NoKey FORCE Gen2

Installing and Operating

Describes how to install your code lock, how to program codes

and how to perform a factory reset.

RCO Security AB

Box 3130

169 03 Solna, Sweden

Tel +46-8-546 560 00

info@rco.se

www.rco.se

Table of Contents

Need help?

Do you have a question about the NoKey FORCE Gen2 and is the answer not in the manual?

Questions and answers

Summary of Contents for RCO NoKey FORCE Gen2

Page 1 Describes how to install your code lock, how to program codes and how to perform a factory reset. RCO Security AB Box 3130 169 03 Solna, Sweden Tel +46-8-546 560 00 info@rco.se © RCO Security AB. All rights reserved, February 2025. www.rco.se...
Page 2: Table Of Contents
Contents Safety and environment Safety provisions CE marking Environment Battery specifications RoHS/WEEE Recycling General Accessories Important! Exploded views Oval cylinder on outside and knob on inside Cover plate on outside and knob on inside and no knob on inside Knob on inside and cover plate on outside Oval cylinder on the outside and cover plate on the inside Preparation Recommendations for oval cylinders...
Page 3 Activating/deactivating sound when unlocking Adjusting how long the door stays unlocked Activating/deactivating sound when battery is low Changing the system code Entering a code for activating/deactivating zero opening Activating zero opening Deactivating zero opening Activating/deactivating code attempt limitation Factory reset Troubleshooting If the handle does not engage after valid access from outside Loose or hanging door handle...
Page 4: Safety And Environment
The CE marking is on the back of each unit. The rating plate is located on the inside of the unit's cover. Environment The environmental declaration is available (in Swedish) at www.rco.se, under Mediearkivet > Kvalitet och miljö. Battery specifications...
Page 5: Rohs/Weee
For more information, please contact your local authorities for waste disposal. The product is marked with the crossed-out waste bin, and can be sent to RCO for recycling or recycled in accordance with local regulations.
Page 6: General
* These are accessories. See chapter "Accessories". Recommendation: Download the information sheet Låshus per NoKey-modell Swedish) from RCO's website. The info sheet uses a matrix to illustrate suitable lock housings for each NoKey model. Manuals and other product documentation are contained in the Document folder on the R-CARD M5 installation media.
Page 7: Accessories
When installing without a lock cylinder, use the accessory cylinder hole cover plate NoKey (RCO item number 94500074) . When installing without a knob, use accessory knob cover plateNoKey (RCO item number 94500072) . NoKey reservdelar och tillbehör (NoKey spare parts and accessories, in Swedish).
Page 8: Exploded Views
Exploded views Exploded views Oval cylinder on outside and knob on inside Preparation when choosing cylinder ring and extender. Butterfly adapter (see page 13).
Page 9: Cover Plate On Outside And Knob On Inside And No Knob On Inside
Exploded views Cover plate on outside and knob on inside and no knob on inside The drawings show NoKey Online. NoKey FORCE is mounted the same way.
Page 10: Knob On Inside And Cover Plate On Outside
Exploded views Knob on inside and cover plate on outside With a knob on the inside and a cover plate on the outside, there is no way to unlock the door from the outside if someone were to lock with the knob. See the respective exploded view in the previous section.
Page 11: Preparation
Preparation Preparation Recommendations for oval cylinders The NoKey reader is is adapted for a cylinder ring with a diameter of 52 mm. We recommend Dormakaba or Habo. To determine the size of the cylinder ring and cylinder extender, use the following measurements: The B measurement, i.e.
Page 12 31.5 33.5 35.5 37.5 RCO Spacer plate outside short (part no. 20180803) RCO Spacer plate outside long (part no. 20180807) Dorma DR 8320-6 Black PVD (part no. 7030000029868) Dorma DR 8320-8 Black PVD (part no. 7030000029869) Cylinder extender Roca 6 mm (part no. 939481) Cylinder extender Roca 8 mm (part no.
Page 13: Recommendations For Spacer Plate
The following applies to the inside of the door, if the C measurement is between 17 and 19.5 mm: Use the accessory spacer plate (RCO part no. 20180815) . The following applies to the outside of the door, if the B measurement is between 16.5 and 19 mm: For a unit with keypad, use accessory spacer plate (RCO part no.
Page 14: 1 Adjusting Handle Hole And/Or Recess For Lock Housing
