Page 1 RA-3B SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO. KP-53V100 RM-Y906 LATIN NORTH SCC-P62E-A ORIGINAL MANUAL ISSUE DATE: 5/2003 ALL REVISIONS AND UPDATES TO THE ORIGINAL MANUAL ARE APPENDED TO THE END OF THE PDF FILE. REVISION DATE...
Page 2 All manuals and user guides at all-guides.com Self Diagnosis Supported model RA-3B SERVICE MANUAL CHASSIS MODEL NAME REMOTE COMMANDER DESTINATION CHASSIS NO. KP-53V100 RM-Y906 LATIN NORTH SCC-P62E-A KP-53V100 RM-Y906 COLOR REAR VIDEO PROJECTION 9-965-942-01...
Page 3: Table Of Contents
All manuals and user guides at all-guides.com KP-53V100 TABLE OF CONTENTS SECTION TITLE PAGE SECTION TITLE PAGE Specifications ................. 4 SECTION 4: CIRCUIT ADJUSTMENTS..........29 Warnings and Cautions ..............5 4-1. TV Input Sub Contrast Adjustment (VPNT-SCON) ....29 Safety Check-Out ................6 4-2.
Page 4: Specifications
All manuals and user guides at all-guides.com KP-53V100 SPECIFICATIONS Power Requirements 120V AC, 60Hz Power Consumption (W) 170W In Use (Max) In Standby Inputs/Outputs Video 1 IN Video 4 IN Y: 1 Vp-p, 75 ohms, sync negative Video 2 INPUT (front) : 0.7 Vp-p, 75 ohms...
Page 5: Warnings And Cautions
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony.
Page 6: Safety Check-Out
All manuals and user guides at all-guides.com KP-53V100 SAFETY CHECK-OUT Leakage Test After correcting the original service problem, perform the following The AC leakage from any exposed metal part to earth ground and from safety checks before releasing the set to the customer: all exposed metal parts to any exposed metal part having a return to chassis, must not exceed 0.5 mA (500 microamperes).
Page 7: Self-Diagnostic Function
All manuals and user guides at all-guides.com KP-53V100 Self Diagnosis SELF-DIAGNOSTIC FUNCTION Supported model The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER LED will automatically begin to flash. The number of times the LED flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER LED flash indicators is listed in the instruction manual for the user’s knowledge and reference.
Page 8 All manuals and user guides at all-guides.com KP-53V100 Self-diagnosis screen displays In cases of malfunctions where it is not possible to determine the symptom such as when the power goes off occasionally or when the screen disappears occasionally, there is a screen display on whether the malfunction occurred or not in the past (and whether the detection circuit operated or not) in order to allow confirmation.
Page 9 All manuals and user guides at all-guides.com KP-53V100 Self-diagnosis function operation Low B and +B line detect DET SHORT, and shut-down POWER ON RELAY. Reset by turning power on/off. In case of +B is loaded approx. 1.3A or more, microcomputer detects it via IC651.
Page 10: Section 1: Disassembly
All manuals and user guides at all-guides.com KP-53V100 SECTION 1: DISASSEMBLY 1-1. REAR BOARD REMOVAL 1-2. CHASSIS ASSEMBLY REMOVAL � �� 1-3. SERVICE POSITION �� ...
Page 11: Beznet Assy Removal
All manuals and user guides at all-guides.com KP-53V100 1-4. BEZNET ASSY REMOVAL Screws, dome washer HEX tap 4x20 Beznet assy Screws, dome washer HEX tap 4x20 1-5. MIRROR COVER REMOVAL Twenty five screws, dome washer HEX tap 4x20 Mirror cover...
Page 12: H4 Board And S Board Removal
All manuals and user guides at all-guides.com KP-53V100 1-6. H4 BOARD AND S BOARD REMOVAL �� 1-7. A BOARD AND G BOARD REMOVAL �...
Page 13: H2 Board Removal
All manuals and user guides at all-guides.com KP-53V100 1-8. H2 BOARD REMOVAL � �� 1-9. H1 BOARD REMOVAL � �� ...
Page 14: High-Voltage Cable Installation And Removal
All manuals and user guides at all-guides.com KP-53V100 1-11. HIGH-VOLTAGE CABLE INSTALLATION AND REMOVAL �� 1-12. PICTURE TUBE REMOVAL CAUTION: Removing the arrow-marked screws is strictly prohibited. If removed, it may cause liquid to spill.
Page 15: Section 2: Set-Up Adjustments
All manuals and user guides at all-guides.com KP-53V100 SECTION 2: SET-UP ADJUSTMENTS 2-3. DEFLECTION YOKE TILT ADJUSTMENT 2-1. SCREEN VOLTAGE ADJUSTMENT (COARSE ADJUSTMENT) 1. Display a cross-hatch pattern 2. Enter the service mode. 1. Select a video input with no signal applied (the screen must be black, and the room must be as dark as possible.
Page 16: Focus Adjustment
All manuals and user guides at all-guides.com KP-53V100 2-4. FOCUS ADJUSTMENT 2-5. FOCUS CONTROL ADJUSTMENT 1. Enter the service mode. In this adjustment, use the remote commander while in service 2. Display a white raster. mode. For details on the usage of the service mode and the remote 3.
Page 17: 2-Pole Magnet Adjustment (Green , Red)
All manuals and user guides at all-guides.com KP-53V100 2-6. 2-POLE MAGNET ADJUSTMENT 8. Repeat steps 1 through 6 for the blue CRT, except now cover the green and red CRT lenses with lens caps to allow only blue to show.
Page 18: Electrical Adjustment By Remote Commander
All manuals and user guides at all-guides.com KP-53V100 2-9. ELECTRICAL ADJUSTMENT BY 2-9-2. MEMORY WRITE CONFIRMATION REMOTE COMMANDER METHOD By using Remote Commander (RM-Y906), all circuit adjustments can be 1. After adjustment, remove the plug from the AC outlet, and then made.
Page 19: Service Mode Lists
All manuals and user guides at all-guides.com KP-53V100 2-9-4. SERVICE MODE LISTS VPNT (Video Processor NTSC) ADJUSTM'T SERVICE DATA NAME SETTING VARIABLE (24) VARIABLE (30) FIXED VARIABLE (10) FIXED FIXED VARIABLE (26) VARIABLE (20) VARIABLE VARIABLE VARIABLE FIXED FIXED FIXED...
Page 20 All manuals and user guides at all-guides.com KP-53V100 PJED (Projection TV Engine) ADJUSTM'T SERVICE DATA NAME SETTING FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED...
Page 21 All manuals and user guides at all-guides.com KP-53V100 3DCM (3D Comb Filter) ADJUSTM'T SERVICE DATA NAME SETTING FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED FIXED...
