SAF Integra-W User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User manual
Integra-W
Integra-WS
VER 2.0
F W 3 . 22 . 15 (MU X)
F W 3 . 22 . 15 (E SW )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Integra-W and is the answer not in the manual?

Questions and answers

Related Manuals for SAF Integra-W

Summary of Contents for SAF Integra-W

  • Page 1 User manual Integra-W Integra-WS VER 2.0 F W 3 . 22 . 15 (MU X) F W 3 . 22 . 15 (E SW )

  • Page 2: Proprietary Notice

    If there is any conflict between this document and compliance statements, the latter will supersede this document. SAF Tehnika, JSC has no liability for typing errors in this document or damages of any kind that result from the use of this document.

  • Page 3: Table Of Contents

    Integra-W 24 GHz FCC & IC IDs ................7 Chapter 2: INSTALLATION ................... 8 Package contents ..................... 8 Integra-W FODU: assembling mounting bracket and installing with antenna on a pole ..........................8 Disassembled mounting bracket and tools required for assembly ....8 Changing polarization of Integra-W FODU and antenna .......
  • Page 4 Chapter 8: INTERFACES ................... 118 SFP port (LAN) ...................... 119 USB port ......................... 119 RSSI LED ........................ 120 Integra-WS RSSI LED description ............. 121 RSSI/audio port ..................... 123 Grounding connection ..................125 Appendix A: TECHNICAL SPECIFICATION ............. 126 ABBREVIATIONS ....................... 132 SAF Tehnika JSC...

  • Page 5: Chapter 1: Overview

    Labelling The label contains the following information (see samples in the picture below): Product model name (“SAF Integra-WS-18”). The FODU model name example is: SAF Integra-W-38 for Integra-W 38GHz FODU, SAF Integra-WS-18 for Integra-WS 18GHz FODU, etc. Product Number / Model Number (P/N or M/N) (D18WSR05LA): product/model number contains various information about the unit.

  • Page 6: Microwave Radiation

    Please note that frequency range is set from the central frequency of the first 40 MHz channel to the central frequency of the last 40 MHz channel (see the diagram below). The frequency range of subband A low side Integra-W 18 GHz FODU: Microwave Radiation...

  • Page 7: Integra-W 24 Ghz Fcc & Ic Ids

    Personen im Frequenzbereich von 30 kHz bis 300 GHz´; - ENV 50166-2, January 1995 (withdrew in December 1999 by CENELEC) ´Human Exposure to Electromagnetic Fields (10 kHz – 300 GHz)´. Integra-W 24 GHz FCC & IC IDs Integra-W 24 GHz: FCC ID: W9Z-INTEGRA24W...

  • Page 8: Chapter 2: Installation

    Installation manual D0DBSRM1 RJ-45 connector 8P shield solid FOACNR02 Installation manual D0DB2RM1 Integra-W FODU: assembling mounting bracket and installing with antenna on a pole Disassembled mounting bracket and tools required for assembly Parts of disassembled mounting bracket Parts of disassembled mounting bracket Three M8x1.25x16 hex flange bolts already attached to clamps for housing and pipe [5]...

  • Page 9: Changing Polarization Of Integra-W Fodu And Antenna

    12 Fixation plate 13 Side screw flange nuts 14 Grounding flange nut Numbers of the mounting bracket and Integra-W FODU parts in next sections will be mentioned in square brackets [ ]. Changing polarization of Integra-W FODU and antenna Tools required: 13mm (0.512”) wrench (comes in package) The default polarization for licensed frequency band radios is vertical.
  • Page 10 INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Remove Integra-W FODU with an antenna Using a 13mm wrench, remove indicated nuts from mounting bracket. and fixation plate [10, 11, 12, 13, 14]. Default polarization is vertical. Removed parts must be attached back with View of Integra-W FODU with swapped 90-degree offset (see above).

  • Page 11: Assembly Procedure

    INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Assembly procedure Tools required: 13mm (0.512”) wrench (comes in package) Attach vertical alignment eye screw [3] to clamps for housing and pipe [5] using hex flange bolt [8] and screw Using a 13mm wrench, slightly loosen three hex on one hex nut [7] and two hex flange nuts [6].
  • Page 12 20 N·m. Make sure that both horizontal and vertical Attach Integra-W FODU with the antenna to the alignment eye screws are turned to the mast mounting bracket so that side screws fit into grooves of before attaching Integra-W FODU.

  • Page 13: Antenna Alignment

    - the mounting bracket: left side screw on hex flange nuts and bolts of azimuth and Integra-W FODU and two hex flange bolts elevation eye screws, right side screw on between both mounting bracket clamps for Integra-W FODU and hex flange bolt on housing and pipe.

