- Page 1 TRUE INDUCTION MINI DUO INDUCTION COOKTOP MANUAL MINI DUO BURNER INDUCTION COOKTOP MANUAL MD-2B...
-
Page 2: Table Of Contents
Troubleshooting & Error Codes 12 - 13 Thank you for purchasing the True Induction Mini Duo burner unit. Please read the entire instruction manual prior to using your unit. If you have any questions regarding the True Induction Cooktop, please visit TrueInduction.com or call: 1-877-862-7049... -
Page 3: Important Safety Information
To avoid potential injury, do not use accessory attachments which aren't recommended by the manufacturer. Do not use outdoors, True Induction Cooktops are designed for household use. Do not let the cord dangle over the edge of a table or counter. Keep the cord away from hot surface. - Page 4 I. Important Safety Information: Do not place metallic objects such as knives, forks, spoons, lids, cans or aluminum foil on the cooktop. It is important to be aware that the unit's surface will remain hot for a period of time after use. When possible, unplug the cooktop from the outlet when not in use and before cleaning.
-
Page 5: Control Panel Overview
II. Control Panel Overview: Left Cooking Zone Right Cooking Zone Ceramic Glass Left Touch Control Panel Right Touch Control Panel Diagram may look different from actual product Left Cooking Zone TImer Control Key Right Cooking Zone Child Safety Lock Ceramic Glass Power Button Left Touch Control Panel MINI DUO BURNER INDUCTION COOKTOP MANUAL... -
Page 6: Specifications & How To Use
III. Specifications & How to Use: Power 1800 Watts Voltage 120V / 60Hz Minimum Circuit Breaker Amperage Power Range 100W - 1800W (Exact Power Settings) Level Selection Select Settings 1 through 10 Max Time Set Timer From 1 to 180 minutes Material Glass Ceramic Top / Metal Body Unit Measurements (WxDxH) -
Page 7: Readiness Mode
III. Specifications & How to Use: Readiness Mode While in Standby Mode, press the "POWER" key, it will make a "beep" sound once and "POWER" indicator light will be blinking, indicating that the induction cooktop functions are ready to use. The unit will automatically return to standby mode if Menu-On is not turned on within 60 seconds. -
Page 8: Power Sharing
III. Specifications & How to Use: Power Sharing When both burners are on, one of the two burners would not have a power level higher than level 7. Both of them together would not be more than Max 10. If only one burner is on, the heating zone can maintain its full heat setting, but when operating both burners, their combined total is Max 10, meaning that when operating the two burners at the same time, they will self adjust levels accordingly. -
Page 9: Compatible Cookware
If is ready to be used on the True Induction your magnet stays on then your cookware cooktop! - Page 10 VI. Cleaning & Maintenance: VI. Cleaning and Maintenance: Cleaning Burned on Residue: Cleaning Burned on Residue: WARNING: Damage to the glass surface may occur if you use scrub pads or any other type of abrasive WARNING: Damage to the glass surface may occur if you use scrub pads or any other types of abrasive cleaning materials.
-
Page 11: Counter Installation Instruction
VII. Counter Installation Instructions: VII. Counter Installation Instructions: Use ---- Countertop Countertop Use Please find 4 feet in the packaging, you can screw them into the bottom of the unit, then the unit Please find 4 feet in the packaging, you can screw them into the bottom of the unit, then the can be used directly on the countertop. -
Page 12: Cooktop Installation
VII. Counter Installation Instructions: Cooktop Installation Cut an opening in the counter surface. Refer to the drawing on the following pages for appropriate dimension sizes and follow these instructions: Select heat-resistant table material to avoid damage caused by heat radiation. Ensure that the underside of the induction cooktop is well ventilated and the air inlet is not blocked. - Page 13 VII. Counter Installation Instructions: Installation MODEL MD-2B 120V 60Hz 20 1/2" (520) 14 1/8" (360) 1800W Min 2" (51) Min 2" (51) Edge of Cutout to Rear Cut-Out To 14 1/8" Edge of Countertop Combustible (360) Materials Overall (Both Sides) Depth 20 1/2"...
-
Page 14: Troubleshooting & Error Codes
VIII. Troubleshooting & Error Codes: If the display shows an error code, please refer to this sheet for a potential solution. Problem Possible Cause Solutions IGBT-Insulated Gate Bipolar Transistor NTC-Negative Temperature Coefficient, to check the temperature of electronic elements NTC1-To check the temperature of IGBT NTC2-To check the temperature of heating center Make sure lock mode is turned off Cooktop controls are locked Check house lights to confirm power... - Page 15 VIII. Troubleshooting & Error Codes: If the display shows an error code, please refer to this sheet for a potential solution. Error Code Possible Cause Solutions IGBT (Insulated Gate Bipolar Turn off unit to allow IGBT to cool. "E0" Appears in the digital display Transistor) overheating Then restart the unit "E1"...
