Century SDU3 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CENTURY
®
L E G E N D A R Y
L E A D E R S H I P
OWNER'S MANUAL
1060 / SDU3
INSTALLATION, OPERATION, MAINTENANCE & PARTS
NOTE: MANUAL including SPECIFICATIONS, subject to change without notice
All ratings specified are based on structural factors only,
not vehicle capacities or capabilities.
CENTURY
®
Miller Industries Towing Equipment Inc.
8503 Hilltop Drive
FORM NO. 0501015
Ooltewah, Tennessee 37363
REV. A
03 / 2006
Phone (423) 238-4171 • FAX (423) 238-5371
PRICE $25.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SDU3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Century SDU3

Summary of Contents for Century SDU3

  • Page 1 L E G E N D A R Y L E A D E R S H I P OWNER'S MANUAL 1060 / SDU3 INSTALLATION, OPERATION, MAINTENANCE & PARTS NOTE: MANUAL including SPECIFICATIONS, subject to change without notice All ratings specified are based on structural factors only, not vehicle capacities or capabilities.
  • Page 2 LIMITED WARRANTY MILLER INDUSTRIES TOWING EQUIPMENT INC., hereinafter referred to as MILLER, warrants to the original purchaser that each new MILLER wrecker or other MILLER products will be free from defects in material and workmanship for a period of twelve (12) months from date placed in service, but in no event shall such warranty period exceed twenty-four (24) months from date of manufacture by MILLER. The purchaser must promptly notify MILLER in writing of any failure in material or workmanship. In no event shall MILLER accept such notification later than twenty-four (24) months from date of delivery or twelve (12) months from date placed in service, whichever is earlier. MILLER's obligation under this warranty, statutory or otherwise, is limited to the repair or replacement at the MILLER factory, or at a point designated by MILLER, of such part or parts as shall appear upon inspection by MILLER to be defective in material or workmanship. New or remanufactured parts will be used for any replacement at MILLER's option. This warranty is not transferable. This warranty does not obligate MILLER to bear the cost of labor or transportation charges in connection with the repair or replacement of any parts found to be defective, nor shall it apply to a product upon which repairs or alterations have been made unless authorized by MILLER. EXCEPT A S EXPRESSLY SET FORTH IN THIS WARRANTY, MILLER MAKES NO OTHER WARRANTY, EXPRESS OR IMPLIED, AND HEREBY DISCLAIMS ALL OTHER WARRANTIES INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. MILLER shall in no event be liable for claimed downtime, claimed loss of...
  • Page 3 OWNER, USER AND OPERATOR: Century appreciates your choice of our wrecker for your application. Our number one priority is user safety which is best achieved by our joint efforts. We feel that you can make a major contribution to safety if you, as the equipment owner and operator: 1.

  • Page 4: Table Of Contents

    BODY ASSEMBLY ....... VI-4 & VI-5 SDU3 ASSEMBLY ....... VI-6 & VI-7...
  • Page 5 SDU3 LIFT & EXTEND HYDRAULICS ....VI-8 & VI-9 SDU3 TILT & FOLD HYDRAULICS ....VI-10 & VI-11 LIFT ADAPTERS .
  • Page 6 NOTES...

  • Page 7: Section I - Safety Precautions

    These recommendations are contained in this manual. Century is not responsible for the results of any unsafe practice of wrecker operators. Furthermore, the division is not responsible for the failure of the wrecker or its accessories resulting from improper maintenance.
  • Page 8 Section I - SAFETY PRECAUTIONS (cont'd) 1.1 Improper use of this equipment can be dangerous! Incorrect operation can result in bodily injury to the operator and bystanders. Therefore, a thorough understanding of the "operating principles" and "operating instructions" as found in this manual is essential. 1.2 Study each job to be done.
  • Page 9 Section I - SAFETY PRECAUTIONS (cont'd) MOVE IN SERVICE, AND REPLACE IF NECESSARY. SECURE ALL CAPS AND FILLER PLUGS FOR ALL SYSTEMS. 6. YOUR CLOTHING SHOULD BE RELATIVELY CLOSEFITTING. 7. ALWAYS WEAR PROTECTIVE ITEMS SUCH AS SAFETY GLASSES, GLOVES, REFLECTIVE CLOTHING AND SAFETY SHOES. 8.
  • Page 10 Section I - SAFETY PRECAUTIONS (cont'd) ONLY AUTHORIZED AND TRAINED PERSONNEL SHOULD BE PERMITTED TO OPERATE THIS WRECKER UNSUPERVISED. TRAINED PERSONNEL ARE THOSE WHO HAVE WORKED UNDER EXPERIENCED SUPERVISION AND HAVE PERFORMED ALL WRECKER MANEUVERS, HAVE READ THE MOUNTING, OPERATING AND MAINTENANCE MANUAL, WARNINGS AND PRECAUTIONS, AND UNDERSTAND AND HAVE HAD EXPLAINED TO THEM BY THEIR EMPLOYER THE HAZARDS OF OPERATING...
  • Page 11 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Death or serious injury can occur when working near power lines. Learn - beforehand - as much about your working area as possible. Be sure that exact locations of overhead power lines, and other obstructions or hazards are known.
  • Page 12 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Proper technique for using wire rope clips. USE CABLE CLIPS ONLY IN THE EVENT OF AN EMERGENCY FIELD TEMPORARY REPAIR. RIGHT WRONG 1. Turn back rope length specified in the chart. Apply first clip so U-bolt is no less than the saddle width from the dead end. Tighten nuts evenly and torque as specified.
  • Page 13 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't use a wrecker that has not been properly maintained. Pay special attention to wrecker mounting bolts, cable condition, and lubrication of moving parts. Don't use damaged cables on your wrecker. Become familiar with the various types of cable damage and carefully inspect all cables being used in a recovery operation before...
  • Page 14 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't expect your wrecker to tow loads equal to the wrecker rating. Wrecker ratings apply to loads imposed during recovery, with the wrecker properly stabilized. Don't pull a load with your wrecker without making absolutely sure that the winch drum clutch is FULLY engaged.
  • Page 15 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't get under a raised vehicle or load unless it has adequate safety blocks in place. Don't exceed WORKING LIMIT ratings of cable. Use breaking strength ratings only for selecting replacement cable. Don't tie down the front end of your wrecker for recovery work or heavy lifts.
  • Page 16 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't lower outboard legs or rear spades unless area under them is clear. Pay particular attention to keeping this area clear. Don't use rear spades on paved surfaces unless you are willing to accept responsibility for possible damage to such surfaces.
  • Page 17 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't completely unwind all cable from a winch while loaded. Keep AT LEAST five wraps on the drum. Don’t operate your wrecker ’s engine faster than recommended. Excessive speeds can damage PTO shafts, hydraulic pumps and winches. Don’t rely on anti-theft steering locks.
  • Page 18 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't use towing forks that are not of proper size for pick-up requirements. After you have hooked up a vehicle for towing, don't start the tow until you have double checked the hook-up, installed safety chains and released the parking brakes on the towed vehicle.
  • Page 19 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don't tow a vehicle on its front wheels if they are damaged. Don't tow a vehicle on its front wheels unless the steering wheel is secured with the front wheels straight ahead. Don't tow a vehicle at night without proper signal lights on the towed vehicle and the wrecker.
  • Page 20 Section I - SAFETY PRECAUTIONS (cont'd) SAFETY TIPS Don’t move wrecker or extend boom where overhead power lines may be encountered. Don’t continue to wind in winch cable after the hook is against the boom end. SAFE TOWING There are two key factors in safe towing: 1. Have enough front axle weight for safe steering.
  • Page 21 Section I - SAFETY PRECAUTIONS (cont'd) SAFE TOWING To use the formula, multiply the unladen weight at the front axle by .5. Multiply the result by the wheel bases. Then, divide that result by the overhang. So, you should calculate the maximum lifted load for each tow truck, using this formula, post those limits in the truck and instruct each driver to strictly observe those limits. You should also observe gross vehicle weight ratings (GVWR), gross axle weight ratings (GAWR), and the towing equipment ratings.
  • Page 22 NOTES...

