COMET SYSTEM
www.cometsystem.com
Web Sensor T0610 with PoE
Web Sensor T4611 with PoE
Web Sensor T3610 with PoE
Web Sensor T3611 with PoE
Web Sensor T7610 with PoE
Web Sensor T7611 with PoE
Web Sensor T7613D with PoE
Web Sensor T6640 with PoE
Web Sensor T6641 with PoE
Web Sensor T5640 with PoE
Web Sensor T5641 with PoE
USER GUIDE
February 2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T4611 and is the answer not in the manual?

Questions and answers

Related Manuals for Comet System T4611

Summary of Contents for Comet System T4611

  • Page 1 COMET SYSTEM www.cometsystem.com Web Sensor T0610 with PoE Web Sensor T4611 with PoE Web Sensor T3610 with PoE Web Sensor T3611 with PoE Web Sensor T7610 with PoE Web Sensor T7611 with PoE Web Sensor T7613D with PoE Web Sensor T6640 with PoE...
  • Page 2 Is prohibited to copy and make any changes in this manual, without explicit agreement of company COMET SYSTEM, s.r.o. All rights reserved. COMET SYSTEM, s.r.o. makes constant development and improvement of all its products. Manufacturer reserves the right to make technical changes without previous notice. Misprints reserved.

  • Page 3: Table Of Contents

    IE-SNC-Tx6xx-09 Table of contents Introduction ................................ 4 General safety rules ............................. 5 Device description and important notices ....................6 Getting started ..............................7 What is needed for operation ........................7 Mounting the device ............................ 7 Device settings ............................. 8 Checking functions ............................9 Device setup ..............................10 Setup using web interface .........................10 Setup using TSensor software .........................21...

  • Page 4: Introduction

    Sensors is Ethernet. Web Sensor can be powered from external power supply adapter or by power over Ethernet – PoE. Device types: Type Temperature Relative humidity Pressure Computed concentration quantity T0610 ✓ T4611 ✓ T3610 ✓ ✓ ✓ T3611 ✓ ✓ ✓...

  • Page 5: General Safety Rules

    IE-SNC-Tx6xx-09 calculating the output value. This fact adds a noise of typ. ±30ppm which has to be considered in terms of accuracy. After power up of the device starts internal test. During this time (about 20s) LCD display shows (----) instead of CO concentration value.

  • Page 6: Device Description And Important Notices

    IE-SNC-Tx6xx-09 Device description and important notices This chapter contains information about basic features. Also there are important notices concerning to functional safety. Measured values can be displayed on LCD display or can be read using an Ethernet connection. The following formats are supported: •...

  • Page 7: Getting Started

    • power supply adapter 5V/250mA or switch with PoE feature • RJ45 LAN connection with appropriate cable • free IP address in your network • for Web Sensor T4611 is required temperature probe Pt1000/3850ppm, connected by shielded cable with maximum length 10m Mounting the device •...

  • Page 8: Device Settings

    When you installing several new devices, connect them to the network one after another. • connect probe Pt1000 to Web Sensor T4611 • connect the Ethernet connector • if the power over Ethernet (PoE) is not used, connect the power adapter 5V/250mA •...

  • Page 9: Checking Functions

    IE-SNC-Tx6xx-09 • click to Change IP to set new address according to network administrator instructions. If your device is not listed, then click Help! My device wasn’t found! Then follow the instructions. MAC address is on product label. The device is factory set to IP 192.168.1.213. •...

  • Page 10: Device Setup

    IE-SNC-Tx6xx-09 Chapter Device setup This chapter describes basic device configuration. There is a description of settings using web interface. Setup using web interface Device can be setup using web interface or TSensor software. Web interface can be managed by the web browser. Main page will be shown when you insert device address into address bar of your web browser.
  • Page 11 IE-SNC-Tx6xx-09 General Device name can be changed using item Device name. Measured values are stored into memory according History storage interval field. After changing of this interval all history values will be cleared. Changes must be confirmed by Apply settings button.
  • Page 12 IE-SNC-Tx6xx-09 Network Network parameters can be obtain automatically from DHCP server using option Obtain an IP address automatically. Static IP address is configurable via field IP address. It is not necessary setup Default gateway while you use device inside one subnet only. DNS server IP is required to set for proper function of DNS.

