- Page 1 NEON FLEX - NA1, NA2, NA3 73060 INSTALLATION GUIDE Horizontal/Vertical bendable weatherproof Neon Flex LED strip...
-
Page 2: Table Of Contents
Neon Flex – NA1, NA2, NA3 (73060_S6-S9) Visit the ENTTEC website for the latest version Contents Safety ............................................... 3 Electrical Safety ........................................3 System Planning and Specification ................................3 Protection from Injury During Installation ..............................3 Installation Safety and Guidelines ................................. 4 Physical Dimensions ........................................ -
Page 3: Safety
ENTTEC device. If you are in any doubt about system safety, or plan to install an ENTTEC device in a configuration not covered within this guide, contact ENTTEC or your ENTTEC supplier for assistance. -
Page 4: Installation Safety And Guidelines
Neon Flex – NA1, NA2, NA3 (73060_S6-S9) Visit the ENTTEC website for the latest version Installation Safety and Guidelines Always work with a plan of installation that respects all system limitations as defined within this guide and adheres to the safety information. -
Page 5: Physical Dimensions
Horizontal Vertical * Length tolerance: ±5% Connector Female Connector Male Connector Note: Connectors for ENTTEC Neon Flex variants S1–S5 and S6–S9 are not cross-compatible. Pin Out Neon Flex – NA1 Neon Flex – NA2 Neon Flex – NA3 Green White... -
Page 6: Wiring Application
Visit the ENTTEC website for the latest version Wiring Application ENTTEC offers various products to control Neon Flex, each designed for different use case scenarios and its ▪ control protocol. ▪ Wiring application for non-addressing single colour (NA1), Tuneable White (NA2), RGBW (NA3) by using ENTTEC... -
Page 7: Na1, Na2, Na3 Wiring Diagram
Neon Flex lighting. Depending on the channel needs, several non-addressable Neon Flex units can be linked to a single CVC4. ▪ For managing your non-addressable Neon Flex, connect multiple CVC4 units in a daisy chain to any ENTTEC DMX or PIXELATOR Series controllers. Visit the CVC4 page on enttec.com to explore versatile wiring options. -
Page 8: Voltage Drop
Power supply unit is not supplied with the product. ENTTEC recommend IP67 rated or higher power supplies ▪ where applicable to your installation requirement. If you are concerned about the voltage drop and the impact on your installation, contact the ENTTEC team or ▪ your reseller. - Page 9 ▪ Always use ENTTEC mounting accessories for mounting installation. Mounting accessories order information can be found at the end of the document and the product datasheet. Install the screw into position and make sure that the screw head is flush or recessed below the base of the ▪...
- Page 10 Neon Flex – NA1, NA2, NA3 (73060_S6-S9) Visit the ENTTEC website for the latest version ▪ Mounting accessories are available in different lengths to accommodate various installation needs. When cutting aluminium accessories, use appropriate tools while prioritising safety. Ensure that the cutting surface is neat and smooth to prevent any damage to the product's finish.
- Page 11 Neon Flex – NA1, NA2, NA3 (73060_S6-S9) Visit the ENTTEC website for the latest version Use an IP-rated waterproof junction box to mount the cable junction in outdoor applications for a hermetic ▪ enclosure and added protection. ▪ Each fixing option serves a specific purpose, but if there is any uncertainty, it is recommended to contact technical support for further assistance.
-
Page 12: Servicing, Inspection & Maintenance
Do not spray Neon Flex or accessories with a high-pressure water jet. ▪ To clean an ENTTEC Neon Flex system, use low-pressure compressed air to remove dust, dirt and loose particles. If deemed necessary, wipe the Neon Flex with a damp microfiber cloth. -
Page 13: Ordering Information
Ordering Information Neon Flex Product Neon Flex 73060 Please refer to the datasheet or contact the ENTTEC team to discuss your customisation needs. Neon Flex Accessories Mounting Accessories Aluminium Mounting Accessory Straight Linear 1000mm 73083 S6 &...
