- Page 1 Aeropro CZ A220 taildragger Maintenance Manual Taildragger Supplement original November 10, 2014...
- Page 2 A E R O P R O C Z Maintenance Manual 1.9.2 CG - calculation A specific C.G. calculation recommendation which has to be carried out prior to each flight is provided in the Pilot Operating Handbook, Section 4. Figure 1-6.
- Page 3 A E R O P R O C Z Maintenance Manual Figure 1-7 Weight and C.G. position record (sample only) Serial Number Registr. Mark: Aircraft Levelling: Values Weighed: Main wheels right-hand left-hand Tail wheel Most = Resulting weight Mres = C.G.
- Page 4 A E R O P R O C Z Maintenance Manual Figure 2-2...
- Page 5 5.1 Landing Gear 5.2 General Description The A220 taildragger has a two wheel main undercarriage with a tail wheel. The main landing gear is formed of composite construction, wheels with low-pressure tires of 800/6 size are provided with hydraulic disc brakes operated from control lever located on the rudder pedals. The tailwheel landing gear has a composite strut and the tailwheel is equipped with a 6x2.25 sized tire.
- Page 6 The aluminum wheels have two flanges and a hub that is manufactured by an Aeropro supplier. The flanges are attached to the wheel hub by thru-bolts and nuts as shown in figure 5-2. During assembly of the main wheel the thru-bold nuts or cap screws, as applicable, shall be tightened evenly and torqued to the value specified in figure 5-2.
- Page 7 5.6.3 Level of Maintenance: Heavy 5.6.4 Certification required: A&P Mechanic or LSA Repairman Maintenance Repair of main gear is possible only in Aeropro company or company which have complete technology for welding. 5.7 Main Wheel Removal 5.7.1 Required Tools: 11/17/19 mm wrenches, wire cutting pliers, plastic hose 5.7.2 Parts required:...
- Page 8 A E R O P R O C Z Maintenance Manual Hoist or jack aircraft in accordance with Section 2. Remove wheel axle. Withdraw main wheel assembly. Deflate the tire, remove thru-bolts and separate wheel halves, removing tire, tube, hub and torque plate.
- Page 9 A E R O P R O C Z Maintenance Manual Assemble the remaining washers and nuts on the thru-bolts and torque to 88 in. lb. (10 Nm). Use Loctite 243 to secure nuts. Uneven or improper torque of thru-bolt nuts can cause failure of bolts, with resultant Caution wheel failure.
- Page 10 A E R O P R O C Z Maintenance Manual Carefully inspect bearings for damage and discoloration or noises when rotating. Do not try to re-lubricate the sealed bearings. If in doubt about bearing condition, replace bearings. Figure 5-3 Composite leg Control lever for tail wheel Springs...
-
Page 11: Troubleshooting
5.20 Steering adjustment Since the tail wheel steering and rudder system are interconnected, adjustment to one system may affect the other system. Section 10 of the Aeropro A220 Maintenance Manual contains rigging instructions for the rudder system. 5.21 Brake system 5.22 General description... - Page 12 A E R O P R O C Z Maintenance Manual 5.24 Brake master cylinders (refer to figure 5-4.) The brake master cylinder, located on the pedals, is activated by gently pushing on the brake pedals positioned on the cockpit floor. A small reservoir is incorporated onto the master cylinder for the fluid supply.
- Page 13 4. switch for landing light 5. landing light 6. cable for landing light (note: In illustration above, this is showing an older-configuration Aeropro taildragger and the newer models have a composite main gear, a composite tailwheel strut, and other changes.)