  • Page 23: Section Ii - Specifications

    Section II - SPECIFICATIONS 2.1 Federal law requires that the final stage manufacturer, i.e., that person or company installing new equipment on a new chassis, must certify the completed vehicle by obtaining, completing and affixing to the door post on the drivers side of the vehicle, a Certification Label similar to the one shown. See Figure 2.1. FIGURE 2.1 II-1...
  • Page 24 Section II - SPECIFICATIONS (cont'd) 2.2 SERIAL NUMBER/SPECIFICATION LABELS Each Century 1060 Wrecker will have a Serial Number/Specification Label mounted on the wrecker frame and each Century Underlift will have a Serial Number/Specification Label mounted on the outer boom support. These labels will display the Model Number, Serial Number, Lift/Tow and Cable Ratings. 2.3 SPECIFICATIONS - 1060 WRECKER (a) Winches Planetary variable speed winches with 50,000 lb. rating on first layer of each drum, air kickout, and fail safe brake. (b) Cable Diameter and Length (Each Drum) ..3/4” dia. x 250 ft. Type....... . .6 x 37 IWRC, XIPS Working Limit, Each Line.
  • Page 25 Section II - SPECIFICATIONS (cont'd) 2.4 SPECIFICATIONS - SDU/3 UNDERLIFT Structural Rating: First Stage ........45,000 lbs. Second Stage .
  • Page 26 Section II - SPECIFICATIONS (cont'd) 2.6 STANDARD FEATURES - 1060S WRECKER • 3 Stage Hydraulic Pump • Dual 45,000 Lb. Variable Speed Hydraulic Planetary Winches • 250' Winch Cable, Each Drum • 360° Directional Boom End Swivels • Power Boom Elevation and Extension • Holding Valves on Boom Elevation and Extension, and Rear Spade Elevation • Spring Loaded Winch Cable Hook Storage • Nylatron Slide Pads in Boom • Lubrication Fittings an All Shafts and Other Moving Parts • 96" Wide Heavy Duty Body with Flat Floor • Modular Body • Hydraulic Rear Spades with Removable Pads • Four Rear Tie-back Loops on Tailgate • Dual Control Stations • Vernier Throttle Control • Pressure Gauges • Mud Flaps...

  • Page 27: Optional Equipment

    Section II - SPECIFICATIONS (cont'd) 2.8 OPTIONAL EQUIPMENT • Truck Hitch with Hook-Up Chains • Spotlights • Convenience Group • Snatch Blocks • Tool Compartment Lights • Work Lights Below Tailgate • Pintle Hook Attachment • Fifth Wheel Adapter • Heavy Duty Wheel Lift • Lightweight Aluminum Boxes • Aerodynamic Light Pylon • Aluminum Package Note: Specifications Subject to Change without Notification. II-5...
  • Page 28 NOTES...

  • Page 29: Section Iii - Operational Functions

    Section III - OPERATIONAL FUNCTIONS WRECKER 3.1 Your new CENTURY 1060 Wrecker is fully hydraulic. It receives its power by means of a Power Take-Off/Pump combination mounted to the truck transmission. Since the pump is attached to the PTO, no drive line or universal joints are required.
  • Page 30 Section III - OPERATIONAL FUNCTIONS WRECKER (cont'd) 3.4 The Control Handles are clearly marked as to their functions and directions. Movement of the control handles meters the flow of oil through valves to control the speed of each function. Each valve is equipped with a pressure gauge to monitor the hydraulic pressure during the operation.
  • Page 31 Section III - OPERATIONAL FUNCTIONS WRECKER (cont'd) 3.8 The winch air free spool switches are located at the left side control station. When activated, the winch clutch is disengaged and the drum will free spool. NOTE THE CONTROL SWITCH ON THE SWITCH PANEL IN THE TRUCK CAB MUST BE ON FOR THE FREE SPOOL SWITCHES TO OPERATE.
  • Page 32 NOTES...

