension adjustment bolt , a half-turn at a time on both the right and left side of the bike. Turn the adjustment bolts the same amount on both sides of the track to tension the track evenly and keep the track aligned (track alignment should be performed before measuring and adjusting track tension).
  • Page 90: Ski Skags

    MAINTENANCE SKI MAINTENANCE Timbersled recommends periodically inspecting your ski for damage. • Check the ski bolt to make sure it is tight. Torque to specification. TORQUE Ski Bolt 33 ft-lbs (45 N·m) WARNING Failure to torque fasteners as directed will adversely affect the steering system and may lead to severe injury or death.
  • Page 91: Skag Replacement

    MAINTENANCE SKAG REPLACEMENT 1. Raise and support the front of the snow bike so the ski is approximately 6 inches (15.2 cm) from the ground. 2. Remove the attaching nuts and pry the skag downward. 3. Remove the front end of the skag. 4.
  • Page 92: Rail Slide Wear

    MAINTENANCE RAIL SLIDE WEAR Timbersled rail slides run along the bottom of the rail to prevent track wear. Both the left and right rail slide should be inspected periodically and replaced when necessary. For ease of inspection, all Timbersled rail slides have a wear limit indicator groove to indicate the minimum permissible slide thickness...
  • Page 93: Extended Storage

    MAINTENANCE MATTE CLEAR COAT CLEANING (IF EQUIPPED) Matte finish products are prone to trapping dirt, oils and other contaminants. Timbersled recommends cleaning with warm water and a mild dish detergent. Use a soft sponge to gently rub the surface and rinse with clean warm water. For stubborn stains such as grease or oil, use a citrus based cleaner (3M®...
  • Page 94 MAINTENANCE TRANSPORTING THE SNOW BIKE Whenever the snow bike is transported: 1. Be sure the fuel cap and oil cap are installed correctly. 2. Tie the snow bike to the transporting unit securely using suitable straps. 3. Remove the ignition key (if equipped) to prevent loss. NOTICE Use of a cover is recommended when transporting your vehicle on an open trailer.
  • Page 95: Specification

    SPECIFICATION SPECIFICATION TIMBERSLED 120 SX DIMENSIONS Estimated Dry Weight - Front 16.5 (7.25 kg) Estimated Dry Weight - Rear 94 (42.6 kg) Overall Length - pivot to bumper 63 in (160 cm) ENGINE AND DRIVETRAIN Drivetrain Type QuickDrive Timbersled (QDT) Engine Chain 70L - 520P Non O-ring Chain Case/Belt Drive...
  • Page 96 SPECIFICATION TIMBERSLED 120 R DIMENSIONS Estimated Dry Weight - Front 16.5 (7.25 kg) Estimated Dry Weight - Rear 94 (42.6 kg) Overall Length - pivot to bumper 63 in (160 cm) ENGINE AND DRIVETRAIN Drivetrain Type QuickDrive Timbersled (QDT) Engine Chain 70L - 520P Non O-ring Chain Case/Belt Drive QuickDrive Belt...
  • Page 97 SPECIFICATION TIMBERSLED ARO 129 SPORT DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 112 (51 kg) Overall Length - pivot to bumper 68 in (172.7 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive 520 X-Ring 52 Link...
  • Page 98 SPECIFICATION TIMBERSLED ARO 129 S SPORT DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 112 (51 kg) Overall Length - pivot to bumper 68 in (172.7 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 99 SPECIFICATION TIMBERSLED ARO 137 PREMIUM DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 120 (53 kg) Overall Length - pivot to bumper 73 in (185.4 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive 520 X-Ring 52 Link...
  • Page 100 SPECIFICATION TIMBERSLED ARO 3 PREMIUM DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 107 (48 kg) Overall Length - pivot to bumper 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive 520 X-Ring 52 Link...
  • Page 101 SPECIFICATION TIMBERSLED ARO 3 S PREMIUM DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 120 (54.4 kg) Overall Length - pivot to bumper 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 102 SPECIFICATION TIMBERSLED ARO 3 PRO DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 107 (48 kg) Overall Length - pivot to bumper 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type QuickDrive Timbersled (QDT) Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 103 SPECIFICATION TIMBERSLED ARO 3 S PRO DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 107 (48 kg) Overall Length - pivot to bumper 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type QuickDrive Timbersled (QDT) Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 104 SPECIFICATION TIMBERSLED RIOT 120 SPORT DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 110 (50 kg) Overall Length - pivot to bumper 65.5 in (165.1 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive 520 X-Ring 52 Link...
  • Page 105 SPECIFICATION TIMBERSLED RIOT 120 S SPORT DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 110 (50 kg) Overall Length - pivot to bumper 65.5 in (165.1 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 106 SPECIFICATION TIMBERSLED RIOT 120 PREMIUM DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 110 (50 kg) Overall Length - pivot to bumper 65.5 in (165.1 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive 520 X-Ring 52 Link...
  • Page 107 SPECIFICATION TIMBERSLED RIOT 120 S PREMIUM DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 110 (50 kg) Overall Length - pivot to bumper 65.5 in (165.1 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 108 SPECIFICATION TIMBERSLED RIOT 3 PREMIUM DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 122.3 (55.5 kg) Overall Length - pivot to bumper 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive 520 X-Ring 52 Link...
  • Page 109 SPECIFICATION TIMBERSLED RIOT 3 S PREMIUM DIMENSIONS Estimated Dry Weight - Front (lbs./kg.) 16 (7.25 kg) Estimated Dry Weight - Rear (lbs./kg.) 122.3 (55.5 kg) Overall Length - pivot to bumper (in./cm.) 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type Chain Drive Engine Chain 520 X-Ring 70 Link...
  • Page 110 SPECIFICATION TIMBERSLED RIOT 3 PRO DIMENSIONS Estimated Dry Weight - Front 16 (7.25 kg) Estimated Dry Weight - Rear 117 (53 kg) Overall Length - pivot to bumper 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type QuickDrive Timbersled (QDT) Engine Chain 520 X-Ring 70 Link Chain Case/Belt Drive...
  • Page 111 SPECIFICATION TIMBERSLED RIOT 3 S PRO DIMENSIONS Estimated Dry Weight - Front (lbs./kg.) 16 (7.25 kg) Estimated Dry Weight - Rear (lbs./kg.) 117 (53 kg) Overall Length - pivot to bumper (in./cm.) 72 in (182.9 cm) ENGINE AND DRIVETRAIN Drivetrain Type QuickDrive Timbersled (QDT) Engine Chain 520 X-Ring 70 Link...
  • Page 112: Torque Tables

