Model:
Item:
CONSUMER SAFETY INFORMATION: PLEASE READ THIS MANUAL
BEFORE INSTALLING AND OPERATING THIS APPLIANCE. FAILURE TO
FOLLOW THESE INSTRUCTIONS MAY RESULT IN A POSSIBLE
ELECTRIC SHOCK, FIRE HAZARD, AND/OR INJURY AND WILL VOID
THE WARRANTY.
WARNING: IF THE INFORMATION IN THIS MANUAL IS NOT
FOLLOWED, AN ELECTRIC SHOCK OR FIRE MAY RESULT IN
PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE.
THIS INSTRUCTION BOOKLET CONTAINS
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
06/12/2024 | REV. A
Uptown
Smart Electric Fireplace
2322-M-P1
EF-TL-23
OWNER'S MANUAL
2822-H-P1
EF-TL-28
IMPORTANT
261046
3322-H-P1
EF-TL-33
SAFETY
Advertisement
Table of Contents
Related Manuals for MODERN EMBER CountryLiving Uptown 2322-M-P1
Summary of Contents for MODERN EMBER CountryLiving Uptown 2322-M-P1
- Page 1 Uptown Smart Electric Fireplace 261046 Model: 2322-M-P1 2822-H-P1 3322-H-P1 Item: EF-TL-23 EF-TL-28 EF-TL-33 OWNER’S MANUAL CONSUMER SAFETY INFORMATION: PLEASE READ THIS MANUAL BEFORE INSTALLING AND OPERATING THIS APPLIANCE. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN A POSSIBLE ELECTRIC SHOCK, FIRE HAZARD, AND/OR INJURY AND WILL VOID THE WARRANTY.
-
Page 2: Important Safety Instructions
Important Safety Instructions When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and/or injury including the following: 13. To disconnect this appliance, turn controls to Read all instructions before using this heater. the off position, then remove plug from outlet. -
Page 3: Parts & Hardware
Parts & Hardware Fireplace Remote Control Manual Plastic Wire Ring Electrical Specifications Voltage: 120 VAC Rating: 1500 Watts Frequency: 60 Hz... -
Page 4: Installation And Assembly
Installation & Assembly INSTALLATION INSTRUCTIONS Plan the installation of your fireplace to avoid the use of an extension cord, and ensure that you have clear access to a grounded electrical outlet. The fireplace appliance comes with a standard 6-ft. (1.8m) 3-wire cord exiting from the rear of the fireplace. Once you have decided on a location, position your assembled mantel close to the final location. - Page 5 Installation & Assembly Do not share a socket with other appliances when using the electric fireplace. Please use a dedicated socket. × √ × Never use with an extension cord or relocatable power tap (outlet / power strip). ×...
-
Page 6: Hardwire Installation
Installation & Assembly HARDWIRE INSTALLATION If it is necessary to hardwire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the household wiring. This appliance must be electrically connected and grounded in accordance with local codes if hardwired. - Page 7 Operating Instructions On the top-right of the fireplace is the touchscreen control panel. This panel contains the buttons to properly operate the electric fireplace. POWER The power button turns the fireplace on and off. When the fireplace is off, pressing the power button once will switch on the fireplace.
- Page 8 Operating Instructions TIMER The timer has adjustable settings from 1 hour to 9 hours and OFF. These are shown as: 1h-2h-3h-4h-5h-6h-7h-8h-9h-OFF. If the digital display turns on and no timer setting is chosen within 10 seconds, the digital display will shut off automatically. Once you set the timer and the timer is up, the unit will close all functions and enter standby mode.
-
Page 9: Remote Control
Operating Instructions REMOTE CONTROL Power The Power Button turns the fireplace ON and OFF. Heater The Heater Button turns the heat ON and OFF. Press “+” or ”-” button to adjust the temperature. Flame The Flame Button is used to turn the flames ON, to alter the flame color, and turn the flames OFF. -
Page 10: Wifi Operation
App Connection Instructions WIFI OPERATION INSTALL TuyaSmart life There are 2 ways to install TuyaSmart: 1. Search for “TuyaSmart life” in the APP store on your phone; download and install. 2. Scan the QR code below with your mobile phone. WIFI SETTING AND FIREPLACE OPERATION NOTE: Before logging into TuyaSmart, make sure the WiFi signal is good and have the WiFi account name and password available. - Page 11 App Connection Instructions Figure 1 Figure 2 Figure 4 Figure 3 Figure 5...
- Page 12 App Connection Instructions Figure 7 Figure 6...
-
Page 13: Care And Maintenance
Care & Maintenance Clean the metal trim using a soft cloth, slightly dampened with citrus oil based product and buff with a clean soft cloth. DO NOT use brass polish or household cleaners as these products will damage the metal trim. Citrus oil based products can be obtained at supermarkets or hardware stores. -
Page 14: Fcc Statement
FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two con- ditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 15: Year Limited Warranty
1 Year Limited Warranty Our electrical fireplace is free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 5. Any installation, labor, construction, 1. This electric fireplace must transportation, other... - Page 16 Questions, problems, missing parts? Before returning to the store, call Customer Service: 8am - 5pm CST, Monday - Friday Phone: 877-430-0703 Email: resolutions@electricfireplacesdirect.com Retain this manual for future use. Made in China Printed in China...
