Multiview T-35

DVB-T to PAL / 5 channels on all TV's

Table of Contents

Need help?

Do you have a question about the Multiview T-35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Macab Multiview T-35

Page 1 120524 • 50138 M5-H.002 Multiview T-35 DVB-T to PAL / 5 channels on all TV’s...
Page 2: Table Of Contents
Contents Multiview ............................3 Features ............................3 Caution ............................3 Front & Rear Panel ........................4 Connecting ............................5 Programming ..........................6 Information ............................. 7 Installation ...........................8–9 Auto Reset ............................. 10 Software Updating ........................10 Test Card Feature .......................... 10 Factory Reset ..........................
Page 3: Multiview
Multiview Multiview can receive up to 3 DVB-T Multiplexes at the same time. From the available programs 5 can be selected to be converted to PAL and distributed to all TV’s in the building, house or school. Multiview is connected after the antenna and before the signal is distributed in the property.
Page 4: Front & Rear Panel
Front and Rear Panel Front Panel 1. Remote control sensor. 2. Enter–Accept menu options. 3. Menu –Enter menu. –Exit and save. 4. Down–Move down in menu. 5. Up–Move up in menu. 6. Left–Scroll options in menu. 7. Right–Scroll options in menu. 8.
Page 5: Connecting
Connections Output (analogue+digital) Antenna signal is looped between the RF In, Antenna Loop Out & RF Loop Input for both analogue & digital signals on RF Out.
Page 6: Programming
Programming Multiview is preset to output on RF channels 40, 43, 46, 50 & 37. The multiVIEW BOX menu is shown only on the first RF output which is channel 40 as de- Information fault. If this output channel is changed please re-tune the TV to con- Setup tinue setup.
Page 7: Information
Information Information Menu multiVIEW BOX 1. Press MENU and scroll down to ”Information” and press ENTER. Information Displays information about the signal quality of the various inputs and Setup Scanning software version. No changes can be made here. Auto RESET •...
Page 8: Installation
Settings ”Setup” Channel Selection and Settings multiVIEW BOX 1. Press MENU and scroll down to ”Setup” and press ENTER. Information Settings for each receiver (Unit) can be adjusted. Check carefully on Setup the first line the ”Unit Number” is the one desired before making any Scanning Auto RESET changes.
Page 9: Radio Mode
Settings ”Setup” Subtitle multiVIEW BOX Choice of language for subtitles in two levels with DVB subtitling op- Information tion. Setup Scanning • Press ENTER for Subtitle menu. Auto RESET • Press right / left to select. • Press down arrow for Subtitle Aux (optional if first choice unavail- able).
Page 10: Auto Reset
”Auto RESET” Multiview can be set to ”Auto RESET” ”Off ” No Auto Reset will be performed. Multiview will only reset if software or hardware watchdogs are triggered. “Every Day” Multiview will perform a hardware reset at 03:00 hours on a daily basis. “Every Week”...
Page 11: Technical Specification
Technical Specifications Technical Specification DVB-T Tuner / Demodulator 3 x DVB-tuner/demodulator (Maxlinear) Frequency Range 170~230MHz, 470~860 MHz Modulation COFDM 2k, 8k Input Level 60–80 dBµV (–47 to –27 dBm) Input Impedance 75 Ohm Connector F Female Noise Figure Typical 7 dB Bandwidth 8 MHz IF center frequency...