    SPECIFICATION TORQUE TABLES TIMBERSLED RIOT MASTER TORQUE TABLE DRIVETRAIN TORQUE ITEM 6 ft-lbs (8 N·m) Front Chain Slider Fastener 25 ft-lbs (34 N·m) Chaincase Chain Idler Fastener 6 ft-lbs (8 N·m) Chaincase Cover Fastener 44 ft-lbs (60 N·m) Driveshaft / Jackshaft Fasteners Bearing Housing Fasteners 18 ft-lbs (25 N·m) 18 ft-lbs (25 N·m)
  • Page 113: Rear Suspension

    SPECIFICATION REAR SUSPENSION TORQUE ITEM Torque Arm Mounting Fasteners 44 ft-lbs (60 N·m) 44 ft-lbs (60 N·m) Cross Shaft Fasteners Upper Shock Shaft Mounting 44 ft-lbs (60 N·m) Fastener Lower Shock Mounting Fastener 44 ft-lbs (60 N·m) 44 ft-lbs (60 N·m) Idler Fastener 7 ft-lbs (10 N·m) Idler Bolt Block Fasteners...
  • Page 114 SPECIFICATION CHASSIS TORQUE ITEM 37 ft-lbs (50 N·m) Frame Slide Fasteners Chain Adjuster Jam Nut 18 ft-lbs (25 N·m) 9 ft-lbs (12 N·m) Tunnel Fasteners Apply Red Loctite® 22 ft-lbs (30 N·m) Bumper Fasteners Apply Red Loctite® BRAKES TORQUE ITEM 18 ft-lbs (25 N·m) Brake Caliper Mounting Fasteners Apply Blue Loctite®...
  • Page 115: Drive Train

    SPECIFICATION TIMBERSLED ARO MASTER TORQUE TABLE DRIVETRAIN TORQUE ITEM 9 ft-lbs (12 N·m) Front Chain Slider Fastener 25 ft-lbs (34 N·m) Chaincase Chain Idler Fastener 9 ft-lbs (12 N·m) Chaincase Cover Fastener 44 ft-lbs (60 N·m) Driveshaft / Jackshaft Fasteners Bearing Housing Fasteners 18 ft-lbs (25 N·m) 18 ft-lbs (25 N·m)
  • Page 116 SPECIFICATION REAR SUSPENSION TORQUE ITEM Torque Arm Mounting Fasteners 44 ft-lbs (60 N·m) 44 ft-lbs (60 N·m) Cross Shaft Fasteners Rear Torque Arm to Rear Pivot 33 ft-lbs (45 N·m) Fastener 44 ft-lbs (60 N·m) Idler Fastener 7 ft-lbs (10 N·m) Idler Bolt Block Fasteners Upper Shock Collar Set Screw 35 in-lbs (4 N·m)
  • Page 117 SPECIFICATION REAR SUSPENSION TORQUE ITEM FOX® 1.5 Zero LSC-R Rebound Jet 40 in-lbs (4 N·m) Check Valve FOX® 1.5 Zero LSC-R Tamper Proof 5 in-lbs (0.5 N·m) Air Valve Cap 22 ft-lbs (30 N·m) Timbersled IFP Shaft Nut CHASSIS TORQUE ITEM 44 ft-lbs (60 N·m) Sub Frame Mounting Fasteners...
  • Page 118 SPECIFICATION BRAKES TORQUE ITEM Fastener to be tightened until Master Cylinder Clamp Fasteners bottomed on clamp Master Cylinder Reservoir Cover 18 in-lbs (2 N·m) Fasteners INSTALL KIT TORQUE ITEM 22 ft-lbs (30 N·m) TSF Lower Strut Rod Fastener 22 ft-lbs (30 N·m) TSS Lower Shock Fastener Torque to OEM manufacturers Upper Shock Mounting Fastener...
  • Page 119: Warranty

