Kohler Serif K-1337 Installation Instructions Manual
Whirlpool
Hide thumbs
Also See for Serif K-1337:
- Installation manual (56 pages) ,
- Homeowner's manual (36 pages) ,
- Installation manual (48 pages)
Troubleshooting
Related Manuals for Kohler Serif K-1337
Summary of Contents for Kohler Serif K-1337
- Page 1 Installation Instructions Whirlpool Retain serial number for reference: Conserver le numéro de série pour référence: Guarde el número de serie para referencia:__________________________ Français, page ″Français-1″ Español, página ″Español-1″ 1193346-2-G...
-
Page 2: Installation Instructions
Do not relocate the whirlpool pump, or make other modifications to the whirlpool system, as this could adversely affect the performance and safe operation of the whirlpool. Kohler Co. shall not be liable under its warranty or otherwise for personal injury or damage caused by any such unauthorized modification. -
Page 3: Tools And Materials
• Conventional Woodworking Tools and Materials • Drop Cloth • Construction Adhesive (Optional) • Cement* or Mortar (Optional) • 2x4s • Plastic Film (Optional) • 1/8" (3 mm) Spacers * Do not use gypsum cement. 100% Silicone Sealant 1193346-2-G Kohler Co. -
Page 4: Prepare The Site
NOTICE: Measure your actual product for site preparation. Note the model number located on the whirlpool pump, then visit the product page at kohler.com for additional information. NOTICE: Provide generous, unrestricted access to the pump. Provide access for servicing the pump. The access must be located immediately next to the pump. - Page 5 NOTE: Do not use gypsum cement or drywall compound for this application, as they will not provide an acceptable, durable bond. NOTE: Lay plastic film on wooden subfloors if desired to prevent water absorption. Set the basin area in 1″ (25 mm) to 2″ (51 mm) of mortar cement. 1193346-2-G Kohler Co.
- Page 6 Install the Plumbing Insert the drain tailpiece into the trapway. Secure the drain tailpiece to the trapway. Install the faucet valve. Check the drain connections for leakage. If required, install the grab bars according to the instructions. 1193346-2-G Kohler Co.
- Page 7 NOTE: Make sure that the air actuator tubing is securely attached to the pump, and is not kinked or damaged. For units with heaters, install a second outlet behind the whirlpool and within reach of the 24″ (610 mm) heater power cord. Plug the heater plug into this outlet. 1193346-2-G Kohler Co.
- Page 8 (if included). No other load should be on these circuits. Provide a Class A GFCI or RCD. Provide a separate equipment grounding conductor for the inside ground or ground lug. The conductor must not be connected to any current-carrying conductor. Bond in accordance with national and local codes. 1193346-2-G Kohler Co.
-
Page 9: Complete The Installation
Finish the Installation IMPORTANT! Kohler Co. strongly recommends the use of 100% silicone sealant as instructed. Other sealants with high filler contents should be avoided, as they may shrink, separate, and peel over time. Install water-resistant wallboard and all finished wall, deck, and floor materials. - Page 10 12 V, must be inaccessible to a person in the whirlpool. Use this whirlpool only for its intended purpose as described in this guide. Do not use attachments not recommended by Kohler Co. The whirlpool must be connected only to a supply circuit that is protected by a Ground-Fault Circuit-Interrupter (GFCI)*.
- Page 11 For this reason, please do not use these products during whirlpool operation. Your new KOHLER whirlpool has been listed by Underwriter’s Laboratories, ensuring safety for you and your family. This whirlpool also conforms to rigid ANSI and IAPMO standards set within the plumbing industry.
-
Page 12: Care And Cleaning
NOTE: If the whirlpool does not function properly, refer to the ″Troubleshooting Procedures″ section. Care and Cleaning For best results, keep the following in mind when caring for your KOHLER product: • Always test your cleaning solution on an inconspicuous area before applying to the entire surface. - Page 13 Run the whirlpool for 5 to 10 minutes. Turn off the whirlpool and drain. If desired, rinse the bath surfaces with water. Rinse the surfaces of the jets, faucet, grab bars, and drain, and wipe them dry with a soft cloth. 1193346-2-G Kohler Co.
-
Page 14: Troubleshooting
Troubleshooting NOTICE: This section is for general aid only. A Kohler Co. Authorized Service Representative or qualified electrician should correct any electrical problems. For warranty service, call 1-800-4KOHLER from within the USA and Canada, or 001-800-456-4537 from within Mexico. - Page 15 A. No power to heater. A. Reset the GFCI or RCD. (“H” models only) B. Water temperature exceeds 104°F B. Allow water to cool and heater (40°C). will re-engage. C. Heater does not work. C. Replace heater. 1193346-2-G Kohler Co.