  • Page 33: Underlift

    Section IIIA - OPERATIONAL FUNCTIONS UNDERLIFT 3A.1 Your new Underlift is fully hydraulic. It receives its power from the truck engine by means of a Power Take-Off/Pump combination attached to the vehicle transmission. Since the pump is attached directly to the PTO, no drive line or universal joints are required. 3A.2 Each function of the Underlift can be controlled from the Control Station located in the left rear compartment of the body, or from the Hand Held Remote Control Unit located in the right rear compartment.
  • Page 34 Section IIIA - OPERATIONAL FUNCTIONS UNDERLIFT (cont'd) 3A.7 Lifting forks and other Underlift towing and lifting accessories are located in the left hand Tool Box of the wrecker body. See Figure 3A.1. FIGURE 3A.1 IIIA-2...

  • Page 35: Section Iv - Operating Instructions

    Section IV - OPERATING INSTRUCTIONS WRECKER 4.1 For reasons of safety, it is important that the Owner(s) and Operator(s) become thoroughly familiar with the controls and functions of the wrecker before attempting any operation. 4.2 HYDRAULIC WINCHES (a) DO NOT fasten the winch hook directly to any vehicle. (b) DO NOT wrap the winch cable around any object.
  • Page 36 Section IV - OPERATING INSTRUCTIONS WRECKER (cont'd) 4.4 CABLE PAYOUT Before operating any control handles, observe the winch cables to make sure they are free and have sufficient slack to allow the boom to extend. If not, pay out cable by using the Cable “IN/OUT” Controls. Maintain tension on cable during payout to avoid fouling line. If manually paying out cable, switch on the Air Free Spool switch and pull cables out to sufficient length for boom extension.
  • Page 37 Section IV - OPERATING INSTRUCTIONS WRECKER (cont'd) 4.6 REAR SPADES (cont'd) STAND CLEAR WHILE OPERATING REAR SPADES USE SAFETY CHAINS ON ALL TOWING AND LIFTING APPLICATIONS IV-3...
  • Page 38 NOTES...
  • Page 39 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT 4A.1 For reasons of safety, it is important that the Owners and Operator(s) become thoroughly familiar with its controls, components and load requirements before attempting any operation. 4A.2 PREPARING TO LOAD VEHICLE (a) Align wrecker with vehicle to be towed. (b) Reduce truck’s engine to an idle, and apply parking brake.
  • Page 40 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.3 UNDERLIFT OPERATION (a) Each function of the underlift can be controlled using the Hand Held Remote Control Unit or by the control handles at the left control station. (b) Press FOLD "DOWN" button until Underlift Boom is all the way down.
  • Page 41 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.4 (cont'd) FIGURE 4A.2 IVA-3...
  • Page 42 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.5 AXLE LIFT (USING FORKS) NOTE STEPS A THRU D ARE NOT REQUIRED IF AXLE IS HIGH ENOUGH TO PERMIT EXTENSION OF CROSSBAR UNDER AXLE WITH FORKS INSTALLED. (a) Press "OUT" button and extend the Underlift Boom (without forks attached) until crossbar is centered with front axle of disabled vehicle.
  • Page 43 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.5 AXLE LIFT (USING FORKS) (cont'd) FIGURE 4A.3 FIGURE 4A.4 IVA-5...
  • Page 44 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.5 AXLE LIFT (USING FORKS) (cont'd) (h) Select forks suited for job and install in fork adapters on crossbar. See Figure 4A.5. FIGURE 4A.5 (i) Press "OUT" button to extend boom until forks are under axle. NOTE TILT BOOM DOWN, AS REQUIRED, USING "TILT DOWN"...
  • Page 45 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.5 AXLE LIFT (USING FORKS) (cont'd) FIGURE 4A.6 (l) Press "TILT UP" button and bring forks into contact with axle. If necessary, press "UP" button to raise boom. (m) Attach safety chains around axle, crossbar tube and forks as shown in Figure 4A.7.
  • Page 46 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.5 AXLE LIFT (USING FORKS) (cont'd) USE SAFETY CHAINS ON ALL TOWING AND LIFTING APPLICATIONS. (n) Press "UP" button to raise vehicle to desired height for towing. (o) Remove blocks if previously placed under front wheels. MAKE NO ATTEMPT TO USE THE FOLD FEATURE OF THE UNDERLIFT BOOM TO RAISE OR PICK UP A LOAD.
  • Page 47 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.6 SPRING LIFT (a) Press "DOWN" button and lower boom completely. (b) Loosen "T" handles on fork adapters and slide adapters onto crossbar. (c) Position fork adapters in desired position on crossbar. (Fork adapters may be placed in any of four (4) positions).
  • Page 48 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.6 SPRING LIFT (cont'd) FIGURE 4A.9 (g) Tighten "T" handles on adapters. Make sure retaining pins at ends of crossbar are secure. (h) Press "UP" button and raise boom until brackets are properly seated under springs at front spring hanger brackets.
  • Page 49 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.6 SPRING LIFT (cont'd) USE SAFETY CHAINS ON ALL TOWING AND LIFTING APPLICATIONS NOTE MAKE SURE THERE IS ENOUGH SLACK IN SAFETY CHAINS TO PERMIT TURNING. (n) Stow remote control unit and give hookup a final check before commencing towing operation. 4A.7 TRUCK WHEEL LIFT (OPTIONAL) (a) Press "DOWN"...
  • Page 50 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.7 TRUCK WHEEL LIFT (cont'd) FIGURE 4A.10 FIGURE 4A.11 (g) Before lifting dual axle vehicles from the rear, install 5/16" high test tow chains on both sides of vehicle to be towed. Attach one end of chain around forward axle, over frame rail and back around axle.
  • Page 51 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.7 TRUCK WHEEL LIFT (cont'd) (i) Raise vehicle to desired height for towing. (j) Attach tiedown strap hooks to outer crosstube and tire support and place strap over tire as shown in Figure 4A.12. FIGURE 4A.12 (k) Release tiedown strap ratchet and pull out sufficient length of strap to insert ratchet hook into hole in the adjustment tube.
  • Page 52 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.7 TRUCK WHEEL LIFT (cont'd) USE SAFETY CHAINS ON ALL TOWING AND LIFTING APPLICATIONS. NOTE MAKE SURE THERE IS ENOUGH SLACK IN SAFETY CHAINS TO PERMIT TURNING. (p) Stow remote control unit and give hookup a final check before commencing towing operation. 4A.8 KINGPIN ADAPTER (OPTIONAL) (a) Install Fork Adapters on crossbar as shown in Figure 4A.13.
  • Page 53 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.8 KINGPIN ADAPTER (cont'd) NOTE PINTLE HOOK MUST BE REMOVED FROM PINTLE HOOK BRACKET FOR KINGPIN ADAPTER APPLICATIONS. FIGURE 4A.14 (c) Attach Kingpin Adapter to pintle hook bracket with attaching pin and lock pin. See Figures 4A.15 and 4A.16. FIGURE 4A.15 IVA-15...
  • Page 54 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.8 KINGPIN ADAPTER (cont'd) FIGURE 4A.16 (d) Position and align kingpin adapter at proper elevation and extend underlift until adapter engages and locks into fifth wheel on the tractor. Refer to Figure 4A.15. NOTE INSPECT FIFTH WHEEL PLATE FOR FATIGUE AND/OR DAMAGE FROM IMPROPER USE PRIOR TO USING THIS ATTACHMENT. (e) Before lifting vehicle, install two (2) 3/8"...
  • Page 55 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.8 KINGPIN ADAPTER (cont'd) FIGURE 4A.17 (f) On tractors with air bag suspensions, you must secure each axle with minimum 5/16" GR70 tow chain to prevent damage to air bags. Route chain around axle on one side, across frame rails and around axle on other side.
  • Page 56 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.9 5TH WHEEL ADAPTER (OPTIONAL) FIGURE 4A.18 (b) Attach pintle hook bracket to fork adapters. Install the two (2) pintle hook bracket retaining pins and tighten "T" handles on fork adapters. See Figure 4A.19. FIGURE 4A.19 (c) Attach 5TH Wheel Adapter to pintle hook bracket with attaching pin and lock pin.
  • Page 57 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.9 5TH WHEEL ADAPTER (cont'd) FIGURE 4A.20 (d) Install left and right Chain Hook Adapters on crossbar and secure with two (2) retaining bolts and safety pins. Remove pull pin from fifth wheel adapter. Position and align fifth wheel adapter with trailer kingpin at proper elevation and extend underlift until adapter engages trailer kingpin.
  • Page 58 SECTION IVA - OPERATING INSTRUCTIONS UNDERLIFT (cont'd) 4A.9 5TH WHEEL ADAPTER (cont'd) FIGURE 4A.21 (e) Secure trailer with safety chains and inspect for transport. IVA-20...

