Owner's Manual
Portrait Flat-Panel
Fixed Wall Mount
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR
PROPERTY DAMAGE MAY OCCUR!
200 x 200 / 300 x 300
200 x 400 / 400 x 400
400 x 600
Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
18-11-269-9338E0-EN.indd 1
(with Security)
Model: DWFPSC4570M
70"
MAX
Tripp Lite по адресу: www.tripplite.com
PROTECT YOUR INVESTMENT!
www.tripplite.com/warranty
Copyright © 2018 Tripp Lite. All rights reserved.
1
110 lb.
(50 kg)
MAX
12/12/2018 11:31:59 AM

Advertisement

loading
Need help?

Need help?

Do you have a question about the DWFPSC4570M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tripp Lite DWFPSC4570M

Summary of Contents for Tripp Lite DWFPSC4570M

  • Page 1 400 x 600 Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: www.tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com...

  • Page 2: Warranty And Product Registration

    PRODUCT REGISTRATION Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary.

  • Page 3: Component Checklist

    Component Checklist IMPORTANT: Ensure all parts according to the component checklist have been received prior to installation. If any parts are missing or faulty, visit www.tripplite.com/support for service. Vertical Wall Plate (x2) Horizontal Wall Plate (x2) Security Bar (x1) Adapter Bracket (x2) M5 x 8 Screw (x8) Bubble Level (x1) Combo Lock (x1)
  • Page 4 1. Assemble the Wall Plate M5 x 8 Vertical Wall Plate Horizontal Wall Plate M5 x 8 Attach the vertical wall plates to the horizontal wall plates using the appropriate screws. Tighten all screws with a proper screwdriver. Bubble Level 18-11-269-9338E0-EN.indd 4 12/12/2018 11:32:00 AM...
  • Page 5 2a. Mount on Wood Stud Wall 55 mm (2.2 in.) O4.5 mm O(3/16 in.) Find and mark the exact location of mounting holes Drill pilot holes Washer Anchor Bolt Screw the WARNING assembled wall plate • Make sure that mounting screws are anchored into the center of the onto the wall studs.
  • Page 6 2b. Mount on Solid Brick and Concrete Block 60 mm (2.4 in.) O10 mm O(3/8 in.) Find and mark the Drill pilot holes exact location of mounting holes Concrete Anchor D6 Washer Anchor Bolt Screw the assembled wall plate onto the wall WARNING •...
  • Page 7 3. Install Adapter Brackets Adapter Bracket Protective Strips Remove the screws on the protective strips. Remove the protective strips. 3a. For Flat Back Screen M5 x 14 M6 x 14 M8 x 20 Washer Note: Choose appropriate screws, washers and spacers (if necessary) according to the type of screen.
  • Page 8 3. Install Adapter Brackets 3b. For Protruded or Recessed Back Screen M8 x 20 M6 x 30 M6 x 30 M6 x 30 M8 x 20 M8 x 30 M8 x 30 M8 x 30 Washer Washer Washer Washer Small Small Spacer Small...
  • Page 9 3. Install Adapter Brackets 3b. For Protruded or Recessed Back Screen (continued) Protective Strips Reattach the protective strips to the adapter brackets using the previously removed screws. 18-11-269-9338E0-EN.indd 9 12/12/2018 11:32:04 AM...
  • Page 10 4. Hang Display onto the Wall Plate Wall Wall Using an assistant or mechanical lifting equipment, hook the display with attached adapter brackets over the top of the mounted wall plate. Wall Wall Open the kickstands to Make sure the bracket is hold the display.
  • Page 11 5. Slide Security Bar through the Mounting Brackets and Attach Combo Lock to Secure Security Insert the security bar to the secure the rail. Security Combo Lock 18-11-269-9338E0-EN.indd 11 12/12/2018 11:32:05 AM...
  • Page 12 5. Slide Security Bar through the Mounting Brackets and Attach Combo Lock to Secure Wall Wall Security Security Fold the kickstands after finishing the security bar installation. 18-11-269-9338E0-EN.indd 12 12/12/2018 11:32:06 AM...

  • Page 13: Removing The Display

    6. Removing the Display Wall Security Bar Remove the security bar. Pull the two straps down to unlock the adapter brackets from the wall plate assembly. Wall Wall Wall Using an assistant or mechanical lifting equipment, carefully lift the display and remove the display from the wall plate.
  • Page 14 18-11-269-9338E0-EN.indd 14 12/12/2018 11:32:07 AM...
  • Page 15 18-11-269-9338E0-EN.indd 15 12/12/2018 11:32:07 AM...
  • Page 16 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 18-11-269 93-38E0_RevA 18-11-269-9338E0-EN.indd 16 12/12/2018 11:32:07 AM...
