Summary of Contents for DiamondCore Tools CINK 2
- Page 1 User Manual Cink 2 Quick Start Video...
-
Page 2: Table Of Contents
Warranty.Coverage........................... 12 Maintenance.Log..........................13 INTRODUCTION The Cink 2 is a complete, self-contained system for cleanup of clay, clay water, pottery tools and accessories. The system is designed to prevent clay from going down drains in plumbing or septic systems. User... -
Page 3: Safety.precautions
Always leave the Cink 2 unplugged during a lightning storm and when it is not in use. • To reduce the risk of fire or electric shock, do not expose the Cink 2 to outdoor elements such as rain, snow, etc. •... -
Page 4: Quick.start
QUICK START QUICK START Faucet Cink 2 Nozzle Tube Pump Quick Start Video String Filter Housing (O-Ring & String Filter inside) Sink Basin Drain Union Leverage Handle Quick Disconnect Filter Bucket Drain Bucket Dolly Bucket Locking Foot Switch Caster Wheels... - Page 5 See page 10 Reattach string filter housing. Be sure it is straight and tight. Reconnect tubes with quick discon- Plug Cink 2 foot switch to grounded Turn right to tighten. nects and reattach drain union. outlet, then plug in pump.
-
Page 6: Operation
NEVER block the sink basin drain and fill the basin with water to wash parts. This may cause the buckets to collapse if the pump keeps pumping. The Cink 2 system is designed to function with continuous recirculation of water. -
Page 7: Maintenance
Emptying the Drain Bucket The drain bucket is intended to capture most of the clay and slip that will be put into the Cink 2. You will need to empty this bucket more frequently than cleaning or replacing the other two filters. - Page 8 MAINTENANCE Emptying the Filter Bucket and Cleaning the Bag Filter The bag filter in the filter bucket is designed to stop small particles and debris that do not settle in the drain bucket. This filter can usually be cleaned instead of replaced. The sediment level in the bottom of the filter bucket should not be allowed to get above 1 inch.
- Page 9 MAINTENANCE Changing the String Filter in the String Filter Housing The string filter housing collects ultra-fine clay particles and should be cleaned at least every 3 months. Eventually, the pores of the filter cartridge will fill up and the water flow from the nozzle will decrease. At that time, please visit diamondcoretools.com, call 619-905-9400 or email cink diamondcoretools.com to purchase replacement string filters.
-
Page 10: Quick.disconnect.usage
Extended Non-Use of the Cink 2 If you don’t plan to use the Cink 2 for an extended period, we recommend unplugging the unit, removing all water and clay from the system, cleaning the unit and allowing the filters to air dry. Follow instructions for Winterizing Cink 2 above. -
Page 11: Frequently.asked.questions
Essential oil (will not address root cause) Copper carbonate (glaze pigment) The water out of the faucet is muddy; how can this be fixed? Clean string filter thoroughly Clean bag filter thoroughly Drain system and refresh water Cink 2 Quick Start Video | 619-905-9400... -
Page 12: Parts.&.Accessories
The CINK Replacement String Filter: $29 The CINK Replacement Bag Filter: $19 The CINK Replacement String Filter Canister: $95 The CINK Acccessory Set: $10 Cink 2 Pump Replacement Kit: $398 For Replacement Parts DiamondCore® Tools 680 W. Bradley Ave. El Cajon, CA 92020... -
Page 13: Maintenance.log
MAINTENANCE LOG DATE ACTION ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________ ___________________________________________________________________________ ____________________... - Page 14 Changing the World of Ceramic Arts Glass Arts Lapidary Arts Wax Arts And More 680 W. Bradley Ave., El Cajon, CA 92020 619-905-9400 | diamondcoretools.com | cink@diamondcoretools.com...