Page 22 All manuals and user guides at all-guides.com KP-53V100 PIP (Picture In Picture) ADJUSTM'T SERVICE DATA NAME SETTING FSEL FIELD SELECT FIXED VACQ 0-15 VERTICAL ACQUISITION VARIABLE HACQ 0-15 HORIZONTAL ACQUISITION VARIABLE ISYS INSET DISPLAY SYSTEM FIXED PSYS PARENT SYSTEM FIXED...
Page 23: Registration Adjustment (Pje) Function Of Buttons Of Remote Commander For Pje Mode Only
All manuals and user guides at all-guides.com KP-53V100 2-10.REGISTRATION ADJUSTMENT (PJE) 1. Enter the service mode by quickly pressing the keys on the remote FUNCTION OF BUTTONS OF REMOTE commander in the standby mode in the following order: COMMANDER FOR PJE MODE ONLY Press “DISPLAY,”...
Page 24: Green Registration Adjustment
All manuals and user guides at all-guides.com KP-53V100 13. Cover the red and blue picture lenses with lens caps to allow only GREEN PINCUSHION green to show, or use the method shown in the note below to turn the 1. Select GRN PIN with the 1 and 4 buttons on the remote commander.
Page 25: Red Registration Adjustment
All manuals and user guides at all-guides.com KP-53V100 4. Press the joystick center button once; the cursor will return to FINE ADJUSTMENT green (or red or blue, depending on the previously selected color). 1. Press the 9 button on the remote commander to shift to the fine When the cursor is green, you can adjust the geometry of the area adjustment mode;...
Page 26: Auto Registration Error Code List
All manuals and user guides at all-guides.com KP-53V100 2-14.AUTO REGISTRATION ERROR CODE LIST If an error code is displayed after the set has been correctly adjusted, check the following items: position, tilt and sizing. If any of these adjustments are off, even slightly, the auto-registration pattern will not hit the four sensors properly. This occurs when the internal generator patterns are being flashed on the screen for the sensors to read.
Page 27: Section 3: Safety-Related Adjustments
All manuals and user guides at all-guides.com KP-53V100 SECTION 3: SAFETY-RELATED ADJUSTMENTS G BOARD 3-2. HV HOLD DOWN CIRCUIT OPERATION CHECK AND ADJUSTMENT 3-1. HV REGULATION CIRCUIT CHECK AND When replacing the following components marked with a Y on the...
Page 28: B Max Voltage Confirmation
All manuals and user guides at all-guides.com KP-53V100 3-3. +B MAX VOLTAGE CONFIRMATION The following adjustments should always be performed when replacing IC654. 1. Supply 130V +/- 2V AC to the set. 2. Display a dot pattern through the video-1 input.
Page 29: Section 4: Circuit Adjustments
All manuals and user guides at all-guides.com KP-53V100 SECTION 4: CIRCUIT ADJUSTMENTS 4-1. TV INPUT SUB CONTRAST 4-3. COMPONENT INPUT SUB-HUE AND ADJUSTMENT (VPNT-SCON) SUB-COLOR ADJUSTMENT (DAC-UVSH, UVSC) 1. Display a color bar signal through the TV’s VHF/UHF input. 2. Mode: Personal 1 or 2 1.
Page 30: Pip Sub-Hue, Sub-Color Adjustment (Pyc-Phue, Pyc-Pcol)
All manuals and user guides at all-guides.com KP-53V100 4-5. PIP SUB-HUE, SUB-COLOR 4-7. PIP POSITION ADJUSTMENT ADJUSTMENT (PIP-POFV, POFH) (PYC-PHUE, PYC-PCOL) 1. Select the PIP mode. 2. Display any signal in the PIP window. 1. Display a color bar signal through the TV’s VHF/UHF input.
Page 31: Section 5: Diagrams
All manuals and user guides at all-guides.com KP-53V100 SECTION 5: DIAGRAMS 5-1. CIRCUIT BOARDS LOCATION � �� 5-2. PRINTING WIRING BOARDS AND SCHEMATIC DIAGRAM INFORMATION All capacitors are in µF unless otherwise noted. pF : µµF 50WV or less The components identified by X in this basic schematic diagram are not indicated except for electrolytics and tantalums.
Page 32 All manuals and user guides at all-guides.com KP-53V100 Terminal name of semiconductors in silk screen REFERENCE INFORMATION printed circuit ( Circuit Device Printed symbol Terminal name RESISTOR : RN METAL FILM Collector : RC SOLID Transistor Emitter Base : FPRD...
Page 33: Block Diagrams
All manuals and user guides at all-guides.com KP-53V100 5-3. BLOCK DIAGRAMS BLOCK DIAGRAM (1 OF 8) �� ...
Page 34 All manuals and user guides at all-guides.com BLOCK DIAGRAM (2 OF 8) KP-53V100 — 34 —...
Page 35 All manuals and user guides at all-guides.com KP-53V100 BLOCK DIAGRAM (3 OF 8) — 35 —...
Page 36 All manuals and user guides at all-guides.com KP-53V100 BLOCK DIAGRAM (4 OF 8) — 36 —...
Page 37 All manuals and user guides at all-guides.com KP-53V100 BLOCK DIAGRAM (5 OF 8) (SENSOR) IC802 IC808 IV CONV (1/6, 3/6) CN802 CN3001 I AREGI D3 I HP SENSOR LEFT I DREG OVF I DREG BSY I AREGI D0 I DREG ACK...
Page 38 All manuals and user guides at all-guides.com KP-53V100 BLOCK DIAGRAM (6 OF 8) D+5V IC808 (1/6, 3/6) TO G BOARD CN1502 TO G BOARD IC801 CN651 TO G BOARD CN501 R OR Q807 REGI OUT G OR Q809 Q811 B OR...
Page 39 All manuals and user guides at all-guides.com KP-53V100 BLOCK DIAGRAM (7 OF 8) CN732 (R DRIVE) IK R CN704 CN701 CN731 CN740 Q704-706 IK R TO A Q731-733 4, 5, BOARD 9, 11 V902 CN204 4, 5, CN702 BUFFER V901...
Page 40 All manuals and user guides at all-guides.com KP-53V100 BLOCK DIAGRAM (8 OF 8) POWER SUPPLY H/V OUT IC1502 IC1501(1/2) SUB DY-DRIVE IC1509 V ZOOMING AMP CN651 V OUT CN501 DY (B) CN1503 V DRIVE (+) CN1506 HR OUT RV DEF V.
Page 41: Frame Schematic Diagram
All manuals and user guides at all-guides.com KP-5 5-4. FRAME SCHEMATIC DIAGRAM CN1291 SIRCS D1291 REMOTE SENSOR (REMOTE SENSOR) S9201-9205 (POWER) S9212 CN9202 CONTROL SWITCHES CN9201 CN9101 S9101 P-ON POWER P-ON POWER POWER STEREO-LED STEREO-LED TIMER TIMER LED STBY TIMER STBY TIMER S9206-9211 RED LED...