  • Page 13: Alarm Limits

    IE-SNC-Tx6xx-09 Alarm limits For each measurement channel is possible to set upper and lower limits, time-delay for alarm activation and hysteresis for alarm clearing. Example of setting the limit to the upper alarm limit: In Point 1 the temperature exceeded the limit. From this time, the time-delay is counting. Because at point 2 the temperature dropped below the limit value before the time delay expired, alarm was not set.
  • Page 14 IE-SNC-Tx6xx-09 The alarm lasted up to Point 5, when the temperature dropped below the set hysteresis (temperature limit – hysteresis). At this moment was active alarm cleared and e-mail sent. When alarm occurs, alarm messages will be sent. In case of power failure or device reset (e.g. changing the configuration) will new alarm state evaluated and new alarm messages will be sent.
  • Page 15 IE-SNC-Tx6xx-09 Mode of CO concentration measuring can be set by item Average CO measuring mode – „SLOW mode“. Whole measuring range of CO concentration (0 to 5000/10000ppm) can be divided into three areas. Using three-color LED the transmitter indicates, in which of these areas the measured value is.
  • Page 16 IE-SNC-Tx6xx-09 Email Email sending enabled option allows email features. It is necessary set address of the SMTP server into SMTP server address field. Domain name for SMTP server can be used. Default port of the SMTP server can be changed using item SMTP server port. SMTP authentication can be enabled using SMTP authentication option.
  • Page 17 IE-SNC-Tx6xx-09 Modbus a Syslog protocols ModbusTCP and Syslog protocol settings are configurable via menu Protocols. Modbus server is enabled by default. Deactivation is possible via Modbus server enabled option. Modbus port can be changed via Modbus port field. Syslog protocol can be enabled using item Syslog enabled.
  • Page 18 IE-SNC-Tx6xx-09 SNMP For reading values via SNMP it is necessary to know password - SNMP read community. SNMP Trap can be delivered up to three IP address - IP address of the Trap recipient. SNMP Traps are sent at alarm or error state on the channel. Trap feature can be enabled by option Trap enabled.
  • Page 19 IE-SNC-Tx6xx-09 Time Time synchronization with SNTP server can be enabled by Time synchronization enabled option. IP address of the SNTP is necessary to set into SNTP server IP address item. List of free NTP servers is available at www.pool.ntp.org/en. SNTP time is synchronized at UTC format, and due to be necessary set corresponding time offset - GSM offset [min].
  • Page 20 IE-SNC-Tx6xx-09 WWW and security Security features can be enabled by the Security enabled option. When security is enabled it is necessary to set administrator password. This password will be required for device settings. When secured access is required even to actual values reading it is possible to enable User account only for viewing enabled.

  • Page 21: Setup Using Tsensor Software

    IE-SNC-Tx6xx-09 Setup using TSensor software TSensor software is an alternative to web configuration. Some less important parameters are configurable only by the TSensor software. TSesnor software allows user adjustment of measured values. Parameter MTU size can reduce size of the Ethernet frame. Lowering of this size can solve some communication problems mainly with Cisco network infrastructure.

  • Page 22: Factory Defaults

    IE-SNC-Tx6xx-09 Factory defaults Factory defaults field set the device into factory configuration. Network parameters (IP address, Subnet mask, Gateway, DNS) are left without changes. Settings relating to measurement are not restored by factory defaults. Network parameters are changed while you close jumper and push button inside device during connecting power supply.
  • Page 23 IE-SNC-Tx6xx-09 Parameter Default value Website refresh interval [sec] Website enabled Website port Security Administrator password cleared User password cleared Modbus port Modbus server enabled History storage interval [sec] SOAP server port SOAP server address cleared SOAP sending interval [sec] SOAP message when alarm occurs SOAP protocol enabled Syslog server IP address 0.0.0.0...

  • Page 24: Communication Protocols

    IE-SNC-Tx6xx-09 Chapter Communication protocols Short introduction to communication protocols of the device. To use some communication protocols is necessary software, which can use the protocol. This software is not included. For detailed description of protocols and application notes please contact your distributor. Website The device supports displaying of measured values, history graphs and configuration using web browser.

