EP-050 / EP-100 WARM AIR GENERATOR
MANUAL OF USE AND INSTRUCTIONS
-
REF. MI-EP050-I
-
December 2014 edition
Rights reserved for making technical modifications in order to improve the product.
-
Total or partial printing is forbidden without previous authorization from MET MANN
-
-
Get In Touch
Call: 01729 824108
Email: info@puravent.co.uk
1 de 16
Our Address
Puravent, Adremit Limited, 6 County Business Park,
Darlington Road, Northallerton, DL6 2NQ
MI-EP050-I
Advertisement
Table of Contents
Summary of Contents for Met Mann EP-050
- Page 1 MANUAL OF USE AND INSTRUCTIONS REF. MI-EP050-I December 2014 edition Rights reserved for making technical modifications in order to improve the product. Total or partial printing is forbidden without previous authorization from MET MANN 1 de 16 Get In Touch Our Address...
- Page 2 MI-EP050-I 2 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk...
-
Page 3: Table Of Contents
Disconnection at the end of the season ....................10 ASSISTANCE.............................10 GENERATOR BREAKDOWN DRAWING ....................11 Position refractory bricks EP-050......................12 Position refractory bricks EP-100......................13 ACCESSORIES GENERATOR PROTECTION (EP-050) ................14 3 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk... -
Page 4: Technical Features
MI-EP050-I TECHNICAL FEATURES MODEL EP-050-H EP-050-C EP-100-C Nominal thermal power (Hi) Airflow at +20ºC 1.700 2.400 3.400 Useful static pressure mm.c.a TREATED AIR Thermal difference ºC Electric tension V/F/Hz 220/380V ACIII 50Hz Installed electric power 0,16 0,19 0,59 Noise level at 3 meters in typical installation... -
Page 5: General Dimensions
MI-EP050-I GENERAL DIMENSIONS MODEL Ø EP-050 1396 1190 EP-100 2105 1682 1013 EP-050 EP-100 5 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk... -
Page 6: Functional Features
Fan group It is made of a helicoidal fan (EP-050) or a centrifugal one (EP-100) with a low noise level and a big airflow. Smoke unloading mouth The equipment has a circular neck to which a metallic chimney can be connected and fixed in a secure way, in order to evacuate the combustion products. -
Page 7: Packing And Transport
MI-EP050-I PACKING AND TRANSPORT The warm air generators are sent in a plastic bubble packing. The accessories will be packaged separately. Shipping, unloading and maintenance must be carried out with the maximum care in order to avoid possible harms. INSTRUCCIONS FOR THE QUALIFIED INSTALLER The EP series warm air generator position must be defined taking into account the following instructions: •... -
Page 8: Instructions For Combustion Gas Evacuation
MI-EP050-I INSTRUCTIONS FOR COMBUSTION GAS EVACUATION Chimneys to be installed shall be homologated for their use and will have the statutory draft regulator. Their section will be set according to the following formula: DRAFT A chimney draft is set by the expression: T= H (YA - YB) T= Draft in mm.c.a. -
Page 9: Operation Irregularities - Reasons And Solutions
MI-EP050-I OPERATION IRREGULARITIES - REASONS AND SOLUTIONS – In case of anomalies in the warm air generators operation, ensure first that: • There is enough electric power • Not to give tensions superior to +10% o -15%. • The fuses work correctly. •... -
Page 10: Instrucctions For The User
MI-EP050-I INSTRUCCTIONS FOR THE USER This equipment is designated to industrial use. You must not install it in direct contact with atmospheric agents. Operation • Load the equipment with wood or similar. • Connect the fan to the electric installation. •... -
Page 11: Generator Breakdown Drawing
MI-EP050-I GENERATOR BREAKDOWN DRAWING Gas outlet Fan group Heat exchanger Socket Loading mouth Ash drawer Combustion chamber 11 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk... -
Page 12: Position Refractory Bricks Ep-050
MI-EP050-I Position refractory bricks EP-050 Nº CODE DIMENSIONS 060622011030 220x110x30 12 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk... -
Page 13: Position Refractory Bricks Ep-100
MI-EP050-I Position refractory bricks EP-100 Nº CODE DIMENSIONS 060622011030 220x110x30 PL13645 220x110x30 PL12128 220x037x30 PL13646 220x110x30 PL12218 220x055x30 PL12127 110x110x30 13 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk... -
Page 14: Accessories Generator Protection (Ep-050)
MI-EP050-I ACCESSORIES GENERATOR PROTECTION (EP-050) 14 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk... - Page 15 MI-EP050-I 15 de 16 Get In Touch Our Address Call: 01729 824108 Puravent, Adremit Limited, 6 County Business Park, Darlington Road, Northallerton, DL6 2NQ Email: info@puravent.co.uk...
- Page 16 MI-EP050-I WARNING The manufacturer don't take any responsibility for beyond modifications in the origin machine. The manufacturer don't take any responsibility for the breakdowns caused for a bad use. The manufacturer don't take any responsibility for que working and quality of the machin if this entails implicit the no observation of the present INSTRUCTIONS OF INSTALLATION, USE AND MAINTENANCE Consult to manufacturer about unexpected changes on the instructions.