  • Page 14: Integra-Ws 15-42Ghz * Fodu: Attaching To The Antenna

    Integra-W FODU and two hex flange bolts right side screw on Integra-W FODU and hex between both mounting bracket clamps for flange bolt on azimuth angle indicator with housing and pipe with torsion 20..25 N·m.
  • Page 15 INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Put Integra-WS on antenna adapter flange by hooking half-turn loosened clamp at the top and leaving the completely loosened clamp at the bottom. Make sure O-ring is in place Using size 5 Allen wrench, loosen one clamp and the adapter flange fits into the Integra- completely and second clamp by a half-turn.
  • Page 16 INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Secure the position of the Integra-WS by fully tightening both fixation clamps. *Integra-WS 15/18/17/23/24/26/32/38/42GHz are separate FODU models It is recommended to protect the installed radio from direct sunlight. The default polarization for licensed frequency band radios is vertical.

  • Page 17: Integra-Ws 6-13Ghz * Fodu: Attaching To The Antenna

    INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Integra-WS 6-13GHz FODU: attaching to the antenna Integra-WS 6-13GHz* FODU features twisted polarization flange and resulting signal polarization is determined by Interface on antenna/OMT. To change signal polarization, please rotate only the antenna interface, as radio always remains in vertical position.
  • Page 18 INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Integra-WS 6-13GHz* FODU features twisted polarization flange resulting signal polarization is determined by Interface on antenna/OMT. To change signal polarization, Example of horizontal polarization interconnection. please rotate only the antenna interface, as radio always remains in vertical position.
  • Page 19 INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Use air level to verify that Integra-WS FODU is Final view of assembled Integra-WS 6-13GHz* 1+0 properly levelled. Tighten all four fixation setup. clamps properly. *Integra-WS 6U/6L/7/8/10/11/13 are separate FODU models If any further assistance is required, please contact techsupport@saftehnika.com...

  • Page 20: Integra-Ws 6-13Ghz* 2+0 & Omt Interconnection

    INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Integra-WS 6-13GHz* 2+0 & OMT interconnection Link aggregation 2+0 for Integra-WS is available only by using external equipment (switches)! Tools required: Size 5 Allen wrench, 240mm 10mm (0.394”) wrench (not supplied) 8mm (0.315”) wrench (not supplied) Level (not supplied) It is recommended to perform steps 1-2 on the ground.
  • Page 21 INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Tighten all 4 Integra fixation clamps on both Final view of assembled Integra-WS 6-13GHz* 2+0 FODUs. When properly attached there’s a gap setup. between FODUs, OMT and antenna. *Integra-WS 6U/6L/7/8/10/11/13 are separate FODU models For connecting Integra-WS 15-42GHz to an OMT, please...

  • Page 22: Connecting Fo Interface Using Fiber Conduit Kit

    SFP module. Disassemble conduit kit and put its parts in the Push FO cable from LC connector side through the following sequence (left – Integra-W direction, conduit. right – CPE direction). Tighten parts on both ends of the conduit. Fasten Connect LC connector to SFP module.

  • Page 23: Integra-Ws 6-13Ghz* Remote Mount Kit Assembly

    INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Integra-WS 6-13GHz* remote mount kit assembly Tools required: Size 5 Allen wrench 13mm (0.512”) wrench (not supplied) Assemble mounting bracket using 13mm wrench: Attach waveguide transition flange to the mounting Screw on one hex flange nut [4] on each of four bracket using size 5 Allen wrench: threaded rods [3].

  • Page 24: Integra-Ws 15-42Ghz* Remote Mount Kit Assembly

    INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Integra-WS 15-42GHz* remote mount kit assembly Tools required: Size 5 Allen wrench 13mm (0.512”) wrench (not supplied) Assemble Mounting Bracket using 13mm wrench: Attach Waveguide transition flange to the mounting Screw on one hex flange nut [4] on each of four bracket using Size 5 Allen wrench: threaded rods [3].

  • Page 25: Initial Setup In Indoor Environment

    INTEGRA-W/INTEGRA-WS User Manual INSTALLATION Initial setup in indoor environment Integra-WS FODUs can be interconnected using a test kit (available for purchase as optional accessory). P/N is DxxTST01, where xx – frequency band, e.g., D11TST01 for 11GHz. The exception is 17 and 24GHz radios.

  • Page 26: Chapter 3: Web Gui

    Chapter 3: WEB GUI Initial configuration Powering Integra-W/Integra-WS FODU and connecting to PC Use Power over Ethernet (PoE) injector P/N I0ATPI43 with an appropriate power supply (10…57V DC). Please see the interconnection scheme below. Use 5-10A rated type B circuit breaker in the chain between the power supply and the PoE injector for isolating each radio powered by the same PSU in case of a surge.
  • Page 27 INTEGRA-W/INTEGRA-WS User Manual WEB GUI The front panel has 3 indication LEDs. LED3 indicates the position of DIP switch S2: PoE enabled and supplied to DATA+POWER port Output voltage is equal to input voltage Input voltage is within the range of 22-57V...

  • Page 28: System Requirements

    -10ºC to +50ºC Mounting With bracket (included) 19” rack mounting shelf (P/N I0KTPI11.003) DIN-rail clip (P/N I0STPI11.001) System requirements To access Integra-W/Integra-WS Web GUI you will need a PC with the following Web browser: • Google Chrome. • Mozilla Firefox. •...

