Summary of Contents for LASER TECH MapStar TruAngle II
- Page 1 MapStar TruAngle ® ® User’s Manual 2nd Edition 1.303.649.1000 ServiceCenter@LaserTech.com 6912 S. Quentin St, Suite A Centennial, CO 80112 @LaserTechnologyInc @LaserTechnologyInc @LaserTechInc_ @LaserTechPro @Laser-Technology...
- Page 2 LTI MapStar® TruAngle® II User’s Manual Edition Part Number 0145025 Copyright Notice: Information in this document is subject to change without notice and does not represent a commitment on the part of Laser Technology, Inc. No part of this manual may be reproduced in any form or by any means, electronic or mechanical, including photocopying, recording, or information storage and retrieval systems, for any purpose other than the purchaser’s personal use, without the express written consent of Laser Technology, Inc.
-
Page 3: Table Of Contents
Section 1 - Introducing the LTI MapStar TruAngle II ....... . -
Page 4: Precautions
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Precautions Page 2 Precautions • Do not expose the instrument to extreme temperatures. TruAngle II components are rated for Operating temperature range of -20 to 50° C (-4 to 122° F). -
Page 5: Section 1 - Introducing The Lti Mapstar Truangle Ii
3D mapping making it the perfect tool because it is unaffected by local magnetic interference. Features of the MapStar TruAngle II: • Bluetooth: Bluetooth Low Energy (BLE), iOS & Android compatible; Laser Tech CR400 serial format. • Simple Intuitive User Interface: 3-button intuitive interface decreases field time. -
Page 6: Understanding How The Mapstar Truangle Ii Works
The precision of the MapStar TruAngle II lies in its patent-pending, capacitively coupled rotor and resolver board set. An on-board processor conditions signals from the rotor and resolver, as well as from a separate inclinometer, providing user feedback to ensure the device remains level during measurements. -
Page 7: Section 2 - Getting Started
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 2 - Getting Started Page 5 Section 2 - Getting Started Parts of the MapStar TruAngle II Figure 1 Copyright© 2025, Laser Technology, Inc. All rights reserved. -
Page 8: Layout
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 2 - Getting Started Page 6 Layout Figure 2 Figure 3 Copyright© 2025, Laser Technology, Inc. All rights reserved. -
Page 9: Powering Up
To conserve battery power, if no buttons are pressed, the unit will completely power OFF automatically after 5 minutes: • The shut down value can be changed with serial command messages. For detailed information on the serial command messages, refer to the Laser Tech's Professional Measurement FAQs technical documents website (https://lasertech.com/professional-measurement-faqs/). Manually Power Off The TruAngle II can be powered off by pressing and holding the On/Off button for 3 seconds. -
Page 10: Section 3 - Quick Start
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 3 - Quick Start Page 8 Section 3 - Quick Start Install charged battery pack (Page Mount to selected mounting options. Press the On/Off button to power on the unit. -
Page 11: Section 4 - Using The Truangle Ii
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 4 - Using the TruAngle II Page 9 Section 4 - Using the TruAngle II Battery Pack Installation The TruAngle II is powered by lithium-ion battery pack. Open the battery compartment cover by gently pulling the battery pack door. -
Page 12: Button Layout And Functions
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 4 - Using the TruAngle II Page 10 Button Layout and Functions The TruAngle II has three buttons. Looking at the faceplate of the TruAngle II: Configuration Button •... -
Page 13: Mounting Options
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 4 - Using the TruAngle II Page 11 Mounting Options The TruAngle II has 5/8” threads (Top Male; Bottom Female) to mount to different type of mounting accessories. •... -
Page 14: Bluetooth Low Energy (Ble)
MapStar TruAngle II Bluetooth® Low Energy (BLE) Connectivity Protocols document on the Laser Tech website. A Smart Device App that has the Laser Tech product protocols, can detect the Bluetooth options and control connectivity to a TruPulse Laser and TruAngle II individually. -
Page 15: Zeroing The Unit
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 4 - Using the TruAngle II Page 13 Zeroing the Unit The TruAngle II does not need to be indexed or calibrated to zero the unit. Long Press the Fire/Zero button. - Page 16 Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 4 - Using the TruAngle II Page 14 LV and LE settings and limits: • LV = Level Assist Visual Limit Set • Sets when the visual LEDs begin to indicate plumb angle.
-
Page 17: Level Assist Visual
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 4 - Using the TruAngle II Page 15 Level Assist Visual If the unit is off level - in the example shown, a max of 7 LEDs will show extreme off level. -
Page 18: Taking A Measurement
The TruAngle II is an App controlled device utilizing BLE only. The TruAngle II requires a smart device with a dedicated designed App to connect, communicate and capture the angle measurements. For developers, a robust list of protocols is available. Refer to MapStar TruAngle II Bluetooth® Low Energy (BLE) Connectivity Protocols document on the Laser Tech website (https://lasertech.com/professional-measurement-faqs/). -
Page 19: Section 5 - Care & Maintenance
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 5 - Care & Maintenance Page 17 Section 5 - Care & Maintenance The batteries are the only user-replaceable parts in the TruAngle II. Do not remove any screws. -
Page 20: Section 6 - Specifications
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 6 - Specifications Page 18 Section 6 - Specifications All specifications are subject to change without notice. Please refer to LTI's website for current specifications. If you are not able to locate the information on the website or if you do not have internet access, please contact LTI via phone or fax. -
Page 21: Section 7 - Lti Limited Warranty
Laser Technology, Inc. MapStar TruAngle II User’s Manual 2nd Edition Section 7 - LTI Limited Warranty Page 19 Section 7 - LTI Limited Warranty What is Covered? Laser Technology, Inc. (LTI) warrants this product to be in good working order. Should the product fail to be in good working order at any time during the warranty period, LTI will, at its option, repair or replace this product at no additional charge.