Page 42: Schematic Diagrams And Supporting Information
All manuals and user guides at all-guides.com KP-5 5-5. SCHEMATIC DIAGRAMS AND SUPPORTING INFORMATION A BOARD SCHEMATIC DIAGRAM (1 OF 3) A (1/3) BOARD WAVEFORMS 1.0Vp-p (H) 1.5Vp-p (H) — TU151 TU152 CN001 BTF-WA412 CN002 BTF-FA401 CN1702 MAIN TUNER CN204 SUB TUNER :S-MICRO :S-MICRO...
Page 43: A Board Schematic Diagram (2 Of 3)
All manuals and user guides at all-guides.com KP-5 A BOARD SCHEMATIC DIAGRAM (2 OF 3) A (2/3) BOARD : IC807, 815, 816, 817 PD6376GS-E2 DIGUTAL ANALOG TO (1/3) POWER SUPPLY POWER SUPPLY SYSTEM SYSTEM L.REF D FOCUS C810 C811 FB805 C850 MAIN DAC —...
Page 44: A Board Schematic Diagram (3 Of 3)
All manuals and user guides at all-guides.com KP-5 A BOARD SCHEMATIC DIAGRAM (3 OF 3) A (3/3) BOARD : IC1902 SDA9588X R1937 D1905 R1944 1SS355 :CHIP :CHIP YUVSW C1920 R1928 Q1602 :CHIP B:1608 R1927 2SD601A R1619 :CHIP MAIN Y 2.2k :CHIP C1922 IC1902...
Page 45 All manuals and user guides at all-guides.com KP-53V100 A BOARD LOCATOR LIST [SYSTEM CONTROL, AUDIO, TUNER, YCJ, PJED, REGI-CORRECTION, P in P, COMB FILTER] DIODE TRANSISTOR COMPONENT SIDE D001 B-12 IC001 A-11 Q022 D002 B-12 IC002 B-10 Q023 D003 A-11...
Page 46 All manuals and user guides at all-guides.com KP-53V100 A BOARD LOCATOR LIST [SYSTEM CONTROL, AUDIO, TUNER, YCJ, PJED, REGI-CORRECTION, P in P, COMB FILTER] DIODE TRANSISTOR CONDUCTOR SIDE D005 I-11 Q002 I-10 D007 I-11 Q013 H-10 D151 C-12 Q151 E-11...
Page 47: G Board Schematic Diagram
All manuals and user guides at all-guides.com KP-5 G BOARD SCHEMATIC DIAGRAM CN1507 CN1508 CN1506 CN1503 CN1504 CN1505 :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO :S-MICRO TO DY(R) TO DY(G) TO DY(B) TO DY(R) TO DY(G) TO DY(B) G BOARD WAVEFORMS IC1502 IC1506 —...
Page 48 All manuals and user guides at all-guides.com KP-53V100 [H/V, DY DRIVE, POWER SUPPLY] COMPONENT SIDE SECONDARY SHADING V.OUT AUDIO(-) EY33 EY32 C602 R612 TP -19V IC653 POWER SUPPLY D660 HEAT R1554 JW215 R1580 R1582 JW138 D670 SINK R611 AUDIO(+) C620...
Page 49 All manuals and user guides at all-guides.com KP-53V100 [H/V, DY DRIVE, POWER SUPPLY] CONDUCTOR SIDE AC.IN ANT.E SUB.OUT CP601 CN502 H.OUT BLUE CN1503 C567 R573 C554 R502 CN653 CN1505 CN1504 GREEN R577 C506 R1596 CN655 TP501 C508 T501 CP602 C553...
Page 50 All manuals and user guides at all-guides.com KP-53V100 G BOARD LOCATOR LIST ' ) ',2'( ' ' ' ) ' ' ' ) ' ' ' ( ' ' ' ) ' ' ' ) ' & ' + ' &...
Page 51: Cb Board Schematic Diagram
All manuals and user guides at all-guides.com KP-53V100 CB BOARD SCHEMATIC DIAGRAM V901 PICTURE TUBE — TO HV BLOCK — TO FOCUS PACK F GND CN766 B DRIVE R777 NL761 R779 1/2W 1/2W R783 CN763 — R762 560k CN762 TO FOCUS PACK...
Page 52 All manuals and user guides at all-guides.com KP-53V100 [B DRIVE] COMPONENT SIDE [B DRIVE] CONDUCTOR SIDE CN762 — 52 —...
Page 53: Cg Board Schematic Diagram
All manuals and user guides at all-guides.com KP-53V100 CG BOARD SCHEMATIC DIAGRAM V902 PICTURE TUBE — TO HV BLOCK CN734 CN737 TO FOCUS PACK :S-MICRO TO FOCUS PACK B-H(+) TO G:CN503 DY(B) CN740 F GND R734 TO G:CN CN733 H(MID)
Page 54 All manuals and user guides at all-guides.com KP-53V100 [G CRT DRIVE, VM DRIVE] COMPONENT SIDE — 54 —...
Page 55 All manuals and user guides at all-guides.com KP-53V100 [G CRT DRIVE, VM DRIVE] CONDUCTOR SIDE — 55 —...
Page 56: Cr Board Schematic Diagram
All manuals and user guides at all-guides.com KP-53V100 CR BOARD SCHEMATIC DIAGRAM V901 PICTURE TUBE — TO HV BLOCK TO FOCUS PACK — CN704 F GND R DRIVE NL701 CN702 R722 R721 1/2W :S-MICRO 1/2W TO CG:CN735 R723 H(+) CN703...
Page 57 All manuals and user guides at all-guides.com KP-53V100 [R DRIVE] COMPONENT SIDE [R DRIVE] CONDUCTOR SIDE CN702 — 57 —...
Page 58: H4 Board Schematic Diagram
All manuals and user guides at all-guides.com KP-53V100 H4 BOARD SCHEMATIC DIAGRAM [IN/OUT SELECT] D1293 COMPONENT SIDE MTZJ-5.6 PROT D1291 STBY 5V GP1U28Y C1291 IR SENS0R SIRCS — R1291 ST 5V CN1291 CN1291 SIRCS D1293 WHT-L VO VC D1292 :S-MICRO...
Page 59: H1 Board Schematic Diagram
All manuals and user guides at all-guides.com KP-53V100 H1 BOARD SCHEMATIC DIAGRAM STBY/LED D9101 TO H2 SLR-325VCT31 CN9201 STBY-TIMER-LED — R9103 STEREO-LED R9107 P-ON :1608 S9101 STBY 5V(TIMER) POWER R9104 TIMER/LED CN9101 :1608 D9102 SLR-325VCT31 — :S-MICRO 9-965-942-01<RA3B> H1 [POWER SWITCH]...