  • Page 29: Ethernet Management Connection

    CLI interfaces (serial, SSH, Telnet). Depending on the P/N Integra-W/Integra-WS may come pre-installed with in-band management or out-band management. In case of out-band management option management access will be available only on dedicated management port (labelled “MM”).

  • Page 30: Accessing Web Gui

    Traffic and management cable installation for out-band Integra-W/Integra-WS is show below. User data PoE (LAN port) Management Accessing Web GUI Launch your browser and in address field enter Integra-W/Integra-WS FODU IP address. Default IP addresses are as follows: • 192.168.205.10 for low side Integra-W/Integra-WS FODU (P/N D*******L*) •...

  • Page 31: Main Page

    Main page After login you will be automatically redirected to the Main page of Web GUI: Web GUI is divided into 5 sections: Top panel Shows information about Integra-W/Integra-WS FODU you are connected to including: • Model name • System name •...
  • Page 32 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Menu panel Allows navigating between Main page (“Main”) and subpages of 4 sections: • Over the air (Radio/modem (NP) configuration) • Networking (Ethernet configuration) • Performance • System 3 Main Web GUI window By default, Main page (“Main”) is shown. Contents will change according to menu panel selection.

  • Page 33: Modifying Basic System Parameters

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Modifying basic system parameters In order to proceed with initial configuration, press MODIFY button and entry fields will appear for adjustable values: Tx power The available range depends on the radio model and selected modulation. The actual range will be indicated in the brackets.
  • Page 34 By pressing changes made to the corresponding section apply only to „Rollback on” the local side Integra-W/Integra-WS. If is selected, the configuration will be reverted in case erroneous configuration changes are applied. Rollback triggers when configuration changes applied interrupt management connectivity.

  • Page 35: Parameters On Main Page

    When the license expires, modulation will drop to “4QAM Limited”, link capacity will drop to 256 Kbps, and you will see a warning. Radio side – shows the radio side of the local and remote Integra-W. Tx mute – Tx shows if the transmitter is currently muted (“Enabled”) or active (“Disabled”).

  • Page 36: Over The Air

    The Radio configuration page is available in the menu (Over The Air → Radio → Configuration). Refer to the chapter Radio configuration – extra fields for description of the extra fields of the 17/24 GHz Integra-W/Integra-WS FODUs. Status mode Press button.
  • Page 37 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Modify mode Tx power – Indicates current Tx (transmit) power value (status mode); allows specifying Tx power value (modify mode). Available range depends on radio model and selected modulation. Actual range will be indicated in the brackets.
  • Page 38 – Indicates minimum and maximum Rx level of remote side Integra-W/Integra-WS for ATPC operation (status mode); allows defining the minimum and maximum Rx level of remote side Integra-W/Integra-WS (modify mode). There should be at least 3dB difference between min and max values.

  • Page 39: Networking

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI radio rssi-led {disable|enable Use to enable or disable RSSI LED operation. [mode {1|2|3}]} Use to enable the red RSSI LED's operation for n seconds. radio rssi-led enable mode Its main purpose is indication of polarization alignment {1|2|3} polarization <seconds>...

  • Page 40: Networking → Ethernet → Link State Propagation

    (up to 9600B) is enabled. When disabled, maximum supported frame size is 1522B. „Execute configuration” 3) By pressing changes made to the corresponding section apply only to the local side Integra-W/Integra-WS. CLI commands (Chapter 4: COMMAND LINE INTERFACE) network port set LAN jumbo...
  • Page 41 „Execute configuration” 8) By pressing changes made to the corresponding section apply „Rollback on” only to the local side Integra-W/Integra-WS. If is selected, the configuration will be reverted in case erroneous configuration changes are applied. CLI commands (Chapter 4: COMMAND LINE...

  • Page 42: Networking → Ethernet → Port Status And Configuration

    SFP module used. „Execute configuration” 7) By pressing changes made to the corresponding section apply „Rollback on” only to the local side Integra-W/Integra-WS. If is selected, the configuration will be reverted in case erroneous configuration changes are applied. SAF Tehnika JSC...

  • Page 43: Performance

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI CLI commands (Chapter 4: COMMAND LINE INTERFACE) network port show info Use to show the status of all ports. network port show config Use to show the configuration of all ports. network port set <port> admin- Use to enable or disable particular port.
  • Page 44 INTEGRA-W/INTEGRA-WS User Manual WEB GUI You also have fast access to alarm filtering, where it is possible to choose which alarm groups you are willing to filter out of all log entries. Status mode Press button. SAF Tehnika JSC...
  • Page 45 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Modify mode Clear alarm log – deletes all alarm log entries. Toggle period selection – opens/closes period selection controls: Load the latest data – refreshes alarm log and shows last 20 log entries. 4) List of alarm log entries – entry number, date and time, source node, status and event name.

