Thank you for purchasing our
TS ProSpred 3000S Fertilizer and
Salt Spreader | Assembly Instructions
We're delighted to have you as a customer and are here to help!
First off, let's get your product assembled!
Table of Contents:
1: Spare Parts
2-4: Assembling your TS ProSpred 3000S
5-7: Remote Border Control Assembly
7-8: How to Swap Over the Material Plates
9: How to Use the TS ProSpred 3000S
10: Warranty Statement
Advertisement
Related Manuals for agri supply Turf Stuff ProSpred 3000S
Summary of Contents for agri supply Turf Stuff ProSpred 3000S
- Page 1 Thank you for purchasing our TS ProSpred 3000S Fertilizer and Salt Spreader | Assembly Instructions We’re delighted to have you as a customer and are here to help! First off, let’s get your product assembled! Table of Contents: 1: Spare Parts 2-4: Assembling your TS ProSpred 3000S 5-7: Remote Border Control Assembly 7-8: How to Swap Over the Material Plates...
-
Page 2: Spare Parts
Spare Parts... - Page 3 Assembling your TS ProSpred 3000S Place the Hopper body (1) on the table so that the Take the backstand (7) and align it with the gearbox is pointing upwards. Take the bolts out of holes on the main frame (1). Place the four bolts the main frame (1) - you will use these to attach through the holes available.
- Page 4 Assembling your TS ProSpred 3000S Take the small cotterpin (10) and place it through Once in position, use the same plyers to split the the hole on the outside of the other wheel. ends of the cotter pin (10) to hold the wheel in place.
- Page 5 Assembling your TS ProSpred 3000S Take the other end of the control rod (3) and Make sure the slider at the bottom of the hopper align it with the hole on the on/off mechanism of is fully open. You should see the entirety of the the handle bar (4).
- Page 6 Remote Border Control Assembly Take the gauge assembly. Place the gauge assembly on the 3 outside of the tube and locate the bolt through the tube. Note: This is locating onto the left side handle. Tighten lock nut onto bolt to secure gauge Loosen the two bolts holding the left side of assembly in place.
- Page 7 Remote Border Control Assembly The pivot bracket should now be securely in Locate the pivot rod end through the hole in place as shown. the pivot bracket as shown. Push the pivot as far in as possible to allow Place the free end of the pivot rod through you to connect the rod into the the bracket the available hole on the end of the border and border control.
- Page 8 Remote Border Control Assembly Place the other end of the remote control rod Put the gauge assembly lever in the off position. through the adjuster screw assembly on the The border control sliding plate needs to also be underside of the gauge assembly. in the off (disengaged) position.
- Page 9 When you have removed the material plate The material plate should be secure and sit level you no longer wish to use, find the alternative underneath the hopper. It should slide smoothly material plate and push it into the groves on the in and out of the groves.
- Page 10 How to use the TS ProSpred 3000S Longitudinal Fertilizer Spreading Cross Sectional Fertilizer Spreading ½ the application rate suggested on ½ the application rate suggested on the back of your fertilizer bag. the back of your fertilizer bag. Cover the area as shown by going Cover the area as shown making over your tire marks left on the the second pass at the edge of your...
-
Page 11: Warranty Statement
Warranty Statement Turf Stuff warrants 100% satisfaction on this product to be free of defects in material and workmanship for a period of one year from the date of purchase. - Page 12 Turf Suff® is a brand owned by Agri Supply® Distributed by Direct Distributors, Inc. Turf Stuff® P.O. Box 799 Garner, NC 27529 Tel: 1-800-345-0169 Email: tech@agrisupply.com...