  • Page 59: Section V - Maintenance

    Section V - MAINTENANCE 5.1 The continued operation of your CENTURY 1060 Wrecker and Super Duty Underlift is largely dependent upon strict adherence to a properly scheduled preventive maintenance program. To help you in this program, CENTURY has provided the following information regarding lubrication, preventive maintenance, hydraulic system and safety devices care.
  • Page 60 Section V - MAINTENANCE (cont'd) 5.3 LUBRICATION & PREVENTIVE MAINTENANCE (cont'd) 6. Hydraulic Oil Filters 7. Oil Reservior 8. Lights and Wiring 9. Winches 10. Pivot Bearing Surfaces and Pins (See Lubrication Charts, page V-4 & V-5.) (b) Check hydraulic oil level in reservoir and fill to center of sight gauge. Refer to 5.4, part (a), SUMMARY OF REQUIRED LUBRICANTS for recommended oils to use.
  • Page 61 Section V - MAINTENANCE (cont'd) 5.3 LUBRICATION & PREVENTIVE MAINTENANCE (cont'd) (i) Lubricate winch cables using an oily rag while respooling onto drum. Other special cable lubricants are available which have better penetrating qualities. Consult your local oil company for a list of these.
  • Page 62 FIVE (5) YEARS REGARDLESS OF APPEARANCE. 5.5 CARE OF HYDRAULICS IN COLD CLIMATE When the CENTURY Wrecker and Underlift are used in seasonal cold climate regions (+20° F and below), the viscosity of the normally recommended 10W30 oil may increase to the point where it adversely affects hydraulic functions during starting and warm-up.
  • Page 63 Section V - MAINTENANCE (cont'd) 5.6 LUBRICATION - WRECKER 1. Winch Oil Level - SAE 140 gear oil to proper level. 2. Hydraulic Reservoir - recommended hydraulic fluid to proper level. 3. Hydraulic Filters - Replace after first week of operation, then every three (3) months. 4. Cable - Use oily rag or approved cable lubricant. 5. Cylinder Pivot Bearings - use synthetic fortified grease. 6. Rear Spade Cylinders - use synthetic fortified grease. 7. Rear Spade Tubes - coat with GP grease. 8. Boom Slide Pads (Top and Bottom) - use synthetic fortified grease.
  • Page 64 Section V - MAINTENANCE (cont'd) 5.7 LUBRICATION - UNDERLIFT 1. Lift Cylinder Pivots (3 places) - use synthetic fortified grease. 2. Lift Slide Rails - use synthetic fortified grease. 3. Tilt Cylinder Pivots - use synthetic fortified grease. 4. Main Pivot Pin - use synthetic fortified grease. 5. Fold Cylinder Pivots - use synthetic fortified grease. 6. Crossbar Pivot - use synthetic fortified grease. 7. Boom Extension Tube - use synthetic fortified grease. NOTE THE ABOVE LUBRICATION REQUIREMENTS SHOULD BE SERVICED MONTHLY. SERVICE MORE OFTEN IF THE WRECKER AND UNDERLIFT ARE USED QUITE FREQUENTLY.
  • Page 65 Section V - MAINTENANCE (cont'd) 5.8 FILTER/REGULATOR OPERATION AND SERVICE (a) The miniature filter/regulator and miniature lubricator are installed on the aft bulkhead of the left rear control station so that air flows in the direction of the arrow on body. See Figure 5.1. FIGURE 5.1 (b) The filter/regulator and lubricator are installed upstream from the device(s) they are to protect and lubricate. (c) Both free moisture and solids are removed automatically by the filter/regulator.
  • Page 66 Section V - MAINTENANCE (cont'd) 5.8 FILTER/REGULATOR OPERATION AND SERVICE (cont'd) 5. Replace bowl gasket; lubricate gasket to assist in retaining it in position. Use only mineral base oils or grease. Do NOT use synthetic oils such as esters, and do NOT use silicones. 6. Screw bowl into body and tighten firmly. (g) The regulator may be serviced without removing it from the line. Before disassembling filter/regulator, SHUT OFF AIR SUPPLY AND EXHAUST PRIMARY AND SECONDARY PRESSURE. Disengage the adjusting knob by pulling upward. Turn the adjusting knob counterclockwise until compression is released from pressure control spring.
  • Page 67 Section V - MAINTENANCE (cont'd) 5.9 LUBRICATOR OPERATION AND SERVICE (a) FILLING - Inlet pressure must be eliminated before the fill plug or bowl is removed. Fill to fill line on the bowl (DO NOT OVERFILL) with oil of 100 to 200 SSU viscosity at 100° F and an aniline point greater than 200° F - same as SAE No. 10 (petroleum base hydraulic oils are good examples). DO NOT USE OILS WITH ADHESIVES OR TACKY ADDITIVES. COMPOUNDED OILS CONTAINING SOLVENTS, GRAPHITE, SOAPS OR DETERGENTS (automotive oils generally contain detergent) ARE NOT RECOMMENDED. (b) Replace the fill plug and/or bowl assembly firmly - excessive torque is not necessary. The lubricator is now ready for setting. Repressurize the lubricator.