  • Page 46: Performance → Alarm → Sensor Configuration

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI log event show module {alarm_only| Use to show entries for a specific module. iman| modem| ns| psu| radio| system} Regarding subcommands “last” and “time” refer to [last <#_of_entries>] [time <starttime> commands above. [<endtime]] log event clear Use to clear alarm log.
  • Page 47 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. Modify mode Group description (name) – Shows 5 groups of sensors divided by different group data destinations (event; perf; snmp), as well as indicates whether group is enabled (state); Ungrouped sensor list –...
  • Page 48 Set all to default – Restores default settings for all groups and sensors. „Execute configuration”, 6) By pressing changes made to the corresponding section apply only to the local side Integra-W/Integra-WS. CLI commands (Chapter 4: COMMAND LINE INTERFACE) log group info Use to show sensor group configuration.

  • Page 49: Performance → Alarm → Alarm Threshold Configuration

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Performance → Alarm → Alarm threshold configuration The page provides a summary of parameters’ alarm thresholds. All thresholds are predefined and some change dynamically according to system configuration. Thresholds can be modified if required. Alarm activates when current value exceeds (low-delta) or (high+delta) values. Alarm deactivates when current value exceeds (low+delta) or (high-delta) values.
  • Page 50 Default value – deselect to activate manual threshold modification. „Execute configuration” 4) By pressing changes made to the corresponding section apply only to the local side Integra-W/Integra-WS. CLI commands (Chapter 4: COMMAND LINE INTERFACE) log sensor info Use to show the configuration of sensor thresholds.

  • Page 51: Performance → Monitoring → Performance Graph

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI log sensor list Use to list all available sensors. Performance → Monitoring → Performance graph Performance graph allows visualizing various parameters over a chosen time period as curves. Available parameters will depend on the Performance → Alarm → Sensor configuration.
  • Page 52 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Left axis sensor – Allows choosing sensor parameter colored in red and displayed on the left axis. Right axis sensor – Allows choosing sensor parameter colored in blue and displayed on the right axis. Sensor log step –...

  • Page 53: Performance → Monitoring → Performance Log

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Performance → Monitoring → Performance log MODIFY button is deactivated in Performance log page. Select sensors – Allows choosing sensor parameters to be displayed in performance log. Select fields – Allows choosing parameter fields to be displayed in performance log.

  • Page 54: Performance → Ethernet → Ethernet Switch Statistics

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Download XML – Press to download performance log in an extensible markup language (.xml) file. CLI commands (Chapter 4: COMMAND LINE INTERFACE) perf show Use to show a specified number of last performance log {1M|15M|60M} last entries with specified sensor log step.
  • Page 55 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode (out-band management FW version – 3.xx.x-mux) SAF Tehnika JSC...
  • Page 56 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Press button. Modify mode (buttons appear at the bottom of the page) Statistics for – time during which statistics have been gathered. Rx detected – The total number of packets detected on port’s ingress. Rx dropped –...
  • Page 57 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Rx Multicast frames – The total number of good packets received that were directed to a multicast address. Note that this number does not include packets directed to the broadcast address. Rx Control frames – The total number of frames received as control frames.
  • Page 58 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode (in-band management FW version – 3.xx.x-esw) Press button. Modify mode (buttons appear at the bottom of the page) Statistics for – time during which statistics have been gathered. Tx detected – The total number of packets detected on port’s egress.
  • Page 59 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Rx Pause frames – The total number of frames received as control frames with valid PAUSE opcodes. Tx Good frames – The number of frames that have been transmitted by this port from its segment excluding fragmented and FCS error frames.

  • Page 60: Performance → Over The Air → Modem Performance

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Performance → Over The Air → Modem performance The Modem performance section shows modem statistics according to ITU-T G.826. Status mode Press button. Modify mode (buttons appear at the bottom of the page) Count time –...

  • Page 61: Performance → Over The Air → Modem Graph

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Performance → Over The Air → Modem graph MODIFY button is deactivated in the Modem graph page. The Modem graph can be activated in two modes – “constellation diagram” and “spectrum”. Graph type – Allows choosing between “constellation” and “spectrum” graph types.
  • Page 62 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Constellation diagram A constellation diagram is a representation of a signal modulated by the digital modulation schemes 1024QAM, 512QAM, 256QAM, 128QAM, 64QAM, 32QAM, 16QAM, 8QAM or 4QAM. It displays the signal as a two-dimensional scatter diagram in the complex plane at symbol sampling instants.
  • Page 63 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Examples of Integra-W/Integra-WS constellation diagrams under ideal conditions are shown below: For the purpose of analyzing the received signal quality, some types of corruption are evident in the constellation diagram. For example: 1) Gaussian noise is displayed as fuzzy constellation points:...
  • Page 64 INTEGRA-W/INTEGRA-WS User Manual WEB GUI 2) Non-coherent single frequency interference is displayed as circular constellation points: 3) Phase noise is displayed as rotationally spreading constellation points: Spectrum A spectrum curve is a representation received signal on the input of the modem. For this reason, spectrum signal levels will not correspond to actual radio receiver’s signal level.
  • Page 65 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Spectrum: (80MHz): Examples of Integra-W/Integra-WS spectrum curves in various channel bandwidths: SAF Tehnika JSC...

