Dresser
Bureau /Cómoda
ASSEMBLY INSTRUCTIONS #10037717
INSTRUCTIONS D'ASSEMBLAGE / /INSTRUCTIVO DE ARMADO
Ready to assemble, ready to be
Listo para ensamblar, listo para ser
PRODUCTION CODE /
**
** Ce numéro devra être conservé pour toute demande de service.
min
90
2
Prêt à être assemblé, prêt à être
CODE DE PRODUCTION / CODIGO PRODUCCION
** This number should be kept for all service request.
** Conserve este número para cualquier solicitud de servicio.
southshorefurniture.com
5
Y
EARS
A
NS
A
ñ
OS
!
!
!
