SIP 06950 Manual

Diesel tank with high flow 12v transfer pump

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

SIP Industrial Products Limited

Gelders Hall Road

Shepshed

Loughborough

Leicestershire

LE12 9NH

United Kingdom

For help or advice please contact

your distributor, or sip directly on:

Tel.: 01509 500400

Email:

sales@sip-group.com

customerservice@sip-group.com

SIP Diesel Tank With High Flow

12v Transfer Pump

06950 - 06951

Please read and fully understand the instructions in this manual

before operation. Keep this manual safe for future reference.

Table of Contents

Need help?

Do you have a question about the 06950 and is the answer not in the manual?

Questions and answers

Summary of Contents for SIP 06950

Page 1 SIP Industrial Products Limited Gelders Hall Road Shepshed Loughborough Leicestershire LE12 9NH United Kingdom SIP Diesel Tank With High Flow 12v Transfer Pump 06950 - 06951 For help or advice please contact your distributor, or sip directly on: Tel.: 01509 500400 Email: sales@sip-group.com...
Page 3: Table Of Contents
INDEX Page Content Technical Specification Getting to Know Your Diesel Fuel Tank 6 - 9 Safety Instructions Safety Symbols Used Within This Manual Guarantee 11 - 14 Operating Instructions Wiring Diagram Maintenance Troubleshooting UKCA Declaration of Conformity CE Declaration of Conformity...
Page 4: Technical Specification
TECHNICAL SPECIFICATION Model 06950 06951 Power & Supply 12V DC 12V DC Motor Power 300W 300W Tank Capacity 200l 430l Max Flow Rate 50l/min 50l/min Motor Speed 3200Rpm 3200Rpm Max Working Pressure 1 Bar 1 Bar Max Pumping Head Thread Diameter 3/4”...
Page 5 GETTING TO KNOW YOUR DIESEL TRANSFER PUMP 06950 Item Description Item Description Lid Strut Dispensing Nozzle Fuel Filler Cap Discharge Hose Fuel Level Guage Power Cable Power Switch Lid Latch Motor...
Page 6 GETTING TO KNOW YOUR DIESEL TRANSFER PUMP 06951 Item Description Item Description Fuel Guage Lid Strut Motor Pump Filler Cap Power Cable Dispensing Nozzle Dispensing Hose Power Switch...
Page 7: Safety Instructions
SAFETY INSTRUCTIONS Cont... IMPORTANT: Please read the following instructions carefully, failure to do so • could lead to serious personal injury and / or damage to the heater. KNOW YOUR ITEM: Read and understand the owner’s manual and labels affixed •...
Page 8 USE ONLY RECOMMENDED ACCESSORIES: Consult this user manual, your distribu- • tor or SIP directly for recommended accessories. Follow the instructions that ac- company the accessories. The use of improper accessories may cause hazards and will invalidate any warranty you may have.
Page 9 SAFETY INSTRUCTIONS Cont... Never operate the pump for more than 1 minute in ‘by-pass’ mode (with the sup- • ply nozzle closed). Never operate the pump ‘dry’ with no fuel running through it; This will damage • the internal components of the pump and invalidate your warranty. Never operate the pump for longer than its duty cycle (30 minutes);...
Page 10: Safety Symbols Used Within This Manual
SAFETY SYMBOLS USED WITHIN THIS MANUAL Danger / Caution: Indicates risk of personal injury and / or the possibility of damage Important: Please read the following instructions carefully, failure to do so could lead to Note: Supplementary Information Important: Please read the following instructions carefully, failure to do so could lead to injury and / or the possibility of damage GUARANTEE This item is covered by a 24 month parts and labour warranty covering failure due...
Page 11: Operating Instructions
Using lifting eyes and slings (06950 only) Using the fork channels in the base of the unit (06950/06951) 06951 06950/06951 Danger / Caution: Ensure all operators are relevantly certified, failure to...
Page 12 When transporting the tank, it is extremely important that it is correctly and securely fastened. • Please follow the guidelines in the images below Danger / Caution: Ensure that all straps and anchor points are correctly load rated and in good condition. 06950 06951...
Page 13 OPERATING INSTRUCTIONS Cont... Connecting the Pump • Before the operation can be completed the pump needs connecting to a suitable power supply (12v DC) • The cables coming from the product are coloured Black (-) and Red (+) These must be connected to the correct battery terminals as shown below RED (+) BLACK (-) Danger / Caution: Always disconnect the pump from the power source...
Page 14 OPERATING INSTRUCTIONS Cont... Dispensing Fuel To dispense fuel from the tank, the following steps are to be followed; Open fuel tank lid, and check fuel level Uncoil the power lead, ensuring it is in good condition III. Ensuring the power switch is “OFF” connect the leads to the power source (As shown page 13) Uncoil the dispensing hose, making sure it is free of kinks and twists Turn the power switch “ON”...
Page 15: Wiring Diagram
WIRING DIAGRAM 06950 - 06951 POSITIVE (+) NEGATIVE (-)
Page 16: Maintenance
MAINTENANCE Warning: Ensure the fuel tank is fully drained, and the power supply has been removed before carrying out maintenance. It is essential that the Fuel Tank is correctly maintained and kept in top condition at all times. Monthly • Wipe the outer surfaces of the product using a damp cloth •...
Page 17: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Solution Tank walls buckle out- This is normal, and does wards during the filling of not compromise the tanks the tank structure or performance Tank walls collapse during Tank breather is blocked Stop discharging fuel im- the discharging of fuel.
Page 18 England As the manufacturer within the UK, England, Scotland & Wales, declare that the SIP 200L Portable Diesel Tank with Higher Flow 12v Transfer Pump SIP 430L Portable Diesel Tank with Higher Flow 12v Transfer Pump Item No(s) 06950 - 06951 Conforms to the requirements of the following regulation(s), as indicated.
Page 19: Eu Declaration Of Conformity
Republic of Ireland As the manufacturers authorised representative within the EC declare that the SIP 200L Portable Diesel Tank with Higher Flow 12v Transfer Pump SIP 430L Portable Diesel Tank with Higher Flow 12v Transfer Pump Item No(s) 06950 - 06951 Conforms to the requirements of the following directive(s), as indicated.
Page 20 FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, Please dispose of packaging for the product in a responsible OR SIP manner. It is suitable for recycling. Help to protect the envi- ronment, take the packaging to the local amenity tip and DIRECTLY ON: place into the appropriate recycling bin.

This manual is also suitable for:

06951