Page 60 All manuals and user guides at all-guides.com KP-53V100 [FUNCTION KEYS] COMPONENT SIDE — — — [FUNCTION KEYS] CONDUCTOR SIDE — — — — 60 —...
Page 61: H3 Board Schematic Diagram
All manuals and user guides at all-guides.com KP-53V100 H3 BOARD SCHEMATIC DIAGRAM CN9301 D9305 C9304 R9305 WHT-L RD10EST1 J9301 :S-MICRO PROT 1/16W :CHIP FR R OUT D9306 C9305 R9306 RD10EST1 — PROT 1/16W FR L OUT :CHIP FR V OUT...
Page 62: Semiconductors
All manuals and user guides at all-guides.com KP-53V100 5-6. SEMICONDUCTORS BA05T CXA2039M-T6 NJM7805FA UPC339C 2SA1175-HFE 11ES2 D1NL20U 2SA1309A D1N20R 2SC2785-HFE D1NL20U CATHODE 2SC3311A D2L20U MTZJ-10B TOP VIEW 14pin MTZJ-13 TOP VIEW MTZJ-15B LETTER SIDE 24pin MTZJ-2.7A MTZJ-3.9B ANODE DM-58 Z8613012SSC-00TR MTZJ-4.7C...
Page 63: Section 6: Exploded Views
PART NO. DESCRIPTION ASSEMBLY INCLUDES X-4041-635-1 ASSY, BEZNET 4-082-286-01 GUIDE, LED 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3 4-047-997-01 EMBLEM (NO. 10), SONY 4-919-393-01 DAMPER 7-685-661-79 SCREW +BVTP 4X12 TYPE2 IT-3 4-081-065-11 SCREEN (53), CONTRAST 4-082-289-01 HOLDER, FRONT TERMINAL 4-070-525-11 PLATE (L), DIFFUSION...
Page 64: Chassis
All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identiﬁ ed by shading and mark are critical for safety. Replace only with part number speciﬁ ed. 6-2. CHASSIS 7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3 REF.NO. PART NO. DESCRIPTION ASSEMBLY INCLUDES REF.NO.
Page 65: Picture Tube
All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identiﬁ ed by shading and mark are critical for safety. Replace only with part number speciﬁ ed. 6-3. PICTURE TUBE 7-685-663-71 SCREW +BVTP 4X16 TYPE2 IT-3 REF.NO. PART NO.
Page 66: Section 7: Electrical Parts List
All manuals and user guides at all-guides.com KP-53V100 The components in this manual identified by the following RESISTORS symbol: • All resistors are in ohms • F : nonflammable • All variable and adjustable resistors have characteristic curve B, unless otherwise noted.
Page 67 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C284 1-162-970-11 CERAMIC CHIP 0.01µF C440 1-126-963-11 ELECT 4.7µF C285 1-162-970-11 CERAMIC CHIP 0.01µF C441 1-130-477-00 MYLAR 0.0033µF 5% C442 1-130-489-00 MYLAR 0.033µF 5%...
Page 68 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C807 1-164-156-11 CERAMIC CHIP 0.1µF C875 1-126-947-11 ELECT 47µF C808 1-164-173-11 CERAMIC CHIP 0.0039µF 10% C876 1-164-156-11 CERAMIC CHIP 0.1µF C877 1-126-947-11 ELECT 47µF...
Page 69 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C927 1-164-156-11 CERAMIC CHIP 0.1µF C1116 1-107-826-11 CERAMIC CHIP 0.1µF C928 1-164-156-11 CERAMIC CHIP 0.1µF C1117 1-162-923-11 CERAMIC CHIP 47pF C1118 1-164-816-11...
Page 70 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C1717 1-162-917-11 CERAMIC CHIP 15pF C1903 1-107-826-11 CERAMIC CHIP 0.1µF C1718 1-126-947-11 ELECT 47µF C1904 1-162-970-11 CERAMIC CHIP 0.01µF C1905 1-126-947-11 ELECT 47µF...
Page 71 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES CN802 1-564-511-11 PLUG, ONNECTOR D809 8-719-988-61 DIODE 1SS355TE-17 CN1702 1-764-334-11 PIN, CONNECTOR(PCB)(V TYPE) 11P D810 8-719-988-61 DIODE 1SS355TE-17 DIODE D816 8-719-988-61 DIODE...
Page 72 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES FB206 1-216-017-91 RES-CHIP 1/10W FB209 1-216-017-91 RES-CHIP 1/10W IC001 8-759-352-91 PST9143NL IC002 8-752-921-41 CXP750010-039Q-TL FB212 1-216-295-91 SHORT CHIP IC004 8-759-675-64 M24C08-MN6T(A) FB215...
Page 73 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES JACK L1723 1-469-555-21 INDUCTOR 10µH...
Page 74 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES Q228 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q1704 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q229 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R Q1705 8-729-120-28 TRANSISTOR 2SC1623-L5L6 Q1706 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R Q230 8-729-026-49...
Page 75 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R023 1-216-049-11 RES-CHIP 1/10W R078 1-216-025-11 RES-CHIP 1/10W R024 1-216-025-11 RES-CHIP 1/10W R079 1-216-057-00 RES-CHIP 2.2K 1/10W R025 1-216-025-11 RES-CHIP 1/10W R026...
Page 76 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R135 1-216-295-91 SHORT CHIP R296 1-216-033-00 RES-CHIP 1/10W R151 1-216-025-11 RES-CHIP 1/10W R297 1-216-033-00 RES-CHIP 1/10W R152 1-216-083-00 RES-CHIP 1/10W R298 1-216-033-00...
Page 77 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R345 1-216-049-11 RES-CHIP 1/10W R449 1-216-049-11 RES-CHIP 1/10W R346 1-216-089-91 RES-CHIP 1/10W R451 1-216-073-91 RES-CHIP 1/10W R347 1-216-073-91 RES-CHIP 1/10W R348 1-216-079-00...
Page 78 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R854 1-216-025-11 RES-CHIP 1/10W R907 1-216-049-11 RES-CHIP 1/10W R855 1-216-025-11 RES-CHIP 1/10W R908 1-216-049-11 RES-CHIP 1/10W R856 1-216-033-00 RES-CHIP 1/10W R858 1-216-073-91...
Page 79 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R968 1-208-806-11 METAL CHIP 0.50% 1/10W R1127 1-216-113-00 RES-CHIP 470K 1/10W R970 1-208-806-11 METAL CHIP 0.50% 1/10W R1128 1-216-073-91 RES-CHIP 1/10W R972...
