- Page 1 USER’S MANUAL C34GSK BOARD Rev. 1.1 NOVEMBER 2014...
-
Page 2: Table Of Contents
USER'S MANUAL TABLE OF CONTENTS Page # Contents OVERVIEW ........................1 FEATURES ........................1 BOARD DESCRIPTION ....................1 JUMPER TO SELECT THE ENABLE ................2 WIRING SAMPLE ......................3 PINOUT ........................... 4 DIMENSION ........................5 User’s Manual Page i... -
Page 3: Overview
OVERVIEW This interfaces board is used for the connection between C35, C32 or C62 and the GSK (DA98B - DA98D) AC SERVO DRIVE. FEATURES • DB44M connector for Connection of Driver. • RJ45 Connector for Axis. • Select Jumper for Hard Enable or Soft Enable. •... -
Page 4: Jumper To Select The Enable
JUMPER TO SELECT THE ENABLE Use Software Enable to keep the driver active only while the system is active. Set of jumper as shown in the image SOFT ENABLE Use Hardware Enable to keep the driver enabled all the time. Set of jumper as shown in the image HARD ENABLE User’s Manual... -
Page 5: Wiring Sample
WIRING SAMPLE Note: This wiring is just to illustrate a sample product application. Specific wiring may vary from system to system. It is the user’s responsibility to implement it correctly. User’s Manual Page 3... -
Page 6: Pinout
PINOUT GSK AC SERVO DRIVE AND C34GSK CONNECTION HDM44D PIN RJ45 PIN FUNCTION ALARM 4(GND) DIR- 4(GND) STEP- Internally SERVO ON routed DIR+ STEP+ 4(GND) COM- 4(GND) COM- COM+ COM+ COMPATIBLE DRIVER GSK DA98B, GSK DA98D User’s Manual Page 4... -
Page 7: Dimension
DIMENSION All dimensions are in Millimeters. DISCLAIMER Use caution. CNC machines could be dangerous machines. DUNCAN USA, LLC or Arturo Duncan are not liable for any accidents resulting from the improper use of these devices. This product is not fail-safe device, and it should not be used in life support systems or in other devices where its failure or possible erratic operation could cause property damage, bodily injury or loss of life.