  • Page 25: Snmp

    IE-SNC-Tx6xx-09 SNMP Using SNMP protocol you can read actual measured values, alarm status and alarm parameters. Via SNMP protocol is also possible to get last 1000 measured values from history table. Writing via SNMP protocol is not supported. It is supported SNMPv1 protocol version only.
  • Page 26 IE-SNC-Tx6xx-09 Description Type .1.3.6.1.4.1.22626.1.2.4.8.0 Relative humidity time-delay Integer .1.3.6.1.4.1.22626.1.2.4.9.0 Computed quantity time-delay Integer .1.3.6.1.4.1.22626.1.2.4.10.0 Temperature hysteresis Int*10 .1.3.6.1.4.1.22626.1.2.4.11.0 Relative humidity hysteresis Int*10 .1.3.6.1.4.1.22626.1.2.4.12.0 Computed quantity hysteresis Int*10 .1.3.6.1.4.1.22626.1.2.4.13.0 Atmospheric pressure, CO concentration low limit Int*X .1.3.6.1.4.1.22626.1.2.4.14.0 Atmospheric pressure, CO concentration high limit Int*X .1.3.6.1.4.1.22626.1.2.4.15.0 Atmospheric pressure, CO...

  • Page 27: Modbus Tcp

    IE-SNC-Tx6xx-09 Modbus TCP Device supports Modbus protocol for communication with SCADA systems. Device use Modbus TCP protocol. TCP port is set to 502 by default. Port can be changed using TSensor software or web interface. Only two Modbus clients can be connected to device at one moment.

  • Page 28: Soap

    IE-SNC-Tx6xx-09 Address [DEC] Address [HEX] Value Type 20504 0x5018 Max. relative humidity memory Int*10 20505 0x5019 Min. computed value memory Int*10 20506 0x501A Max. computed value memory Int*10 20507 0x501B Min. atmospheric pressure, CO concentration memory Int*X 20508 0x501C Max. atmospheric pressure, CO concentration memory Int*X Type:...
  • Page 29 IE-SNC-Tx6xx-09 <?xml version="1.0" encoding="utf-8"?> <soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema"> <soap:Body> <InsertTx5xxCO2Sample xmlns="http://cometsystem.cz/schemas/soapTx5xxCO2.xsd"> <passKey>13960932</passKey> <device>4200</device> <temp>1.4</temp> <relHum>91.9</relHum> <compQuant>0.3</compQuant> <co2>1050</co2> <alarms>hi,no,no,no</alarms> <lev1>0</lev1> <lev2>1</lev2> <lev3>0</lev3> <compType>Dew point</compType> <tempU>C</tempU> <timer>60</timer> </InsertTx5xxCO2Sample> </soap:Body> </soap:Envelope> Element Description <passKey> Contains the device serial number (an eight digit number). <device>...
  • Page 30 IE-SNC-Tx6xx-09 <soap:Envelope xmlns:soap="http://schemas.xmlsoap.org/soap/envelope/" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xmlns:xsd="http://www.w3.org/2001/XMLSchema"> <soap:Body> <InsertTx5xxSample xmlns="http://cometsystem.cz/schemas/soapTx5xx_v2.xsd"> <passKey>13960932</passKey> <device>4175</device> <temp>1.4</temp> <relHum>91.9</relHum> <compQuant>0.3</compQuant> <pressure>-9999</pressure> <alarms>hi,no,no,no</alarms> <compType>Dew point</compType> <tempU>C</tempU> <pressureU>n/a</pressureU> <timer>60</timer> </InsertTx5xxSample> </soap:Body> </soap:Envelope> Element Description <passKey> Contains the device serial number (an eight digit number). <device> Device type identification number (code). <temp>...

  • Page 31: Syslog

    IE-SNC-Tx6xx-09 Syslog The device allows sending text message to selected Syslog server. Events are send using UDP protocol on port 514. Syslog protocol implantation is according to RFC5424 and RFC5426. Events when Syslog messages are send: Text Event Sensor - fw 1-5-7.x Reset of the device NTP synchronization error NTP synchronization error...

  • Page 32: Troubleshooting

    IE-SNC-Tx6xx-09 Chapter Troubleshooting The chapter describes the common problems with devices Web Sensor Tx6xx and methods how to fix these problems. Please read this chapter before you will call technical support. I forgot the device IP address IP address is factory set to 192.168.1.213. If you had changed it and forgot new IP address, run the TSensor software and press Find device...

  • Page 33: I Forgot The Password For Setup

    IE-SNC-Tx6xx-09 the software instructions. An alternative is to reset device to factory defaults using factory- defaults button. I forgot the password for setup Please reset device to factory defaults. Procedure is described at following point. Factory defaults This procedure restore device to factory settings including network parameters (IP address, Subnet mask, etc.).

