Kurzanleitung Einbau
Der OKIMAT ist für den Einbau in elektromotorisch verstellbare
Lattenroste vorgesehen, er wird einbaufertig geliefert.
Falls die Motoren sich nicht in Einbaulage befinden sollten, schließen Sie bitte den
Netzstecker an (bei Ausführung Netzfreischaltung dann die grüne Taste im Stecker für 1
Sek. drücken). Betätigen Sie die Abwärtstasten an ihrem Handschalter. Die Motoren
fahren in Einbaulage. Ziehen Sie jetzt aus Sicherheitsgründen den Netzstecker.
Legen Sie zur einfacheren Montage den Lattenrost auf den Rücken, damit der
Beschlag nach oben zeigt. Entfernen Sie die Seitenschieber
OKIMATEN fest auf die Hebel am Beschlag bis der OKIMAT in die vorgesehenen
Aufnahmen
einrastet.
Das aufgeprägte Rückensymbol
n
Kopfende des Lattenrostes zeigen!
Setzen Sie die Seitenschieber
Stecken Sie das Handschalterkabel ein
und führen Sie das Kabel durch die
j
Zugentlastung
. Legen Sie den Lattenrost in das Bettgestell und stecken Sie den
k
Netzstecker in die Steckdose.
Bei Ausführung mit Netzfreischaltung und Notabsenkung (siehe Sonderausstattung)
befindet sich im Netzstecker eine grüne Taste, die nach dem Einstecken 1 Sek. lang
gedrückt werden muß, damit der interne Energiespeicher aufladen kann. Danach bitte
Batterie anklemmen
.
l
Achtung: max. 5 Schaltzyklen pro min.
.Bei Ausführungen mit Infrarot oder
Funk lesen Sie bitte die spezielle Montageanleitung. Zur vollständigen
Inbetriebnahme lesen sie bitte die Montageanleitung.
Sonderausstattung
Netzfreischaltung
Die Netzfreischaltung schützt vor elektromagnetischen und elektrischen
Wechselfeldern. Im Netzstecker trennt ein 2-poliges Relais nach jeder
Handschalterbetätigung die Netzfreischaltung vom Hausnetz (hörbares Relaisklicken).
Der Antrieb ist dann völlig Netzspannungsfrei und das gesamte System verbraucht im
Ruhezustand keinen Netzstrom. Die Netzfreischaltung arbeitet mit allen
übergeordneten Netzfreischaltungen zusammen.
D
Short mounting instructions
The OKIMAT is intended to be mounted in electromotoric adjustable
slatted frames and is supplied ready for installation.
If the motors are not in the correct position for installation, connect the plug (if
supplied with mains isolation circuit, push green button for 1 sec.). Then push the
downwards buttons on the handset. The motors will move to the right position for
installation. Pull the connection plug for safety reasons.
For easier fitting put the slatted frame upside down so that the steel pipes point up.
, drücken Sie den
m
Remove the sliding covers
pipes snap in the U-shaped gap
muss in Richtung
o
OKIMAT points towards the head section of the slatted frame. Close the sliding
wieder auf.
m
covers again .
m
When the installation of the OKIMAT is complete, please check that the handset
cable is plugged in
frame into the bed and plug the connection plug into the socket.
Models with mains isolation circuit and auxiliary movement (see special equip-
ment) are fitted with a green button on the plug, which must be pushed for 1 sec.
after connection, to load the internal energy storage. Then attach the battery
Attention: max. 5 cycles per minute.
read the special mounting instruction. For complete comissioning please
read the mounting instruction.
Special equipment
Mains isolation circuit
Mains isolation protects against potential dangers resulting from electrical or
magnetic alternating fields since a 2-pool relay in the connection plug cuts
immediately off mains connection (audible click in the relay).
Now the actuator is completely isolated from the mains, and the complete system
does not use any current at rest. The mains isolation circuit works together
perfectly with all preceding mains isolation circuits.
.Push the OKIMAT firmly over the lever until the
m
. Make sure that the back symbol
on the
n
o
and pull it through the strain relief
. Now put the slatted
j
k
For versions with IR or RF please
GB
Instructions concises pour le montage
Le moteur OKIMAT est prévu pour le montage dans des sommiers à lattes
réglables par moteur électrique. Après la livraison, il est prêt à être installé.
Si les moteurs ne sont pas en position de montage, embrochez la fiche secteur (sur le
modèle à déconnexion du réseau, appuyer sur la touche verte dans la fiche pendant 1
seconde; voir la fig.w). Actionnez les touches de descente sur votre unité de télécommande.
Les moteurs vont en position d'installation. Pour des raisons de sécurité, débranchez
maintenant la fiche secteur.
Afin de faciliter le montage, retournez le sommier à lattes d'une manière que les tuyaux
d'acier soient dirigés vers le haut. Enlevez les couvercles à coulisses
OKIMAT rigidement sur le crochet, jusqu'à ce que les tuyaux soient bloqués dans les
encoches
. Le symbole
doit être dirigé vers le chevet du sommier à lattes. Remettez
n
o
les couvercles à coulisses
en place.
m
Enfichez le câble de l'unité de télécommande
soulagement de traction
Mettez le sommier dans le lit et embrochez la fiche secteur
k
.
dans la prise.
Sur le modèle avec déconnexion du réseau et fonction de descente auxiliaire (voir
Accessoires), la fiche secteur possède une touche verte. Après l'enfichage, celle-ci doit être
enfoncée pendant 1 seconde pour charger l'accumulateur d'énergie interne. Ensuite,
.
connecter la pile
l
l
.
Attention: max. 5 cycles de commutation par minute.
complète, lisez les notices de montage. Pour les modèles à récepteur infrarouge ou
radioélectrique, lisez les notices de montage correspondantes.
Accessoires
Déconnexion du réseau (en option)
La déconnexion du réseau garantit la protection contre les champs électromagnétiques et
électriques alternatifs. Lorsqu'on actionne l'unité de télécommande, un relais à 2 pôles dans
la fiche secteur assure la déconnexion du secteur (vous entendez le clic du relais).
Le moteur est alors complètement libre de tension. A l'état de repos, le système ne
consomme pas d'énergie. La fonction de déconnexion s'intègre parfaitement dans tous les
circuits supérieurs pour la déconnexion du réseau.
F
, poussez le moteur
m
et insérez le câble dans le dispositif de
j
Pour la mise en service
