FSR
PWB-CMU8-HNGWHT-C Installation Instructions
244 Bergen Boulevard, Woodland Park, NJ 07424, Phone: 973.785.4347 - FAX 973.785.4207
1. TO INSTALL THE FINISH COVER REMOVE AND DISCARD CONSTRUCTION COVER AND HARDWARE.
CONSTRUCTION COVER
2. INSTALL HINGED COVER WITH HARDWARE PROVIDED. COVER CAN BE ROTATED 180 TO POSITION
DOOR LATCH TO LEFT OR RIGHT SIDE OF DOOR.
HINGED COVER
43448
DOOR
LATCH
DOOR
RIGHT-SIDE DOOR LATCH MOUNTING
LEFT-SIDE DOOR LATCH MOUNTING
LIT1861
Advertisement
Summary of Contents for FSR PWB-CMU8-HNGWHT-C
- Page 1 PWB-CMU8-HNGWHT-C Installation Instructions 244 Bergen Boulevard, Woodland Park, NJ 07424, Phone: 973.785.4347 - FAX 973.785.4207 1. TO INSTALL THE FINISH COVER REMOVE AND DISCARD CONSTRUCTION COVER AND HARDWARE. CONSTRUCTION COVER 2. INSTALL HINGED COVER WITH HARDWARE PROVIDED. COVER CAN BE ROTATED 180 TO POSITION DOOR LATCH TO LEFT OR RIGHT SIDE OF DOOR.
- Page 2 HANDLE LOCK INSTALLATION: REMOVE LOCK ASSEMBLY FROM BAG, THEN REMOVE SCREW, CAM AND NUT FROM LOCK. MAKE SURE LOCK HOUSING (NOTE LOCK PIN LOCATION) AND HANDLE ARE ORIENTED AS SHOWN, THEN SLIP LOCK ASSEMBLY INTO DOOR. INSTALL NUT ON LOCK HOUSING. ORIENT CAM AS SHOWN AND SECURE ONTO LOCK WITH SCREW.