  • Page 34: Device Error States

    IE-SNC-Tx6xx-09 Device error states Device still make self-tests. If error occurred, LCD shows error codes: Error LCD display Description Error 0 Err0 Internal memory CRC error. In this state device doesn't work. This is a critical error, contact the distributor. Error 1 Err1 Measured or computed quantity is over the upper limit.

  • Page 35: Technical Specifications

    IE-SNC-Tx6xx-09 Chapter Technical specifications Information about technical specifications of the device. Dimensions Web Sensor T0610: Web Sensor T4611:...
  • Page 36 IE-SNC-Tx6xx-09 Web Sensor T3610, T7610, T6640: Web Sensor T3611, T7611:...
  • Page 37 IE-SNC-Tx6xx-09 Web Sensor T7613D: Web Sensor T5641:...
  • Page 38 IE-SNC-Tx6xx-09 Web Sensor T5640: Web Sensor T6641:...

  • Page 39: General Parameters

    It is not allowed to remove the sensor cover to avoid any mechanical damage of the sensors. Case material: Weight: T0610 ~310g T4611 ~310g T3610 ~320g T7610 ~320g T3611/1m probe ~380g, T3611/2m ~420g, T3611/4m ~500g T7611/1m probe ~380g, T7611/2m ~420g, T7611/4m ~500g...

  • Page 40: Measured Values

    Memory: 1000 values for each channel inside non-backup RAM memory EMC: EN 61326-1, EN 55011 Measured values Type Temperature Relative humidity Pressure Computed concentration quantity T0610 ✓ T4611 ✓ T3610 ✓ ✓ ✓ T3611 ✓ ✓ ✓ T7610 ✓ ✓...

  • Page 41: Temperature Measurement

    Temperature response time with stainless steel sensor cover (F5200) in air flow 1m/s: T361x, T761x, T664x t90 < 6min, temperature step 20°C T7613D t90 < 9min, temperature step 20°C Temperature probe for Web Sensor T4611: Pt1000/3850ppm, connected by shielded cable max. length 10m Relative humidity measurement Temperature and humidity measuring range is limited - see graph below.

  • Page 42: Atmospheric Pressure Measurement

    IE-SNC-Tx6xx-09 Relative humidity and temperature restrictions: Atmospheric pressure measurement Unit Range Accuracy T = 23°C 0 ≤ T ≤ 40°C else 600 to 1100 ±1.3 ±1.5 ±2.0 mBar 600 to 1100 ±1.3 ±1.5 ±2.0 8.70 to 15.95 ±0.02 ±0.02 ±0.03 mmHg 450.0 to 825.1 ±1.0...

  • Page 43: Computed Quantities

    IE-SNC-Tx6xx-09 Computed quantities Dew point temperature Range: -60 to +80°C (-20 to 176°F) Accuracy: ±1.5°C (±2.7°F) at ambient temperature T < 25°C (77°F) a RH > 30%, for more details see graphs: Specific humidity This value depends on atmospheric pressure. Pressure for quantities calculation is stored in device memory.

  • Page 44: Specific Enthalpy

    T3611 (-4 to +140°F) (-22 to +221°F) T7611 limited by graph T6641 -25°C to +60°C (-13°F to +140°F) * T5641 -5°C to +60°C (23°F to +140°F) ** T5640 T4611 depends on used Pt1000 probe * fixed installation ** moving use...

  • Page 45: End Of Operation

    Other environmental conditions (external influences) according to HD 60364-5-51: normal Storage conditions: same as the operating ranges Working position T3611, T4611, T7611, T5641, T6641: arbitrary Working position T0610, T3610, T7610, T7613D, T6640, T5640: with sensor cover downwards End of operation Disconnect the device and dispose it according to current legislation for dealing with electronic equipment (WEEE directive).

  • Page 46: Technical Support And Service

    1 year (temperature 2 years, relative humidity 1 year, atmospheric pressure 1 year) T3611 1 year (temperature 2 years, relative humidity 1 year) T4611 2 years T7611 1 year (temperature 2 years, relative humidity 1 year, atmospheric pressure 1 year)

  • Page 47: Optional Accessories

    Manufacturer recommends using only original accessories. All available optional accessories are on manufacturer webpages. Temperature probe Pt1000 for Web Sensor T4611 Wide ranges of Pt1000/3850ppm probes are available as optional accessories. Please contact your local distributor to help you with choice of correct probe according your application.
