- Page 1 INSTRUCTION MANUAL Deluxe Basketball Hoop SKY9400 + SKY9401 + SKY9402 Ver. 1...
- Page 2 As shoppers, we’re always trying to find the perfect balance between quality & value. At BCP, we believe we’ve achieved that. Our diverse catalog of everyday essentials is tailored especially to our customers & guaranteed to hit that sweet spot of high quality & low price.
-
Page 3: Safety Instructions
NOTICE Please retain these instructions for future reference. • Please read all instructions before attempting to install or assemble this item. Assembly should be done by adults only. • Firmly secure all screws before use. • Reconfirm that all bolts, screws, and knobs are secure before each use. •... - Page 4 WARNING FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. • Only hang from the rim briefly to regain balance or avoid injuring others. Release the rim as soon as safely possible. • During play, especially when performing dunk type activities, keep players face away from the backboard, rim, and net.
-
Page 5: Tools Required
TOOLS REQUIRED ADULT ASSEMBLY 2 PERSON UP TO 20 MIN. SLEEVES WRENCH ASSEMBLY ASSEMBLY REQUIRED (4 SETS) (PROVIDED) HARDWARE M8 x 110mm M8 x 40mm M8 x 20mm M8 x 16mm SPRING SCREW BOLT & NUT BOLT & NUT BOLT 2 SETS 2 SETS 4 SETS... - Page 6 PARTS BACKBOARD 1 PC 2 PCS 1 PC BASE GUARD BOARD TRIANGULAR BLOCK 1 PC 1 PC 1 PC SHORT SUPPORT ROD LONG SUPPORT ROD POLE BRACE I 2 PCS 2 PCS 1 PC POLE BRACE II POLE BRACE III POLE BRACE IV 1 PC 1 PC...
- Page 7 PARTS TOP POLE MIDDLE POLE BOTTOM POLE 1 PC 1 PC 1 PC BASE GEL POWDER LIFTING ROD SPRING HOOK 1 LB 1 PC 1 PC M10 x 180mm BOLT & M10 x 180mm BOLT & M10 x 180mm BOLT & NUT SET I NUT SET II NUT SET III...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Assemble this product outside in your desired play space. Attach the part Y lower pole to the part P base with one part H bolt & nut set. Locate and overlap the four part U pole braces onto either side of the part Y lower pole’s fastener hole, then secure the four braces with one part G bolt &... - Page 9 PRODUCT ASSEMBLY Locate the part L board bracket, and gently NOTE: Insert the part A bolts into the top bend the two tines into a ‘Y’ shape. holes of the rim and the part B bolts into the bottom holes. Attach the part L board bracket to the back of the part O backboard with two part D bolt &...
- Page 10 PRODUCT ASSEMBLY Attach the part N net to the part M rim as shown: Attach the part S short support rods to the part W top pole with one part 4 bolt & nut set. Attach the part T long support rods to the part W top pole with one part 3 bolt & nut set. Attach the part BB lifting rod to the ends of the part T long support rods with one part 2 bolt &...
- Page 11 PRODUCT ASSEMBLY Insert one part 3 bolt set between the central fastener holes of the part S short support rods. Adjust the backboard so the support rods are nearly perpendicular to the ground before proceeding. Hook the end of one part 5 spring I into the receiver of the part L board bracket, then loop the other end to the part 1 spring hook.
- Page 12 PRODUCT ASSEMBLY Slide the part X middle pole into the part Y bottom pole, then secure with two part I bolt & nut sets. Slide the part X middle pole into the part W top pole, then secure with two part I bolt & nut sets.
- Page 13 PRODUCT ASSEMBLY The product is fully assembled at regulation height (2.3m – 3.05m), remove the middle pole to use the product at 1.35 – 2.15m. With a second person, carefully return the assembled product to the upright position and fill the part P base with your choice of sand, water, or the part Z base gel powder (see ‘Base Gel Mixing’...
- Page 14 POLE CARE AND SYSTEM MAINTENANCE • Avoid exposure to corrosives such as salt, pesticides, or herbicides. • Excessive use or misuse may contribute to pole failure, which may result in property damage, personal injury, or death. • Check your basketball system frequently for loose hardware, excessive ware, and signs of corrosion. •...
- Page 15 Earn points while you shop. Join today! Give your friends 15% o their first order! For each successful referral you’ll receive 100 points. bestchoiceproducts.com...
-
Page 16: Help Center
HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
