- Page 1 Soft Starter VersiStart II plus 6-32A Assembly- and Commissioning Instructions Original Quality is our Drive.
-
Page 2: Table Of Contents
VS II plus as per 04/25 16300.10005 Table of Contents Page Quick start Safety notes Conformity General description Usage to the intended purpose EC Declaration of Conformity Block diagram Commissioning Mounting instructions Connection Parameter settings Starting frequency Starting and stopping Soft start Soft stop 10. -
Page 3: Disposal Instructions
VS II plus These commissioning instructions were prepared with great care. Nevertheless, PETER electronic GmbH & Co. KG does not assume liability for damage resulting from mistakes possibly contained in this manual. Technical changes that serve to improve the product are subject to change without notice. -
Page 4: Quick Start
VS II plus Quick start 6-12A 22-32A Current rating Current rating AC-Power Supply 3x 200...480VAC -15% / +10% 50/60Hz Fuses: See Chapter 13 “Dimensioning rules” LED's to display the operating states, see Chapter 11 "LED indica- tors" 3 potentiom eters for setting the starting time, starting voltage and stopping time. -
Page 5: Safety Notes
Caution: Even if the motor is at rest, it is not physically separated from the mains. Conformity In industrial linguistic usage the drive controllers of the type series VersiStart II plus 6-32A are called "devices", however, in the sense of the "law on the safety of equipment", the "EMC-law" or the "EC-maschinery directive"... -
Page 6: General Description
VS II plus General description In the case of the soft starters of the VersiStart II plus 6-32A type the motor voltage is changed in two phases (1L1/3L2) by a generalized phase control and power semiconductors. Starting from an adjustable starting trigger angle the trigger angle is continually reduced. Via the adjusted ramp-up time the motor voltage increases according to a ramp function until the maximum value is reached. -
Page 7: Ec Declaration Of Conformity
VS II plus EC Declaration of Conformity EC Declaration of Conformity The manufacturer / company placing the product on the market (authorized representatives of the manufacturer / companies placing the product on the market that are established within the Community) Name / Address: PETER electronic GmbH &... -
Page 8: Block Diagram
VS II plus Block diagram +24V control supply U L01 (Out) supply voltage t on t off Electronics BOOST Trigger- Ramp- pulse control generator LI2 (Start) U start Control LI1 (Stop) bypass relay output Commissioning The device is to be put into operation in 3 steps: 1. -
Page 9: Mounting Instructions
The following conditions are to be complied with in order to ensure a safe and reliable operation of the VersiStart II plus 6-32A. 1. The device series VersiStart II plus 6-32A is to be used under conditions of the overvoltage category III. -
Page 10: Screw Mounting
VS II plus Place the device vertically on a vertical mounting surface. The motor terminals must be mounted downwards. The devices can be attached to the mounting surface using screw mounting or by snapping onto standard rails in accordance with DIN EN 50022: Screw mounting: Drilling pattern 6 - 12A devices Drilling pattern 22 - 32A devices... -
Page 11: Connection
Control supply voltage Us The VersiStart II plus 6-32A device series is supplied with a direct voltage of 24VDC ±10% / 100mA between the terminals LI+ and COM. Caution: Danger to life through electric shock! -
Page 12: Parameter Settings
VS II plus Parameter settings On the front panel there are 3 potentiometers by means of which the following settings can be made. Parameter Poti Setting range Acceleration time Acceleration time adjustable from 1...10sec Starting voltage 30…80% of rated voltage Start Deceleration time adjustable from 1...10sec... -
Page 13: Starting And Stopping
VS II plus Starting and stopping Soft start With VersiStart II plus 6-32A devices, different starting methods can be selected: 1. Voltage ramp: 2. Boost function: 1. Start with voltage ramp: In this case, motor starting is time-controlled, with a voltage ramp adjustable within a range... - Page 14 VS II plus 2. Start with boost function: If a high level is applied to the “BOOST” input, the device switches to the “soft start with boost” function. At the beginning of the soft start, the motor voltage is increased to 80% of the mains voltage for a short pulse (300ms).
-
Page 15: Soft Stop
Note: To enable soft stop, the VersiStart II plus 6-32A, during the deceleration phase, has to be supplied with power from the supply mains. In the case of these devices, the cut-off voltage is factory-set to 70%. -
Page 16: Control In- And Outputs
VS II plus 10. Control in- and outputs Connection Description Input/ Properties Output Open collector output. Output Digital Output Output switches when start-up ramp is com- pleted. BOOST Activation of boost Input 27 kOhm impedance function Power supply Input +24VDC ± 10 % (max. 28V / 100mA) LI2 Start Start input Input... -
Page 17: Technical Data
VS II plus 12. Technical data VS II plus VS II plus VS II plus VS II plus VS II plus Technical specifications 480-6 B, 24VDC 480-9 B, 24VDC 480-12 B, 24VDC 480-22 B, 24VDC 480-32 B, 24VDC device rated current motor rated power at 4,5kW 5,5kW... -
Page 18: Environmental Conditions
VS II plus 12.1 Environmental conditions Storage temperature -25 ... 85°C Ambient temperature -10 ... 50°C up to 1000m installation height, non-conden- sing Power reduction Derating: higher 40°C - 2% per °C up to max. 50°C Degree of protection IP 20 Environment Overvoltage categ. - Page 19 VS II plus Short circuit protection according to IEC 60947-4-2 edition 4.0 - with fuse type gG Device Typ Icc @440V 3Ph Fuse value in coor- Fuse type dination class “1“ (recommendation) NH0gG VS II plus...-6... NH0gG VS II plus...-9... NH0gG VS II plus...-12...
-
Page 20: Determining The Permissible Starting Frequency
VS II plus 13.2 Determining the permissible starting frequency: The starting frequency depends on the: 1. starting current or the heat loss across the power semiconductors. 2. ambient temperature. 3. current carrying capacity and the temperature increase of the power semiconductors. 4. - Page 21 VS II plus...
-
Page 22: Installation Guideline
VS II plus 14. Installation guideline The devices are to be installed into a switchbox or switchgear cabinet according to point 8. It must be ensured that the switchbox/switchgear cabinet is capable of dissipating the occurring heat loss (see techn. data). 14.1 Connection The device is to be installed according to the attached connection diagram. -
Page 23: Connection Examples
VS II plus 14.2 Connection examples 14.2.1 2-/3-wire control with motor protection switch 200...480VAC +24VDC 50/60Hz I> I> I> LO1 Out LI1 Stop VS II plus... LI2 Start 3-wire control 2-wire control BOOST... - Page 24 VS II plus Functional diagram for the 2-wire control: Control Supply Voltage Power Supply Voltage Green LED Logic Input LI2 Start Relay Output R1A/R1C Yellow LED Motor Voltage Functional diagram for the 3-wire control: Control Supply Voltage Power Supply Voltage Green LED Logic Input LI2 Start Logic Input LI1 Stop...
- Page 25 VS II plus 14.2.2 3-wire control with motor contactor and overload relay 200...480VAC +24VDC 110...230V 50/60Hz - f1 LO1 Out VS II plus... LI1 Stop -KM1 BOOST R1C LI2 Start (KM1) (-KM1)
- Page 26 LO1 Out Yellow LED Boost 200ms Boost Motor Voltage Note: Further connection diagrams for special circuit arrangements are available on our homepage at www.peter-electronic.com. Note: Prior to putting the VersiStart II plus 6-32A into operation the wiring is to be checked.
- Page 27 VS II plus...
- Page 28 VS II plus...
- Page 29 VS II plus...