Page 80 All manuals and user guides at all-guides.com KP-53V100 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R1191 1-216-025-11 RES-CHIP 1/10W R1713 1-216-025-11 RES-CHIP 1/10W R1193 1-216-041-00 RES-CHIP 1/10W R1714 1-216-025-11 RES-CHIP 1/10W R1197 1-216-041-00 RES-CHIP 1/10W R1202 1-216-025-11...
Page 81 All manuals and user guides at all-guides.com KP-53V100 A component identified by this NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES...
Page 82 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C543 1-117-813-11 FILM 0.75µF 250V...
Page 83 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES C1536 1-162-117-00 CERAMIC 100pF 500V...
Page 84 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES D664 8-719-981-94 DIODE MTZJ-2.7A FUSE HOLDER...
Page 85 All manuals and user guides at all-guides.com KP-53V100 A component identified by this NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES...
Page 86 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R574 1-216-490-11 METAL OXIDE R624...
Page 87 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R1510 1-214-800-11 METAL 1/2W R1562...
Page 88 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES SPARK GAP DIODE SG501 1-519-466-11...
Page 89 All manuals and user guides at all-guides.com KP-53V100 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES D736 8-719-109-85 DIODE RD5.1ESB2 D1304...
Page 90 All manuals and user guides at all-guides.com KP-53V100 CG CR H4 NOTE: The components identified by shading mark are critical for safety. Replace only with part number specified. REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES R1307 1-260-311-11...
Page 91 All manuals and user guides at all-guides.com KP-53V100 S H1 H2 H3 REF.NO. PART NO. DESCRIPTION VALUES REF.NO. PART NO. DESCRIPTION VALUES RESISTOR RESISTOR R1291 1-247-807-31 CARBON 1/4W R9201 1-218-692-11 METAL CHIP 0.50% 1/10W R9202 1-218-696-11 METAL CHIP 1.5K 0.50% 1/10W...
Page 92 MANUAL, INSTRUCTION 4-090-161-01 PALLET, CUSHION 4-042-463-01 SHEET, PROTECTION 4-090-015-01 TRAY REMOTE COMMANDER 1-418-469-11 REMOTE COMMANDER (RM-Y906) 4-978-977-01 BATTERY COVER (RM-Y906) Sony Corporation English Sony Technology Center 2003EJ74WEB-1 Technical Services Printed in USA 9-965-942-01 Service Promotion Department © 2003.5 — 92 —...
Page 93: Frame Schematic Diagram
All manuals and user guides at all-guides.com 5-4. FRAME SCHEMATIC DIAGRAM CN1291 SIRCS REMO (REMOTE CN9202 POWER TIMER LED RED LED MENU KEY (CON...
Page 94 All manuals and user guides at all-guides.com KP-53V100 D1291 REMOTE SENSOR OTE SENSOR) S9201-9205 (POWER) S9212 CONTROL SWITCHES CN9201 CN9101 S9101 P-ON P-ON POWER POWER STEREO-LED STEREO-LED TIMER STBY TIMER STBY TIMER S9206-9211 STBY +5V MENU SWITCHES (CONTROL SWITCHES) (MENU SWITCHES)
Page 95 All manuals and user guides at all-guides.com — 41 —...
Page 96 All manuals and user guides at all-guides.com —...
Page 97: A Board Schematic Diagram (1 Of 3)
All manuals and user guides at all-guides.com 5-5. SCHEMATIC DIAGRAMS AND SUPPORINTING INFORMATION A BOARD SCHEMATIC DIAGRAM (1 OF 3) — TU151 TU152 CN001 BTF-WA412 CN002 BTF-FA401 CN1702 MAIN TUNER SUB TUNER :S-MICRO :S-MICRO :S-MICRO TO H4:CN1291 TO H3:CN9301 TO ANT SW TO H2:CN9202 C152 C166...
Page 98 All manuals and user guides at all-guides.com KP-53V100 A (1/3) BOARD WAVEFORMS 1.0Vp-p (H) 1.5Vp-p (H) CN204 :S-MICRO TO CG:CN731 2.4Vp-p (H) 1.2Vp-p (H) R361 Q302 R352 D303 8.2k D302 Q232 2SD601A 1SS355 :RN-CP 13.1 1SS355 FB2007 FB209 MUTE :CHIP...
Page 99 All manuals and user guides at all-guides.com :RN CP R1113 R1162 MTU AUMT RELAY C1106 Q1125 D1104 Q1119 :CHIP UDZS-TE17-10B :CHIP R1175 2SB709A S-OUT ANTSW2 2SD601A BUFF BUFF :RN-CP RM-IN ANTSW1 R1183 R1112 D1103 C1105 R1168 :CHIP Q1118 UDZS-TE17-10B R122 R001 2SD601A :CHIP...
Page 100 All manuals and user guides at all-guides.com CH:1608 0.47 (SENSOR) :CHIP R282 R294 R283 R345 4.7k Q230 :S-MICRO 4.7k :CHIP A (1/3) BOARD : IC1011 CXA2079Q LEFT :CHIP 2SB709A :CHIP :CHIP LEFT INV. IC406 Q231 TDA7265 2SB709A RIGHT L/R AMP UPPER UPPER S3001...
Page 101: A Board Schematic Diagram (2 Of 3)
All manuals and user guides at all-guides.com A BOARD SCHEMATIC DIAGRAM (2 OF 3) TO (1/3) D FOCUS — C810 C811 FB805 C850 D+5V BLM21A102SPT F:1608 D+5V C813 C821 R903 :CHIP R911 C852 C820 C812 :CHIP F:1608 F:1608 IC807 BV DAC —...
Page 102 All manuals and user guides at all-guides.com KP-53V100 A (2/3) BOARD : IC807, 815, 816, 817 µPD6376GS-E2 DIGUTAL ANALOG POWER SUPPLY POWER SUPPLY C956 R957 R1001 L828 L835 SYSTEM SYSTEM 0.0068 :FLR50 :EL0606 :CHIP :RN-CP B:1608 L.REF C888 C938 C909...
Page 103 All manuals and user guides at all-guides.com PJED-CPU R914 :CHIP O IIC SW I DREG OVF R840 :CHIP O NVM STOP R839 :CHIP O DREGI RST I DSCAN R838 :CHIP C873 O DREGI MUTE I 5060 C864 C875 R810 Q813 I HP I WIDE D+5V...
Page 104 All manuals and user guides at all-guides.com L831 L824 R999 :EL0606 :FLR50 :RN-CP C884 C890 C952 C902 C919 C934 R987 0.0068 0.001 0.0047 R954 :RN-CP B:1608 CH:1608 CH:1608 B:1608 :CHIP R959 D-BV :RN-CP D-BH C958 C964 R953 :CHIP F:1608 R968 R979 C901 :RN-CP...