  • Page 68: Maintenance Record

    Section V - MAINTENANCE (cont'd) MAINTENANCE RECORD DATE MECHANIC WEEKLY* MONTHLY QUARTERLY SERVICE PERFORMED *IMPORTANT: HYDRAULIC HOSES AND CABLES SHOULD BE INSPECTED WEEKLY FOR SIGNS OF ABRASION. V-10...
  • Page 69 Section V - MAINTENANCE (cont'd) MAINTENANCE RECORD DATE MECHANIC WEEKLY* MONTHLY QUARTERLY SERVICE PERFORMED *IMPORTANT: HYDRAULIC HOSES AND CABLES SHOULD BE INSPECTED WEEKLY FOR SIGNS OF ABRASION. V-11...
  • Page 70 Section V - MAINTENANCE (cont'd) MAINTENANCE RECORD DATE MECHANIC WEEKLY* MONTHLY QUARTERLY SERVICE PERFORMED *IMPORTANT: HYDRAULIC HOSES AND CABLES SHOULD BE INSPECTED WEEKLY FOR SIGNS OF ABRASION. V-12...
  • Page 71 Section V - MAINTENANCE (cont'd) MAINTENANCE RECORD DATE MECHANIC WEEKLY* MONTHLY QUARTERLY SERVICE PERFORMED *IMPORTANT: HYDRAULIC HOSES AND CABLES SHOULD BE INSPECTED WEEKLY FOR SIGNS OF ABRASION. V-13...
  • Page 72 NOTES...

  • Page 73: Section Vi - Parts

    Be certain to use only original equipment replacement parts for warranty purposes as well as for keeping your CENTURY 1060 Wrecker and SDU3 Underlift in its original state and optimum operating capacities.

  • Page 74: Subframe Assembly

    Section VI - PARTS (cont'd) SUBFRAME ASSEMBLY VI-2...
  • Page 75 Section VI - PARTS (cont'd) SUBFRAME ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION 10 ft. 0301851 TRIM-lOCk, 1/8" 0302540 CENTER BONDED MOUNT (BE0102) 0302541 WASHER, SPECIAl (BE0103) 0303445 SAFETy CHAIN, SySTEM 10, 1/2" x 14' 0303481 SlIDE PAD, BUMPER REF. 0303688 CylINDER, REAR SPADE 0400066 SCREW, 1/4"-20 x 3/4"...

  • Page 76: Body Assembly

    Section VI - PARTS (cont'd) BODY ASSEMBLY VI-4...
  • Page 77 ClIP, 1/4" TINNERMAN 0400392 NUT, 3/8"-16 NylOk HEx 0400431 NUT, 3/4"-10 NylOk HEx GR8 0400451 WASHER, 1/4" FlAT 0400566 RIVET, 1/4" 0500406 CENTURy NAMEPlATE 0705090 MUDFlAP MTG ANGlE, lEFT 0705091 MUDFlAP MTG ANGlE, RIGHT 0705092 BAR, MUDFlAP 0706609 RETAINING STRIP, FENDER 0707174...
  • Page 78 Section VI - PARTS (cont'd) SDU3 ASSEMBLY VI-6...
  • Page 79 PART REQ'D NUMBER DESCRIPTION REQ'D NUMBER DESCRIPTION 0904652 INSTALLATION SDU/2 FIX & ROT. 0907809 UNDERLIFT SDU3 ASSY (cont'd) 0300113 GREASE FITTING, 1/4"-28 945030004 UPPER WEAR PAD, RECOVERY 0300329 SNAP RING, EXTERNAL 2" HC0159 CYLINDER, LIFT 0301397 GREASE FITTING, 1/4"-28 90°...

  • Page 80: Sdu3 Lift & Extend Hydraulics

    Section VI - PARTS (cont'd) SDU3 LIFT & EXTEND HYDRAULICS VI-8...
  • Page 81 Section VI - PARTS (cont'd) SDU3 LIFT & EXTEND HYDRAULICS REF. PART REF. PART REQ'D NUMBER DESCRIPTION REQ'D NUMBER DESCRIPTION 0904652 INSTALLATION SDU/2 FIXED & ROTATOR 0906748 CONTROL VALVE ASSEMBLY, SDU/2 (cont'd) 0301998 HOSE ASSEMBLY, 24" 0303017 CONNECTOR, 8MB-6FB 0302065...
  • Page 82 Section VI - PARTS (cont'd) SDU3 TILT & FOLD HYDRAULICS VI-10...

