Before connecting, operating or adjusting this product, please read
these instructions completely.
Please keep this manual for future reference.
Dear customer
Thank you for purchasing this product.
For optimum performance and safety, please read these instructions
carefully.
User memo:
DATE OF PURCHASE
DEALER NAME
DEALER ADDRESS
TELEPHONE NUMBER
The model number and serial number of this product can be found
on either the back or the bottom of the unit.
Please note them in the space provided below and keep for future
reference.
MODEL NUMBER
-WA100
SERIAL NUMBER
Please check and identify the supplied accessories.
Use numbers indicated in parentheses when asking for replacement
parts.
(Only for U.S.A.)
To order accessories contact 1-800-332-5368 or web site (http:
//www.panasonic.com).
The included AC power supply cord is for use with this unit only.
Do not use it with other equipment.
O Speaker feet (RFAOG31A-K) ..0......cccccccecceceeceeneee 1sheet (4 feet)
Replacements sold in 1-sheet lots (4 feet per sheet).
ee
Panasonic
Active subwoofer system
erating
Instructions
8
ModelNo.
SB-WA100
Mi SPEAKER SECTION
Type
1 way 2 speaker system
Bass-reflex type
Speaker
Woofer
14 cm(5-1/2") cone type * 2
Impedance
1Q
Input power
Music
200 W
DIN
100 W
Sound pressure level
82 dB/W (1.0 m)
Frequency range
40 — 380 Hz (at -16 dB)
45 — 310 Hz (at—10 dB)
@ AMPLIFIER SECTION
Continuous power output
20-200 Hz (THD 1%)
100 W (1 Q)
Phase switching
NORMAL/REVERSE
Input sensitivity/impedance
335 mV/15 kQ
Low pass filter
50-200 Hz Variable
E GENERAL
Power supply
AC 120 V, 60 Hz
Power consumption
40 W
Dimensions (W * H * D)
(231 x 450 x 350) mm
(9-3/32" X 17-23/32" x 13-25/32")
Mass
9.0 kg(19.8 Ib.)
Specifications are subject to change without notice.
Mass and dimensions are approximate.
Product service
Do not attempt to remove the cover(s) or repair the unit yourself.
Refer servicing to qualified personnel only.
Product information
For product service, product information or assistance with prod-
uct operation, refer to the servicenter directory.
For detailed instructions, contact an authorized servicenter
in the U.S.A. and Panasonic Canada Inc. Customer Care Cen-
tre in Canada.
In the U.S.A.1-800-211-7262 or web site
(http://www.panasonic.com)
In Canada 905-624-5505 or web site
(www.panasonic.ca)
RQTJ0127
