Summary of Contents for PUSR USR-SH800
- Page 1 Quick Operating Manual USR-SH800 Integrated Screen of IOT Edge computing, network management ,Built-in configuration, rich in protocols ,Open source system, simple configuration Be Honest & Do Best Your Trustworthy Smart Industrial IoT Partner...
-
Page 2: Table Of Contents
Catalogue 1. Product introduction ..........................4 2. Unpack ..............................4 3. Hardware connection ..........................6 3.1. Interface introduction ........................6 3.2. Hardware operating instructions ....................7 4. Application Parameter Configuration ......................9 4.1. Open the WEB interface........................9 4.2. Network configuration .........................12 4.3. Data collection ..........................13 4.4. -
Page 3: Product Introduction
IoT applications. 2. Unpack USR-SH800 factory neutral packaging, there is a small label on the outer packaging box, as a delivery and warehousing inspection use, marked with SN and product model; the packaging box... - Page 4 Physical drawing:...
-
Page 5: Hardware Connection
3. Hardware connection 3.1. Interface introduction RS485/RS232 interface introduction: Serial number Definition Property Describe 3.3V output 3.3V voltage output TX/A output TX/A RX/B Input Receive (RX/B) Ground electrode Ground electrode... -
Page 6: Hardware Operating Instructions
Introduction to the network port: Serial number Definition Property Describe WAN/LAN Default WAN WAN/LAN switchable Default LAN 3.2. Hardware operating instructions 1. After unpacking, take out the equipment and connect it to WiFi antenna (SH800-EW WiFi version); 2. To configure the SH800 by directly connecting it to a PC: ,（1）Connect one end of an Ethernet cable to the LAN port of the SH800, and the other end to your computer;... - Page 7 （5）If you want to enter the Ubuntu desktop, long press the screen, and then click the cross icon that pops up. You can exit the full-screen configuration mode. After minimizing the browser, you can enter the Ubuntu desktop to perform operations. At this point, the device has been successfully started. （6）To restart the configuration in full - screen mode on the desktop, you just need to open the minimized interface from the desktop, find the three - dot button in the browser, and maximize the window.
-
Page 8: Application Parameter Configuration
4. Application Parameter Configuration SH800 has built-in WukongEdge, which is enabled by default. WukongEdge function parameters are mainly configured through built-in WEB. This chapter mainly introduces network parameter configuration, edge calculation parameter configuration, configuration function editing and parameter association. Note: During use, if WukongEdge is turned off, the built-in WEB cannot be activated. 4.1. - Page 9 4.Device basic information and network connection status can be seen on the overview interface. Open the built-in WEB based on your own screen(you can also access the mouse and keyboard directly) 1. Hardware connection:access mouse and keyboard through USB interface (use peripheral operation, if direct touch screen operation,ignore this step);...
- Page 10 3. Open the browser on the desktop and enter the IP address of the LAN port(default192.168.1.1); 4. Enter user name (default admin) and password (default admin) in the web login interface, which can be modified after logging in; 5. Basic information and network connection status of the equipment can be seen in the overview interface.
-
Page 11: Network Configuration
4.2. Network configuration 1. WiFi connection, need to open the web page "network-> wireless client " interface, click the search button,search WiFi AP hot spot, wait for the search to complete, click the input box, there will be a drop-down box pop-up, you can directly select the AP side, you can also enter the hot spot in the input box for fuzzy search to filter.After selecting AP, configure encryption method and... -
Page 12: Data Collection
4.3. Data collection This chapter mainly introduces the data acquisition part of the edge calculation function, which relies on the point configuration and uses Modbus Slave to test the data acquisition. Before the function test, install Modbus Slave software on the computer; the function test steps are as follows: 1.Hardware connection: connect the computer and the device LAN port through the network cable (refer to Section 3.2);... - Page 13 lave is added, select the slave and click the Add button in the Slave-Point List interface 5. After the s add points. In the pop-up window, configure the point information. For the convenience of later configuration display, add 12 data at a time for this test. The specific operation is that the point name is "test", the register is "40001", the data type is "16-bit unsigned", and the number of points is "12".
- Page 14 6. At this point, the slave and point configuration is completed, and the device is restarted according to the web page prompt; 7. Open Modbus Slave software on the computer, find "Slave Definition" in "Setup" and open it, Slave ID is configured as 1, Funtionis configured as " 03 Holding Register(4x)",Address is configured as 0, Quantity is configured as 12, and others remain default;...
- Page 15 8. Find "Connection" in the menu bar, and configure it as shown in the following figure address and port are consistent with device slave configuration). Click OK to complete the configuration, and the word "No connection" disappears, indicating that the device has been successfully connected to Modbus Slave;...
- Page 16 10. Return to the WEB interface of the device. In the "Edge Calculation-> Data Points" interface, you will see that the slave is online, and the corresponding points have all acquired data. The data acquisition test is completed.
-
Page 17: Data Reporting
4.4. Data reporting After data collection is completed, the data can be transmitted to the server for data processing and display through the data reporting function. This chapter will describe the reporting operation in combination with the data obtained in the "Data Collection" chapter. Make sure you download Network Debugging Assistant on your PC before you start. - Page 18 8. After completing the grouping report, you need to configure the communication link and find the "Edge Computing-> Edge Gateway-> Data Report" interface; 9. Open "Link 1", configure the communication protocol as TCP, fill in the computer IP address, set the remote port as 8234, default other parameters, click Apply and restart the device;...
-
Page 19: Configuration Application
11. After the device is restarted, it will be connected to the computer and report the data according to the cycle of 5s; 12. Verification of data reporting function is completed. 4.5. Configuration application The configuration function of equipment mainly realizes the local visualization of equipment acquisition data, which is convenient for on-site data monitoring and management. -
Page 20: Configuration Design
4.5.1. Configuration design 1. Open the "Edge Calculation-> Configuration Management" interface in the web page, find "Create", click Create New Configuration; 2. Select the new configuration, find the "Configuration Design" button, click to enter the configuration editing interface; 3. Configuration design is carried out in the configuration design interface. Design is carried out through the component library and gallery on the left side of the design interface. - Page 21 After the configuration is completed, bind the points. Select the variable value in the configuration, and the data source will be displayed on the right side. Select the slave and point to bind (slave and data are added in the edge acquisition point table, refer to the data acquisition chapter); 5.
- Page 22 6. Return to the built-in web page configuration management interface, refresh the web page, select the new configuration, the edited configuration screen will be displayed, if the data has been successfully collected, the actual data display will be seen; The configuration design is completed to this test.
-
Page 23: Configure Full Screen Startup
4.5.2. Configure full screen startup The full-screen configuration startup function refers to the function that, after the device is powered on, the full-screen display of the configuration is directly carried out. As shown in the figure above, by default, the first configuration in the configuration group is displayed. The full-screen configuration display function can be turned on and off through the configuration management interface. - Page 24 Official Website: www.pusr.com shop.usriot.com Official Shop: h.usriot.com Technical Support: inquiry@usriot.com Inquiry Email: +86 13405313834 Skype & WhatsApp: Product Catalog Facebook Youtube Click to view more: & &...
