Welcome to Follett
Follett Products LLC ice storage bins enjoy a well-deserved reputation for excellent performance, long-term reliability and
outstanding after-the-sale support. To ensure that this bin delivers that same degree of service, we ask that you take a
moment to review this instruction before beginning the installation of the bin. Should you have any questions or require
technical help at any point, please call our technical service group at (877) 612 5086 (US & Canada) or +1 610 252 7301
and in Poland: +48 58 785 6140.
Before you begin
After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage
is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if
necessary.
!
Important cautions
§ Top is NOT fastened to bin.
§ Avoid excessive tightening force when connecting to the bin drain fitting.
§ Do not apply excessive heat if any sweating of fittings is necessary. Heat conduction through
metal may melt threads in plastic drain fitting.
§ When leveling, do not extend any leg more than 1 in. (26mm) for total leg height no greater than
2.125 in. (54mm).
§ SDU1000: Legs must be secured to floor through feet to avoid possible movement and resulting
injury.
Attention Installer!
Any 3rd party ice machines must be installed and operated in accordance with the
manufacturer's instructions
Single Door Upright Ice Storage
Bins with SmartGATE
Installation Instructions and Parts List
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612 5086 • +1 610 252 7301
www.follettice.com
Ice Shield
®
207890R09
Advertisement
Related Manuals for Follett SG1300S-48
Summary of Contents for Follett SG1300S-48
- Page 1 Before you begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary.
-
Page 2: Installation
Installing icemaker drain (Required for some icemaker applications) Some icemakers require a special drain system. For these machines Follett predrills the hole and provides the 3/4" straight threaded drain fitting to be installed through the hole. To install the fitting: 1. -
Page 3: Operation
Operation SmartGATE operation Follett’s unique SmartGATE positively controls the flow of ice into lower door assembly area for removal with either a scoop or shovel. SmartGATE can also be adjusted and locked at one of several levels to accommodate flow characteristics of different types of ice. - Page 4 Interior of bin must be cleaned and sanitized prior to use and should be cleaned on routine basis during use. Interior bin care Follett single door upright ice storage bins with SmartGATE are equipped with polyethylene liner walls and stainless steel bottoms which should be cleaned and sanitized periodically with any product suitable for use in a food zone.
-
Page 5: Replacement Parts
Replacement parts Reference # Description Part # (2) Inspection windows, 21.125"W x 8.625"H (537mm W x 219mm H) (2 used per bin) 502237 (2) Inspection window, 12.5"W x 9"H (318mm W x 229mm H) (2 used per bin) 502264 Frame assembly, lower door, 45" (1067mm) (includes 502177 and 502363) 502361 Frame assembly, lower door, 28 (686mm) (includes 502176 and 502367) 502365... - Page 6 Le rogamos consulte el manual de instalación y de instrucciones adjunto, ya que es muy importante que la instalación se realice según las especificaciones de fábrica para que el equipo funcione a su máxima eficiencia. Follett LLC no se hace responsable de los daños indirectos, costos, gastos por conexión y desconexión o pérdidas por causa de defecto de la máquina.
