Himmelstrutz 8/Infinity Guitar Amplifier
Owner's Manual
(Serial. #1-)
Congratulations on your choice of Himmelstrutz 8/Infinity (H8/I)—your analogue alternative/complement to your
valve amplifier which may sound fantastic but is big and heavy and requires maintenance and probably much
electrical energy/power. H8/I is small, handy and powerful!
Tip: Read this document before connecting the wires to power up and play your H8/I, which will give you a better
understanding about this little unique Swedish product.
Background:
Please check the background of H8/I at www.himmelstrutz.com
Setup/usage:
First of all: Adjust the mighty
the Volume/Output Power.
1. Speaker
Connect a speaker of 4 to 16 Ω to the
Note: As there's no speaker included with this product, it's your
mission to obtain one or plenty of 4 to 16 Ω speaker cabinet(s) aimed
for guitar amplifiers. Please check this out with your favourite local
music dealer or online.
2. Instrument In
Connect your instrument, or the output from your pedal(s) to
the
Instrument Input
1/4" Jack
Doc: 6403038_om_001-. (#001–)
control to zero. The Vol sets
Vol
Speaker
1/4" Jack.
.
Vol/Output Power
Speaker Output
Instrument Input
1:5
