Summary of Contents for World Chemical GREASECOMING
- Page 1 SEPARATOR WITH SCRAPER GREASE COMING YD-35FO INSTRUCTION MANUAL Version: 20250404...
-
Page 2: Table Of Contents
Table of Contents Safety Precaution ............................1 PREFACE ............................. 4 COMPOSITION AND STRUCTURE ....................4 INSTALLATION ............................ 8 PREPARATION FOR OPERATION ..................... 9 OPERATION AND ADJUSTMENT..................... 10 MAINTENANCE AND INSPECTION....................11 TROUBLESHOOTING ........................12 WARRANTY / REPAIR ........................13 NOTICE: This instruction manual is based on the standard equipment. Regarding the special type unit, substitute the specification with the appropriate article words. - Page 3 (2) When opening the wooden box, take care not to get injuries by nails or chips. (3) Install the trestle on the level at the firm place and fix it on the floor with anchor bolts. (4) The power of the scraper motor should be connected by the qualified person under the electric install technical standards.
- Page 4 (1) When servicing or inspecting of the scraper system, always turn off the main power. If it is maintained with power, it may cause electric shock. (2) When repairing “GREASECOMING”, contact the agent or our sale department. Additionally, when sending it back, clean thoroughly and pack it in wooden crates or cartons after checking no adherence or leaks of liquid.
-
Page 5: Preface
Instruction manual 1. PREFACE Thank you for purchasing World Chemical’s “GREASECOMING”. It is assembled with a pump and an oil collecting skimmer, such as a fix skimmer or a float suction, and configured floating oil collecting separating system. It can be installed with collecting tanks in factories, grease traps in company cafeterias, big restaurants or cleaning waste water tanks in food factories. - Page 6 The water drain cap (6) is attached inside of the drain tank for smooth drain. The liquid level of the separator is designed to coincide with the top edge of the water drain cap. The inside of the water drain cap is the screw structure (The pitch: 2mm). The liquid level in the separator can be finely adjusted by rotating of the cap.
- Page 7 which is assembled with the sloping boards. Then, it floats through the sloping board. The drain water low in fat enters from the top of the agglomerated board unit to the dough-nut shaped water passage and is carried to the pipe of the drain tank under the main body. After that, it overflows and be discharged from the water drain cap (6).
-
Page 9: Installation
3. INSTALLATION (1) When lifting the separator, use belt slings or wire ropes to prevent slip it. When transporting it, make sure to withdraw liquid. (2) It makes oily water collected from the oil collecting pit separate oil and water and water is discharged by natural drop. -
Page 10: Preparation For Operation
4. PREPARATION FOR OPERATION (１) Verify that the power specification on the name plate of the scraper motor is coincident with the AC power. (２) Connect with the AC power. When connecting with AC power, make sure the main power off to prevent the electric shock and short circuit. -
Page 11: Operation And Adjustment
The correct rotation is the clockwise as viewed from above. If the motor is 3 phase / 200V and rotates backward, make sure to turn off the power and reverse two out of three motor power cables. 5. OPERATION AND ADJUSTMENT The following is adjustment procedures after stating the operation. -
Page 12: Maintenance And Inspection
6. MAINTENANCE AND INSPECTION If much sludge or foreign objects are mixed with collected oily water, it may disrupt the performance of GREASECOMING. Take a maintenance check periodically or as appropriate. When taking a maintenance check, make sure the precautions. -
Page 13: Troubleshooting
washing. 7. TROUBLESHOOTING Types of Breakdown Cause Countermeasure Separation defect Oil is mixed with drain water. Adjustment defect of the Readjust the flow rate of the pump to the pump's flow rate. capability of the separator (Around 20L/min). Water is mixed with collected Emulsification of collecting oil. -
Page 14: Warranty / Repair
8. WARRANTY / REPAIR 1. period and coverage The warranty period is 12 months from dispatched from our factory. (2) During warranty period, if the pump breaks down or is damaged at the use under the condition instructed in this manual due to manufacturing defect(s), the failure parts are repaired free of charge. - Page 15 Installation record Model: Purchase date: Serial number: Start date: Supplier:...
- Page 16 WORCHEMI TAIWAN CO., LTD. / Taichung, Taiwan No.915, Zhongshan Rd., Shengang Dist., Taichung City 42955, TAIWAN TEL 886-4-2562-8358 FAX 886-4-2562-8351 WORLD CHEMICAL USA, INC. / California, U.S.A. 25691 Atlantic Ocean Dr.Unit B-15 Lake Forest, CA 92630, U.S.A. TEL 1-949-462-0900 FAX 1-888-860-3364 SUZHOU WORLD TECHNOLOGY CO., LTD.
