Save This Manual for Future Reference
Dust Extractor
OPERATOR'S MANUAL
MODEL NUMBER
SC0050
SERIAL NUMBER
PURCHASE DATE
Both model number and serial
number may be found on the
main label. You should record
both of them in a safe place for
future use.
WARNING
Carefully read and understand this entire operator's manual before installing and using this product.
Pay attention to all the cautions and warnings.
Your Tools. Your Shop.
™
Advertisement
Table of Contents
Summary of Contents for SHOPMAX SC0050
- Page 1 Save This Manual for Future Reference Dust Extractor OPERATOR’S MANUAL MODEL NUMBER SC0050 SERIAL NUMBER PURCHASE DATE Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use.
-
Page 2: Table Of Contents
Shopmax Tools and Machines for your Shop MAX Performance, MAX Value, MAX Support Shopmax manufactures a full line of rugged, long-lasting √ Backed by decades of proven manufacturing expertise shop tools in several categories, including band saws, √ Enhanced design features come standard drill presses, shop vacuums, and more. -
Page 3: California Proposition 65 Warning
WARNING Cancer and Reproductive Harm. www.P65Warnings.ca.gov. SUPPORT ENVIRONMENTAL Have questions about your SHOPMAX equipment? Call us at 847-327-0566 or 844-YARDMAX, email Recycle unwanted materials instead of disposing us at info@shopmax.com for a replacement. of them as waste. All tools, hoses, and packaging... -
Page 4: Specifications
SPECIFICATIONS Model Number SC0050 Motor 120V Power 1.48HP Maximum Air Flow Capacity 108 CFM Interior Hose Diameter 3.94“ Tank Capacity 13.2 Gal. Decibel(Sound) Rating 83.40 dB(A) Product Depth 14.76“ Product Width 14.76” Product Height 26.38“ Weight 20 lbs SYMBOLS The rating plate on your machine may show symbols. These represent important information about the product or instructions on its use. -
Page 5: Safety
Transporting or performing maintenance or service on a Personal Safety machine with its switch on invites accidents. If the machine Do not permit children to operate this machine at any time. should start to vibrate abnormally, stop the motor and check www.shopmax.com... - Page 6 • Check tightness of the casing and of the sealing of filter and specific limitations. filter bag regularly. • Disconnect tool when changing the filter cartridge or filter • Inspect the power cords for damage on a regular basis. bag. Make sure that during this inspection the power cord is not www.shopmax.com...
- Page 7 • Be alert and think clearly. Never operate power tools when order to avoid a hazard. tired, intoxicated or when taking medications that cause drowsiness. • There is an electrical hazard when improper electrical connecting cables are being used. www.shopmax.com...
-
Page 8: Contents Supplied
The dust extractor comes partially assembled and is shipped in carefully packed carton. After all the parts have been removed from the carton, you should have: Description Qty. Motor Housing with Filter Cartridge/ Locking Strap Filter Bag Suction Hose Collection Canister Hose Adapter V Operator's Manual www.shopmax.com... -
Page 9: Assembly
( See Figure 1 ) Motor Housing Filter Cartridge Filter Bag Figure 1 Place the motor housing with filter cartridge/bag on to the collection canister and lock in place with the locking strap. ( See Figure 3 Figure 2 ) Figure 2 www.shopmax.com... -
Page 10: Know Your Machine
KNOW YOUR MACHINE FEATURES AND CONTROLS Motor Housing Power Cord Locking Strap Hose Coupling Suction Hose Hose Adapters Hose Clamp Switch Hose Coupling Hose Clamp Collection Canister www.shopmax.com... -
Page 11: Operation
The ingress of water into an electric tool increases repair.Have any work on the device that is not described in this the risk of an electric shock. instruction guide performed by a professional. Only use original www.shopmax.com... -
Page 12: Transport
5 and 30°C. Store the electric tool in its original 4. Remove bag from cartridge. ( See Figure 5 ) packaging. Cover the electric tool in order to protect it from dust and moisture. Filter Cartridge Filter Cartridge Filter Bag Filter Bag Figure 5 www.shopmax.com... -
Page 13: Wiring Diagram
13.2GAL. Dust Extractor Operator’s Manual » WIRING DIAGRAM www.shopmax.com... -
Page 14: Troubleshooting
4. The lumber is wet and dust is from dust extractor not flowing through the hose 4. Process lumber with less than 20% moisture smoothly content 5. There is a leak in the hose 5. Inspect and replace hose www.shopmax.com... - Page 15 2. Incorrect fuses or circuit breakers Motor stalls 3. Turn off other machines and retry 3. Overloaded circuit 4. Check the power line for the proper voltage. 4. Low Voltage Use another circuit or have a qualified electrician upgrade the service www.shopmax.com...
-
Page 16: Parts Diagram
PARTS DIAGRAM www.shopmax.com... -
Page 17: Parts List
Hose Clamp Switch Suction Hose Power Cord Hose Coupling 1 Philips Screw ST4.2x13 Hose Adapter I Strain Relief M16 Hose Adapter II Left Guard Hose Adapter III Philips Screw M5x35 Hose Adapter IV Philips Screw M5x50 Hose Adapter V www.shopmax.com... -
Page 18: Warranty
The customer may have other rights not disclosed herein; and they may vary from state to state. Have questions about your SHOPMAX equipment? Call us at 847-327-0566 or 844-YARDMAX, email us at info@shopmax.com www.shopmax.com... - Page 19 13.2GAL. Dust Extractor Operator’s Manual » www.shopmax.com...
- Page 20 Your Tools. Your Shop. ™ 847-327-0566 info@shopmax.com...