1 Adjusting handle hole and/or recess for lock housing 1 Adjusting handle hole and/or recess for lock housing If the gauge does not go into the handle hole, or if there is not enough space for the cable, the necessary adjustments will have to be made. Loosen and remove the lock housing.
Page 15: 2 Adapting For Left-Hinged Doors
2 Adapting for left-hinged doors 2 Adapting for left-hinged doors The lock is set for right-hinged doors. Use this process to adapt it for left-hinged doors: Repositioning is achieved on the outer unit by turning the handle and lock mechanism. Remove the two screws (Torx T25) that hold the mechanism in place.
Page 16: 3 Checking Placement Of Lock Housing; Altering Length Of Square Pin
3 Checking placement of lock housing; altering length of square pin 3 Checking placement of lock housing; altering length of square pin This section ensures that a good mechanical function is achieved. It is needed for all NoKey models. Use this procedure: On the inside of the door, insert the square pin with the rounded end towards the lock housing.
Page 17 3 Checking placement of lock housing; altering length of square pin Cut the square pin to the correct length as per the mark. Make sure the cut is at a right angle. Smooth off the cut face with a suitable tool. Round off the edges slightly.
Page 18: 4 Installation With Oval Cylinder And Knob
4 Installation with oval cylinder and knob 4 Installation with oval cylinder and knob This describes the installation of an outer unit with an oval cylinder together with an inner unit with a knob. The installation is the same, whether the unit has a keypad or not, and the drawings below can show both variations.
Page 19 4 Installation with oval cylinder and knob Remove the cover from the base plate. Cut the 2 mounting screws to the correct length. This is easiest if you thread the screw in, pull back the cylinder and measure how much needs to be cut. Then thread the screws through the plate on the back.
Page 20 4 Installation with oval cylinder and knob A spacer plate may be needed for thin doors and for a B measurement between 16.5 and 19 mm (see page 13). When the outer unit is mounted in a later step, loosen the screw that secures the base plate to the outer unit and then thread the screw through the spacer...
Page 21 Door Length of thickness hex pin 38 – 58 mm 80 mm 58 – 81 mm 100 mm 81 – 110 mm 130 mm A 130 mm hex pin is available for purchase from RCO Security, part number 20180820.
Page 22 4 Installation with oval cylinder and knob Thread the cable with its 4.10 contact through the oblong hole down to the left in the inner unit. Ensure that the cable runs freely and does not get trapped when the units are later screwed tight.
Page 23 4 Installation with oval cylinder and knob Cut the lower lock screws as 4.12 follows: Min. = door thickness + 18 mm Max. = door thickness + 26 mm Take care to ensure the threads are not damaged. Smooth off the cut face with a suitable tool.
Page 24 4 Installation with oval cylinder and knob Place the 52 mm cylinder ring 4.15 against the seat on the outer unit, on top of the cylinder. Measure the 2 mounting screws and cut them to the correct size. They should be as long as possible.
Page 25 4 Installation with oval cylinder and knob Check the handle function 4.18 from the outside. The lock is always unlocked until it is in operation. If something is sticking, this could be because: The lock or square pin does not have enough clearance against the door or lock housing.
Page 26 4 Installation with oval cylinder and knob Fold the cable double and 4.20 place it under the load holder. Insert the batteries (5 x AA) into the battery compartment. Close the rubber cable 4.21 grommet (1). Ensure the gap is no more than 1 mm.
Page 27 4 Installation with oval cylinder and knob To define the length of the 4.22 knob pin: Insert the pin towards the lock housing until it reaches the bottom. Measure distance 'A'. Cut the pin to measurement ‘A’ + at least 1 mm, but always to one of the cutting guides 1 –...
Page 28 4 Installation with oval cylinder and knob Reinstall the inner unit. Be 4.23 sure to align the handle with the square pin and the knob with the lock housing. Re-insert the four screws for 4.24 the cover and tighten. (Allen 3 mm) Replace the battery cover and 4.25 tighten the screws on the...
Page 29: 5 Installation Without Cylinder And Knob
5 Installation without cylinder and knob 5 Installation without cylinder and knob This described the installation of an outer unit without a lock cylinder together with an inner unit without a knob. Place the cover over the hole on the outer unit. Install the cover plate by screwing in the supplied screw (T25) and washer from...
