Royale S13930 Bariatric Extra Wide User Manual

User Manual
Royale Medical Over Toilet Aid
S11187
SKU
Premium
Overall Width 68cm
Overall Depth 52cm
Seat Width 34cm
Width Between Arms 46cm
Seat Height 44-55cm
Armrest Height 22cm
Weight 4.8kg
Safe Work Load (SWL) 280kg
Independent Living Specialists
S13930
S11965
Bariatric
Bariatric
Extra Wide
70cm 85cm
48cm 49cm
37.5cm 61cm
56cm 65cm
44-59cm 44-56cm
25cm 25cm
5kg 5.3kg
280kg 305kg
1
Safety & Precautions
User Safety: It is recommended that the below safety checks are completed
prior to each use:
• All locking pins must be fully protruding.
• Adjusted to appropriate height for user.
• Legs are in a secure position with anti-slip rubber tips attached.
• Weight on chair does not exceed safe work load.
Weight Capacity: the maximum safety weight limit for the product is 250kg
(S11187), 280kg (S11965) or 305kg (S13930). If the maximum safety weight limit
is exceeded, this can increase the risk of damage to the product and/or risk
of serious injury to the user and others.
Instructions for Use
Product Assembly
1. Remove contents from packaging.
2. Clip the toilet seat and lid onto the frame.
3. Attach all four legs by sliding leg component into main frame receiver
until the locking pin is secured and protruding at the appropriate height
for the user
4. Ensure legs are stable and secure.
Adjusting the Height
1. Push locking pin in and slide internal leg up or down to the appropriate
height. Ensure all locking pins are fully protruding prior to use.
2. Please note that one leg has additional holes, to assist with stabilising
product on uneven floors.
Independent Living Specialists
Royale Medical Over Toilet Aid Manual
2