  • Page 66: System

    – Reboots Integra-W/Integra-WS (cold restart). Delete – Deletes selected firmware file from the list. Choose File – Press to browse for a firmware file on your hard disk drive. Upload – Press to upload a firmware file to Integra-W/Integra-WS. SAF Tehnika JSC...
  • Page 67 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Integra series firmware upgrade via Web GUI Firmware update package contains firmware file (.bin extension), release notes and firmware upgrade instructions. Latest Integra firmware update package can be downloaded at the following URL: https://www.saftehnika.com/en/downloads (registration required).
  • Page 68 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Upgrading from in-band management (3.xx.x-esw) to out-band management (3.xx.x-mux) firmware version Follow instructions in the section Integra series firmware upgrade via Web GUI. Management will be available only on dedicated management (MM) port, thus in order...

  • Page 69: System → Configuration → Ip Configuration

    (status mode); allows specifying IP address of Integra-W/Integra-WS you are currently logged in (modify mode). Default IP address is 192.168.205.10 or 192.168.205.11 – depending on which side the specific Integra-W/Integra-WS is – low side has 192.168.205.10 IP address and high side – 192.168.205.11.

  • Page 70: System → Configuration → Snmp Configuration

    The SNMP configuration pages provide configuration of SNMP communities, host and trap addresses. SAF NMS system will work only when SNMP is properly configured. Relevant MIB files can be downloaded directly from Integra-W/Integra-WS Web GUI. See (7) below. SAF Tehnika JSC...
  • Page 71 INTEGRA-W/INTEGRA-WS User Manual WEB GUI SNMPv1/v2c setup Status mode Press button. Modify mode Read community – Indicates currently specified read community for SNMPv1/v2c (status mode); allows specifying read community for SNMPv1/v2c of the agent to enable parameters to be read (modify mode). The default read community name is “saf-public”.
  • Page 72 – Shows a list of configured SNMPv1 trap IP addresses (status mode); allows adding/deleting SNMPv1 trap IP addresses (modify mode). The Integra-W/Integra-WS management controller sends SNMPv1 traps to the Trap Manager with the IP address specified here. List of trap v2c managers –...
  • Page 73 Integra-W/Integra-WS. SNMPv3 security settings – Shows SNMPv3 security settings used. Download MIB file – Click to download Integra-W/Integra-WS MIB files. CLI commands (Chapter 4: COMMAND LINE INTERFACE) snmp...

  • Page 74: System → Configuration → Configuration File

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI snmp syscontact <syscontact> Use to show/set system contact. snmp traps trap-community {set | del} Use to show/set/delete trap community name. <trap-community> snmp traps trapv1manager {add | Use to show/add/delete v1 trap manager IP address. delete} <trapv1manager>...
  • Page 75 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. Modify mode Download – Press to download saved system configuration txt file and store it on your hard drive. SAF Tehnika JSC...

  • Page 76: System → Configuration → Users Configuration

    – Press to browse for a previously saved configuration file on your hard disk drive. Cfg import – Press to upload a configuration file to Integra-W/Integra-WS. Uploaded configuration overwrites the saved configuration. Cfg restore – Press to restore saved system configuration, i.e., unsaved changes will be discarded! Restoring configuration overwrites running configuration with the saved configuration.
  • Page 77 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. Modify mode Users – Shows the list of available users (Username), full name (if specified), permissions, and whether the user is active (enabled). SAF Tehnika JSC...

  • Page 78: System → Configuration → System Configuration

    – Uncheck to display the entered password in plaintext. „Execute configuration”, 10) By pressing changes made to the corresponding section apply only to the local side Integra-W/Integra-WS. By default, the password for the “admin” account is ‘ changeme ’, while no password is defined for the “guest”...
  • Page 79 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. SAF Tehnika JSC...
  • Page 80 Modify mode System name – Allows entering a preferable system name. The maximum length of the system name cannot exceed 32 symbols. The default name is ‘SAF’. Location name – Allows entering preferable system location name. The maximum length of the location name cannot exceed 64 symbols. By default, the system location is not specified.

  • Page 81: System → Configuration → System Services

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI system discovery refresh Use to refresh device surroundings Use to perform remote discovery using specified system discovery remote <dst> <bcast> IP address and broadcast IP address Use to resolve a domain using configured DNS system dns dig <domain name>...
  • Page 82 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. Modify mode HTTP – allows disabling or enabling HTTP access to Web GUI. By default HTTP access is enabled. HTTP port – allows specifying TCP port for Web GUI access via HTTP. By default, TCP port 80 is defined.
  • Page 83 Telnet service on the device. Telnet port - allows selecting a port number for Telnet service. Reboot – allows rebooting the Integra-W/Integra-WS device (cold restart). 20) By pressing „Execute configuration” changes made in this section will be applied to the local side Integra device.