  • Page 83: Sdu3 Tilt & Fold Hydraulics

    Section VI - PARTS (cont'd) SDU3 TILT & FOLD HYDRAULICS REF. PART REQ'D NUMBER DESCRIPTION 0904652 INSTALLATION SDU/2 FIXED & ROTATOR 0300044 CONNECTOR, 6MJ-8MB 0301470 ELBOW, 6MJ-8MB90 0301522 CONNECTOR, 6MJ-6MB 0301619 BRANCH TEE, 6MJ-6MJ-6MB 0301696 ELBOW, 6MJ-6FJX90 0301730 VALVE, DOUBLE HOLDING 0301998 HOSE ASSEMBLY, 24"...

  • Page 84: Lift Adapters

    Section VI - PARTS (cont'd) SDU3 LIFT ADAPTERS KING PIN & FIFTH WHEEL ADAPTER VI-12...
  • Page 85 Section VI - PARTS (cont'd) SDU3 LIFT ADAPTERS REF. PART REQ'D NUMBER DESCRIPTION 0200018 FORK, SHORT 3" OPENING 0200019 FORK, SHORT 4-1/2" OPENING 0200020 FORK, MEDIUM 3" OPENING 0200021 FORK, MEDIUM 4-1/2" OPENING 0200022 FORK, LONG 3" OPENING 0200023 FORK, LONG 4-1/2" OPENING 0200024 FORK, OFFSET REAR AXLE 6"...

  • Page 86: Wrecker Frame Assembly

    Section VI - PARTS (cont'd) WRECKER FRAME ASSEMBLY VI-14...
  • Page 87 Section VI - PARTS (cont'd) WRECKER FRAME ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION 0300076 LICENSE PLATE BRACKET 0300117 RUBBER GROMMET, #316 0300273 LICENSE PLATE ILLUMINATOR 0301081 CAP PLUG (NOT SHOWN) 0301541 SIGHT GAUGE, TYPE S-1 REF. 0303092 CYLINDER, BOOM LIFT 0303504 WINCH, DP MODEL S50-50K 0305006...

  • Page 88: 2-Stage Boom Assembly

    Section VI - PARTS (cont'd) 2-STAGE BOOM ASSEMBLY VI-16...
  • Page 89 Section VI - PARTS (cont'd) 2-STAGE BOOM ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION 0300113 GREASE FITTING 0301691 OBLONG MASTER LINK 0301923 SLIDE PAD, BOOM BOTTOM 0301924 SLIDE PAD, BOOM SIDE 0302273 SPRING, WINCH CABLE TIE BACK 0305023 SNAP RING 0305031 SLIDE PAD, INNER BOOM 0400122 SCREW, 3/8"-16 X 1-1/4"...

  • Page 90: 3-Stage Boom Assembly

    Section VI - PARTS (cont'd) 3-STAGE BOOM ASSEMBLY VI-18...
  • Page 91 Section VI - PARTS (cont'd) 3-STAGE BOOM ASSEMBLY REF. PART REF. PART REQ'D NUMBER DESCRIPTION REQ'D NUMBER DESCRIPTION — — 0908004 3-STAGE BOOM ASSEMBLY — — 0906536 BOOM SWIVEL KIT 0300113 GREASE FITTING,1/4"-28 STRAIGHT 0400557 ROLL PIN, 1/2" X 1-1/4" ZP 0301923 SLIDE PAD, BOOM BOTTOM 0906537...
  • Page 92 Section VI - PARTS (cont'd) 3-STAGE EXTENSION SYSTEM ASSEMBLY VI-20...

  • Page 93: 3-Stage Extension System Assembly

    Section VI - PARTS (cont'd) 3-STAGE EXTENSION SYSTEM ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION — — 0908003 3-STAGE EXTENSION SYSTEM ASSEMBLY 0300113 GREASE FITTING,1/4"-28 STRAIGHT 0303441 SHEAVE, 10" DIA. X 1-1/2" BORE 0307160 EXTEND CABLE ASSEMBLY 0307161 RETRACT CABLE ASSEMBLY 0307393 BOOM EXTEND CYLINDER, 1060S 3-STAGE 0400239...

  • Page 94: Wrecker Hydraulics

    Section VI - PARTS (cont'd) WRECKER HYDRAULICS (LESS BOOM ELEVATION HYDRAULICS) VI-22...
  • Page 95 Section VI - PARTS (cont'd) WRECKER HYDRAULICS (LESS BOOM ELEVATION HYDRAULICS) REF. PART REQ'D NUMBER DESCRIPTION 0300659 HOSE ASSEMBLY, 45" 0301376 CONNECTOR, 8MJ-10MB 0301388 ELBOW, 8MJ-8MB90 0301445 EXTENDED CONNECTOR, 8MJ-8MB 0301893 HOSE ASSEMBLY, 84" 0301982 BULKHEAD ELBOW w/ NUT, 12MJ90 REF.

  • Page 96: Boom Elevation Hydraulics

    Section VI - PARTS (cont'd) BOOM ELEVATION HYDRAULICS VI-24...
  • Page 97 Section VI - PARTS (cont'd) BOOM ELEVATION HYDRAULICS REF. PART REQ'D NUMBER DESCRIPTION 0300040 CONNECTOR, 8MJ-8MP 0300113 GREASE FITTING 0300644 HOSE CLAMP, 8" 0300761 STRAIGHT ADAPTER 0300762 MALE CONNECTOR 0300763 MALE ELBOW 0300766 MALE BRANCH TEE 0300767 TEE UNION 0300901 ELBOW 0301376 CONNECTOR, 8MJ-10MB...

  • Page 98: Pump, Valve & Filter Hydraulics

    Section VI - PARTS (cont'd) PUMP, VALVE & FILTER HYDRAULICS VI-26...
  • Page 99 Section VI - PARTS (cont'd) PUMP, VALVE & FILTER HYDRAULICS REF. PART REQ'D NUMBER DESCRIPTION 0300052 ELBOW, 8MJ-10MB90 0300056 BARB, 16C4-16MP 18 FT. 0300058 SUCTION HOSE, 1" 0300071 HOSE CLAMP, 1" 0300364 HOSE CLAMP, 1" - 2-1/4" 0300434 HOSE BARB, 2" 32C4-32MP 0300446 PIPE PLUG, 3/4"...

