Summary of Contents for Ascent EC2101B
- Page 1 EC2101B MPEG-2/4/H.264 HD Encoder User Manual Revision 1A...
- Page 2 Manual Revision 1A Copyright © 2025 Ascent Communication Technology Limited. All rights reserved. Reproduction in any manner whatsoever without the express written permission of Ascent Communication Technology is strictly forbidden. This document is produced to assist professional and properly trained personnel with installation and maintenance issues for the product.
-
Page 3: Table Of Contents
EC2101B MPEG-4 HD Encoder Contents 1. Introduction .......................... 5 1.1 Product Overview· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5 1.2 Key Features ·... - Page 4 The contents of this document are subject to revision without notice due to continued progress in methodology, design and manufacturing. ASCENT shall have no liability for any error or damage of any kind resulting from the use of this document.
-
Page 5: Introduction
EC2101B MPEG-4 HD Encoder The EC2101B MPEG-2/H.264 HD Encoder is an advanced broadcasting audio and video encoding solution designed with robust functionality to meet diverse professional requirements. This device features a comprehensive array of input interfaces, including HDMI, SDI, YPbPr, and CVBS for video, alongside AES and XLR for audio, ensuring seamless compatibility with a wide range of signal sources. -
Page 6: Block Diagram
EC2101B MPEG-4 HD Encoder CC (Closed Caption) AC3 pass-through General Characteristics Parameter Description Video Interface IxHDMI, 1xHD-SDI, IxYPbPr and 1xCVBS (only for CC) Resolution Input Output Interface Applicable 1920x1080p@60/59.94 1920x1080p@60 SDI, HDMI 1920x1080p@50 1920x1080p@50 1920x1080i@60/59.94 1920x1080i @60 SDI, HDMI, YpbPr... -
Page 7: Appearance And Description
EC2101B MPEG-4 HD Encoder Description Parameter Power AC110V±10%, 50/60Hz; AC 220V±10%,50/60Hz Consumption Front Panel Illustration ① LCD window ② Indicators ③ Up and down, left and right navigation buttons Enter button: for confirm ④ Menu button: for back step ⑤... -
Page 8: Installation Guide
EC2101B MPEG-4 HD Encoder This section is to explain the cautions the users must know in some case that possible injure may bring to users when it’s used or installed. For this reason, please read all details here and make in mind before installing or using the product. -
Page 9: Grounding Requirement
EC2101B MPEG-4 HD Encoder Pressure 86 to 105KPa Door & Window Installing rubber strip for sealing door-gaps and dual level glasses for window Wall It can be covered with wallpaper, or brightness less paint. Fire Protection Fire alarm system and extinguisher... -
Page 10: Front Panel Operation
EC2101B MPEG-4 HD Encoder EC2101B front panel is user operation interface where users configure the device manually. The LCD is a 2-line * 40- character back-lit dot-matrix user interface with pushbuttons for UP, DOWN, LEFT, RIGHT, ENTER, MENU, and LOCK for front panel control. - Page 11 EC2101B MPEG-4 HD Encoder Bottom Air Inlet Heat Dissipation Diagram of Simulated Air Duct Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 11 of 24...
- Page 12 EC2101B MPEG-4 HD Encoder Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 12 of 24...
-
Page 13: Web Nms Operation
Use web browser to connect the device with PC by inputting the device’s IP address in the browser’s address bar and press Enter. It will display the Login interface as below figure. Input the Username and Password (The default Username is “admin” and Password is “ascent”.) and then click “LOGIN” to start the device setting. 4.2 Operation Parameter ->Status When we confirm the login, it displays the Status interface as below figure where user can view the system information. - Page 14 EC2101B MPEG-4 HD Encoder Parameter -> Encoder Click “Encoder” on the top column and it displays interface as below figure. User can set the Encoder parameters. Parameter -> Encoder-> Video Setting Video input interface：HDMI,SDI, CVBS,YPbPr optional. Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com...
-
Page 15: Audio Format
Select one Chroma Sample mode from the 2 options listed. They are applicable for both MPEG2 and H.264 encoding mode. Video Buffer: EC2101B support video buffer which makes it free to switch video sources. If enable video buffer, the time of system latency will be raised about 100ms. - Page 16 EC2101B MPEG-4 HD Encoder Parameter -> TS config> Stream Select From the menu on left side of the webpage, clicking “TS Config”, it displays the interface where users can multiplex the programs from the encoder and ASI inputs. Input Area...
- Page 17 EC2101B MPEG-4 HD Encoder Parameter -> TS config -> General From the TS Config menu on up side of the webpage, clicking “General”, it displays the interface where users can set Output Bitrate, Character Encoding and TDT/TOT/NIT tables. (Below figure) Parameter ->...
- Page 18 Parameter -> IP stream EC2101B supports TS to output in IP format through the DATA1 (only one MPTS) or DATA2 port. The output programs information in MPTS. Clicking “IP Stream”, it displays the interface where to set IP out parameters (Below figure).
- Page 19 EC2101B MPEG-4 HD Encoder System -> Network Clicking “Network”, it displays the interface as below figure where to set network parameters. System -> Account Clicking “Account”, it displays the interface as below figure where to set use-name and password of the equipment.
- Page 20 EC2101B MPEG-4 HD Encoder System -> Configuration Clicking “Configuration”, it displays the screen as below figure where to save/ restore/factory setting/ backup/ load your configurations. System -> Firmware Clicking “Firmware”, it displays the screen as below figure where to update firmware for the encoder.
- Page 21 EC2101B MPEG-4 HD Encoder System -> Date/Time Clicking “Date/Time”, it displays the screen as below figure where to set date and time for the device. System -> Log Clicking “Log”, it displays the log interface as below figure where to check or export the Kernel/System log.
-
Page 22: Troubleshooting
EC2101B MPEG-4 HD Encoder For guarantee the products’ quality, reliability and stability. All ASCENT products have been passed the testing and inspection before ship out factory. The testing and inspection scheme already covers all the Optical, Electronic and Mechanical criteria which have been published by ASCENT. To prevent potential hazard, please strictly follow the operation conditions. -
Page 23: Packing List
EC2101B MPEG-4 HD Encoder EC2101B MPEG-2/4/H.264 HD Encoder User Manual HDMI Cable SDI Cable YPbPr Cable CVBS Cable XLR adapter Cables RCA adapter Cables Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 23 of 24... - Page 24 Cau Giay District, Hanoi 10649, VIETNAM Phone: +84-24-37955917 WEB: www.ascentcomtec.com EMAIL: sales@ascentcomtec.com Specification product availability are subject to change without notice. Copyright © 2025 Ascent Communication Technology Limited. All rights reserved. Ver. ACT_EC2101B_MPEG_Encoder_User_Manual_V1a_Apr_2024 Solutions Provider for FTTx, RFoG, and HFC www.ascentcomtec.com Page 24 of 24...
