Summary of Contents for Odin OD-VERTILINE
- Page 1 OD-VERTILINE / VERTICAL LIFELINE SYSTEM User Guide www.odinsafety.com.tr / www.odinisguvenligi.com...
- Page 2 OD-VERTILINE / VERTICAL LIFELINE SYSTEM User Guide Product Usage Report Serial Number : ................Date of Production : ................Date of Delivery : ................Stamp & Signature : ......................................................................................................... Date of first use : ..............Name & Surname of user : ..............
- Page 3 OD-VERTILINE Vertical Lifeline System (EN 353-1:2014+ A1:2017 PPE 2016/425) 3.1 Area of Use OD-VERTILINE is the fixed vertical lifeline and it provides you with safe access to heights (fixed stairs, tower tops, poles, lighting towers, chimneys…) with its features. 3.2 Features »...
- Page 4 Maximum No of Users Force Directions EN 353-1: PPE 2016/425 2014+A1:2017 Installation Substructure OD-VERTILINE Components 4.1 OD-MAXILINE Components - General Code Description Code Description OD-ELL-1 Main Anchor OD-ELL-4 Main Anchor Fall Arrest Device OD-CH 8 Rope Holder OD-VLG OD-TED Tension Meter...
- Page 5 4.2 OD-VERTILINE Components- Details OD-ELL-1 Main Anchor / Aluminium OD-ELL-4 Main Anchor / Aluminium OD-CH 8 Rope Holder / Stainless Steel OD-LLC 7x19 Steel Rope / Stainless Steel OD-TED Tension Meter OD-VLG Fall Arrest Device / Aluminium / Stainless Steel Energy Absorber (Tenacity>0.6 Ntex)
- Page 6 Label OD-VertiLine OD-VertiLine OD-ELL1 OD-ELL4 EN 353-1:2014+A1:2017 EN 353-1:2014+A1:2017 PPE-R11.119 PPE-R11.119 2927 2927 USERS USERS SERI NO / SERIAL NO: XXXX-XXXX SERI NO / SERIAL NO: XXXX-XXXX Ür. Ay/YIL / M. MONTH / YEAR: XX-XX Ür. Ay/YIL / M. MONTH / YEAR: XX-XX Ür.
- Page 7 SAFETY ENERGY ABSORBER Serial No.: 0000 Date of HALAT TUTUCU manufacture: MM-YYYY OD-VLG Code Description Code Description Manufacturer Name Name of the notified body in charge of annual control of the production Serial Number / M. Month /Year Name of the PPE Component reference Max weight for user with equipements allowed...
- Page 8 Every user can be influenced and fall due to the movement of the line initiated by the other user. +90 (212) 335 25 82 Odin Safety Endüstriyel Ürünler A. Ş. Merkez: Beybi Giz Plaza Maslak Mah. Maslak Meydan Sokak No:1 +90 (541) 953 20 41 Sarıyer 34485 İstanbul...
- Page 9 Installation OD-VERTILINE (Vertical Lifeline) system installation should be done by Odin Safety installation teams or personnel authorized by Odin Safety after receiving installation and disassembly training. » Tested and approved with only 15° side angles. » In case of a possible fall in the use of the vertical lifeline, the force that will come to the structure will be in the direction of the user’s fall and to the upper anchorage point of the structure, the...
- Page 10 It is the responsibility of the user to learn and apply proper usage techniques and safety methods. » OD-VERTILINE ( Vertical Lifeline) must be used only by or under the supervision of trained personnel. » Misuse or improper use can cause serious injury and fatal accidents.
- Page 11 B.1 Connecting OD-VLG Fall Arrest Device to the lifeline system Connecting to the vertical lifeline system wire, press the locking lever (Fig. 1.2) and while keeping it pressed down as necessary, rotate the locking cam until it is fully opened (Fig. 1.3 - 1.4). Place OD-VLG on the cable making sure it is in the correct direction (Fig.
- Page 12 Figure1.9 Figure1.10 Figure1.11 Warning: Your OD-VLG Fall Arrest Device is a personal equipment and you should remove it from the line after each use. Warning: Your OD-VLG Fall Arrest Device may not work easily when the OD-VLG Fall Arrest Device is left on the line, due to the dirt, dust, etc in the environment. Warning: Use only original OD-VLG Fall Arrest Device and carabinar tested and certified together with the system .
- Page 13 Warning: The weight of the user, including tools and equipment, must not be greater than the maximum rated loads marked on OD-VLG. Warning: The weight of the user, excluding tools and equipment, must not be less than the rated loads marked on OD-VLG. Warning: In the event where the harness loosens during the ascent or the descent, it will have to be adjusted again from a safe position.
- Page 14 Figure-1.1 Figure-1.2 Figure-1.3 Figure-1.4 » OD-VLG Fall Arrest Device should always be below chest level when climbing up. For the convenience of the user, two hands should be climbed with one foot or one hand with two feet while climbing. »...
- Page 15 B.4 Safe Open Drop Height The fall clearance distance is the minimum distance needed under the feet of the operator in order to avoid the collision with the structure, the ground, or other obstacles, in case of a fall from a height. »...
- Page 16 D. Product Control and Validation D1. Before Every Usage OD-VERTILINE’s all componets including OD-VLG (fall arrest device) must be checked regularly before and after each use, and findings must be recorded and verify that the lifeline is intact and in adequate conditions;...
- Page 17 Metallic materials do not have a theoretical lifetime. The product must be checked periodically at least once a year and it must be documented whether it is safe to use or not. ODIN SAFETY is not responsible for the use of the product that doe not have annual periodic control.
- Page 18 Any repairs on the product are carried out only by the manufacturer (Odin Safety) or the manufacturer’s authorized persons. » Odin Safety is not responsible for the dangers that may arise if the repair and maintenance are carried out by unauthorized persons. »...
- Page 19 +90 (212) 335 25 82 +90 (541) 953 20 41 info@odinsafety.com.tr odinsafety.com.tr...