  • Page 100: Left Control Assembly

    Section VI - PARTS (cont'd) LEFT CONTROL ASSEMBLY VI-28...
  • Page 101 Section VI - PARTS (cont'd) LEFT CONTROL ASSEMBLY REF. PART REF. PART REQ'D NUMBER DESCRIPTION REQ'D NUMBER DESCRIPTION 0300834 KNOB, IN-OUT 0400384 NUT, 5/16"-24 HEX NYLOK 0300835 KNOB, BOOM UP-DOWN 0400466 LOCKWASHER, 5/16" INTERNAL TOOTH 0300836 KNOB, JACK UP-DOWN 0801054 CONTROL CABLE CONNECTOR 0300837 KNOB, BOOM IN-OUT...
  • Page 102 Section VI - PARTS (cont'd) RIGHT CONTROL ASSEMBLY VI-30...

  • Page 103: Right Control Assembly

    Section VI - PARTS (cont'd) RIGHT CONTROL ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION 0300834 KNOB, IN-OUT 0300835 KNOB, BOOM UP-DOWN 0300836 KNOB, JACK UP-DOWN 0300837 KNOB, BOOM IN-OUT 0301884 CONTROL CABLE, 96" 0301969 CONTROL CABLE, 84" 0302457 CONTROL CABLE, 104" 0302726 GREASE FITTING, 1/4"-28 X 45°...
  • Page 104 Section VI - PARTS (cont'd) SPADE HYDRAULICS REF. PART REQ'D NUMBER DESCRIPTION 0300040 CONNECTOR, 8MJ-8MP 0301376 CONNECTOR, 8MJ-10MB 0301445 EXTENDED CONNECTOR, 8MJ-8MBL 0301816 FITTING, 8FP-8FP45 REF. 0302296 CONTROL VALVE, VDP12CDD118 0302980 PIPE NIPPLE, BLACK 1/2" X 5" 0303176 CONNECTOR, 10MB-8FB 0303588 HOSE ASSEMBLY, 108"...

  • Page 105: Hydraulic Cylinders

    Section VI - PARTS (cont'd) HYDRAULIC CYLINDERS REF. PART REQ'D NUMBER DESCRIPTION HC0159 UNDERLIFT LIFT CYLINDER 0304522 SEAL KIT, UNDERLIFT LIFT CYLINDER 0303501 UNDERLIFT EXTEND CYLINDER 0304590 SEAL KIT, UNDERLIFT EXTEND CYLINDER 0306746 UNDERLIFT FOLD CYLINDER 0304609 SEAL KIT, UNDERLIFT FOLD CYLINDER 0307378 UNDERLIFT TILT CYLINDER SEAL KIT, UNDERLIFT TILT CYLINDER...

  • Page 106: Boom End Swivel Assembly

    Section VI - PARTS (cont'd) BOOM END SWIVEL ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION 0300113 GREASE FITTING 0300311 SHEAVE, 10" 0400133 SCREW, 3/8"-16 X 3" HEX HD CAP 0400140 SCREW, 3/8"-16 X 4" HEX HD CAP 0400392 NUT, 3/8"-16 NYLOK HEX 0700511 CABLE GUIDE, BOTTOM 0700563...

  • Page 107: Modular Light Kit

    Section VI - PARTS (cont'd) MODULAR LIGHT KIT REF. PART REQ'D NUMBER DESCRIPTION 0302542 LIGHT, STOP & TURN 0302543 LIGHT, CLEAR BACKUP 0400025 SCREW, #8-32 X 3/4" RD HD SLOTTED REF. PART REQ'D NUMBER DESCRIPTION 0300442 3-LIGHT BAR ASSEMBLY (COMPLETE) 0300507 BULB, MARKER LIGHT 0400025...
  • Page 108 Section VI - PARTS (cont'd) MODULAR LIGHT KIT REF. PART REQ'D NUMBER DESCRIPTION 0302201 LIGHT, FLOOD (COMPLETE) 0302611 LIGHT, AMBER OVAL (COMPLETE) REF. PART REQ'D NUMBER DESCRIPTION 0302544 LIGHT, DOME (COMPLETE) VI-36...
  • Page 109 Section VI - PARTS (cont'd) MODULAR LIGHT KIT REF. PART REQ'D NUMBER DESCRIPTION 0300076 LICENSE PLATE BRACKET 0300273 LICENSE PLATE ILLUMINATOR 0300512 BULB, LICENSE PLATE ILLUMINATOR VI-37...

  • Page 110: Glad Hand Assembly

    Section VI - PARTS (cont'd) GLAD HAND ASSEMBLY REF. PART REQ'D NUMBER DESCRIPTION 0301862 CATERPILLAR GROMMET 0301909 RECEPTACLE BOOT 0301944 GLAD HAND COUPLING 0301945 GLAD HAND BOOT 0301946 BULKHEAD CONNECTOR 0301947 45° ADAPTER, 1/4" NPM X 3/8" SYN. HOSE 0301948 HD 7-WAY TRAILER CONNECTOR 0302534 45°...

  • Page 111: Truck Wheel Lift

    Section VI - PARTS (cont'd) TRUCK WHEEL LIFT REF. PART REQ'D NUMBER DESCRIPTION 0301932 5/16" X 12' H.T. CHAIN ASSEMBLY (N.S.) 0300311 RATCHET WITH HOOK (N.S.) 0303680 TIE DOWN STRAP, ADJUSTABLE (N.S.) 0802839 TIRE SUPPORT, RIGHT 0802841 OUTER CROSSTUBE, LEFT 0802842 OUTER CROSSTUBE, RIGHT 0802877...
  • Page 112 NOTES...

  • Page 113: Section Vii - Installation

    Section VII - INSTALLATION 7.1 SWITCH PANEL & PTO SHIFTER INSTALLATION The Switch Panel is generally located beside the driver's seat or in the overhead console, and controls the light bar, flood lights, auxiliary lights, control station lights, and lower work lights. Refer to Figure 3.2. The air shift PTO control knob and indicator light are generally located on dash panel in cab. (a) Attach switch panel wiring harness (0302746). Refer to electrical schematic & switch panel wiring, pages VIII-1 & VIII-2.