    WARRANTY TIMBERSLED CONVERSION SYSTEMS LIM- ITED WARRANTY POLARIS Sales Inc., 2100 Highway 55, Medina, MN 55340 (POLARIS) gives a 12 MONTH LIMITED WARRANTY on all components of your TIMBERSLED Conversion System against defects in material or workmanship. This warranty covers parts and dealer labor charges for repair or replacement of defective parts and begins on the date of purchase by the original retail purchaser.
  • Page 120 WARRANTY WARRANTY COVERAGE AND EXCLUSIONS: LIMITATIONS OF WARRANTIES AND REMEDIES This TIMBERSLED limited warranty excludes any failures that are not caused by a defect in material or workmanship. THIS WARRANTY DOES NOT COVER CLAIMS OF DEFECTIVE DESIGN. This warranty also does not cover damage caused due to incorrect installation, acts of God, accidental damage, normal wear and tear, abuse or improper handling.
  • Page 121 MATERIALS, COMPONENTS, OR PRODUCTS. THE REMEDIES SET FORTH IN THIS WARRANTY ARE THE ONLY REMEDIES AVAILABLE TO ANY PERSON FOR BREACH OF THIS WARRANTY. POLARIS SHALL HAVE NO LIABILITY TO ANY PERSON FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY DESCRIPTION, WHETHER ARISING OUT OF EXPRESS OR IMPLIED WARRANTY OR ANY OTHER CONTRACT, NEGLIGENCE, OR OTHER TORT OR OTHERWISE.
  • Page 122: How To Obtain Warranty Service

    WARRANTY HOW TO OBTAIN WARRANTY SERVICE If your Conversion System requires warranty service, you must take it to a TIMBERSLED Servicing Dealer. When requesting warranty service you must present your copy of the Warranty Registration to the dealer. (THE COST OF TRANSPORTATION TO AND FROM THE DEALER IS YOUR RESPONSIBILITY).
  • Page 123: Exported Products

    If any of the above terms are void because of federal, state, local law, all other warranty terms will remain in effect. For questions call TIMBERSLED Customer Assistance: United States & Canada: 1-800-POLARIS (1-800-765-2747) French: 1–800–268–6334...
  • Page 125: Maintenance Log

    MAINTENANCE LOG MAINTENANCE LOG MAINTENANCE LOG Present this section of your manual to your dealer each time your snowmobile is serviced. This will provide you and future owners with an accurate log of maintenance and services performed on the snowmobile. MILES SERVICE PERFORMED / DATE...
  • Page 126 MAINTENANCE LOG SERVICE PERFORMED / DATE HOURS TECHNICIAN COMMENTS...
  • Page 127 INDEX 120 SX and 120 R Models ... 44 Tension Adjustment....70 Tension Measurement ..... 68 Driver Awareness ...... 15 Driving Downhill ......23 Driving in Hilly Terrain ....23 Accessories ......32 Driving on Slippery Surfaces ..22 Accessory Warning ....27 Driving Responsibly ....
  • Page 128 INDEX Maintenance Log..... 123 Maintenance Recommendations... 11 Safe Riding Gear ....... 12 Maneuverability......24 Safety Master Torque Table Hidden Obstructions....15 Timbersled ARO....113 Safety Gear......17 Timbersled RIOT ....110 Safety Symbols ......4 Matte Finish ......91 Signal Words ......4 Mountainous Terrain Riding ..
  • Page 129 INDEX Track Care ......91 Warranty.........117 Storage, Daily ......57 Welcome Page ......3 Survival Preparation....14 Windchill Charts ......25 Suspension Inspection, Pre-Ride ........ 51 Suspension Maintenance .... 62 Suspension mounting bolts ..51 Suspension Settings Spring Preload ....... 34 Timbersled ARO Models ..
  • Page 131 For your nearest Timbersled dealer, call 1-800-POLARIS (765-2747) or visit www.timbersled.com Polaris Industries Inc. 2100 Highway 55 Part No. 9940893 Rev 01 Medina, MN 55340 Printed in USA...
