DURABLE DC8316BC-G Series Installation Instructions Manual

INSTALLATION INSTRUCTIONS
Art#: DC8316BC-G SERIES
DOOR CLOSER
CAUTION
An improperly installed or incorrectly adjusted
door closer can result in property damage or
personal injury. Follow these instructions carefully
to prevent misapplication or misadjustment.
HOW TO ASSEMBLE GUIDE RAIL
！
CAUTION
WITH MAIN ARM
MAIN
ARM
MAIN ARM
INSERT
SCREW
GUIDE RAIL
Lock
side
END CAP
x4 x2 x1 x4 x2 x2
x1
SCREWS
HINGE (PULL)
SIDE MOUNTING
MAX. OPENING 120°
TOP JAMB (PUSH)
SIDE MOUNTING
MAX. OPENING 120°
STOP FACE
SIDE MOUNTING
MAX. OPENING 85°
DUE TO SAFETY PURPOSE,THE FIRE
RATED DOOR IS NOT ALLOWED
WITH HOLD OPEN STOP
Hinge
side
WITHOUT MAIN ARM
SLIDER
MOUNTING
SCREW
Lock
Side
Strong (H.O force)
END CAP
HOLD OPEN STOP
SLIDER
Weak (H.O force)
HOLD OPEN STOP
x4
x1
MAIN ARM SCREW THROUGH BOLT AND SCREW
www.durablecollection.co.uk
Adjustable power size by valve (1 to 6)
PAGE 2
PAGE 3
(PUSH)
PAGE 4
HOW TO ADJUST CLOSER
Adjusting the closing (S),
Latching (L) speed, and
Backcheck (BC)
！
CAUTION
DO NOT
back the valves out of
the closer, or a leaking will result.
Hinge
side
+
Decrease Increase
A
x4
0°
x4 BC
L
15°
S
Unit: mm
Grade 1, meets ANSI A 156.4
NEVER
CLOSE THIS
VALVE
L , S BC
COMPLETELY
Weaker Stonger
Faster Slower
Power Adjustment Chart
Leaf
Full clockwise turns of closer power
size
adjustment nut (from "0" turns)
interior exterior
mm
door
609.6 - 762
-4
762 - 863.6
0
6
863.6 - 965.2
965.2 - 1219.2 12
1219.2 - 1371.6
050325 Page: 1/10
door
0
5
10
