Summary of Contents for inBiot Sigfox Access Station Micro
- Page 1 Sigfox Gateway Configuration V1.0 03/24...
-
Page 2: Table Of Contents
Table of Contents Box contents...........................3 Sigfox Access Station Micro ....................4 Sigfox Station parts ......................4 LED operation guide ......................4 Read before you start ......................5 Instalation of the station .....................6 Configuration with USB dongle ...................9 Copyright © inBiot Monitoring SL... -
Page 3: Box Contents
Box contents Make sure your package contains all the items: Sigfox Access Station Micro Passive PoE injector Power supply Ethernet cable Mounting kit Optional elements: 3G/4G USB Dongle Sealing cover Copyright © inBiot Monitoring SL... -
Page 4: Sigfox Access Station Micro
Sigfox Access Station Micro Sigfox Station parts USB PORT (CELLULAR) ETHERNET PORT (DATA + POWER) LED operation guide Copyright © inBiot Monitoring SL... -
Page 5: Read Before You Start
Internet connection: Either through the Ethernet port or a compatible USB 3G/4G dongle. 3.2. Indoor 220/110 VAC power outlet. For more detailed information, product updates, and online manuals, visit micro. sigfox.com. For support, contact your local Sigfox Operator or distributor. Copyright © inBiot Monitoring SL... -
Page 6: Instalation Of The Station
INSTALATION SIGFOX ACCESS STATION MICRO Copyright © inBiot Monitoring SL... - Page 7 2.2. Connection using Ethernet: 2.2.1. Connect the Ethernet cable to the station’s Ethernet port. 2.2.2. Connect the other end of the Ethernet cable to the PoE injector, and the PoE injector to the wall network socket or router. Copyright © inBiot Monitoring SL...
- Page 8 LED is solid green. This should take less than 2 minutes under normal temperature conditions, and all LED colors shown in the LED operation guide may occur. 2 MINUTES Copyright © inBiot Monitoring SL...
-
Page 9: Configuration With Usb Dongle
CONFIGURATION WITH USB DONGLE Copyright © inBiot Monitoring SL... - Page 10 Configura la Red para tu Estación Sigfox Important: If the SIM cards are provided by inBiot, you do not need to perform these steps. You only need to perform this configuration if you are going to use your own SIM cards. In that case, remember that the SIM cards must have at least 1GB of monthly data.
- Page 11 Once configured, you can now plug the USB dongle to your station. At that point, the base station LED should change from orange to green. If not, check the connectivity settings or contact technical support. Copyright © inBiot Monitoring SL...
- Page 12 support@inbiot.es...
