- Page 1 ChargeIT! mini Product Family Model Numbers: CG-PD60PPS, CG-PD110C2, CG-PD200MAX, CG-PD140EPR, CG-PD100C, CG-PD82HVV, CG-CMD60W . CG-PD99PPS Product Manual Coolgear, Inc. Version: 1.1 Date: 2025-03-04...
-
Page 2: Table Of Contents
1.4 Screw-Locking Ports 1.5 Supported USB Devices 1.6 Environmental Specifications 1.7 Package Contents 1.8 Certifications 2. Notes, Tips, Warnings, and Safety 2.1 Supporting References Revision History Revision Date Comments 2023-02-23 First Release Addition of CG-PD99PPS 2025-03-04 Need help? Visit: coolgear.com/support... -
Page 3: Introduction
ChargeIT! mini – Product Manual 1. Introduction Coolgear’s ChargeIT! mini line is a series of compact high power usb power delivery chargers. Intended for use in PC power adapters, mobile chargers, car chargers, and power bank applications these chargers offer high power charging in a small chassis. Often featuring 1 or 2 ports, these chargers are perfect for charging mobile phones, tablets, notebooks, laptops, and other high-power USB-C devices. -
Page 4: Hardware Diagram
Surface mounting flanges (Removable on CG-CMD60W) USB Type-C Charging Port Power delivery port USB Type-A Charging Port Qualcomm Quick Charging compatible 2-Pin Phoenix Terminal Block Power input of varying input voltages DC Barrel Jack Power input of varying input voltages Need help? Visit: coolgear.com/support... -
Page 5: Hardware Installation
4. (OPTIONAL) Mount your hub on the wall/surface. For the CG-CMD60W use on desktop with included rubber feet or attach optional surface mounting bracket. 5. (OPTIONAL for USB Type-C Ports) Attach screw-locking USB-C cable for safer connections. Need help? Visit: coolgear.com/support... -
Page 6: Screw-Locking Ports
DC Barrel 1.4 Screw-Locking Ports All models feature screw-locking capabilities on USB Type-C ports. Port screw-hole and Coolgear Screw-Locking USB-C Cables are both USB-IF screw lock compliant. Attach screw-locking cable for safe & secure connections. 1.5 Supported USB Devices ● Supports mobile phones, tablets, notepads, laptops, and other USB Type-C devices 1.6 Environmental Specifications... -
Page 7: Package Contents
ChargeIT! mini – Product Manual 1.7 Package Contents Package Contents CG-PD60PPS, CG-PD110C2, CG-PD200MAX, CG-PD140EPR, CG-PD100C, CG-PD82HVV, CG-PD99PPS ● Charger ● 2-Pin Terminal Block Power supply not included Package Contents CG-CMD60W ● Charger ● Surface Mounting Flange ● Terminal Block Power Adapter & Power Cord ●... -
Page 8: Certifications
The CG-PD99PPS, ChargeIT! mini 99W Dual Port USB-A & USB-C PD Charger isn’t just powerful—it’s been rigorously tested to meet the highest international safety standards. Our comprehensive testing ensures you can rely on the device in even the most demanding automotive, industrial, and commercial applications. Need help? Visit: coolgear.com/support... -
Page 9: Notes, Tips, Warnings, And Safety
Do not disassemble the product. Handling the product’s internal components can expose it to ESD (Electro-Static Discharge) hazards that can affect the function of the device. If this product is not functioning properly, email our support team at support@coolgear.com. Need help? Visit: coolgear.com/support... -
Page 10: Supporting References
ChargeIT! mini – Product Manual 2.1 Supporting References Website Product Pages Link https://www.coolgear.com/product/usb-power-del CG-PD60PPS ivery-60w-high-power-industrial-adapter-charger-c cg3pa https://www.coolgear.com/product/chargeit-mini-11 CG-PD110C2 0w-dual-type-c-pd-charger-65w-usb-c-port-45w-usb- c-port https://www.coolgear.com/product/chargeit-mini-20 CG-PD200MAX 0w-dual-type-c-pd-charger-100w-output-each-port-2 4v-input https://www.coolgear.com/product/chargeit-mini-14 CG-PD140EPR 0w-usb-type-c-pd-charger-w-epr-support https://www.coolgear.com/product/chargeit-100-wat CG-PD100C t-usb-type-c-charger https://www.coolgear.com/product/chargeit-mini-82 CG-PD82HVV w-usb-type-c-pd-charger-high-w-2448v-dc-input https://www.coolgear.com/product/chargeit-mini-de CG-CMD60W sktop-75w-dual-port-usb-a-usb-c-pd-charger-w-pps-q c4-0-support https://www.coolgear.com/product/chargeit- mini-99w-dual-port-usb-a-usb-c-pd-charger-w-pps- CG-PD99PPS... - Page 11 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