Page 30 5 Installation without cylinder and knob Remove the chassis cover and the 4 screws (3 mm Allen). Save the screws for reassembly. Remove the cover from the base plate. Remove the upper and lower track runners (1) from the inner unit using track runner pliers.
Page 31 5 Installation without cylinder and knob Remove the knob. Save it for possible reassembly. Mount the cover plate on the inner unit. Use the supplied washers and Torx 25 (T25) screw. A spacer plate may be needed for thin doors and for a B measurement between 16.5 and 19 mm (see page 13).
Page 32 5 Installation without cylinder and knob Thread the cabling from the 5.10 outer unit through the door under the lock housing. Ensure there is enough space. If not, adjustments must be made – see page 14. Insert a locking screw into 5.11 one of the upper holes to temporarily secure the outer...
Page 33 58 – 81 mm 100 mm 81 – 110 mm 130 mm A 130 mm hex pin is available for purchase from RCO Security, part number 20180820. Thread the cable with its 5.14 contact through the oblong hole down to the left in the inner unit.
Page 34 5 Installation without cylinder and knob Insert the unit with the hex 5.15 pin and square pin to the lock housing and the outer unit. Cut the lower lock screws as 5.16 follows: Min. = door thickness + 18 mm Max. = door thickness + 26 mm Take care to ensure the threads are not damaged.
Page 35 5 Installation without cylinder and knob Remove the temporary upper 5.18 screw. Cut the upper lock screws as 5.19 follows: Min. = door thickness + 6 mm Max. = door thickness + 11 mm Take care to ensure the threads are not damaged. Smooth off the cut face with a suitable tool.
Page 36 5 Installation without cylinder and knob Remove the transport 5.21 protection by pulling it out straight, not to the side. (If the transport production has already been removed, see "If the handle does not engage after valid access from outside" on page 52.) Check the handle function 5.22...
Page 37 5 Installation without cylinder and knob Fit the contact in the circuit 5.23 board. Fold the cable double and 5.24 place it under the load holder. Insert the batteries (5 x AA) into the battery compartment. Close the rubber cable 5.25 grommet (1).
Page 38 5 Installation without cylinder and knob Reinstall the cover on the 5.26 inner unit. Be sure to fit the handle onto the square pin. Re-insert the four screws for 5.27 the cover and tighten. (Allen 3 mm) Replace the battery cover and 5.28 tighten the screws on the underside.
Page 39: The Latch Can Protrude
5 Installation without cylinder and knob The latch can protrude Tolerance: When the handle is pressed, the latch can stick out 1–2 mm.
Page 40: 6 Programming The Code Lock
6 Programming the code lock 6 Programming the code lock General In order to perform any programming, the unit must be set to programming mode. This can be done by entering the system code. The default system code is 1234. Recommendation: Change the factory-set system code with your own system code as soon as possible.
Page 41: Entering Codes To Unlock The Door
6 Programming the code lock Entering codes to unlock the door It is very important to document which memory positions are used, in order to be able to ensure correct management (replacement or deletion) of programmed codes. A table for this purpose is provided on page 58. Description Quick guide Signal...
Page 42: Changing Access Codes
6 Programming the code lock Changing access codes Description Quick guide Signal Put the unit in programming mode by x x x x entering the system code. Press 1 (menu selection), then #. 1 + # Enter memory position (1–98) of the code to 1–98 + # be changed.
Page 43: Deleting Access Codes
6 Programming the code lock Deleting access codes If a code is to be changed, the new code can be programmed over the existing code, without first needing to delete the old one. See "Changing access codes" above. Description Quick guide Signal Put the unit in programming mode by x x x x entering the system code.
Page 44: Activating/Deactivating Sound When Unlocking
6 Programming the code lock Activating/deactivating sound when unlocking Activating the sound will negatively impact the lifespan of the batteries. Sound is deactivated by default. Description Quick guide Signal Put the unit in programming mode by x x x x entering the system code. Press 5 (menu selection), then #.
Page 45: Adjusting How Long The Door Stays Unlocked
6 Programming the code lock Adjusting how long the door stays unlocked The lock opening time can be set between 1 and 9 seconds, or to 0 to get 30 seconds. The default time is 3 seconds. Description Quick guide Signal Put the unit in programming mode by x x x x entering the system code.