  • Page 84: System → Configuration → Syslog

    <secret> than 33 characters long). system radius status Use to show RADIUS configuration status. System → Configuration → Syslog Integra-W/Integra-WS supports the Syslog standard for system management message logging and sending to a monitoring Syslog server. SAF Tehnika JSC...
  • Page 85 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. Modify mode Syslog service – allows enabling or disabling Syslog service on the device. Facility code – allows selecting facility code for the Syslog messages from the device. Messages with different facility codes may be handled differently on the Syslog server.
  • Page 86 – allows configuring port that the device should use for Syslog message sending. „Execute configuration”, By pressing changes made to the corresponding section apply only to the local side Integra-W/Integra-WS. CLI commands (Chapter 4: COMMAND LINE INTERFACE) log syslog cfg...

  • Page 87: System → Diagnostic → Loopback Configuration

    (modify mode). During modem loopback, the signal is looped back to local end after the modem and Integra-W/Integra-WS should be able to synchronize to itself. Both Signal Quality and FEC load should not generate an alarm (values should not be colored in red).

  • Page 88: System → Diagnostic → Download Troubleshooting File

    By navigating to the “Download troubleshooting file” a “.tar.gz” archive containing various troubleshooting data files will be automatically generated and downloaded to your PC. When contacting SAF technical support team (techsupport@saftehnika.com) regarding troubleshooting issues, please provide the troubleshooting file. SAF Tehnika JSC...

  • Page 89: System → Tools → License Management

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI Clicking on the link will download troubleshooting file archive package to your hard disk drive (“Downloads” folder of your browser). File contents: conf Subfolder with last configuration files. config.txt Saved system configuration file. constell.bmp Snapshot of modem constellation graph.
  • Page 90 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Status mode Press button. SAF Tehnika JSC...
  • Page 91 – Press to browse for a license file (*.lic) on your hard disk drive. Upload – Press to upload a license file (*.lic) to Integra-W/Integra-WS. 6) Details of the selected license. If new license supports previously running modem configuration, no changes will be applied.

  • Page 92: System → Tools → License Management, Steps On Adding And Activating A New License

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI System → Tools → License management, steps on adding and activating a new license For activating a license, please follow these steps: 1) Open License management page in Web GUI System → Tools → License management.
  • Page 93 INTEGRA-W/INTEGRA-WS User Manual WEB GUI Use syntax “<command> ?” to see information on subcommands. Use  ENTER key to execute entered command. List of valid CLI commands can be found at the end of each Web GUI page description. Refer to...

  • Page 94: System → About → About System

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI System → About → About System Provides a short description of Integra-W/Integra-WS series products. CLI commands (Chapter 4: COMMAND LINE INTERFACE) product info Use to show detailed information on Integra-W / Integra-WS FODU. system number Use to show Integra-W / Integra-WS serial number.

  • Page 95: System → About → Inventory

    INTEGRA-W/INTEGRA-WS User Manual WEB GUI System → About → Inventory Displays inventory information. SAF Tehnika JSC...

  • Page 96: Chapter 4: Command Line Interface

    (System → Tools → Console) those shortcuts will not work. Connecting to serial RS232 interface In order to connect to Integra-W/Integra-WS serial terminal, you will require USB cable with USB Type B connector. Please refer to Chapter USB port for pinouts.
  • Page 97 3) Enter username and password. Default credentials are as follows: • login: admin • password: changeme 4) After successful login “SAF>” prompt should appear (prompt will differ if system name is not the default one): 5) Press “Ctrl+C” to log off from the current session. PuTTY Closing window without “Ctrl+C”...

  • Page 98: Connecting To Ssh

    ). After successful login following prompt should appear: 3) Enter username and password. Default credentials are as follows: • login: admin • password: changeme 4) After successful login “SAF>” prompt should appear (prompt will differ if system name is not the default one): SAF Tehnika JSC...

  • Page 99: Connecting To Telnet

    Press “Open” to connect. After successful connection following prompt should appear: Enter username and password. Default credentials are as follows: • login: admin • password: changeme After successful login “SAF>” prompt should appear (prompt will differ if system name is not the default one): SAF Tehnika JSC...

  • Page 100: Chapter 5: 17/24Ghz

    INTEGRA-W/INTEGRA-WS User Manual 17/24GHz Chapter 5: 17/24GHz Polarization Considerations Polarizations at both ends of the link must be opposite for 17/24 GHz Integra-W/Integra-WS FODUs. For example: If High side radio is installed in Vertical then Low side radio must be installed in...

  • Page 101: Setting Bandwidth To 80Mhz

    Configuration. Unavailable channel bandwidths (100 and 112MHz) will not be selectable due to “Disabled by duplex shift”, maximum allowed channel bandwidth for Integra-W/-WS 17/24GHz radio units – 80MHz. 1) Access the Web GUI. Configure the Tx frequency to 17140MHz (17GHz) or 24090MHz (24GHz) if it is low side unit or to 17260MHz (17GHz) or 24210MHz (24GHz) if it is high side unit.

  • Page 102: Chapter 6: Functional Description

    FUNCTIONAL DESCRIPTION Information about built-in cooling fans Integra-W/Integra-WS 6-13GHz FODU have two class IP68 built-in cooling fans. The operation and monitoring of the cooling fans are automatically managed by the device software and users cannot control or intervene with their operation, for example, turn on or turn off any of them.

