  • Page 1 USER MANUAL RAPSODO DIAMOND V3 Pro...

  • Page 2: What's In The Box

    What’s in the box? USB Adaptor Rapsodo Diamond Unit USB Cable...

  • Page 3: Unit Overview

    UNIT OVERVIEW The Rapsodo Diamond Unit has 1 power port, 1 WiFi port and a power LED. All configuration and usage of the device is via the Rapsodo Diamond application on your computer, tablet or smart phone. COMPATIBLE PLATFORMS Rapsodo Diamond is compatible across many platforms such as smartphone, iPad, Android Tablet, or PC.

  • Page 4: Powering On/Off

    To turn off Rapsodo Diamond, press the power button again. Charging Plug the USB cable into a PC or other USB charger, such as your mobile phone charger, to charge the internal battery. The power LED will turn AMBER when Rapsodo Diamond is charging.
  • Page 5 CONNECTING THE DEVICE WIRELESSLY 1. Activate Wi-Fi on your mobile device or PC. Make sure that the Rapsodo Diamond unit is powered on. Connect your mobile device or PC to the access point that starts with “DIAMOND”. 2. Start the Rapsodo Diamond application on your mobile device or PC.
  • Page 6 Make sure the Rapsodo Diamond unit is placed flat on the ground, without any elevation. When a ball is hit, the LED laser will turn off and you can view your data in the application.
  • Page 7 HITTING DIAGRAM...

  • Page 8: Care Instructions

    CARE INSTRUCTIONS Rapsodo Diamond uses advanced optics that are behind the plastic window. Scratches and dust or other issues that impact the window quality may interfere with Rapsodo Diamond operation. Keeping the window clean and scratch-free will ensure the measurement accuracy and longevity of your Rapsodo Diamond system.

  • Page 9: Fcc Warning

    FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
