Design and Specification Package:
To guarantee a safe and proper installation of PITT cooking, we kindly ask you forward this
document onto any trade professionals that may be involved in your project.
Thank you for considering PITT cooking.
PITT® cooking gas hobs are handmade in Holland, which are beautifully integrated directly
into your benchtop.
PITT® cooking are specialists in integrated cooking, our mission is to offer you the perfect
combination of functionality and design.
Please forward this document package onto your trade professionals listed below.
❏ Architect
❏ Designer
❏ Kitchen Company
❏ Builder
❏ Cabinet Maker
❏ Stonemason
❏ Gas Fitter/Installer (If not using the Handy Crew)
If there are any questions about the above information, please feel free to contact us.
pittcooking.info​ is a trade website for designers and installers, it's full of detailed instructions
Kind regards,
PITT cooking Australia
e: info@pittcooking.com.au
p: 07 3890 0577
w: www.pittcooking.com.au

Advertisement

loading
Need help?

Need help?

Do you have a question about the AZUMA and is the answer not in the manual?

Questions and answers

Related Manuals for PITT AZUMA

Summary of Contents for PITT AZUMA

  • Page 1 Design and Specification Package: To guarantee a safe and proper installation of PITT cooking, we kindly ask you forward this document onto any trade professionals that may be involved in your project. Thank you for considering PITT cooking. PITT® cooking gas hobs are handmade in Holland, which are beautifully integrated directly into your benchtop.
  • Page 2 We would like to summarise the most important points of interest: 1. Design of cabinetry Make sure that the module always can be accessed, in the case of service, the PITT® cooking module should always be able to be disassembled without disassembling the cabinets and/or kitchen benchtop.
  • Page 3 These documents contain instructions to securely and successfully install PITT cooking into ® kitchen benchtops. Furthermore, they indicate which level of craftsmanship is required. To make a warranty claim, installation procedures should be applied as described. PITT cooking ® is exclusively intended for consumer use.
  • Page 4 Contents 1. Benchtop materials suitable for PITT cooking ® 2. Manufacturing hole cut-outs 3. Manufacturing hole cut-outs | Solid Surface 4. Installation the kitchen benchtop 5. Installation PITT cooking in the kitchen benchtop ®...
  • Page 5 1. Benchtop material suitable for PITT cooking ® PITT cooking can safely be built into: ® • Compact board (eg. Trespa) • Solid Surface (eg. Corian, Hi-Macs, Staron) • Quartz composite (Caesarstone, Silestone, Quantum Quartz, Smartstone) • Concrete • Glass •...
  • Page 6 Manufacturing hole cut-outs for benchtop’s The guidelines of the kitchen manufacturer and/or the manufacturer of the kitchen benchtop should always be strictly followed. Fig. 1 The C-size for Top Side models should be at least 50 mm (fig.1). The distance between the cut out (Top Side and Front Side) and the sides (left or right) of the benchtop should be at least 150 mm.
  • Page 7 Manufacturing hole cut-outs Fig. 4 Fig. 5 The insides of the holes should be smooth and even (fig. 4). Irregularities can cause cracking (fig. 5). Facet 1x1 mm Fig. 6 On the top and bottom of the recess(es) should be a facet of at least 1x1 mm be applied (with exception for Solid Surface) (fig.
  • Page 8 Manufacturing hole cut-outs Fig. 9 The minimum clearance from a combustible surface shall be a 200 mm horizontal distance from the periphery of any gas burner (AS/NZS 5601.1). (fig. 9). If that horizontal clearance is less than 200 mm, that vertical surface must be protected by a non-combustible material for 150 mm above the cooktop surface across the entire length (depth, width).
  • Page 9 Fig. 11 Glue an extra Solid Surface plate at all times at the bottom of the benchtop. This plate should have the same measurements as the PITT cooking heat conductor, and the same thickness as the benchtop (fig. 10). A range of minimum R=3 mm should be applied on the top and bottom of the recess(es). By sanding it smooth afterwards, possible cracks can be prevented (fig.
  • Page 10 Manufacturing hole cut-outs | Solid Surface (eg. Corian, Sharon, Hi-Macs) Aluminum tape Thermo tape Aluminum tape Note! Tape may not be folded on edge of recess. Fig. 13 Heat conductor Apply aluminium tape and thermo tape in the recess(es), in this order: 1) aluminum tape 2) thermo tape 3) aluminum tape (fig.
  • Page 11 The cabinets should be placed perfectly levelled (fig. 14 and 15). Fig. 16 If there is a substrate under the benchtop the substrate should be cut to fit the PIT cooktop. The cutout should be the same size (+10 mm) as the PITT cooking module. This is to bring ®...
  • Page 12 Fig. 17 Fig. 18 The benchtop should have full support on the left, right, front and back side of the PITT cooking unit (fig. 17). This prevents tension in the benchtop from the weight of the cooking unit. We advise to support the benchtop with a ladder frame.
  • Page 13 FS = Front Side Fig. 16 Fig. 19 Fig. 20 The PITT cooking module should always be fully supported with the PITT cooking support ® ® set to prevent bending of the kitchen benchtop (fig. 19 and 20). Fig. 21...
  • Page 14 Made in Holland Installation instructions www.pittcooking.com IN2017-1-PC/EN...
  • Page 15 Installation instructions 1. Overview of components. 3. Overview of the set screws, divided 10. Do not separate the protective film 11. Gently shift the unit into a position 2. Gently push the sealing ring around 12. Firmly press down the control knobs in 3 groups that will be referred to later from the adhesive strip for the next where all gas tab pins are in the center of...

  • Page 16: Contents Of Package

    ATTENTION: FOR THE ® connection and the electricity block are freely accessible. POSITIONING, SEE STEP 4. 5. Push the beams firmly against the underside of the PITT ® 6. Push the beams firmly against the underside of the PITT ®...

  • Page 19: Maintenance Advice

    The open structure of the cast iron can cause soap residue to remain in the material, resulting in a dull appearance. PITT cooking Nederland | Web: www.pittcooking.com | Mail: info@pittcooking.com | Tel: +31(0) 88 088 70 70...
  • Page 20 Technisch document / Technical document Azuma dams Bovenaanzicht / View from top PITT cooking Nederland | Web: www.pittcooking.com | Mail: info@pittcooking.com | Tel: +31(0) 88 088 70 70 ®...
  • Page 21 Technisch document / Technical document Azuma dams Achteraanzicht / View from back PITT cooking Nederland | Web: www.pittcooking.com | Mail: info@pittcooking.com | Tel: +31(0) 88 088 70 70 ®...
  • Page 22 Technisch document / Technical document Azuma dams Zij-aanzicht / View from side PITT cooking Nederland | Web: www.pittcooking.com | Mail: info@pittcooking.com | Tel: +31(0) 88 088 70 70 ®...
  • Page 23 Technisch document / Technical document Azuma dams Gastoevoer / Gas inlet Elektrapunt / Electricity connector Vooraanzicht / View from front PITT cooking Nederland | Web: www.pittcooking.com | Mail: info@pittcooking.com | Tel: +31(0) 88 088 70 70 ®...
  • Page 24 Technisch document / Technical document Azuma dams Gatenpatroon / Hole pattern Gatenpatroon in DXF te downloaden via pittcooking.com Hole pattern in DXF can be downloaded via pittcooking.com PITT cooking Nederland | Web: www.pittcooking.com | Mail: info@pittcooking.com | Tel: +31(0) 88 088 70 70...