- Page 16 Installation Guide Drop-In Bath Whirlpool K-1106, K-1112, K-1114, K-1126, K-1131, K-1139, K-1144, K-1146, K-1148, K-1154, K-1157, K-1160, K-1162, K-1164, K-1192, K-1194, K-1201, K-1209, K-1221, K-1224, K-1226, K-1239, K-1244, K-1246, K-1248, K-1257, K-1263, K-1337 M product numbers are for Mexico (i.e. K-12345M) Los números de productos seguidos de M corresponden a México (Ej.
-
Page 17: Important Information
Do not relocate the whirlpool pump, or make other modifications to the whirlpool system, as this could adversely affect the performance and safe operation of the whirlpool. Kohler Co. shall not be liable under its warranty or otherwise for personal injury or damage caused by any such unauthorized modification. -
Page 18: Table Of Contents
Inspect the whirlpool for damage before you begin installation. Confirm adequate mounting and connection space for the faucet specified for your installation. Kohler Co. reserves the right to make revisions in the design of products without notice, as specified in the Price Book. -
Page 19: Prepare The Site
Carefully lay out and cut the rough deck material. Use the cut-out template, if one is provided, or refer to the Roughing-In Guide for cutout information. Position the plumbing according to the roughing-in information packed. Cap the supplies, and check for leaks. 1010564-2-K Kohler Co. -
Page 20: Prepare The Whirlpool
Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool. Option Using Construction Adhesive Apply a generous amount of high-quality construction adhesive to the bottom of the support blocks. With help, carefully lift the whirlpool into position. Kohler Co. 1010564-2-K... - Page 21 Insert the drain tailpiece into the trap. Ensure the whirlpool is level and resting on all support blocks. Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool. 1010564-2-K Kohler Co.
-
Page 22: Secure The Whirlpool To The Stud Framing
Use #6 large-head galvanized nails to secure the nailing-in flange to the studs. For tile ledge installations, size and install a pressure-treated wood batten along the nailing-in flange. Pre-drill nail holes through the wood batten and nailing-in flange before securing with galvanized nails. Kohler Co. 1010564-2-K... -
Page 23: Secure The Unit - Models With Whirlpool Base
Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool. Option Using Silicone Sealant With help, carefully lift the whirlpool into position. 1010564-2-K Kohler Co. - Page 24 floor. Drill small pilot holes through the whirlpool base as needed. Remove the protective tape from the rim. Apply a continuous bead of high-quality silicone sealant around the entire rim of the whirlpool. Kohler Co. 1010564-2-K...
-
Page 25: Cut The Pump Banding Straps
NOTE: If your pump model does not have banding straps, proceed to the next section. IMPORTANT! This step is necessary to make your Kohler whirlpool operate more quietly. NOTE: Do not raise the pump higher than it was before you cut the pump banding straps. If the pump is raised too high, it will not prime properly. -
Page 26: Install A Rim-Mounted Faucet
Install the faucet to the rim and plywood according to the faucet manufacturer’s instructions. Open the hot and cold water supplies, and check the supply connections for leakage. Run water into the whirlpool, and check the drain connections for leakage. Kohler Co. 1010564-2-K... -
Page 27: Make Electrical Connections
Fill the whirlpool to a level at least 2″ (5.1 cm) above the top of the highest jet. Refer to ″Confirm Proper Operation″ section for additional information. Operate the whirlpool for 5 minutes, and check all whirlpool piping connections for leaks. 1010564-2-K Kohler Co. -
Page 28: Complete The Finished Deck
Tape and mud the water-resistant deck material. Install the finished deck to the water-resistant deck material. Seal the joints between the whirlpool rim and the finished deck material with silicone sealant. Install the faucet trim according to the trim manufacturer’s instructions. Kohler Co. 1010564-2-K... -
Page 29: Complete The Finished Wall
Remove plaster by carefully scraping with a wood edge. Do not use metal scrapers, wire brushes, or other metal tools. Use a powder-type detergent on a damp cloth to provide mild abrasive action to any residual plaster. 1010564-2-K Kohler Co. -
Page 30: Confirm Proper Operation
If equipped with a heater, the heater will engage automatically when the pump is turned on and will disengage when the pump is turned off. The heater will not turn on if the water temperature exceeds 104°F (40°C). Press the air actuator a second time to turn off the whirlpool. Kohler Co. 1010564-2-K... -
Page 31: Troubleshooting
Insert the jet into the housing, and lightly push and rotate until it snaps in position. Troubleshooting NOTICE: This section is for general aid only. A Kohler Authorized Service Representative or qualified electrician should correct any electrical problems. For warranty service, contact your dealer or wholesale distributor. - Page 32 (units with the pump. the connection has power. heaters only). B. The water temperature is above 104°F B. As a safety precaution, the heater will not (40°C). operate when the water temperature is above 104°F (40°C). Kohler Co. 1010564-2-K...
