- Page 1 Biochemical Incubator LBCI-A10 www.labtron.com info@labtron.com...
- Page 2 Biochemical Incubator LBCI-A10 Index Sr.no Title Page no Introduction Features Specifications Applications Instrument Structure Installation Operation Maintenance Troubleshooting Accessories Circuit diagram...
- Page 3 Biochemical Incubator LBCI-A10 1. Introduction Biochemical Incubator LBCI-A10 is a thermostatic incubator designed with microprocessor controlled system offers 100 L capacity and 0 to 60°C temperature range. Designed with stainless steel chamber, adjustable shelves, and glass door for clear visualization unit. High quality compressor, and CFC free refrigerant ensures stable running, efficient cooling, energy saving and protecting environment.
-
Page 4: Specifications
Biochemical Incubator LBCI-A10 3. Specifications Model No. LBCI-A10 Capacity 100 L Temperature range 0 to 60°C Accuracy ± 0.5°C Ambient temperature 0 to 60°C Temperature fluctuation ± 0.5°C Temperature uniformity ± 1°C Temperature resolution 0.1°C Chamber material Stainless steel Test hole... -
Page 5: Instrument Structure
Biochemical Incubator LBCI-A10 5. Instrument Structure... -
Page 6: Installation
Biochemical Incubator LBCI-A10 6. Installation 1. The equipment should be installed in a ventilated place to avoid direct sunlight. The distance between the equipment and the wall must be much more than 10 2. Keep the incubator balance by adjusting the screw. (Refer to technical drawing. - Page 7 Biochemical Incubator LBCI-A10 continuously. 12. “Lighting” key： lighting lamp button, press this key to turn on or turn of the lighting lamp.
- Page 8 Biochemical Incubator LBCI-A10 7. Operations 1. After power is connected, the left screen displays “index number and version number”, and the right screen displays “the max setting temperature”. It will access normal mode after 3 seconds. 2. View and set temperature and time of constant temperature.
- Page 9 Biochemical Incubator LBCI-A10 6. Without pressing any key within 1 minute in setting mode, it will be back to normal mode automatically. View and set intrinsic parameters: Long press the set key for 3 seconds, and the left screen displays “Lc”, and the right screen displays the password, you can modify the required value by the “increase”...
- Page 10 Biochemical Incubator LBCI-A10 When turning on the light lamp, it will Light lamp (0～30 mins) turn off automatically after a delay Lt delay-off If “Lt=0”, delay is unavailable, you function must turn off the light lamp manually. Control cycle Heating control cycle (1～30seconds ) 5...
- Page 11 Biochemical Incubator LBCI-A10 When ndc=2 The auto-switch (-50.0～ If setting temperature ≥ ambient point of the 50.0℃) temperature + Htd, the compressor works in compressor intermittent mode, on the contrary, it will running mode work in balanced mode. When the compressor works in intermittent mode.
- Page 12 Biochemical Incubator LBCI-A10 Intrinsic parameter -3 Parameter （range factory Parameter Parameter instruction code default When “Lc=18” view Password ambient temperature surrounding temperature of Ambient temp. the controller Notice: These intrinsic parameters have been adjusted well; it is not necessary to adjust...
-
Page 13: Maintenance
Biochemical Incubator LBCI-A10 8. Maintenance Keep upright when moving this biochemical incubator. To prolong the lifetime of equipment, don’t change the setting value frequently. This equipment is equipped with two fuses, If there is something wrong with this equipment when running, please disconnect the power supply first, check the fuse whether is undamaged then check the other parts. -
Page 14: Troubleshooting
Biochemical Incubator LBCI-A10 9. Troubleshooting Troubleshooting Handing There is something wrong with the temperature Screen displays (----) sensor, check the temperature sensor, model: PT100. The setting temperature is lower than the display temperature. Check whether the heater is damaged Temperature can’t reach... - Page 15 Biochemical Incubator LBCI-A10 Accessories S.NO. Name Quantity Finish product Instruction manual Certification Quality warranty card 2（ 70L） 2（100L） Shelf 2（150L） 2（250L） Optional Accessories S.NO. Name Printer...
-
Page 16: Circuit Diagram
Biochemical Incubator LBCI-A10 11. Circuit Diagram Labtron Equipment Ltd. Quatro House, Lyon Way, Camberley, Surrey GU16 7ER United Kingdom Email: info@labtron.com | Website: www.labtron.com...
