Summary of Contents for RIX MHP
- Page 1 AIR DRIVEN HYDRAULIC PRESSURE INTENSIFIER PUMP HYDRO PUMP MHP Type Nominal ratio 1:5 1:10 1:24 1:50 1:75 1:100 1:150 1:200 CHP Type Nominal ratio 1:20 1:65 1:150 1:230 1:400 RIX CORPORATION...
- Page 2 AIR DRIVEN HYDRAULIC PRESSURE INTENSIFIER PUMP HYDRO PUMP Features Compressed air driven. Discharge pressure is adjustable. In a pressurized state for long hours the temperature A continuous reciprocating discharge function. of the fluid dose not rise. Kerosene, light oil and heavy oil is applicable. City water is applicable.
- Page 3 ( For ES, ESC and One-Shot Booster. ) 3. In the case of MHP , CHP&THP type, Indicates the maximum working pressure on the secondary side. In the case of AB&FB type, it indicates the discharge amount per shot. [cc/shot]...
- Page 4 CHP400 Double action [ Forward and backward discharge. ] Single action [ Forward only discharge. ] Discharge method MHP / CHP type The standard for the hydro pump discharge method is doble-acting. External mounting of ※the primary and secondary pistons are operated by an automatic switching valve built into the pump.
- Page 5 Accessories for HYDRO PUMP [ Option ] Device that can use each type of hydro pump is available as an option. If necessary, select each reference number from the table below and contact with the pump body. ( Not included in pump body coat. ) Primary pressure Secondary pressure Suction set...
-
Page 6: Examples Of Use
AIR DRIVEN HYDRAULIC PRESSURE INTENSIFIER PUMP HYDRO PUMP Examples of use Electric discharge machine Ultrapure water washing machine Hydraulic pump unit Outside Operation Valve Accumulator is unnecessary Nozzle Hydraulic Pump Cutter Laying (Manual Switching in discharge line. Main Body Pipes Valve) of Unit Line Filter... - Page 8 RIX CORPORATION Contact detail: International business Headquarters ・ The contents described in this catalog are subject to change 1-15-15, Sanno, Hakata-ku, Fukuoka city, Fukuoka, 811-8672, JAPAN TEL : 81-92-472-7311 FAX : 81-92-472-3399 and revision without notice for improvement. ・ Unauthorized conversion of the contents of the catalog is Manufactured by Production Headquarters prohibited.
