Summary of Contents for Valentine Liguria
- Page 1 Cuiseur à pâtes Liguria Mode d’emploi Pastacooker Liguria Instruction manual Pastakocher Liguria Bedienungsanleitung Ed. 05/2022 Manuel original/Originalbetriebsanleitung /Original manual ©Valentine Fabrique SA,2022...
- Page 2 Please keep for future reference. mode d’emploi Vous pouvez télécharger le avec ce QR-code. user manual You can download the with the following QR-code. Kurzanleitung Sie können die mit diesem QR-Kode herunterladen. Scan me www.Valentine.ch info@Valentine.ch...
- Page 3 Vue d’ensemble — Überblick — Overview ► §2 ► §3 ► §3 ► §4 4 bar typ. (max 10bar) 400kPa typ (max 1000kpa) ► §2 58 Psi typ (max 145Psi) Max 60°C...
- Page 4 Vue d’ensemble — Überblick — Overview L’equipement supplémentaire comme les paniers peut différer de la representation du manuel. Zusätzliche Ausrüstungen wie Körbe können von den Bildern der Anleitung abweichen. Accessories like baskets might be different from illustration in the manual. Niveau de remplissage Füllstand Markierung Level mark...
- Page 5 1. Welcome - Safety Congratulations on your purchase of a Valentine cooker, a product of the best quality well known in Europe for over 65 years. This product will work optimally for many years if you respect a few basic rules outlined in this manual.
- Page 6 The inlet pipe is fitted with a backflow preventer. This must never be removed. If required, it must be replaced by an original spare part (available from Valentine) or by an equivalent component, compli- ant to local regulations for water supply.
-
Page 7: Operation
3. Operation Baskets must always rest on the perforated plate. Never put the baskets directly onto the heater, it could be damaged. Heating control : The heating power can be adjusted continuously with the knob [2]. The regulation is made through variation of power, which allows the controls to operate even when the water has reached the boiling point. -
Page 8: Safety Thermostat
Safety thermostat The appliance is equipped with a safety thermostat for the heater. In case of overheating (e.g. because of lack of water) the safety thermostat will be released and switch off the heater. (Also if the room temperature drops below zero, the thermostat may also be released) During normal operation, the control light appears white as soon as the control knob is turned on and the appliance is heating. -
Page 9: Cleaning And Maintenance
4. Cleaning and maintenance Drain the cooker after every use. To do so, rotate the lever of the drain valve to the front. (When the appli- ance is new, the drain valve requires more force to rotate, this is normal) Regularly clean the pan and the heater to remove resi- dues and scale. - Page 10 If operation is paused and the water must be kept warm, reduce power to about 75%. This will avoid losses caused by boiling, and the water will remain hot. Filling of baskets : Valentine offers various baskets compatible with this cooker. Adequate filling will allow best cooking of the food. Model...
- Page 11 Declaration of conformity Liguria We manufacturer Valentine Fabrique SA Z.I. Moulin du Choc E CH - 1122 Romanel-sur-Morges Tél.: +41 21 637 37 40 Fax: +41 21 637 37 41 Mail : info@valentine.ch Internet : www.valentine.ch hereby declare that these products comply with the following directives and standards:...
- Page 12 Charactéristiques techniques — Technische Daten — Technical data Type / Typ LIG 400V 4.5kW Poids à vide, max. Leergewicht, max. 15kg Weight, empty, max. Peso en vacío, máx. Volume d’eau maximal Maximaler Wasserinhalt Maximum water volume Charge maximale de cuisson (pâtes sèches) Maximale zu kochende Charge (trockene Teigwaren) Maximum batch load (dry pasta) Consommation / valeur minimale du coupe circuit...
- Page 13 Schéma électrique / Schaltplan / Wiring diagramm...
- Page 14 Valentine Fabrique SA Z.I. Moulin du Choc E CH - 1122 Romanel-sur-Morges T +41 21 637 37 40 F +41 21 637 37 41 info@valentine.ch www.valentine.ch Ed. 05/2022 Manuel original/Originalbetriebsanleitung /Original manual ©Valentine Fabrique SA,2022...