  • Page 103: Acm (Adaptive Coding And Modulation)

    INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION State event output – shows whether fan status indication is recorded in the event log of the device. fan_available – shows whether the device can detect installed fans. time_on – shows the time in seconds for how long fans will turn on in case of the device reboot, power-on, or 24-hour self-check.
  • Page 104 INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION the required availability based on the priority. As a result, high-priority services such as voice enjoy 99.995% availability, while low-priority services like video streaming are allocated lower priorities. Use of QoS prioritizing defines which services should be transmitted under any link condition and which services should be adapted whenever the link condition is degraded, and the link payload is decreased.
  • Page 105 INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION Signal quality values for ACM downshift and upshift can be found in the table below: 40 MHz 50 MHz 56 MHz 60 MHz 80 MHz 100 MHz 112 MHz 8QAM-->4QAM 74.6 74.6 74.6 74.6 74.6 70.7...

  • Page 106: Atpc (Automatic Transmit Power Control)

    INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION In comparison system using 1024QAM without ACM and providing similar capacity would offer only 99.964% of availability. You would have to decrease the distance, decrease modulation or increase antenna sizes to achieve 99.999% availability for the given link.

  • Page 107: Ftp Directory

    Use CLI command system service ftp enable to activate FTP directory function. After system service ftp is enabled it is possible to connect to Integra-W/Integra-WS by using your favorite FTP client. Username is anonymous and password is empty.

  • Page 108: Firmware Upgrade Management With Snmp

    3) Transfer the required firmware file (“bin” file inside the FW package archive) to the "firmware" folder in the FTP directory (for more information, refer to chapter directory). Use the following FTP address: ftp://anonymous@DEVICE_IP:/firmware/ DEVICE_IP (where should be substituted with the IP address of Integra-W/Integra-WS). 4) Initiate upload transferred firmware file setting integraWsystemServicesFwUpload variable to “1”.
  • Page 109 INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION firmware should be seen in integraWsystemServicesFwAvailView list (see the next step) and available for installation. 5) View information about the firmware versions already available for installation by reading integraWsystemServicesFwAvailView variable: you will get a string containing index numbers and names of all firmware versions available for installation (n1: candfw1;...

  • Page 110: Radius Authentication

    INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION RADIUS authentication Configuration of the RADIUS server authentication Always check your RADIUS server documentation before modifying the RADIUS configuration. RADIUS vendor ID for Integra equipment is 7571. The configuration of the FreeRADIUS software based on the Linux system (Ubuntu) is given below as an example.

  • Page 111: Assigning Administrator Rights To A Radius User

    INTEGRA-W/INTEGRA-WS User Manual FUNCTIONAL DESCRIPTION 5) Execute a configuration, save the configuration changes and reboot Integra. 6) Log in to Integra using the secure HTTPS connection. Proceed to assigning administrative rights to a user if needed, see next chapter Assigning administrator rights to a RADIUS user.

  • Page 112: Chapter 7: Tools

    The Link Layer Discovery Tool is a command line application for MS Windows. It sends requests to LLD server application which runs on all Integra series devices. The tool is used to discover Integra-W/Integra-WS devices and reset their passwords or settings.
  • Page 113 INTEGRA-W/INTEGRA-WS User Manual TOOLS Available commands and network adapter list should be shown. To scan for Integra devices, the command should be run as follows: lld <network interface> For example: lld \DEVICE\NPF_{A67EA6B7-1686-4E98-BA19-2A7E5B205DCF} To copy the interface address from the network adapter list, click the right mouse button over the console and select “Mark”:...
  • Page 114 INTEGRA-W/INTEGRA-WS User Manual TOOLS Then by holding the left button select the interface address: After selecting, release the left button and click the mouse right button anywhere on the console. The address should be copied. Type “lld“ and paste the address by clicking the right button anywhere on the console:...
  • Page 115 INTEGRA-W/INTEGRA-WS User Manual TOOLS The result should be similar as in the image below: Press ENTER and the recovery tool will now scan for Integra devices. Available devices and their information will appear in the console. Make sure that the device has finished booting up.
  • Page 116 INTEGRA-W/INTEGRA-WS User Manual TOOLS Different reset options are available depending on the reset requirement. Reboot and store options are also available. Store option saves the device current configuration so it will be restored after system reboot. The commands are available in the reset command list.

  • Page 117: Mib Files

    INTEGRA-W/INTEGRA-WS User Manual TOOLS MIB files Relevant MIB files can be downloaded directly from Integra-W/Integra-WS Web GUI. See Chapter “System → Configuration → SNMP configuration” for further details. SAF Tehnika JSC...

  • Page 118: Chapter 8: Interfaces

    PoE power polarity can be reversed. In case an Ethernet cable is used for power & data (with PoE injector), the combined Ethernet cable length from the PoE injector to Integra-W/Integra-WS FODU and from the PoE injector to CPE is limited to 100m / 328ft.

