Summary of Contents for ADJ DATA DISTRO 6
- Page 1 DATA DISTRO 6 User Manual...
-
Page 2: Document Version
©2024 ADJ Products, LLC all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. ADJ Products, LLC logo and identifying product names and numbers herein are trademarks of ADJ Products, LLC. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted. -
Page 3: Table Of Contents
C O N T E N T S General Information Limited Warranty (USA Only) Warranty Registration | Features Safety Guidelines Overview Installation Remote Device Management (RDM) Operation Cleaning and Maintenance | Ordering Information Specifications Dimensional Drawings FCC Statement... -
Page 4: General Information
Voice: 800-322-6337 | Fax: 323-582-2941 | support@adj.com ADJ SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET Voice: +31 45 546 85 60 | Fax: +31 45 546 85 96 | support@adj.eu ADJ PRODUCTS LLC USA 6122 S. Eastern Ave. Los Angeles, CA. 90040 323-582-2650 | Fax 323-532-2941 | www.adj.com... -
Page 5: Limited Warranty (Usa Only)
All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be shipped with the product. -
Page 6: Included Items
WA R R A N T Y R E G I S T R AT I O N This device carries a 2 year limited warranty. Please fill out the enclosed warranty card to validate your purchase. All returned service items, whether under warranty or not, must be freight pre-paid and accompanied by a return authorization (R.A.) number. -
Page 7: Safety Guidelines
To guarantee a smooth operation, it is important to follow all instructions and guidelines in this manual. ADJ Products, LLC is not responsible for injury and/or damages resulting from the misuse of this device due to the disregard of the information printed in this manual. Only qualified and/or certified personnel should perform installation of this device and only the original rigging parts included with this device should be used for installation. - Page 8 S A F E T Y G U I D E L I N E S • For your own personal safety, please read and understand this manual in its entirety before attempting to install or operate this device. • Save the packing carton for use in the unlikely event the device may have to be returned for service.
-
Page 9: Overview
O V E R V I E W Indicators (2 per port) Clamp Strap Mounting Mounting Bracket Bracket Power Indicator Thru Link Out / Terminate DMX IN DMX THRU Switch POWER DATADISTRO6 DMX/RDMBRANCH LINK OUT TERMINATE RDM / DMX SIGNAL Switch Fuse FUS E... -
Page 10: Installation
I N S TA L L AT I O N FLAMMABLE MATERIAL WARNING Keep device at least 8in. (0.2m) away from any flammable materials, decorations, pyrotechnics, etc. ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations. -
Page 11: Mounting Clamp
I N S TA L L AT I O N CLAMP MOUNTING This device can be mounted directly to a mounting clamp. To do so, install a mounting clamp of the appropriate weight rating by inserting an M10 bolt through the hole in the mounting clamp and the hole in the clamp mounting bracket, then secure the clamp in place with the matching washer and nut. -
Page 12: Mounting Straps
I N S TA L L AT I O N STRAP MOUNTING This device can be mounted directly to a truss using the strap mounting brackets on the top of the device. To do so, remove the clamp mount bracket, then press the top of the device against the truss beam so that the truss beam fits securely into the semi-circular channel on the top of the device. -
Page 13: Remote Device Management (Rdm)
R E M O T E D E V I C E M A N A G E M E N T ( R D M ) NOTE: In order for RDM to work properly, RDM enabled equipment must be used throughout the entire system, including DMX data splitters and wireless systems. -
Page 14: Operation
LINK OUT / TERMINATION SWITCH When this switch is in the “Link Out” position, the Data Distro 6 will also pass signal through the “DMX Thru” port. This signal can be sent to additional Data Distro 6 units by connecting the “DMX Thru”... -
Page 15: Fuse Replacement
AC IN: 100~240V. 5x20mm 50/60Hz. 1.25A Max. Made in C hina FUSE LOCATION O R D E R I N G I N F O R M AT I O N SKU (US) SKU (EU) ITEM DAT600 1321000084 ADJ Data Distro 6... -
Page 16: Specifications
S P E C I F I C AT I O N S Protocols: • DMX512 • Physical: • 1 Truss Mount with Velcro Straps or M10 Screw Clamp (Clamp Not Included) • 1x Indoor 5pin XLR Input • 1x Indoor 5pin XLR Thru •... -
Page 17: Dimensional Drawings
D I M E N S I O N A L D R AW I N G S 4.7in (120.00mm) DMX IN DMX THRU POWER LINK OUT TERMINATE SIGNAL FUSE AC IN FUSE: 1.25A. 250V AC IN: 100~240V. 5x20mm 50/60Hz. 1.25A Max. Made in China... -
Page 18: Fcc Statement
F C C S TAT E M E N T Please note that changes or modifications to this product that are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. - Page 19 This page intentionally left blank.