Page 46: Activating/Deactivating Sound When Battery Is Low
6 Programming the code lock Activating/deactivating sound when battery is low When the battery level is low, three short beeps will be emitted upon lock opening. Activating the sound will negatively impact the batteries’ lifespan. Sound is activated by default. Description Quick guide Signal Put the unit in programming mode by...
Page 47: Changing The System Code
6 Programming the code lock Changing the system code Note! The system code cannot be the same as any of the access codes. If the system code has more digits than a code, but shares the same initial digits, the remaining digits must be entered within 2 seconds of the code’s last digit.
Page 48: Entering A Code For Activating/Deactivating Zero Opening
6 Programming the code lock Entering a code for activating/deactivating zero opening Zero opening means that the door can be opened by simply pressing 0 instead of entering a code in the normal way. Here is how to specify a code to be used to activate or deactivate zero opening.
Page 49: Activating/Deactivating Code Attempt Limitation
6 Programming the code lock Activating/deactivating code attempt limitation In order to prevent someone from trying out a valid access code, you can limit the number of attempts a person can make. If the function is activated, the unit keypad will be locked for a short amount of time after 16 digits have been entered without a correct code.
Page 50: Factory Reset
6 Programming the code lock Factory reset Factory settings: Recommendation: Change the System code: 1234 factory-set system code with your own system code as soon as Battery warning with sound: On possible. (See "Changing the system code" on page 47.) Lock opening time: 3 seconds. Sound on lock opening: Off Code attempt limitation: Off Code for zero opening: Not set...
Page 51 6 Programming the code lock If the system code is not known If the system code is lost, this reset is the only possibility to reprogram and continue operation of the code lock. This procedure deletes all pre-programmed codes and resets the unit to factory settings, including system code 1234.
Page 52: Troubleshooting
Troubleshooting Troubleshooting If the handle does not engage after valid access from outside Problem description If the outside door handle cannot be used after valid access, it may be because the solenoid has ended up activated when it should not be. This can occur if the red transport protection marked REMOVE LAST was removed before the product was mounted on the door, or if the unit was moved from one door to another without resetting the solenoid and without using the transport protection.
Page 53 Troubleshooting Solution Reset the solenoid manually. Remove the unit from the door. Reset the solenoid to the inactive position. Insert a small flathead screwdriver into the hole where the red transport protection was located and poke the piston back up to its initial position.
Page 54: Loose Or Hanging Door Handle
Troubleshooting Loose or hanging door handle On delivery, the unit is configured for a right-hinged door. If it has been adapted for a left-hinged door, the spring may have jumped out of position. How to check Here you can see a gap between the cylinder and the unit.
Page 55 Troubleshooting Refit the spring Make sure that the lower leg of the spring is in the resistance hole in the cylinder housing. Grasp the cylinder with a polygrip, for example, and turn anticlockwise until the spring retainer and spring hop back into position.
Page 56: Appendix 1: Signals In Nokey Force
APPENDIX 1: Signals in NoKey Force APPENDIX 1: Signals in NoKey Force NoKey force has a green LED lamp and a sound that tell you the unit’s status. Signals are used both during programming and during daily use. Only the left lamp is used in NoKey Force. LED lamp Signal Meaning...
Page 57: Appendix 2: Specifications
APPENDIX 2: Specifications APPENDIX 2: Specifications Dimensions Width Height Depth Weight Outer unit 67 mm 260 mm 17 mm 1160 g Inner unit 68 mm 272 mm 25 mm 1440 g Power supply 5 pcs. alkaline AA LR6 batteries (not included). Battery life More than 3 years with normal usage (100 passages/day). Alternative power supply 9-volt battery (6LR6) for backup power on the outside.
Page 58 Table for your codes Table for your codes Memory Name/use Code Memory Name/use Code position position...
Page 59 Table for your codes Memory Name/use Code Memory Name/use Code position position Code for activating and (99) deactivating zero opening – System code...
