Top-of-Pole Mount for 3 Modules (TPM3)
YOUR DPW SOLAR DISTRIBUTOR
SOLARIS
720-474-6050
www.solaris-shop.com
For Module Types A, B, & C
A
SSEMBLY
assembly and installation
Module
Type Width
Length
A
19-23" 35-44"
B
20-26" 39-50"
C
22-27" 56-63"
I
NSTRUCTIONS
step-by-step
Version 2, Rev B
PCN 061411-5
Advertisement
Summary of Contents for Solaris POWER-FAB DPW SOLAR TPM3
- Page 1 Type Width Length 19-23” 35-44” 20-26” 39-50” 22-27” 56-63” Top-of-Pole Mount for 3 Modules (TPM3) For Module Types A, B, & C SSEMBLY NSTRUCTIONS step-by-step assembly and installation YOUR DPW SOLAR DISTRIBUTOR Version 2, Rev B SOLARIS 720-474-6050 PCN 061411-5 www.solaris-shop.com...
- Page 2 Top-of-Pole Mount for 3 Modules (TPM3) For Module Types A, B, & C A few words about the product The TPM3 for module types A, B, & C is designed to mount on 2-1/2 or 3 inch SCH40/80 galvanized steel pipe (installer supplied). Pipe size and foundation requirements are based on several factors including the array surface area, maximum design wind speed, exposure category, soil type, steepest expected tilt angle, and above-ground clearance.
- Page 3 2 of 7 Assembly Instructions, Top-of-Pole Mount for 3 Modules (TPM3) For Module Types A, B, & C (Version 2, Rev B)
- Page 4 Step 1: Install the Mounting Sleeve on Vertical Pipe Before installing the Mounting Sleeve, verify that the Mounting Pole is plumb to CAUTION: the ground and hasn't shifted or leaned while the concrete footing has cured. Use care while The Mounting Sleeve slips on top of the Mounting Pole and has two 3/8” Set Bolts working around the structure which are used to secure it to the Mounting Pole.
- Page 5 B. Remove the Pivot Bolt from the Mounting Sleeve and collect the 3/8” x 1-1/4” CAUTION: bolt, flat washers and lock washer needed to secure the Support Bar to its This is a two person activity. Pivot Tab on the Mounting Sleeve. The Strongback C.
- Page 6 F. Pivot the Strongback and the Support Support Bar to align the mounting holes of the Support Bar with the Pivot Tab on the Mounting Sleeve. Pivot 3/8” Insert the 3/8” x 1-1/4” bolt and Hex Nut one flat washer thru the Support Lock Bar and Mounting Tab and secure Washer...
- Page 7 Step 4: Installing PV Modules to Module Rails CAUTION: This is a two PV Modules are secured to the Module Rails using 1/4” x 3/4” bolts and hardware. person activity. PV Modules are A. Place the PV Module on the Module Rails. Align the mounting holes and heavy and secure with 1/4”...
- Page 8 CAUTION: Do not attempt to remove the Pivot Bolt during tilt adjustments! Removal could lead to serious personal injury or death. Adjustments Remove are made with the Support Arm Pivot Bolt Hardware hardware loosened Loosen (upper hardware only) but in place. Pivot Bolt CAUTION: This is a two...
- Page 9 4000-B Vassar Drive NE Albuquerque, New Mexico 87107 Telephone: 800.260.3792 Fax: 505.889.3548 Web Site: www.DPWSolar.com E-mail: info@power-fab.com © 2011 Preformed Line Products PCN 061411-5 Version 2, Rev B...