  • Page 114: Pto Installation

    Section VII - INSTALLATION (cont'd) 7.1 SWITCH PANEL & PTO SHIFTER INSTALLATION (cont’d) (f) Install nylon tubing from inlet port on PTO shifter to tee fitting at pressure protection valve. (NOTE: Other side of tee fitting is connected to wrecker winch air shifter cylinders.) (g) Connect outlet line from PTO shifter valve to PTO after PTO is installed. 7.2 PTO INSTALLATION (a) Drain transmission oil. (b) Disengage PTO (gears should turn freely).
  • Page 115 Section VII - INSTALLATION (cont'd) 7.4 PREPARATION OF TRUCK FRAME (cont’d) RELOCATING EXHAUST SYSTEM COMPONENTS, ELECTRICAL COMPONENTS, BRAKING SYSTEM COMPONENTS, AND/OR FUEL SYSTEM COMPONENTS MUST BE PERFORMED BY QUALIFIED PERSONS ONLY! ALL MODIFICATIONS COVERED BY FEDERAL AND STATE SAFETY CODES MUST BE CERTIFIED AFTER THE MODIFICATION IS COMPLETED.
  • Page 116 Section VII - INSTALLATION (cont'd) 7.4 PREPARATION OF TRUCK FRAME (cont’d) (b) If frame rail width is greater than 10", frame rails must be notched as shown in Figure 7.3. FIGURE 7.3 7.5 MOUNTING ANGLE INSTALLATION (a) Clamp mounting angles to chassis frame as shown in Figure 7.4. FIGURE 7.4 (b) Using holes in the mounting angles as a guide, drill the chassis frame for 7/8" mounting bolts. NOTE ALL EXISTING CROSSMEMBER BOLTS MUST BE REPLACED IN THEIR ORIGINAL LOCATIONS. VII-4...
  • Page 117 Section VII - INSTALLATION (cont'd) 7.5 MOUNTING ANGLE INSTALLATION (cont'd) DO NOT WELD ANGLES TO CHASSIS FRAME RAILS! D.O.T. REGULATIONS PROHIBIT ANY WELDING TO CHASSIS FRAME. NOTE IT MAY BE NECESSARY TO NOTCH MOUNTING PLATES TO CLEAR SPRING HANGERS AND OTHER UNMOVABLE OBJECTS. (c) Attach mounting angles to frame using 7/8"-9 x 2-1/2" Grade 8 mounting bolts and nylon lock nuts from body mounting hardware kit.

  • Page 118: Wiring Hook-Up

    Section VII - INSTALLATION (cont'd) 7.6 WRECKER SUBFRAME INSTALLATION (cont'd) (e) Weld subframe permanently to mounting angles using a continuous weld. Apply weld to both inside and outside of each mounting angle. 7.7 REAR OUTRIGGER SUPPORT BRACKET INSTALLATION (a) Rear outrigger support brackets must fit up against the rear outrigger and flush with the chassis frame rail. (b) Grind the area where each support bracket meets the rear outrigger to ensure a good weld surface.

  • Page 119: Hydraulic Hose Hook-Up

    Section VII - INSTALLATION (cont'd) 7.8 WIRING HOOK-UP (cont'd) (b) Complete the wiring hook-ups between the truck cab and wrecker body. Refer to Section VII - Electrical Schematic. Holes are provided in the left front, inner part of the body for the wiring harness to pass through. Wires are then attached to the proper locations in the junction boxes located in the left front tool compartment. (c) Mount the light bar assembly, if applicable. It may be necessary to add another hole in the body for the light bar wiring harness. 7.9 HYDRAULIC HOSE HOOK-UP Refer to Pump, Valve, and Filter Hydraulics, page VI-16 and Hydraulic Schematic, page VII-2. Install hydraulic fittings from pump kit to...
  • Page 120 Section VII - INSTALLATION (cont'd) 7.9 HYDRAULIC HOSE HOOK-UP (cont'd) FIGURE 7.6 (c) Attach the suction hoses from the hydraulic reservoir to the barbed fittings on the pump. Use hose clamps supplied in pump kit. (d) Attach the pressure hoses from the control valves to the threaded fittings on pressure side of pump. (e) Fill the hydraulic reservoir with hydraulic oil selected from Section 5.4 (a), Summary Of Required Lubricants, page V-3, until the oil level is in the center of the sight gauge on the reservoir. 7.10 WINCH AIR SHIFTER Connect nylon line from winch air solenoid valve to tee fitting at pressure protection valve at air supply point. 7.11 AIR CONTROL MANIFOLD Connect nylon line from air regulator, located in left rear control compartment, to tee fitting at pressure protection valve at the air supply point. Set air pressure at the regulator to 50-60 pounds. Refer to Section 5.7, Filter / Regulator Operation And Service, pages V-6 and V-7.

  • Page 121: Installation Check

    Section VII - INSTALLATION (cont'd) 7.12 GLAD HAND HOOK-UP The wrecker assembly is furnished with glad hand and electrical receptacles installed in the tailgate. It is the customers responsibility to attach these units to the truck air and electrical systems. 7.13 INSTALLATION CHECK Check all installation points for completeness and correct assembly. (a) Mounting plates to chassis frame and wrecker sub-frame. (b) Hydraulic and air line hook-ups. Oil in reservoir. (c) Wiring harness hook-up. Check light operation. 7.14 WINCH CABLE INSTALLATION Installation is now complete except for winch cable installation.
  • Page 122 NOTES...

  • Page 123: Section Viii - Schematics

    Section VIII - SCHEMATICS ELECTRICAL VIII-1...

  • Page 124: Switch Panel Wiring

    Section VIII - SCHEMATICS (cont'd) SWITCH PANEL WIRING VIII-2...
  • Page 125 Section VIII - SCHEMATICS (cont'd) REMOTE CONTROL ELECTRICAL 8-POSITION POWER PAL 15-POSITION POWER PAL VIII-3...

  • Page 126: Hydraulic

    Section VIII - SCHEMATICS (cont'd) HYDRAULIC VIII-4...
  • Page 127 NOTES...
  • Page 128 CENTURY ® Miller Industries Towing Equipment Inc. 8503 Hilltop Drive • Ooltewah, Tennessee 37363 • (423) 238-4171 www.millerind.com...