Page 105: A Board Schematic Diagram (3 Of 3)
All manuals and user guides at all-guides.com A BOARD SCHEMATIC DIAGRAM (3 OF 3) YUVSW C1920 R192 Q1602 B:1608 R192 2SD601A R1619 MAIN Y 2.2k :CHIP C1922 — D1903 R1614 1SS355 B:1608 R1911 :CHIP IC1601 4.7k D1906 Z8622912SSC-00TR :CHIP 1SS355 MAIN V CHIP/CC.
Page 106 All manuals and user guides at all-guides.com KP-53V100 A (3/3) BOARD : IC1902 SDA9588X R1937 D1905 R1944 1SS355 :CHIP :CHIP R1928 :CHIP R1927 :CHIP IC1902 IC1904 SDA9588X Q1913 CXA1315M-T4 C1947 C1938 PIP PROCESSOR X1903 2SD601A D/A CONV. 0.01 CH:1608 20.25MHz...
Page 107 All manuals and user guides at all-guides.com :LB2016 R1720 :CHIP :LB2016 C1714 R1715 R1716 R1717 R1718 :CHIP 2.2k 220k CH:1608 2.2k 5.6k C1717 :CHIP Q1705 :CHIP :CHIP :CHIP :CHIP :RN-CP C1711 C1721 2SD601A C1710 C1708 C1712 BUFF CH:1608 R1722 F:1608 F:1608 :CHIP F:1608...
Page 108 All manuals and user guides at all-guides.com Q1918 C1952 C1954 2SD601A 0.01 R1976 5.6k BUFFER B:1608 :CHIP IC1903 BU4053BCF-E2 YUV SW R1981 :CHIP R1977 V IN U/Y O :CHIP V/C O U IN C IN Y IN DVD SW DVD SW C1939 0.01 DVD SW...
Page 109: G Board Schematic Diagram
All manuals and user guides at all-guides.com G BOARD SCHEMATIC DIAGRAM CN1503 CN1504 :S-MICRO :S-MICRO TO DY(R) TO DY(G) IC1502 IC1506 STK392-150 STK392-150 — R1593 SUB DY-DRIVE SUB DY-DRIVE R1595 Ch.3 Ch.2 Ch.1 Pre. Pre. Ch.3 Ch.2 Ch.1 Pre. Pre. SUB.
Page 110 All manuals and user guides at all-guides.com KP-53V100 CN1507 CN1508 CN1506 CN1505 :S-MICRO :S-MICRO :S-MICRO :S-MICRO TO DY(R) TO DY(G) TO DY(B) TO DY(B) G BOARD WAVEFORMS R1597 IC1509 LA78045 V OUT R1587 R1588 R1589 R1590 R1591 R1592 R1598 C1557 12.5Vp-p (H)
Page 111 All manuals and user guides at all-guides.com R601 L657 0.0022 2.2M 2200 F652 250V CN601 1/2W :LHL08 F601 C606 6.3A 0.0022 C658 D655 125V 2200 250V L656 F651 D4SBS4-F L501 R508 R606 1.8k AC(L) 15V RECT :LHL08 0.82 :LHL08 FB652 FH601 FH602 TP-15V...
Page 112 All manuals and user guides at all-guides.com CN506 JW168 RGP02-20EL DF.BIAS RECT 135V TO DY(R) 135V R-H(+) C522 D518 C535 L504 14000p ERC06-15S 680p G BOARD : IC654 DM-58 C517 1.2kV DUMPER C543 0.001 0.75 C547 250V R582 R-H(-) C534 Q502 137.4 680p...
Page 113 All manuals and user guides at all-guides.com 4-094-821-31(1) evisor de proyección e instrucciones ANTE LEA DETALLADAMENTE AL DE INSTRUCCIONES ONECTAR Y OPERAR ESTE CUERDE QUE UN MAL USO DE PODRIA ANULAR LA Corporation 3/20/03, 10:11 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 114 UHF, VHF, o transmitidos por compañías de cablevisión para uso del público en general, puede requerir la autorización de la emisora/compañía de cable y/o del propietario del programa. 2/27/03, 3:15 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 115 Rosa ....Botones para el empleo de reproductor de DVD. Para obtener una descripción detallada sobre la mayoría de los botones, consulte la abreviatura de “Multi Disk Player (Reproductor “Visualización de TV” en la página 20. últiples)”. 18/2/03, 6:27 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 116 Uso del menú de Ajustes ....34 Conexión de sistema de bocinas de la Uso de la función de Control paterno ..36 serie SAVA de Sony ......17 Activación de la función de Control Indicaciones básicas ...... 18 paterno ..........36 Selección de una clasificación...
Page 117: Indicaciones Básicas
Recomendamos que lea cada una proyección de video de Sony. detenidamente en el orden en que aparecen Este manual es para el modelo KP-53V100. para tener la seguridad de que comprende perfectamente el funcionamiento de su nuevo A continuación se enumeran las TV de proyección.
Page 118: Instalación
Asimismo, se recomienda instalar el TV de proyección en una habitación cuyo suelo y paredes no sean de material reflectante. 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 119 No vierta nunca ningún toma adecuada. No elimine la finalidad de tipo de líquido sobre el televisor. seguridad de la clavija de 3 terminales insertándolo con fuerza. (continúa) 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 120 - No coloque el televisor hacer que se cayese tal combinación. cerca ni sobre un radiador o una salida de aire caliente, ni expuesto a la luz solar directa. 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 121 NEC: National del NEC) agua. Electrical Code En caso de descarga eléctrica Para evitar daños al televisor debido a una (continúa) descarga eléctrica o a una sobretensión de 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 122 Solicite este - No transporte el TV de proyección servicio a un técnico agarrando la rejilla de la bocina. calificado. - Agarre firmemente el TV de proyección cuando lo transporte. 2/27/03, 3:18 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 123 All manuals and user guides at all-guides.com ón del TV de proyección Área de visualización Instalación del TV de recomendada (vertical) proyección Área de visualización recomendada (horizontal) 60° 20° 60° 60° 20° 2/27/03, 3:18 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 124: Cable Control S
Cable Sony para realizar la conexión Conexión directa a cable o a antena CONTROL S. Esta función es exclusiva de los productos Sony, y permite un mayor control La conexión que escoja dependerá del tipo de de todos los equipos Sony.
Page 125: Decodificador Y Cable
VHF/UHF Notas: Cable coaxial • Es posible programar el control remoto Sony para emplear el decodificador (consulte “Uso de un decodificador o un receptor satelital (SAT)” en la página 49). • Durante la visualización de la imagen con la función PIP o Canal favorito, la entrada...
