Summary of Contents for MYCOOLMAN CCP 30 Single Zone
- Page 1 CCP FRIDGE·FREEZER Operation Manual for AC/DC Fridge ·Freezer Single Zone Models CCP 30 / 36 / 44 / 60 / 73 / 105 Dual Zone Models CCP 69 / 85 / 96 www.mycoolman.com.au LEISURE-TEC Australia Pty Ltd...
- Page 2 CCP FRIDGE·FREEZER Contents Important Safety Warnings page Important Product Information page Product Features page LED Control Panel & Operation Instructions page 4-5 Bluetooth Mode Instructions page Two Way Opening and Removable Lid page Emergency Override page Cleaning & Maintenance page Troubleshooting page Status Indicator...
-
Page 3: Important Product Information
CCP FRIDGE·FREEZER Important Product Information • Make sure the voltage is within the correct • Best performance is achieved in ambient range for socket and cable being used. temperatures between +10 °C and + 43 °C. • Do not place any electrical devices inside •... -
Page 4: Turning The Unit On And Off
CCP FRIDGE·FREEZER LED Control Panel & Operation Instructions Control Panel Single Zone Control Panel Dual Zone (CCP 30 / 36 / 44 / 60 / 73 & 105) (CCP 69 / 85 & 96) Power/Status Power/Status Power Switch LED-Displays Switch Compartments / Mode Power Switch LED-Display Indicator Light... - Page 5 CCP FRIDGE·FREEZER LED Control Panel & Operation Instructions Engaging Turbo mode: What is the purpose of Turbo Mode? It enables the compressor to run at a higher speed, therefore achieving faster cooling to your nominated temperature. Step 1: Press the button once to turn on.
- Page 6 • OPE: Bluetooth connection is open. You can now ‘search’ using your App for your unit and pair your unit to the App Installing Bluetooth App: Step 1: Download the ‘myCOOLMAN’ app (for FREE) from the Apple or Google Play store. Step 2: Open the App.
- Page 7 CCP FRIDGE·FREEZER Two Way Opening and Removable Lid Purpose for removing the lid: CCP 30, 36 & 44 – This lid can be removed for cleaning. CCP 60, 69, 73, 85, 96, 105 – This lid can be removed to aid with cleaning and to change the opening direction. You can change the direction of the lid by following the below instructions.
-
Page 8: Emergency Override
CCP FRIDGE·FREEZER Emergency Override Fuse 6.3A The Emergency Override Switch is NOTE: located just below the main control • In EMERGENCY OVERRIDE, the cooler runs panel next to the power inlets with full cooling capacity (i.e. will chill as heavily as possible with no regard to the For normal operation the switch is in the set temperature) and may freeze. -
Page 9: Troubleshooting
Unusual noise when refrigerator is working • The refrigerator is not placed on a level surface. If none of the above solves your issue, see page 3 or contact myCOOLMAN. NOTE: At inclinations of more than 15 ° the compressor noise level may increase (without any effect on the cooling performance). -
Page 10: Status Indicator
CCP FRIDGE·FREEZER Status Indicator E0 flash every 4 seconds temperature sensor issue: • Contact Leisure-Tec on 1300 07 2018 E1 flash every 4 seconds - low voltage & Battery Protection: • An E1 will occur when the battery protection level has been reached. i.e input voltage to low for protection setting, check power source voltage. - Page 11 CCP FRIDGE·FREEZER Notes: page 11...
-
Page 12: Product Specifications
If we determine that a myCOOLMAN product is defective in materials or workmanship during the warranty period, we will either repair or replace the unit. - Page 13 PORTABLE POWER PACK Operation Manual for Portable Fridge Power Pack Model CPP 15 www.mycoolman.com.au LEISURE-TEC Australia Pty Ltd...
-
Page 14: Table Of Contents
PORTABLE POWER PACK Content Thank you for purchasing the myCOOLMAN Power Pack. For safety, please read this operation manual and store the Power Pack safely when not in use. If the Power Pack is a gift for someone else, please make sure to include this manual as well. -
Page 15: Important Safety Warnings
PORTABLE POWER PACK Important Safety Warnings The myCOOLMAN Power Pack is designed for use with the myCOOLMAN portable fridges. No responsibility is taken for poor performance or damage to the Power Pack or 3rd party product connected to the Power Pack. -
Page 16: Led Battery Capacity Indicator
PORTABLE POWER PACK Operation Instructions & Further Information Product Features: • Magnetic Mounting Pads • ON/OFF Switch • DC Power Outlet • LED Battery Capacity Indicator • Charging Port • Rated to IP66 LED Battery Capacity Indicator DC Power Outlet Charging Port ON/OFF Switch Magnetic Mounting Pads LED Battery Capacity Indicator LED Indicator... -
Page 17: System Protection
• Completely Discharged Battery • Excessive Ambient Heat NOTE: When using the Power Pack with your myCOOLMAN portable fridge/freezer, it is suggested to set the fridges battery protect level to LOW. NOTE: We recommend charging the Power Pack fully at least once every 3 months, even if the Power Pack has not been used. -
Page 18: Cleaning & Maintenance
PORTABLE POWER PACK Cleaning & Maintenance • You can clean the Power Pack by wiping down the outside with a clean damp cloth, dry carefully. • DO NOT wash. • DO NOT submerse the Power Pack in liquid, get wet or spray it with water. Troubleshooting The Battery Pack is not turning on: • Ensure that the battery is charged • Ensure that the unit is powered on • Battery will shut down if exposed to excessive heat – Allow to cool and re-start The Battery Pack is not charging: • Ensure that plug is fully pushed in • Check that the power point is working • Charging must be conducted under 43 °C Battery Disposal Batteries should be recycled in an environmentally sustainable manner, for more information see your local regulatory body or visit: https://batteryrecycling.org.au page 6... -
Page 19: Notes
PORTABLE POWER PACK Notes: page 7... -
Page 20: Product Specifications
Physical Dimension 330 x 140 x 36.5 mm Operation Temperature Recommended +16 °C to + 43 °C * *Operation above 43 °C is possible, however higher temperatures may increase current draw (Ah) and reduce refrigerator performance. Warranty Terms & Conditions To warranty register your unit please head to: https://mycoolman.com.au/pages/warranty-registration and upload a copy of your proof of purchase as well as completing the online form. When you buy a myCOOLMAN Power Pack you have peace of mind knowing that it is backed by a 1 year warranty against defects in materials and workmanship. The myCOOLMAN warranty is provided in addition to any rights provided under Australian Consumer Law. All claims under this warranty should be made by returning the product to the place of purchase at your expense, with the detail of the fault, proof of purchase and fitment details. If we determine that a myCOOLMAN product is defective in materials or workmanship during the warranty period, we will either repair or replace the unit.
