SPECIFICATION: Model no. MO-G20D Voltage 230Va.c. 60Hz Input Power _____________ Rated Microwave Power Output _____________ Microwave Frequency _____________ Outside Dimension _____________ Oven Cavity Dimension _____________ Oven Capacity _____________ IMPORTANT SAFEGUARDS: The following basic precautions should always be followed when using electrical appliance: 1.
Page 3
The contents of feeding bottles and baby food jars are to be stirred or shaken and the temperature is to be checked before consumption, in order to avoid burns. 8. Never operate the oven further if the door or door seals are damaged or the oven is malfunctioned or supply cord is damaged.
OPERATION THEORY OF MICROWAVE OVEN Microwave is a kind of high frequency electromagnetic wave, which is commonly distributed in the nature. But the existing form of microwave is dispersed so that it cannot be collected together for heating purpose. The key component of magnetron of microwave oven will transform the energy of electricity to microwave and huge energy of microwave field is established under the closed cavity.
Bent doors. Broken or loosened hinges and latches. Leaks on door seals and sealing surfaces. The oven should not be adjusted or repaired by anyone aside from an authorized Imarflex service technician. Do not tamper the safety interlocks. IF THE MICROWAVE FAILS TO OPERATE Check to ensure that the oven is plugged in securely.
Cover for standing time which allows the food to finish cooking without overcooking. 9. Check for doneness Observe the food color and hardness to determine whether the food is cooked. Doneness signs include: Steams throughout food, not just at edge part. ...
Page 7
Utensils Remarks Follow manufacturer’s instructions. The bottom of browning dish must be at Browning D ish least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Microwave-safe only. Follow manufacturer's instructions. Do not use Dinnerware cracked or chipped dishes.
DESCRIPTION OF PARTS Remove the oven and all materials from the carton and oven cavity. The oven comes with the following accessories:...
Page 9
OPERATING INSTRUCTION 1. Power Level Level Power 100% Display PL10 2. Clock Setting Press “CLOCK ", "00:00" will appear on the display. Press the number keys to set time. For example, the time is 12:10, press “1,2,1,0” in turn. Press the “CLOCK” to finish clock setting. “:” will flash and the clock will be lighted. If the numbers input are not within the range of 1:00-12:59, the setting will be invalid until valid numbers are input.
Page 10
Example: To cook the food with 50% microwave power for 15 minutes. Press "TIME COOK" once."00:00" displays. Press "1","5","0", and “0". Press "POWER" once, and then press "5" to select 50% microwave power. Press "START/+30SEC." to start cooking. Note: In the process of setting, if the “STOP/CANCEL" button is pressed or if there is no operation within 1 minute, the oven will go back to the former setting automatically.
8. POPCORN Press “POPCORN” once, "50", will appears in the display, press twice "100” will appear on the display. Numbers shown correspond with the grams. Press " START/+30 SEC. " to cook, beep will sound five times and then turn back to waiting state.
12. DINNER PLATE Press " DINNER PLATE " repeatedly until the number you wish appears in the display, "250","350","500" g will display in order. For example, press "DINNER PLATE" once, "250" will appear on the display. Press " START/+30 SEC. " to cook. When cooking time is finish, beep sound five times and then turn back to waiting state.
Example: If you want to cook with 80% microwave power for 5 minutes + 60% microwave power for 10 minutes. The cooking steps are as following: Press "TIME COOK" once, then press "5","0","0" to set the cooking time; Press "POWER" once, and then press "8" to select 80% microwave power. Press "TIME COOK"...
Page 14
Wash with mild soapy water and dry thoroughly. REMINDER: Please do not forget to fill up and upload warranty card with a copy of the receipt to our website https://imarflex.ph Distributed By: Topgadget Distributions, Inc. 2120 A.linao St., Malate, Manila...