Page 126 AUDIO S VIDEO (VAR/FIX) S VIDEO AUDIO R AUDIO L VIDEO VIDEO LINE VHF/UHF (MONO) (MONO) LINE AUDIO AUDIO COMPONENT VIDEO VMC-810S/820S S VIDEO AUDIO-L (no incluido) AUDIO-R Decodificador YC-15V/30V (no incluido) 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 127 All manuals and user guides at all-guides.com 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 128 VHF/UHF S VIDEO AUDIO (VAR/FIX) VIDEO SATELLITE IN VHF/UHF AUDIO R AUDIO L VIDEO S VIDEO (MONO) (MONO) AUDIO AUDIO LINE OUT COMPONENT S VIDEO AUDIO-L AUDIO-R RK-74A (no incluido) YC-15V/30V (no incluido) 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 129 AUDIO AUDIO YC-15V/ satelital COMPONENT VMC-810S/820S VIDEO (no incluido) incluido) S VIDEO AUDIO-L AUDIO-R S VIDEO AUDIO R AUDIO L VIDEO LINE VHF/UHF Videocasetera LINE VMC-810S/820S (no incluido) Cable/ Antena YC-15V/30V (no incluido) 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 130 AUDIO AUDIO COMPONENT Antena de tejado AUDIO-R RK-74A (no incluido) AUDIO-L S VIDEO VIDEO (amarillo) YC-15V/30V (no suministrado) VMC-810S/820S (no suministrado) Salida A/V AUDIO-L (blanco) AUDIO-R (rojo) (Parte frontal del TV de proyección) 18/2/03, 6:28 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 131 VIDEO 4 VHF/UHF S VIDEO AUDIO (VAR/FIX) do” VIDEO LINE OUT S VIDEO OUT COMPONENT VIDEO OUT S-LINK DIGITAL OUT (MONO) (MONO) R–AUDIO 1–L VIDEO OPTICAL COAXIAL AUDIO AUDIO COMPONENT VMC-10HG (no incluido) 18/2/03, 6:29 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 132 (Parte posterior del TV de proyección) Amplificador estereofónico VIDEO 1 VIDEO 3 VIDEO 4 AUDIO S VIDEO (VAR/FIX) AUDIO-L VIDEO (blanco) (MONO) (MONO) AUDIO AUDIO Entradas de línea CONTROL S COMPONENT RK-74A AUDIO-R (no incluido) (rojo) 18/2/03, 6:29 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 133 (blanco) VIDEO 1 IN L (MONO) (MONO) AUDIO AUDIO CONTROL S 1 IN R COMPONENT AUDIO-R (rojo) Cable de audio CONTROL S suministrado con RK-G34, etc. (no incluido) las bocinas CONTROL S IN 18/2/03, 6:29 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 134: Programación Del Tv De Proyección
• Antes de ejecutar la función Auto Programación, compruebe que la entrada de ANT esté seleccionada en lugar de AUX. Para ello, oprima ANT hasta que “AUX” deje de aparecer junto al número 18/2/03, 6:29 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 135: Notas Sobre Los Indicadores Timer/Stand By
Nota: ajuste el temporizador y permanecerán • FLASH FOCUS se cancela si realiza otra encendidos aunque se apague el TV. Para operación mientras ésta está funcionando. obtener más información, consulte la página 29. 24/2/03, 9:44 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 136 (como el “Brillo”, “Color”, etc.) imir el sonido. “Suprimir el sonido” aparecerá en según sus preferencias. Para obtener detalles, curridos tres segundos. Para restaurar el sonido, VOL +. consulte “Modo” en la página 26. 2/27/03, 3:19 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 137 MTS/SAP (si se ha ación SAP desaparece y el resto de scurridos tres segundos. , vuelva a oprimir DISPLAY. (continúa) 18/2/03, 6:29 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 138 SAP. (Consulte “MTS/SAP” en la página 27.) na opción de audio: y No. (Consulte “Efecto” en la página 27.) lizar la videocasetera y desee cambiar a la entrada a videocasetera permanecerá activada. de proyección y todos los equipos Sony. 18/2/03, 6:29 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 139 VIDEO” en la página 21.) (botón de etiqueta blanca) Consejo z Si oprime RESET en el modo PIP, la imagen de ventana se desplazará a la parte inferior derecha (ubicación predefinida de fábrica). 18/2/03, 6:30 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 140 1/9 si era uperar la visualización PIP normal. epción de audio y video de la imagen principal y de la , la imagen y el sonido de las dos imágenes se 18/2/03, 6:30 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 141 Consejo z Volverá a aparecer la pantalla anterior. También puede utilizar los botones MENU, , situados en el interior de la puerta del panel frontal del TV de proyección, para seleccionar el menú. 18/2/03, 6:30 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 142 Seleccione Sí para reducir el ruido en la imagen. Reducción de ruido Seleccione No para cancelar esta función. La opción de “Reducción de ruido” puede ajustarse por separado de los ajustes de “Modo” del menú de Video. 2/27/03, 3:20 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 143: Auto Volumen
No: Recepción normal estéreo o monofónica. Acceso rápido a los efectos: Oprima en el control remoto para recorrer cíclicamente las opciones de “Efecto” de la siguiente forma: Simulado t Surround t BBE t No. (continúa) 18/2/03, 6:31 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 144 TV de ontrol SAVA SP” más abajo). un sistema de bocinas de la serie SAVA de Sony” en sólo podrá ajustarse si “Bocinas” está ajustado en e mantiene en un nivel fijo a través del sistema de del receptor AV para ajustar el volumen.
