Summary of Contents for TOLSEN TOOLS FORCE XPRESS 62491
- Page 1 62491/62492 ELECTRIC HOIST 230V~50Hz INSTRUCTION MANUAL SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.
-
Page 2: Important Safety Information
SAFETY IMPORTANT SAFETY INFORMATION Important! When using this equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating manual with due care. Keep this manual in a safe place, so that the information is available at all times. If you give the equipment to any other person, give them these operating instructions as well. - Page 3 SAFETY 11. Prohibit unwanted start-ups on loose steel rope. Be sure to hoist the loads with lowest speed from the ground. And the cable should be tense but not unwound when start loading from the ground. 12. Pull out the plug when the cable hoist is not in use. 13.
-
Page 4: Specifications
SPECIFICATIONS & LAYOUT Compressor use and care LAYOUT 1. Fastening clamp 2. Fastening hole for hook 3. Drum 4. Lever for maximum cable length 5. Automatic stop mechanism lever 6. Steel cable 7. Cut-out weight 8. Load Hook 9. Emergency Stop switch 10. -
Page 5: Proper Use
SETUP OPERATING INSTRUCTIONS Proper use The cable hoist is designed for li ing and lowering loads in enclosed areas commensurate with the machine’s capacity. The equipment is to be used only for its prescribed purpose. Any other use is deemed to be a case of misuse. The user / operator and not the manufacturer will be liable for any damage or injuries of any kind caused as a result of this. - Page 6 SETUP Unpacking A er opening the packaging, inspect the frame, the steel cable, the hook and the electric control mechanism for signs of possible transit damage. Assembly The cable hoist is fitted with two fastening clamps (1) with which it has to be fastened to a rectangular tube. The dimensions of the arm must conform with the size of the fastening clamps and must be capable of supporting twice the rated load.
-
Page 7: Information For Operation
SETUP Information for operation 1. Remove the adhesive tape from the drum (3) before using the hoist for the first time. 2. The value of the A-rated noise emissions at the operator’s position is less than 70 dB. 3. Supply voltage: 230 V ± 10%, 50 Hz ± 1%. 4. - Page 8 SETUP Operation (Figure 6) 1. Check whether the Emergency Stop switch (9) is pressed. Turn the red stop switch clockwise to release it. 2. Press the pushbutton ▲ (10) to raise the load. 3. Press the pushbutton ▼ (10) to lower the load. 4.
-
Page 9: Maintenance And Servicing
MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING Always pull out the mains power plug before starting any cleaning work. Cleaning 1. Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. wipe the equipment with a clean cloth or blow it with compressed air at low pressure. 2. - Page 10 MAINTENANCE AND SERVICING Servicing Important. Always ensure that the machine is not connected to the mains supply before you start any servicing work. 1. In the following: One cycle means one raising and lowering movement of a load. Periodic inspection means an inspection a er 100 cycles.
-
Page 11: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Common Malfunction Cause Solution 1. It is not plugged into the power 1. Connect the item to the power supply. The Off-On-Switch is used but the motor 2. Check the wires and plug it in again to the supply. - Page 12 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT SCAN TO VISIT PRODUCT LINK PRODUCT LINK TolsenWorld MADE IN CHINA 62491 62492...