  • Page 119: Sfp Port (Lan)

    1000BASE-SX, 1000BASE-LX, 1000Base-T (note: 1000FDX only). Inquire SAF representative about compatible SFP modules. In the case of third-party modules, inquire SAF representative about the testing possibility. USB port USB port provides serial terminal access to CLI. The socket is B type.

  • Page 120: Rssi Led

    INTEGRA-W/INTEGRA-WS User Manual INTERFACES RSSI LED RSSI LED can be activated in three operational modes – Mode 1, Mode 2, and Mode 3. By default, RSSI LED is enabled in Mode 1. For further details please refer to the Over The Air →...

  • Page 121: Integra-Ws Rssi Led Description

    INTEGRA-W/INTEGRA-WS User Manual INTERFACES Integra-WS RSSI LED description The 15-42 GHz Integra-WS FODUs have a dual-color RSSI LED. The RSSI LED can blink either in green or red color. The blinking pattern is as given in the figure above and is the same for both colors.
  • Page 122 INTEGRA-W/INTEGRA-WS User Manual INTERFACES 4) If the FODU will be installed with its interfaces upwards. 5) If the FODU will be placed on any surface horizontally. Note that 17&24 GHz Integra-WS FODUs must be installed in opposite polarizations. SAF Tehnika JSC...

  • Page 123: Rssi/Audio Port

    The following charts and tables show the typical relationship of the received signal level (Rx level) displayed by Integra-W/Integra-WS vs. RSSI port output voltage (RSSI – Received Signal Strength Indicator) and audio frequency. The RSSI port is located on FODU. The evaluated Rx level has an error of +/-2 dB.
  • Page 124 INTEGRA-W/INTEGRA-WS User Manual INTERFACES Output voltage Rx level RSSI (dBm) voltage (V) Audio Output audio frequency level frequency (dBm (Hz) -100 1000 SAF Tehnika JSC...

  • Page 125: Grounding Connection

    INTEGRA-W/INTEGRA-WS User Manual INTERFACES Grounding connection Always provide a good connection from the FODU grounding screw to the tower/mast/building grounding circuit or body. You must choose one, the most convenient, of 2 screws for grounding connection. SAF Tehnika JSC...

  • Page 126: Appendix A: Technical Specification

    36 … 60 V DC all Integra models; 22...60 V DC models with ≤50 W consumption Temperature range -33 ... +55 °C / -28 … +130 °F Voltage range using I0ATPI24 Power over Ethernet Injector * Inquire SAF representative for more information SAF Tehnika JSC...
  • Page 127 INTEGRA-W/INTEGRA-WS User Manual TECHNICAL SPECIFICATION Mechanical & environmental specification Antenna type External antenna (default) 0.3m / 1ft, integrated 0.6m / 2ft, integrated Integrated antenna, factory assembled with SAF2R 6…13 GHz (discontinued solution, more Antenna interface radio SAF2 15…38 GHz available) Stationary use Conforms to ETSI EN 300 019 Class 4.1, NEMA 4X...
  • Page 128 INTEGRA-W/INTEGRA-WS User Manual TECHNICAL SPECIFICATION Integra-W RSL Thresholds at BER 10 and Total Payload Capacity (Mbps) Modulation, Capacity, BW, MHz Guaranteed RSL Threshold, dBm Mbps Strong FEC 4QAM -82.5 -82.5 -82.5 -82.5 -83.5 -80.5 -75.5 -78.5 8QAM -77.5 -80.5 -76.5 16QAM -75.5...
  • Page 129 -54.5 -54.5 1024QAM -51.5 -51.5 -51.5 -51.5 100 MHz and 112 MHz channel bandwidths are available for all Integra-W models except 17GHz and 24GHz UL. Maximum Tx Power for Integra-W Tx power, dBm Modulation 15, 18, 23, 17 GHz 26, 28 GHz...
  • Page 130 INTEGRA-W/INTEGRA-WS User Manual TECHNICAL SPECIFICATION High Performance integrated antenna specification Half power F/B ratio, Compliance Gain, Frequency, Size beamwidth ETSI 32.1 4.3° Class 3 33.4 3.5° Class 3 34.2 3.3° Class 3 35.3 3.0° Class 3 0.3m 36.1 2.6° Class 3 36.6...
  • Page 131 INTEGRA-W/INTEGRA-WS User Manual TECHNICAL SPECIFICATION Exterior design of Integra-W models Solution with 15-38 GHz integrated antenna 15, 18-23, 26-38 GHz 17, 24 GHz General design 6-13 GHz SAF Tehnika JSC...

  • Page 132: Abbreviations

    TFTP – Trivial File Transfer Protocol TM – Tide Mark TP – Twisted Pair TS – Threshold Seconds Tx – Transmit USB – Universal Serial Bus VLAN – Virtual Local Area Network WAN – Wide Area Network SAF Tehnika JSC...
  • Page 133 SAF Tehnika JSC 24a, Ganibu dambis, Riga, LV-1005, Latvia, EU techsupport@saftehnika.com www.saftehnika.com SAF Tehnika JSC...

This manual is also suitable for:

Integra-ws

Table of Contents
