TAIBM9382W0Y Chapter 1: Mainboard Appearance Diagram (The images in this manual are for reference only; some details may be adjusted based on actual design. Please refer to the physical product, and our company reserves the right to interpret.) 3 / 15...
Page 4
TAIBM9382W0Y Chapter 2: Mainboard Hardware Introduction 2.1. Precautions Before Installation The mainboard is composed of many precision integrated circuits and components, which may be damaged by strong static electricity. Please read this user manual carefully and prepare as follows before installation: 2.1.1 Before installation, please confirm that the chassis/case structure you are using is compatible with the mainboard.
Page 5
TAIBM9382W0Y Storage 2 One M.2 slot M2_SSD_A (near the CPU) supports 2280 NVME SSD (up to PCIE4.0 X4 lanes) M2_SSD_B (far from the CPU) supports 2280 SATA/NVME SSD (NVME up to PCIE3.0 X4 lanes SSD, SATA/NVME adaptive recognition) Four SATA3.0 interfaces Rear Ports: 2 USB 3.2 GEN1 (5Gbps) TYPE A Ports 2 USB 3.2 GEN2x1 (10Gbps) TYPE A Ports 2 USB 2.0 TYPE A Ports...
Page 6
TAIBM9382W0Y Chapter 3: Introduction to Rear Panel Interfaces : PS2 Interface Used for connecting PS2 devices, such as PS2 keyboards/PS2 mice. : USB2.0 TYPE A Interface Used for connectingUSB2.0 TYPE A devices, backward compatible with USB1.1 standard. : DP Interface Used for connecting DP display devices, supporting a maximum resolution of 4096x2160@60Hz.
Page 7
TAIBM9382W0Y G: USB3.2 GEN1 TYPE A port For connectingUSB TYPE A devices, with a maximum speed of USB3.2 GEN1 (5G), backward compatible with USB2.0/1.1 standards. H: USB3.2 GEN2x1 TYPE A port For connectingUSB TYPE A devices, with a maximum speed of USB3.2 GEN2x1 (10G), backward compatible with USB2.0/1.1 standards. I: Audio port For connecting audio output devices, such as headphones, speakers, and other external playback devices;...
Page 8
TAIBM9382W0Y Chapter 4: Introduction to Mainboard Pins and Jumpers 4.1, F_AUDIO Header The front audio header is used to connect front audio cables to support external audio devices, compliant with HD Audio specifications. Before installation, please confirm that the connector pin definitions match the header definitions, as improper installation may result in the device being unusable or damaged. Definition Definition Pin Number...
Page 9
TAIBM9382W0Y 4.3, F_PANEL ( Switch Control Indicator Pins) Used for connecting the power button, reset button, hard drive indicator light, and power indicator light. Definition Definition Pin Number Pin Number HDD-LED+ PWR-LED+ HDD-LED- PWR-LED- PWR_SW RESET NO PIN 4.4, CPU_FAN Pins Used to connect the CPU cooler fan wire, featuring smart fan control functionality (smart fan control also requires fan support).
Page 10
TAIBM9382W0Y 4.5, SATA Interface Used for connecting the hard disk SATA cable; the hard disk SATA cable can connect this socket to the hard disk data port to transfer data to the hard disk. Definition Pin Number 4.6, CLR_CMOS Jumper Short the jumper to restore the BIOS settings to their default state;...
Page 11
TAIBM9382W0Y 4.7, CASE_OPEN Jumper This function is disabled by default in the BIOS and must be manually enabled in the BIOS to work with the chassis alarm. When the jumper is open: CASE_OPEN function is disabled; when the motherboard is powered on and the chassis is opened, there will be no action from the motherboard. When the jumper is shorted: CASE_OPEN function is enabled;...
Page 12
TAIBM9382W0Y 4.9 ,SYS_FAN Header Used to connect the system cooling fan cable. The socket has a foolproof design; please pay attention to the orientation of the plug dur- ing installation to avoid damaging the motherboard and the fan. When installing into the chassis, please ensure that the airflow design of the case is reasonable to achieve optimal cooling performance, so as to avoid reduced processor performance due to poor heat dissipation.
Page 13
TAIBM9382W0Y 4.11, COM Header Used for connecting RS232 interface devices. Pin Number Definition Pin Number SOUT RI/PWR Definition 4.12, COM1_9P_SET/COM2_9P_SET Interface Used to set the function of the 9th pin of COM1/COM2 header, default is RI, can be switched to 12V/5V. Definition Pin Jumper Status 1-2 (default)
Page 14
TAIBM9382W0Y 4.13, GPIO Header GPIO header, can define the pins as Input/Output, default configuration is Output, high level. Pin Number GPI4 GPI3 GPI2 GPI1 Definition Pin Number GPO4 GPO3 GPO2 GPO1 Definition 4.14, MULTI_COM Pin Header RS485 and RS422 Combined Pin Header. Effective only after setting the COM1_SET/COM2_SET function. Pin Number 422- 422+...
Page 15
TAIBM9382W0Y 4.15, COM1_SET/COM2_SET Pin Header Used to switch between the functions of the COM1/COM2 and MULTI_COM1/MULTI_COM2 pin headers: Default jumper cap is on 1-2, supporting RS232, enabling COM1/COM2 functionality, with MULTI_COM1/MULTI_COM2 having no function; Switching jumper cap to 3-4, MULTI_COM1/MULTI_COM2 set to RS485, with COM1/COM2 having no function; Switching jumper cap to 5-6, MULTI_COM1/MULTI_COM2 set to RS422, with COM1/COM2 having no function.