Page 145: Hora De Verano
Oprima MENU para salir de esta función. Para cancelar los ajustes del Reloj, oprima RESET mientras se encuentre en la ventana Reloj. El empleo de Auto programación borrará todos los ajustes del Reloj. 2/26/03, 9:37 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 146 Canales favoritos (Para más detalles sobre la definición de esta función, consulte “Ajuste y selección de usuario de Canal favorito” en la página 32.) Nota: “Canal Favorito” no funciona con la entrada AUX. 18/2/03, 6:31 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 147 V de proyección programe automáticamente todos los vez almacenados todos los canales, aparecerá el r la función de Auto programación. oyección está conectado a un sistema de televisión por oyección está conectado a una antena. 18/2/03, 6:31 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 148 Oprima V o v para seleccionar una posición (1–8) y oprima C a n a l f a v o r i t o C N N S P T N 1 0 0 Seleccione el canal 2/27/03, 3:21 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 149: Uso De Canal Favorito
Oprima V o v para seleccionar en el menú el canal que desee ver. La imagen del canal seleccionado aparecerá en la imagen de ventana. C N N S P T N 1 0 0 S a l i r 18/2/03, 6:31 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 150 • No podrán utilizarse simultáneamente la indicación de estado, XDS y Caption Vision. Seleccione el idioma que desee (English, Español o Français) para que todos Idioma los menús aparezcan en el idioma elegido. Idioma preferido del usuario 18/2/03, 6:31 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 151 TV/VIDEO. para iniciar el ajuste de enfoque automático (Flash o el ajuste, el patrón de cruz en pantalla aparecerá en ormación, consulte la página 19). elar la función Flash Focus. 18/2/03, 6:31 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 152: Activación De La Función De Control Paterno
C l a s i f i c : I n f a n t e C a m b i a r l a c o n t r a s e ñ a Mover Escogar Salir MENU 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 153 E t i q u e t a d e v i d e o F l a s h F o c u s : Mover Escogar Salir MENU Oprima MENU para salir del menú. Mover Escogar Salir MENU 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 154: Selección De Una Clasificación Personalizada En E.e.u.u
N o c l a s i f i c a d o s : M i r a r Aparece el menú de Control paterno. Compruebe que “País” está ajustado en “EE.UU.”. E l i j a c a t e g o r í a Mover Escogar Salir MENU 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 155 E l i j a c a t e g o r í a Todos los ampliadores incluidos en las MENU Mover Escogar Salir clasificaciones seleccionadas se (continúa) bloquearán. Si desea que pueda visualizarse alguno de ellos, proceda con el paso 8. 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 156 – – – PG–13 – NC–17 – E l i j a c l a s i f i c a c i ó n MENU Mover Escogar Salir Oprima MENU para salir. 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 157: Selección De Una Clasificación Personalizada En Canadá
C l a s i f i c : I n f a n t e C a m b i a r l a c o n t r a s e ñ a Mover Seleccionar Salir MENU 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 158: Cambio De La Contraseña
ñ a pueda verse, vaya al paso 8. d e 4 d í g i t o s Mover Salir MENU Oprima MENU para salir del menú. 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 159: Significado De Las Clasificaciones
Clasificaciones de películas que pueden verse Se trata de clasificaciones originales en E.E.U.U.: G, PG, PG-13, NR y N/A predeterminadas por Sony en función de la Clasificaciones de programas de TV que edad del televidente. Cada clasificación pueden verse en E.E.U.U.: TV-Y, TV-Y7, TV- permite ver determinados programas, según...
Page 160 17 años. TV-Y (Niños de todas las edades): Este programa está diseñado para niños pequeños con edades comprendidas entre 2 y 6 años y es adecuado para niños de todas las edades. 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 161: Clasificaciones En Canadá
Clasificaciones de francés canadiense que Se trata de clasificaciones originales pueden verse: G, 8 ans+, 13 ans+ predeterminadas por Sony de acuerdo con la Clasificaciones de TV que pueden verse en edad del telespectador. Cada clasificación E.E.U.U.: TV-Y, TV-Y7, TV-G, TV-PG, TV-14 permite ver ciertos programas, según sigue.
Page 162 Programación destinada a una amplia audiencia, pero que contiene violencia ocasional o leve que podría impresionar a los niños (menores de 8 años). Se recomienda que éstos vean este tipo de programación con un adulto. 18/2/03, 6:32 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 163 325, 338, 321 Fabricante Código 314, 336, 337 Sony (Videocasetera de VHS) Olympic 309, 308 Sony (Videocasetera de 8mm) Optimus Sony (Videocaseteras Beta, ED Beta) Panasonic 308, 309, 306, 307 Aiwa Pentax 305, 304 Admiral (M. Ward) Philco 308, 309...
Page 164 Oprima los botones 0-9. directamente control remoto Selección del menú Oprima MENU. Encendido/apagado Oprima DVD/VTR (POWER). (de ajustes) [Botón verde] Reproducción Oprima Detención Oprima Pausa Oprima . Para reanudar la reproducción normal, vuelva a oprimirlo. 18/2/03, 6:33 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 165 Los botones GUIDE e INDEX (etiqueta azul) pueden utilizarse solamente con un receptor satelital. Si el control remoto no funciona • Intente repetir la programación del control remoto, utilizando los demás códigos correspondientes al equipo. 2/21/03, 8:50 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 166 (los indicadores superior e inferior parpadearán al unísono). Es conveniente que cuente el número de parpadeos para informar ado de Sony sobre el estado del TV de proyección. e alimentación (POWER) del TV de proyección para apagarlo y luego indique el número de parpadeos a un técnico calificado de Sony. ble de corriente esté bien enchufado.
Page 167 PIP. Para ver la entrada AUX en PIP, oprima el botón ANT y, a continuación, el botón PIP. La la imagen principal y la otra fuente de video en la imagen de ventana. 18/2/03, 6:33 PM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 168 Durante el uso (Máx.): 170W En modo de espera: 1 W Dimensiones (an/al/prf) 1 180 × 1 417 × 632 mm × 55 × 25 pulgadas) Masa 70,5 kg (155 lbs 8 oz) 3/20/03, 8:13 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 169 All manuals and user guides at all-guides.com sistema de bocinas de la serie SAVA de Sony ......17 ..........31 Efecto (BBE/Surround/ una videocasetera ......10 xial ......8, 9, 10, 13 Simulado/No) ......27 Contraseña ......... 36 antena ........9 Equipos de video (uso) ....
Page 170 Y, Z TV/VTR (botón) ....... 22 ........14, 15 TV/VIDEO (botón) ....21, 23 ..........27 BLE (FUNCTION) (botón) ..........49 d ..........2 audio (Fijo/Variable) ..28 de los menús ....25 3/20/03, 8:13 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 171 SYSTEM OFF (Apaga el TV de proyección y el equipo de Sony) TV (FUNCTION) (Activa el control remoto) TV POWER (Enciende/Apaga el EV de proyección) TV/VTR (Intercambia la entrada de TV a VCR) VOLUME +/– (Ajusta el volumen) 3/20/03, 8:13 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 172 All manuals and user guides at all-guides.com 3/20/03, 8:13 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 173 All manuals and user guides at all-guides.com 3/20/03, 8:13 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 174 All manuals and user guides at all-guides.com 3/20/03, 8:13 AM Sony KP-53V100 (ES) 4-094-821-31(1)
Page 175: Schematic Diagrams
All manuals and user guides at all-guides.com PRINTING THE SERVICE MANUAL The PDF of this service manual is not designed to be printed from cover to cover. The pages vary in size, and must therefore be printed in sections based on page dimensions. NON-SCHEMATIC PAGES Data that does NOT INCLUDE schematic diagrams are formatted to 8.5 x 11 inches and can be printed on standard letter-size and/or A4-sized paper.
Page 176 All manuals and user guides at all-guides.com ON-SCREEN SEARCH OPTION All of the text within the service manual PDF is content searchable. This means that you can enter any text, word, phrase or reference number that appears in the manual, and the PDF software will search, ﬁ nd and move the cursor to the location where you requested text ﬁ rst appears. This feature can be particularly useful in locating components on a speciﬁ...

Sony KP-53V100 Service Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Sony KP-53V100

Summary of Contents for Sony KP-53V100

Table of Contents
