INSTALLATION GUIDE
Draw wire mechanics SX
For further information please see the data sheet at
www.waycon.biz/products/draw-wire-sensors
FIRST STEPS
WayCon Positionsmesstechnik GmbH would like to thank you for the trust you have placed in us and
our products. This manual will make you familiar with the installation and operation of our draw wire
sensors. Please read this manual carefully before initial operation!
Unpacking and checking:
Carefully lift the device out of the box by grabbing the housing. Do not pull the rope. After unpacking
the device, check it for any visible damage as a result of rough handling during the shipment. Check
the delivery for completeness.
If necessary consult the transportation company, or contact WayCon directly for further assistance.
MOUNTING OF THE SENSOR
• Please start by mounting the encoder to the SX draw wire mechanics. A description is given on the
following pages.
• Next mount the sensor at the designated place by using the fixing holes before extracting the rope
and before attaching the rope to the measuring target.
• Depending on the sensor model it can be installed either by using the boreholes in the mounting
plate or by using the supplied T-slot nuts/clamp brackets. You will find a detailed description of both
installation methods in this installation guide.
• Open the rope clip after the sensor is fully mounted and carefully extract the measuring rope. Hook
the rope clip on the measuring target and close the bracket of the clip. For safety reasons put a screw
driver through the clip to extract the rope.
HANDLING THE WIRE ROPE
• When installing or operating the sensor, take care not to let the rope snap back by mistake or extract
the rope over the specified measurement range, as this might destroy the sensor.
• The rope must be extracted from the sensor vertically. The maximum variation from the vertical is
3°. Avoid extracting the rope at an inclination, since the durability of the instrument would shorten
considerably. If it is not possible to keep the limit of 3°, a deflection pulley has to be used.
• Guide the rope preferably in corners or guarded in channels to prevent pollution or accidental touch.
• Avoid guiding the rope over edges or corners. Use a deflection pulley instead.
• Do not operate the sensor if the rope is buckled or damaged. A ripping of the rope may lead to
injuries or a damaging of the sensor.
Advertisement
Related Manuals for Waycon SX80
Summary of Contents for Waycon SX80
- Page 1 FIRST STEPS WayCon Positionsmesstechnik GmbH would like to thank you for the trust you have placed in us and our products. This manual will make you familiar with the installation and operation of our draw wire sensors. Please read this manual carefully before initial operation! Unpacking and checking: Carefully lift the device out of the box by grabbing the housing.
- Page 2 MOUNTING AN ENCODER Mounting an encoder to draw wire mechanics SX80, SX120 and SX135 up to 8 m The F58NK draw wire mechanics allows a fast and easy encoder assembly by the customer. A detailed description of the mounting procedure is shown in the following pictures.
- Page 3 MOUNTING AN ENCODER Mounting by clamping flange 3. By tightening (approx. 2 Nm) the inner radial screw with a hexagon screwdriver, size 2.5 the encoder shaft will be clamped to the sensor mechanics and is secured from twisting. 4. By tightening (approx. 2 Nm) the outer radial screw with a hexagon screwdriver, size 2.5 the encoder housing will be clamped to the sensor housing and is secured from twisting.
- Page 4 MOUNTING AN ENCODER Mounting an encoder to draw wire mechanics SX135 with measurement range 10 m and above The SX135 with measurement ranges 10 m or greater is available in a version (F58K) prepared for an encoder assembly by the customer. You will find a detailed 3 step description of this EASY-Clamp-Mechanism in the next section.
- Page 5 MOUNTING AN ENCODER Easy-Clamp-Mechanism 3. By tightening (1.5 Nm) the radial screw the encoder will be clamped and secured from twisting. Use a hexagon screwdriver, size 3. The system is now ready to be mounted at the designated place.
- Page 6 MOUNTING THE SENSOR SX80 AND SX120 Mounting standard rope outlet, rope outlet sideways top (S1) The sensor is usually installed by using the regular mounting plate. By disassembling the mounting plate, there are 2 x M4 threads in the sensor housing for alternative installation:...
- Page 7 MOUNTING THE SENSOR SX135 1. Mounting via T-slot nuts The included T-slot nuts can be easily inserted into the grooves of the sensor housing. The nuts have a metric thread M6. Two (up to 20 m measurement range) or four (more than 25 m measurement range) T-slot nuts are included in the delivery.
-
Page 8: Warning Notices
The devices are maintenance-free. If however, the rope is soiled due to adverse environmental conditions, it can be cleaned with a cloth drenched in resin-free machine oil. DECLARATION OF EU-CONFORMITY Manufacturer WayCon Positionsmesstechnik GmbH Mehlbeerenstrasse 4 82024 Taufkirchen / Germany This is to certify that the products...
